VC 068WG - Vacuum Cleaner HYUNDAI - Free user manual and instructions

Product Type	Canister Vacuum Cleaner
Model	VC 068WG
Brand	Hyundai
Color	White and Grey
Dust Capacity	1.5 L
Filtration System	HEPA Filter
Motor Power	800 W
Noise Level	78 dB
Cord Length	6 m
Operating Radius	9 m
Weight	4.5 kg
Dimensions (L x W x H)	400 x 260 x 300 mm
Power Supply	220-240 V, 50/60 Hz
Accessories Included	Crevice tool, Upholstery tool, Floor brush
Suction Type	Bagless, Cyclonic
Filter Maintenance	Washable reusable HEPA filter
Safety Features	Overheat protection, Automatic cord rewinder
Repairability	Spare parts available; replaceable motor brush
Warranty	2 years limited warranty

Frequently Asked Questions - VC 068WG HYUNDAI

How do I empty the dust container?

Press the release button on the dust container, pull it out, and empty the contents into a trash bin. Rinse the container with water if needed and let it dry completely before reinserting.

How often should I clean the HEPA filter?

Clean the HEPA filter every 3-6 months by tapping off loose dust or rinsing under water. Allow 24 hours to dry before reinserting. Replace the filter annually for optimal performance.

What should I do if suction power decreases?

Check if the dust container is full, the filter is clogged, or the hose is blocked. Empty the container, clean the filter, and inspect the hose for obstructions. Also ensure the floor brush nozzle is not blocked.

How do I replace the motor brush (carbon brushes)?

Unplug the vacuum. Remove the motor housing cover, locate the carbon brushes, and replace them with original Hyundai parts. Reassemble carefully. Refer to the manual for exact steps.

What accessories come with the VC 068WG?

The vacuum includes a crevice tool for tight spaces, an upholstery tool for furniture, and a combination floor brush for carpets and hard floors.

How do I store the vacuum cleaner?

Wrap the power cord around the hooks on the back of the canister. Attach the accessories to the dedicated holders. Store upright in a dry place, away from direct sunlight.

What does the overheat protection do?

If the motor temperature exceeds safe limits, the vacuum automatically shuts off. Allow it to cool for 30 minutes before restarting. This prevents damage.

Can I use the vacuum on hardwood floors?

Yes, the floor brush is suitable for hardwood. Ensure the brush bristles are clean and the suction setting is not too high. Use the hard floor mode if available.

How do I clean the hose if it is blocked?

Detach the hose from the vacuum and straighten it. Use a long object (e.g., broom handle) to gently push the blockage out. Rinse with water if needed and dry thoroughly before reattaching.

Where can I find spare parts for my Hyundai vacuum?

Spare parts such as filters, brushes, and belts are available from authorized Hyundai service centers or online retailers. Use the model number VC 068WG to ensure compatibility.

USER MANUAL VC 068WG HYUNDAI

Black 800W vacuum cleaner with digital display and hexagonal grille (no visible text or symbols)

NÁVOD K POUŽITÍ / NÁVOD NA POUŽITIE INSTRUKCJA OBSŁUGI / INSTRUCTION MANUAL HASZNÁLATÍ ÚTMUTATÓ / BEDIENUNGSANLEITUNG

	B1
	B2
	B3
	B4

II. EQUIPMENT AND ACCESSORIES....26

III. VACUUM CLEANER PREPARATION 26

IV. USE OF VACUUM CLEANER 26

V. REPLACEMENT OF THE DUSTBAG AND FILTERS....27

VI. CLEANING AND MAINTENANCE 27

VII. LEGISLATIVE & ECOLOGY....28

VIII. TECHNICAL DATA....28

HU I. BIZTONSÁGI ELŐÍRÁSOK....30

II. TERMÉKLEÍRÁS 32

VII. SKLADOVÁNÍ

www.hyundai-electronics.sk

VII. SKLADOVANIE

Dear customer, thank you for purchasing our product. Keep these instructions including the receipt and, if possible, the box with the internal packing.

I. SAFETY WARNING

GENERAL PROVISIONS:

• Before the first use, read the instructions for use carefully, look at the illustrations and store the instructions for use for the future. Consider the instructions for use as a part of the appliance and pass them on to any other user of the appliance.
• This appliance may only be used by children aged 8 years or older, and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision. Children younger than 8 years must be kept out of reach of the appliance and its power cord.
• Before replacing accessories or any accessible parts, before assembly and disassembly, before cleaning or maintenance, when you let the appliance unattended or if you finish the work with the appliance, switch off the appliance and disconnect it from the mains by unplugging the power cord plug from electrical socket.
• The appliance is designated to be used indoor only.
• Never immerse the appliance in water (not even partially) and do not wash it under running water!
• When vacuuming certain types of carpets, upholstering fabric, etc., static electricity may be produced. No static electricity discharge is dangerous to health.
• Do not put fingers or other things to input and output vents of the appliance.
• In order to ensure safety and proper function of the appliance, use only original spare parts and accessories approved by the manufacturer.
• Only use this appliance for the purpose it was designed for, as specified in this manual.
• All texts in foreign languages and pictures shown on the packaging or the product itself, are translated and explained at the end of this language mutation.
• The manufacturer is not responsible for damage caused by improper use of the appliance and the accessories.

USE OF THE APPLIANCE:

• The product is only intended for home use and similar purposes (in shops, offices and similar workplaces, at hotels, motels and other residential environments, and in facilities providing bed and breakfast). It is not intended for commercial use!
• The appliance must not be used in damp or wet environment and in any environment with the danger of fire or explosion.
• Do not use the appliance to vacuum water, liquids or aggressive fluids!

• Do not vacuum wet or moist floor coverings, and do not use the vacuum cleaner outdoor!

• Do not vacuum sharp objects (e.g. glass, shatter), hot, flammable, explosive items (e.g. ash, hot cigarette butts, gasoline, thinners and aerosol vapours) or greases (e.g. fats, oils), caustic agents (e.g. acids, solvents).

• The paper or synthetic bags are disposable which means that once they are foul, they cannot be cleaned and re-used! If the paper or synthetic bag is cleaned mechanically, it can damage, besides other things, the inner filtration layers which results in a loss of filtration and mechanical properties of the bag.
• Do not use the vacuum cleaner to vacuum dirt produced during/after construction such as plasterboard dust, fine sand, cement, dust from construction, parts of plaster etc.
• WARNING: There is a risk of injury in case of incorrect use (not in accordance with the manual) of the appliance.

ACCESSORIES AND ASSEMBLY OF THE APPLIANCE:

- Do not put the suction nozzle or the tube end or accessories close to eyes and ears and do not insert them into body orifices!

POWER CABLE:

• Check whether the data on the type label corresponds with the voltage in your socket. The power cord plug may only be connected to the electrical socket complying with the applicable standards.
• If the power cord of the appliance is corrupted, it has to be replaced by the manufacturer, its service technician or a similarly qualified person.
• Always disconnect the appliance from power by unplugging the power cord from the electrical socket, if the appliance is left unattended and before assembly, disassembly or cleaning.
• Never use the appliance if the power cord or power plug are damaged, if the appliance is not correctly operating or if it has fallen on the floor and been damaged, or if it has fallen into water.
• Do not apply force to unwind the cord beyond the red mark.
• Do not unplug the power plug by pulling the power cord or the vacuum cleaner unit.
• When winding the cord, hold the plug to prevent lashing of the cord around and to prevent possible injury.
• The power cord must not be damaged with sharp or hot objects, open fire, it must not be sunk into water or bent over sharp edges.
• Check the condition of the power cord of the appliance regularly.

II. EQUIPMENT AND ACCESSORIES

A - vacuum cleaner (Fig. 1)

A1 – suction vent

A2 – lid

A3 – lid lock

A4 – handle

A5 – depression for attachment of accessories (2x)

A6 - ON/OFF button

A7 – power cord winding button

A8 – knob for suction power regulation

A9 – full bag indicator

A10 – power cord

A11 – rear wheels

A12 – plastic fixture for the dustbag

A13 – dust bag

A14 – grille for the suction filters

A15 – input filter

B - accessories (Fig. 1)

B1 – floor nozzle

B2 – upholstery nozzle

B3 – brush

B4 – crevice nozzle

B5 – suction hose

B6 – plastic suction tube (2x)

B7 – regulation of suction power

B8 – accessory holder

III. VACUUM CLEANER PREPARATION

Remove all packing material, take out the vacuum cleaner and the accessories. Remove all possible adhesion foils, stick-on labels or paper from the appliance.

VACUUM CLEANER ASSEMBLY

When assembling the vacuum cleaner, follow the procedure indicated in Fig. 1. Choose appropriate accessories as required (B1-B6) (Fig. 3).

Note

When the dust bag A13 is properly fitted in the plastic fixture A12, the mechanical safety lock is released and the vacuum cleaner cover can be closed.

IV. USE OF VACUUM CLEANER

Before use, unwind (by pulling) the power cable A10 from the vacuum cleaner to a required length and plug the vacuum cleaner to the mains.

CONTROL

A6 button - vacuum cleaner ON/OFF switch

A7 button - when pressed and held, the unwound part of the power cable rewinds back inside

Knob A8 - by turning it to the right, you increase the suction power

- by turning it to the left, you reduce the suction power

V. REPLACEMENT OF THE DUSTBAG AND FILTERS

DUSTBAG REPLACEMENT

Full bag indicator

If the A9 indicator is permanently coloured, the dustbag needs to be replaced. If the indicator A9 is activated occasionally when you are vacuuming, you can ignore it. To remove the dustbag, follow the procedure indicated in Fig. 2. To fit a new dustbag in the vacuum cleaner, proceed in reverse order.

Spare bags: ETA960068030

INPUT FILTER REPLACEMENT

To remove the input filter, follow the procedure indicated in Fig. 2. To fit a new input filter in the vacuum cleaner, proceed in reverse order.

VI. CLEANING AND MAINTENANCE

Caution

• Maximum suction performance can be achieved when the filters are clean and the dustbag is empty.
• When you have replaced the dustbag about five times, the filters need to be cleaned, or replaced.
• When you are vacuuming very fine dust, the dustbag and filter pores might get clogged. This reduces the air flow and deteriorates the suction performance. In such a case, the dustbag needs to be replaced as soon as possible (even though it might not be full yet) and the filters must be cleaned or replaced.
  • Used dustbags and filters are to be disposed of with regular household waste.

Treat surface of the appliance with a soft and damp cloth, do not use coarse and aggressive detergents!

Accessories

After any vacuuming it is recommended to check visually the brushes or collectors for possible impurities. If there are some impurities, remove them.

Input filter

Rinse the input filter A15 under running water. Allow them to dry out properly before their re-use.

Caution

• Do not clean the filter with any aggressive washing or cleaning detergents or hot water.
• The filter is not dish-washer safe.

Other parts

Clean the plastic suction tubes B6, suction hose B5 and outlet grid A14 with a wet cloth.

Allow all the parts to dry out properly before re-use.

More extensive maintenance or maintenance requiring intervention in the inner parts of the appliance must be carried out by professional service! Failure to comply with the instructions of the manufacturer will lead to expiration of the right to repair!

The information regarding warranty and product repairs you can find on the website www.hyundai-electronics.cz/servis-eu

VII. LEGISLATIVE & ECOLOGY

WARNING: DO NOT USE THIS PRODUCT NEAR WATER, IN WET AREAS TO AVOID FIRE OR INJURY OF ELECTRIC CURRENT. ALWAYS TURN OFF THE PRODUCT WHEN YOU DON'T USE IT OR BEFORE A REVISION. THERE AREN'T ANY PARTS IN THIS APPLIANCE WHICH ARE REPARABLE BY CONSUMER. ALWAYS APPEAL TO A QUALIFIED AUTHORIZED SERVICE. THE PRODUCT IS UNDER A DANGEROUS TENTION.

Disposal of old Electrical & Electronic Equipment (Applicable in the European Union and other European countries with separate collection systems).

This symbol on the product or on its packaging indicates that this product (or battery/accumulator) shall not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. The recycling of materials will help to conserve natural resources. For more detailed information about recycling of this product, please contact your local Civic Office, your household waste disposal service or the shop where you purchased the product.

VIII. TECHNICAL DATA

Voltage (V) / Input (W) specified on the type label of the appliance Protection class of the appliance II.

Weight (kg) approx. 4.5

Size of the product (mm) 330 x 260 x 210

Input in off mode is 0.00 W

Declared acoustic level is 78 dB(A) re 1pW.

The manufacturer reserves the right to change the technical specifications and accessories for the respective models.

WARNINGS AND SYMBOLS USED ON THE APPLIANCE, PACKAGING OR IN THE INSTRUCTIONS MANUAL:

HOUSEHOLD USE ONLY. DO NOT IMMERSE IN WATER OR OTHER LIQUIDS.

TO AVOID DANGER OF SUFFOCATION, KEEP THIS PLASTIC BAG AWAY FROM BABIES AND CHILDREN. DO NOT USE THIS BAG IN CRIBS, BEDS, ARRIAGES OR PLAYPENS. THIS BAG IS NOT A TOY.

WARNING

ANSAUGFILTER AUSTAUSCHEN

WARNUNG: SETZEN SIE DAS GERÄT NICHT DEM REGEN ODER DER FEUCHTIGKEIT AUS, UM EINEN BRAND ODER STROMSCHLAG ZU VERMEIDEN. ZIEHEN SIE IMMER DEN STECKER AUS DER STECKDOSE, WENN SIE DAS GERÄT NICHT BENUTZEN ODER BEVOR SIE ES REPARIEREN. DAS GERÄT ENTHÄLT KEINE VOM VERBRAUCHER REPARIERBAREN TEILE. WENDEN SIE SICH IMMER AN EIN QUALIFIZIERTES, AUTORISIERTES SERVICEZENTRUM. DAS GERÄT UNTER GEFÄHRLICHER SPANNUNG STEHT.

GENUINE PRODUCT OF HYUNDAI CORPORATION
