HOBEE PH20 - Cooker Eldom - Free user manual and instructions

Product Type	Portable Ceramic Cooker
Brand	Eldom
Model	HOBEE PH20
Power	2300W (2 x 1150W)
Supply Voltage	230V ~ 50Hz
Number of Heating Plates	2
Heating Plate Material	Ceramic
Temperature Control	Smooth adjustment via thermostat (settings 1-3 low, 4-MAX high)
Indicator Lights	Yes, for each plate
Housing Material	Plastic
Cord Length	Approx. 1.2 m
Weight	Approx. 3.5 kg
Dimensions (approx.)	52 x 32 x 8 cm
Safety Features	Overheat protection, child safety (supervision required for children 8+ and persons with limited capabilities)
Warranty	Valid for private household use only; not for professional use
Cleaning Method	Wipe with soft damp cloth and mild detergent; do not immerse or use abrasive agents
Dish Compatibility	Metal and ovenproof dishes with flat, stable bottoms
Intended Use	Indoor, well-ventilated areas; not for outdoor use or heating rooms

Frequently Asked Questions - HOBEE PH20 Eldom

How do I turn on the Eldom HOBEE PH20 cooker?

First, ensure the thermostats (1) are set to 'MIN'. Place the cooker on a level, heat-resistant surface. Plug it into a grounded outlet. Place a dish with food on the heating plate (2), then turn the thermostat to the desired temperature setting. The control light (3) will indicate operation.

What type of cookware should I use with this cooker?

Use only metal and ovenproof dishes with flat and stable bottoms. The dish diameter should provide good contact with the heating plate for efficient cooking and safety.

The cooker emits a strange smell during first use. Is that normal?

Yes, during the first activation, a specific smell may be emitted from the heating elements and insulation. This is normal and should dissipate after a few uses.

How do I clean the Eldom HOBEE PH20?

Unplug the appliance and wait for it to cool completely. Do not immerse in water or wash in a dishwasher. Wipe all surfaces with a soft, damp cloth and a mild cleaning agent. Do not use abrasive cleaners.

Can I use both heating plates at the same time?

Yes, each heating plate has its own thermostat and control light, so you can use both plates simultaneously for different cooking tasks.

What are the safety precautions while using the cooker?

Always supervise the appliance, especially with children. Keep at least 5 cm clearance from walls and flammable materials. Do not touch the hot surfaces. Use only on a stable, heat-resistant surface. Do not move the cooker while it is on.

What is the power consumption of this cooker?

The total power is 2300W, with each heating plate rated at 1150W. Ensure your electrical circuit can handle this load, and avoid using with other high-power devices on the same circuit.

What should I do if the power cord is damaged?

If the power cord is damaged, it must be replaced by the manufacturer's service center to avoid hazard. Do not use the cooker with a damaged cord.

Can I use the cooker outdoors?

No, the cooker is designed for indoor use only. It can be used under a roof protected from rain and wind, but not in open air.

What is covered under the warranty?

The warranty is valid for private household use only. It does not cover damages from improper operation, professional use, or repairs by unauthorized personnel. Always refer to the warranty card for details.

USER MANUAL HOBEE PH20 Eldom

Exterior view of a black ELDOM portable stove with two red heat sinks (no text or symbols visible)

WSKAZÓWKI BEZPIECZEŃSTWA

• before operating the appliance, read the user manual thoroughly
• plug in the connecting cable to a grounded electrical outlet
• ensure that a limited number of receivers are connected to one current circuit
• if an extension cord is used, it should be grounded and placed in a safe manner
• 'the appliance is intended for household use only
• use only in rooms with good ventilation
• keep an eye on the operating appliance, especially when there are children nearby. Before leaving - the room with the appliance, switch it off.
• if the appliance is not working, unplug it
• before unplugging, set the thermostat (1) in the position "MIN"
• do not use in open air. The cooker can be used under the roof where it is protected against rain and wind
• The device can be used by children aged 8 and older and by persons with limited physical, sensory or mental capabilities, or persons without sufficient experience and knowledge only under supervision or if previously instructed on the safe use of the appliance and the possible risks. Children shall not play with the appliance. Cleaning and maintenance that are the responsibility of the user shall not be carried out by children without supervision. Protect the appliance and the power cord against children under 8 years old.
• make sure that children do not play with the equipment,
• never place products directly on the heating plate (2). It poses the risk of serious burning and damage of the appliance
• do not use the appliance near curtains, blinds or other inflammable material
• do not place the appliance in a corner of a room or directly next to the wall. The space of at least 5 cm from the sides of the appliance should be provided.
• to ensure free and safe access to the appliance, place it at a proper height.
• the cooker can be only positioned on a level, stable and high-temperature resistant surface. No items of inflammable material can be placed above the appliance

SAFETY INSTRUCTIONS

• do not touch the housing and the heating plate of the operating appliance (risk of serious
  burning), and when the appliance is no longer used, wait until it cools down completely
• do not move the appliance during its operation
• do not place the power supply cable over the cooker
• do not use for heating rooms
• place dishes with products on the heating plate in a central position
• do not use the cooker without dishes with products
• use only metal and ovenproof dishes with flat and stable bottoms
• never use when the power cable or the appliance is damaged
• if the power cable is damaged, it must be replaced in the Manufacturer's Service in order to avoid hazard
• repairs of the equipment can only be performed by an authorized servicing point (a list
  of servicing points in the appendix and on the website www.eldom.eu). Any modernizations or the use of non-original spare parts or elements of the appliance is prohibited and may cause a serious hazard to the user
• The company Eldom Sp. z o. o. shall bear no responsibility for any possible damages resulting from the improper usage of the appliance

This symbol warns against the high temperature of the surface of the appliance.

ENVIRONMENTAL PROTECTION

• the appliance is made of materials which can be reprocessed or recycled
• they should be handed over to a relevant point which deals with the collection and recycling of electric and electronic appliances

WARRANTY

• the appliance is intended for a private use in a household
• it cannot be used for professional purposes,
• the warranty is invalid in the case of improper operation

GENERAL DESCRIPTION

1. Thermostats
2. Heating plates
3. Control lights
4. Housing

TECHNICAL DATA

• power: 2300W (2 x 1150W)
• supply voltage: 230V \~ 50Hz

OPERATION

The ceramic cooker allows to prepare food in many different ways (cooking, frying, etc.) The use of infrared lamp in appliance allows to reach rapidly required temperature, which saves time and reduces power consumption.

Before operating and plugging in the appliance, set thermostats (1)

in the position "MIN" (the appliance switched off).

Position the appliance on a level, dry, stable and high-temperature resistant surface. The housing (4) heats up considerably when operated. Thus, the space of at least 5 cm from the sides of the device should be provided.

To ensure free and safe access to the appliance, place it at a proper height.

• plug in the appliance
• place a dish with products on the heating plate (2)
• switch on the appliance selecting the working temperature of the thermostat (1). Each heating plate (2) is controlled by a separate thermostat (1).
  Both plates can be used at the same time.

Thermostat enables smooth adjustment of the temperature.

Settings 1-3 correspond to the lower temperature proper for heating meals.

Settings 4 - MAX - high temperature intended for cooking. Operation of the appliance is signalled by the control light (3).

The operation of the appliance is signalled by control lights (3).

During the first activation of the appliance, a specific smell can be emitted from the heating elements and the insulation. It is a normal occurrence.

In order to ensure safety and high efficiency of the operation, use only dishes with flat bottoms and of a proper diameter which guarantee stability and good contact of the dish with the heating plate

CLEANING AND MAINTENANCE

Before cleaning, unplug the appliance and wait until it cools down completely.

• Do not immerse the appliance in water or wash it in a dish-washer machine.
• All surfaces can be cleaned only by wiping them with a soft, damp cloth with the addition of gentle cleaning agents.
• Do not use abrasive agents.
