Product Type	Countertop Oven
Brand	Eldom
Model	Rast PR300
Temperature Range	100°C - 230°C
Heating Functions	5 modes: top heat, bottom heat, top & bottom, top & bottom with fan, top heat with fan & rotisserie
Timer	Mechanical timer with audible signal
Interior Light	Yes, lights up during operation
Door Material	Tempered glass
Maximum Load on Grill/Plate	3.5 kg
Maximum Load on Rotisserie	2.5 kg
Included Accessories	Grill, baking plate, rotisserie, handle, rotisserie handle
Controls	Knobs for temperature, function selection, timer
Cleaning	Dishwasher safe accessories; wipe body with damp cloth
Safety Features	Automatic shut-off after timer; thermostat regulation; tempered glass door
Intended Use	Grilling, roasting, baking, general cooking
Bulb Type	Heat-resistant bulb (replaceable)
Warranty	Household use only; non-professional
Power Supply	Connected to mains as per specification in manual
Material	Metal body with heat-resistant glass door
Storage	Store in original box, clean and dry, do not wrap cord around appliance

Frequently Asked Questions - Rast PR300 Eldom

How do I set the timer on the Eldom Rast PR300 oven?

To set the timer, turn the timer knob (9) to the right to your desired cooking time. A sound signal will sound when the time elapses. The oven starts only when temperature, function, and timer are set.

What is the maximum weight I can put on the grill or plate?

The maximum load on the grill (10) and plate (11) is 3.5 kg. For the rotisserie (13), the maximum is 2.5 kg. Ensure products do not touch the walls, door, or heating elements.

Can I use paper or plastic containers in the oven?

No. Do not use paper, plastic, cardboard, or similar materials in the oven. Only use heat-resistant vessels such as metal or glass containers.

How do I clean the oven and its accessories?

Turn off and unplug the oven, let it cool. Wash removable accessories (grill, plate, handles, rotisserie) in warm water with washing-up liquid or in the dishwasher. Wipe the oven body and interior with a damp cloth. Never immerse the body in water.

What should I do if the interior light bulb burns out?

Replace the bulb with a heat-resistant bulb of the same type. Remove the protective cover, unscrew the old bulb, and screw in a new one. Purchase the bulb from a service shop or specialist store.

What heating functions are available?

The function knob (8) offers 5 modes: top heat only, bottom heat only, top and bottom heat combined, top and bottom heat with fan, and top heat with fan and rotisserie. Turn to 'OFF' to stop.

How do I use the rotisserie function?

Place meat on the rotisserie rod (13) and secure it. Insert the rod into the oven using the rotisserie handle (14). Select the function that includes rotisserie (top heat, fan, and rotisserie). Set temperature and timer as desired.

Is it safe to open the door while the oven is running?

Yes, but be cautious: hot steam may escape. Turn the function knob to 'OFF' before opening. Use insulated kitchen gloves and avoid contact with steam. The oven stops when the door is opened (by turning off function) but the timer continues.

What precautions should I take during use?

Place the oven on a flat, heat-resistant surface with at least 12 cm space on all sides. Do not cover the appliance. Use protective gloves when handling hot parts. Keep children away. Unplug after use. Do not use if cord is damaged.

Can I use metal foil in the oven?

No. Do not cover food or any part of the oven with metal foil, as it can cause overheating. Also, do not place products wrapped in metal foil inside the oven.

USER MANUAL Rast PR300 Eldom

Line drawing of an old electric oven with control knobs and a warning triangle (no text or symbols on the device itself)

/EN/ Disposal of used electrical and electronic equipment (applies to the European Union countries and other European countries with separate waste collection systems).

The symbol on the product or its packaging indicates that the product should not be classified as household waste. It should be handed over to a collection point that deals with the collection and recycling of electrical and electronic devices. Correct disposal of the product prevents potential negative consequences for the environment and human health that could be caused by improper disposal of the product. Material recycling helps to preserve natural resources. For detailed information on recycling of this product, please contact your local authority, a cleaning service provider or a shop where the product has been bought.

Simple line drawing of a hat with a curved arrow indicating rotation or movement (no text or symbols)

1. Read the whole content of this user manual before using the appliance for the first time connect the connection cord to a socket which complies with the specification provided in the manual.
2. Set the appliance on a flat, stable and high temperature resistant surface.
3. Always disconnect the appliance from the mains by pulling the plug, not the power cord.
4. Disconnect the appliance from the mains whenever it is not used or before cleaning it.
5. Do not immerse the cord or the appliance in water.
6. Do not use in open air.
7. Do not use nearby inflammable materials such as furniture, bedding, paper, clothes, lace curtains, linings etc.
8. Do not leave children without care nearby the appliance parts of the appliance become hot when the appliance is being used. You should hold the appliance only by the handgrip.
9. Be careful when taking out the sandwiches. Ready made sandwiches are hot and can burn.
10. Do not leave the appliance unattended when it is being used.
11. The device can be used by children aged 8 and older and by persons with limited physical, sensory or mental capabilities, or persons without sufficient experience and knowledge only under supervision or if previously instructed on the safe use of the appliance and the possible risks. Children shall not play with the appliance. Cleaning and maintenance that are the responsibility of the user shall not be carried out by children without supervision. Protect the appliance and the power cord against children under 8 years old.
12. Pay attention to make sure that the appliance is not played with by children.
13. Do not carry or move the appliance when it is being used.
14. Do not cover the appliance when it is being used.

15. Do not put any products in metal foils into the appliance.

16. Do not grasp the appliance with wet hands.

17. Keep the appliance and its cable out of reach of children under 8 years of age.
18. Make sure that the cable does not hang over the edge of the table or other table top and does not touch hot surfaces.
19. Do not place the appliance on or near a hot gas or electric burner, in a preheated oven or microwave oven.
20. When using the appliance, ensure that there is at least 12 cm of space on all sides of the appliance to provide adequate air circulation.
21. Special care should be taken when using containers made of materials other than metal or glass.
22. Do not place any of the following materials in the oven: cardboard, plastic, paper, etc.
23. Always wear protective, insulated kitchen gloves when inserting or removing objects from the hot appliance.
24. This appliance has a safe, tempered glass door. This glass is stronger than ordinary glass and more resistant to cracking. Avoid scratching the door surface or scuffing the edges. If the door glass is scratched or scuffed, contact your nearest authorised service centre for inspection and repair before using the appliance again.
25. Move vessels containing hot oil or other hot liquids with extreme care.
26. To avoid overheating, do not cover food or any other part of the oven with metal foil.
27. Do not place objects on glass doors when they are fully open.
28. The appliance is intended for household use only.

29. A very hot stream of steam may come out of the appliance when the cover is being opened do not use the appliance if the power cord has been damages or when the appliance has fallen down or was damaged in another way. The appliance should be repaired by an authorized service shop; see the annexe or visit the site www.eldom.eu for the list of authorized service shops.

30. The appliance may be repaired only by an authorized service outlet.

31. Modernizing the appliance or using other spare parts or components for the appliance with the genuine ones is forbidden and threatens the safety of use.
32. Eldom Sp. z o. o. is not responsible for any potential damages caused by improper use of the appliance.

This symbol is a warning against the high temperature of the appliance surface.

WARNINGS

• Do not cover the intake and outflow air openings.
• Ensure sufficient space around the appliance.

GUARANTEE

• The device is designed to be used in households.
• Not for professional use.
• The control lamp is not subject to guarantee.
• The guarantee expires when device is used improperly. Detailed warranty description in the annex.

KEEP THIS INSTRUCTION MANUAL

EN

- oil temperature control: 100°C – 230°C

INTENDED USE

The PR300 oven is designed for grilling, roasting, baking and general cooking in heat-resistant vessels. In addition, it is equipped with a rotisserie.

SETTING UP THE APPLIANCE

Before using the appliance, make sure that the appliance, the plug and the power cable are in good technical order and whether all parts of the package were removed.

Before the first use, all parts of the appliance that are in contact with food must be thoroughly washed (see: Cleaning and maintenance).

Specific smell may be sensed during the first use, which results from the production process. It is a normal process and it will go away after a time. Ensure the proper ventilation in the room, e.g. opening the window.

The first use of the appliance should be without products.

USE

Before using the appliance for the first time:

- Read the instruction manual.

- Make sure that the appliance is disconnected from the mains and that the knobs (6, 8, 9) are turned all the way to the left, indicating that the appliance is switched off.

- Place the appliance on a flat, hard, stable, and heat-resistant surface, taking care to ensure that there is enough room around the appliance.

- Plug the appliance into the mains, in line with the parameters specified in the instruction manual.

- Set the operating parameters.

TEMPERATURE SETTING

Use the knob (6) to set the temperature. The temperature can be set from low to 230^ C.

Using the knob (8) you can select 5 different functions for different baking methods:

top heater on
-bottom heater on
- top and bottom heaters on
- top and bottom heaters and fan oven function on
- top heater, fan oven function + rotisserie on

Turn knob (8) to the "OFF" position to turn the appliance off.

Set the operating time by turning the knob (9).

To start the timer, turn the knob (9) to the right.

A sound signal will be heard after the programmed time has elapsed.

NOTE.

In order for the appliance to start operating, you need to set the temperature, the operating time and choose one of the functions.

There is an internal light in the oven chamber (3) which lights up when the appliance is in operation.

During operation, the indicator light (7) lights up and goes out. The thermostat maintains the proper temperature.

ACCESSORIES

• grill (10) – used for grilling, roasting, baking and general cooking in heat-resistant vessels,
• plate (11) – used for baking various dishes containing water or releasing water or oil during cooking (e.g. meat, poultry, fish, etc.),
• handle (12) – facilitates inserting and removing the grill (10) and the plate (11) from the appliance,
• rotisserie (13) – used for roasting poultry and other types of meat,
• rotisserie handle (14) – facilitates inserting and removing the rotisserie (13).

OPERATION

- Place the products directly on the grill (10), plate (11) or rotisserie (13), place them in the heating chamber (3) and close the oven door (2).

NOTE:

Do not use any paper or plastic containers.

Products should be placed evenly on the grill (10), plate (11) or rotisserie (13).

• Set the temperature, select the baking method.
• The appliance will start once the time has been set using the knob (9).

NOTE.

In order for the appliance to start operating, you need to set the temperature, the operating time and choose one of the functions.

- To check the baking progress during operation, turn the knob (8) to the "OFF" position and open the door (2) by pulling the handle (1).

NOTE:

When the door (2) is opened, hot steam may escape from the interior.

• Use kitchen gloves and the appropriate handles (12, 14) to remove the food.
• After the set time has elapsed, a sound signal will be heard and the appliance will switch off.
• When cooking is finished, turn the knob (8) to the "OFF" position and disconnect the appliance from the mains.

TIPS

• A maximum of 3.5 kg can be placed on the grill (10) and the plate (11), and a maximum of 2.5 kg on the rotisserie (13), but the products must not come into contact with the walls, the door or the heating elements.
• Products must be distributed evenly.
• The baking time should be adapted to the size, type and initial temperature of the products.
• Consecutive portions of the same food can be cooked faster due to the warming up of the interior.

CLEANING AND MAINTENANCE

• Turn the knobs (6, 8, 9) to the left as far as possible before cleaning the appliance, disconnect it from the power supply and let it cool down.
• Do not use sharp-edged or sharp objects to clean the appliance, as they may damage functional parts or compromise the safety of the unit.
• All moving parts should be washed with warm water and washing-up liquid. It is best to wash them directly after use. After rinsing with clean water, they must be dried immediately.
• Never immerse the body (4) in water or wash under running water. Clean the body (4) and the heating chamber (3) with a damp cloth.
• If it is difficult to wash the grill (10), plate (11) and rotisserie (13), they can be immersed in hot water with washing-up liquid and left for a few minutes.

- The dishwasher can be used to clean elements (10, 11, 12, 13, 14).

BULB REPLACEMENT IN THE OVEN CHAMBER

If the bulb in the oven chamber burns out, replace it with a bulb of the same type. The bulb must be heat-resistant. It can be purchased in the maintenance shop or in a specialist shop. Do not use other types of bulbs.

Simple line drawing of a hat with a curved arrow indicating rotation or movement (no text or symbols)

• Turn the knobs (6, 8, 9) to the left as far as possible before putting the product away, disconnect the appliance from the power supply and let it cool down.
• Remove the cover and then the bulb fig.1.
• Screw in the new bulb of the same type, and then screw in the cover.

STORAGE

• Turn the knobs (6, 8, 9) to the left as far as possible before putting the product away, disconnect it from the power supply and let it cool down.
• Never put the appliance away when it is hot or still plugged in to the power supply.
• Clean the appliance and all its components.
• Store the oven in the box (preferably the original one) in a clean and dry place.
• Do not wrap the cable around the appliance. Do not tighten the cable, as this may weaken or tear the cable.

ENVIRONMENT PROTECTION

• The device is made of materials which can be reused or recycled.
• The device should be handled to a special point which deals with collecting and recycling of electric and electronic equipment.
