HDM1043P - Hammer Ferm - Free user manual and instructions

Product Type	Rotary Hammer Drill
Model	HDM1043P
Brand	Ferm
Power Input	1100 W
Mains Voltage	220-240 V ~
Mains Frequency	50 Hz
No-Load Speed	300-760 /min
Impact Rate	1950-4860 /min
Chuck Size	SDS-max
Max. Drill Diameter	35 mm
Weight	6.06 kg
Sound Pressure Level (Rotary Hammer)	91 dB(A) K=3 dB(A)
Sound Pressure Level (Chisel)	100 dB(A) K=3 dB(A)
Vibration (Hammer Drilling)	17.9 m/s² K=1.5 m/s²
Vibration (Chiseling)	16.5 m/s² K=1.5 m/s²
Functions	Hammer Drilling, Chisel Angle Adjustment, Chipping
Variable Speed Control	Yes, thumbwheel (1-6 + max)
Side Handle	360° rotatable
Depth Stop	Yes, adjustable with ruler
Carbon Brush Indicator	Yes, light indicator
Safety Features	Double insulation, RCD recommended, ear protection required
Maintenance	Clean with soft cloth, no solvents; carbon brushes replaceable by service
Warranty	See enclosed warranty card
Standards	EN60745, 2011/65/EU (RoHS)

Frequently Asked Questions - HDM1043P Ferm

How do I change the drill bit on the Ferm HDM1043P?

First, unplug the tool. Lightly oil the bit shaft. Push the SDS-max bit into the chuck until it clicks. Do not slide the locking sleeve back when inserting. To remove, slide the locking sleeve back and pull out the bit.

How do I adjust the depth stop?

Loosen the depth stop knob (9) counter-clockwise. Insert the depth stop ruler (8) through the hole in the side handle ring. Slide to desired depth and tighten the knob clockwise.

How do I use the chisel function?

Ensure the motor is completely stopped. Turn the function selection switch (5) to position C (chipping). For chisel angle adjustment, use position B and then back to D before use. Always wait for the motor to stop before changing functions.

What safety precautions should I take when using this rotary hammer?

Always wear ear protection, safety goggles, and a dust mask. Use the auxiliary side handle. Hold the tool by insulated gripping surfaces to avoid electric shock if cutting into hidden wiring. Use an RCD in damp locations.

How do I clean and maintain the hammer drill?

Unplug the tool. Clean casings with a soft cloth, preferably after each use. Ensure ventilation openings are free of dust. For persistent dirt, use a cloth moistened with soapy water. Do not use solvents. Regularly inspect for damage to cord, switch, or moving parts.

What does the carbon brush indicator mean?

When the carbon brush indicator (4) lights up, the carbon brushes are worn. They must be replaced by the manufacturer's service department or a similarly qualified person.

Can I use this hammer drill as a demolition hammer?

Yes, the machine can be used as a demolition hammer for chipping and small demolition jobs. Select the chipping function (position C) and apply light pressure.

What is the maximum drilling diameter?

The maximum drill diameter is 35 mm in masonry such as brick and concrete. For very hard concrete, start with a smaller pilot bit.

How do I adjust the speed?

Use the variable speed control thumbwheel (3). Settings: 1-2 low, 3-4 medium, 5-6 high, Max for maximum speed. Adjust while running as needed.

What should I do if the power cord is damaged?

Immediately unplug the tool. The cord must be replaced by the manufacturer, its service agent, or a similarly qualified person to avoid hazard.

USER MANUAL HDM1043P Ferm

Black FERM 3-wheeled drill put tool with handle and grip (no visible text or symbols)

HDM1043P

Mechanical component diagram showing a drill bit being inserted into a drill bit, with labeled parts 7 and an arrow indicating direction (no text or symbols beyond labels)

Fig. C

Pure diagram of a circular device with directional arrows and symbols, no readable text or labels

Circular device with a triangular handle and directional arrow, labeled 'B' (no text or symbols on the device itself)

Pure diagram of a circular device with a play button and directional arrows, no text or symbols present.

Fig. D

Rotary Hammer drill 1100W HDM1043P

Thank you for buying this FERM product. By doing so you now have an excellent product, delivered by one of Europe's leading suppliers. All products delivered to you by Ferm are manufactured according to the highest standards of performance and safety. As part of our philosophy we also provide an excellent customer service, backed by our comprehensive warranty. We hope you will enjoy using this product for many years to come.

1.SAFETYWARNINGS

WARNING

Read the enclosed safety warnings, the additional safety warnings and

the instructions. Failure to follow the safety warnings and the instructions may result in electric shock, fire and/or serious injury. Save the safety warnings and the instructions for future reference.

The following symbols are used in the user manual or on the product:

Read the user manual.

Denotes risk of personal injury, loss of life or damage to the tool in case of non-observance of the instructions in this manual.

Risk of electric shock

Immediately remove the mains plug from the mains if the mains cable becomes damaged and during cleaning and maintenance.

Always wear eye protection!

Wear hearing protection.

Wear a dust mask.

Wear safety gloves.

Do not dispose of the product in unsuitable containers.

Variable electronic speed

The product is in accordance with the applicable safety standards in the European directives.

Additional safety warnings for rotary hammers

a) Wear ear protectors. Exposure to noise can cause hearing loss.
b) Use auxiliary handle(s), if supplied with the tool. Loss of control can cause personal injury.
c) Hold power tool by insulated gripping surfaces, when performing an operation where the cutting accessory may contact hidden wiring or its own cord. Cutting accessory contacting a "live" wire may make exposed metal parts of the power tool "live" and could give the operator an electric shock.

Electrical safety

When using electric machines always observe the safety regulations applicable in your country to reduce the risk of fire, electric shock and personal injury. Read the following safety instructions and also the enclosed safety instructions.

Always check that the voltage of the power supply corresponds to the voltage on the rating plate label.

Class II machine - Double insulation - You don't need any earthed plug.

If operating a power tool in a damp location is unavoidable, use a residual current device (RCD) protected supply. Use of an RCD reduces the risk of electric shock.

Replacement of power cords or plugs

If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

Use of extension leads

Only ever use approved extension leads that are suitable for the power rating of the machine. The minimum core thickness is 1.5 mm^2 . Whenever using a reel extension lead, always fully unroll the lead.

Immediately switch off the machine when:

• Excessive sparking of the carbon brushes.
- Interruption of the mains plug, mains lead or mains lead damage.
- Defectswitch.
- Smoke or stench of scorched isolation.

2. MACHINE INFORMATION

Intended use

This rotary hammer is intended for drilling holes in masonry such as brick, concrete and similar material. Furthermore, the machine can be used as a demolition hammer. The machine is on no account intended for other purposes.

Technical specifications HDM1043P

Mains voltage 220-240 V ~
Mains frequency 50 Hz
Power input 1100 W
No-load speed 300-760 /min
Impact rate 1950-4860 /min
Chuck size SDS-max
Max. Drill diameter	35 mm
Weight	6,06kg
Sound pressure ( L_PA )- Rotary hammer mode- Chisel mode	91dB(A) K=3 dB(A)100dB(A) K=3 dB(A)
Acoustic power ( L_WA )- Rotary hammer mode- Chisel mode	102dB(A) K=3 dB(A)111dB(A) K=3 dB(A)
Vibration
Hammer drilling concrete a_h,HD	17.9 m/s ^2 K=1,5 m/s ^2
Chiseling a_h,Cheq	16.5 m/s ^2 K=1,5 m/s ^2

Vibration level

The vibration emission level stated in this instruction manual has been measured in accordance with a standardized test given in EN60745. It may be used to compare one tool with another and as a preliminary assessment of exposure to vibration when using the tool for the applications mentioned.

• Using the tool for different applications, or with different or poorly maintained accessories, may significantly increase the exposure level.
• The times when the tool is switched off or when it is running but not actually doing the job, may significantly reduce the exposure level.

Protect yourself against the effects of vibration by maintaining the tool and its accessories, keeping your hands warm and organizing your work patterns.

Description

The numbers in the text refer to the diagrams on pages 2-3

Fig. A

1. Power indicator
2. On/Off switch
3. Variable speed control
4. Carbon brush indicator
5. Function selection switch
6. Side handle
7. Locking sleeve
8. Depth stop ruler
9. Depth stop knob
10. Lubrication point

3. OPERATING

Hammer drills require very little operator pressure. Excessive pressure on the tool can lead to unnecessary overheating of the motor, and burning of the driven tool. It also may happen the drill bit deforms and cannot be removed from the machine again.

Side handle

Fig. A

The side handle (6) can be rotated 360^ around the drill head, enabling safe and comfortable operation for both left and right-handed users.

• Loosen the handgrip by turning it anticlockwise.
• Rotate the handgrip to the desired position.
• Retighten the handgrip in the new position by turning it clockwise.

Exchanging and removing drill bits

Fig. A - B

Before exchanging bits, first remove the power plug from the wall socket.

Inspect bits regularly during use. Blunt bits should be re-sharpened or replaced.

Lightly oil the bit shaft before inserting it into the chuck.

- SDS drills can be inserted by pushing the drill into the chuck until a click can be heard. If needed rotate the SDS drill a little to ensure the keyway in the bit fits the chuck well.

DO NOT slide the locking sleeve (7) to the rear when inserting bits.

- To remove the SDS drill, slide the locking sleeve (7) to the rear and remove the SDS drill while keeping the sleeve (7) in this position.

Setting depth stop

Fig. A

• The depth stop ruler can be added to the side handle by turning the depth stop knob (9) counter-clockwise.
• Insert the depth stop ruler (8) through the hole on the side handle ring.
• Slide the ruler to the desired depth.
• Tighten the depth stop knob (9).

The On/Off switch

Fig. A

- Switch the machine on by pressing the On/Off switch (2). When releasing the On/Off switch (2) the machine will turn off.

Variable speed control (3)

Fig. A

The required speed can be preselected with the thumbwheel. Also during running the rotational speed can be adjusted.

1 - 2 = low speed
3 - 4 = medium speed
5 - 6 = high speed
Max = maximum speed

The required speeds depends on the material and can be determined by practical testing.

Function selection switch

In order to avoid damage to the machine, adjusting the function selection switch (5) shall only be done when machine is not running. Fig. C

Fig. D

The correct position of the function selection switch (5) for each function is shown in the pictures in fig. D. Always make sure the function switch clicks in the desired position.

A) Hammer Drilling (with hammer function): for drilling in masonry such as brick, concrete and similar material.
B) Chisel angle adjustment: for changing the angle of the chisel. When set under right angle switch back to position D. before using the tool.
C) Chipping (chisel function): for chipping and small demolition jobs.

User tips

Always use the machine with the side handle firmly anchored in place - you will not only work with more comfort, you will also work with more precision.

Caution: drills and chisels can get very hot.

Hammer drilling (Function A)

• For large holes, for instance in very hard concrete, start using a smaller bit for pilot drilling first, then drill to nominal size.
• Hold the machine firmly with 2 hands. Be aware the drill can jam and because of that machine might suddenly turn (especially when drilling deep holes).
• Do not apply a lot of pressure on the machine, let the machine do the work.

Chipping in concrete and brick (Function B & C)

• It's also possible to use the machine for chipping.
• Only change the function when the motor has come to a standstill.
• Do not apply a lot of pressure on the machine, let the machine do the work.

4. MAINTENANCE

Before cleaning and maintenance, always switch off the machine and remove the mains plug from the mains.

Clean the machine casings regularly with a soft cloth, preferably after each use. Make sure that the ventilation openings are free of dust and dirt. Remove very persistent dirt using a soft cloth moistened with soapsuds. Do not use any solvents such as gasoline, alcohol, ammonia etc. Chemicals such as these will damage the synthetic components.

Defects

The machine should be regularly inspected for the following possible defects and repaired if necessary.

• Damage to power cord.
• Broken on/off trigger assembly.
• Shortcircuiting.
  • Damaged moving parts.

Faults

Should a fault occur, e.g. after wear of a part, please contact your seller or the service address on the warranty card. Separate you find an exploded view showing the parts that can be ordered.

Carbon brush indicator Fig. A

If the carbon brushes are worn, the carbon brush indicator (4) will come on. The carbon brushes must be replaced by the customer service department of the manufacturer or a similarly qualified person.

WARRANTY

The warranty conditions can be found on the separately enclosed warranty card.

ENVIRONMENT

Faulty and/or discarded electrical or electronic apparatus have to be collected at the appropriate recycling locations.

Only for EC countries

Do not dispose of power tools into domestic waste. According to the European Guideline 2012/19/EC for Waste Electrical and Electronic Equipment and its implementation into national right, power tools that are no longer usable must be collected separately and disposed of in an environmentally friendly way.

The product and the user manual are subject to change. Specifications can be changed without further notice.

Kırıcı Delici Matkap 1100W HDM1043P

DECLARATION OF CONFORMITY HDM1043P - ROTARY HAMMER

(EN) We declare under our sole responsibility that this product is in conformity with directive 2011/65/EU of the European parliament and of the council of 8 June on the restriction of the use of certain hazardous substances in electrical and electronic equipment is in conformity and accordance with the following standards and regulations:
(DE) Der Hersteller erklärt eigenverantwortlich, dass dieses Produkt der Direktive 2011/65/EU des Europäischen Parlaments und des Rats vom 8. Juni 2011 über die Einschränkung der Anwendung von bestimmten gefährlichen Stoffen in elektrischen und elektronischen Geräten entspricht. den folgenden Standards und Vorschriften entspricht:
(NL) Wij verklaren onder onze volledige verantwoordelijkheid dat dit product voldoet aan de conform Richtlijn 2011/65/EU van het Europees Parlement en de Raad van 8 juni 2011 betreffende beperking van het gebruik van bepaalde gevaarlijke stoffen in elektrische en elektronische apparatuur en in overeenstem ming is met de volgende standaarden en reguleringen:
(FR) Nous déclarons sous notre seule responsabilité que ce produit est conforme aux standards et directives suivants: est conforme à la Directive 2011/65/EU du Parlement Européen et du Conseil du 8 juin 2011 concernant la limitation d'usage de certaines substances dangereuses dans l'équipement électrique et électronique.
(ES) Declaramos bajo nuestra exclusiva responsabilidad que este producto cumple con las siguientes normas y estándares de funcionamiento: se encuentra conforme con la Directiva 2011/65/UE del Parlamento Europeo y del Consejo de 8 de junio de 2011 sobre la restricción del uso de determinadas sustancias peligrosas en los equipos eléctricos y electrónicos.
(PT) Declaramos por nossa total responsabilidade-de que este produto está em conformidade e cumpre as normas e regulamentações que se seguem: está em conformidade com a Directiva 2011/65/EU do Parlamento Europeu e com o Conselho de 8 de Junho de 2011 no que respeita à restrição de utilização de determinadas substâncias perigosas existentes em equipamento eléctrico e electrónico.
(IT) Dichiariamo, sotto la nostra responsabilità, che questo prodotto è conforme alle normative e ai regolamenti seguenti: è conforme alla Direttiva 2011/65/UE del Parlamento Europeo e del Consiglio dell'8 giugno 2011 sulla limitazione dell'uso di determinate sostanze pericolose nelle apparecchiature elettriche ed elettroniche.
(SV) Vi garanterar på eget ansvar att denna produkt uppfyller och följer följande standarder och bestämmelser: uppfyller direktiv 2011/65/EU från Europeiska parlamentet och EG-rádet från den 8 juni 2011 om begränsningen av användning av farliga substanser i elektrisk och elektronisk utrustning.
(FI) Vakuutamme yksinomaan omalla vastuillamme, että tämä tuote täyttää seuraavat standardit ja säädökset: täyttää Euroopan parlamentin ja neuvoston 8. kesäkuuta 2011 päivätyn direktiivin 2011/65/EU vaatimukset koskien vaarallisten aineiden käytön rajoilusta sähkö- ja elektronisissa laitteissa.
(NO) Vi erklærer under vårt eget ansvar at dette produktet er i samsvar med følgende standarder og regler: er i samsvar med EU-direktivet 2011/65/EU fra Europa-parlamentet og Europa-rådet, pr. 8 juni 2011, om begrensning i bruken av visse farlige stoffer i elektrisk og elektronisk utstyr.
(DA) Vi erklærer under eget ansvar, at dette produkt er i overensstemmelse med folgende standarder og bestemmelser: er i overensstemmelse med direktiv 2011/65/EU fra Europa-Parlamentet og Rådet af 8. juni 2011 om begrænsning af anvendelsen af visse farlige stoffer i elektrisk og elektronisk udstyr.
(HU) Felelősségünk teljes tudatában kijelentjük, hogy ez a termék teljes mértékben megfelel az alábbi szabványoknak és előírásoknak: je v souladu se směrnící 2011/65/EU Evropského parlamentu a Rady EU ze dne 8. června 2011, která se týká omezení použití určitých nebezpečných látek v elektrických a elektronických zařízeních.
(CS) Na naši vlastní zodpovědnost prohlašujeme, že je tento výrobek v souladu s následujícími standardy a normami: Je v súlade s normou 2011/65/EÚ Európskeho
