CM-1000B - Kettle Vivax - Free user manual and instructions

Product Type	Electric Kettle / Coffee Maker
Brand	Vivax
Model	CM-1000B
Voltage	220-240V AC
Frequency	50/60Hz
Power	1000W
Capacity	0.4 L (max 4 cups)
Material	Plastic body, stainless steel heating element
Heating Element	Hidden resistance heater
Control	On/Off switch on handle
Safety Features	Double safety system against overheating, auto shut-off
Handle	Ergonomic, stay-cool
Functions	Boil water, brew Turkish coffee (up to 4 cups)
Usage	Household only, not for commercial use
Cleaning	Interior with soft sponge and mild detergent; exterior with damp cloth
Descaling	Use non-toxic descaler or vinegar solution (no boiling)
Repairability	Do not repair yourself; contact authorized service
Warranty	12 months for small home appliances (Europe)
Included Accessories	None (unit only)
Dimensions (approx.)	20 x 15 x 18 cm (estimated)
Weight (approx.)	0.5 kg (estimated)

Frequently Asked Questions - CM-1000B Vivax

How do I use the Vivax CM-1000B to make coffee?

Add water, coffee, and sugar up to 4 cups (max 0.4 L). Plug into a grounded socket, turn the On/Off switch to 'I', stir briefly. When the coffee boils, turn switch to 'O' and pour into cups.

Can I boil only water in this kettle?

Yes. Fill with water (max 4 cups), switch on, and wait for it to boil. Then turn off and use the hot water for tea or other purposes.

What is the maximum capacity?

The maximum capacity is 0.4 liters, which corresponds to 4 standard coffee cups. Do not overfill to avoid boiling over.

How do I clean the kettle?

Unplug and let it cool. Clean the interior with a soft sponge and mild detergent, then rinse. Wipe the exterior with a damp cloth. Do not immerse in water or use abrasive cleaners.

How do I descale the CM-1000B?

Use a non-toxic descaler or a mixture of 3 cups vinegar and water. Do not boil; let it sit overnight, then empty. Rinse with water, then boil once with clean water and discard.

Is it safe to leave the kettle unattended while boiling?

No. Always monitor the kettle while in use. It has a safety system but should not be left unattended. Unplug after use.

What should I do if the kettle stops working?

Check the plug and socket. If still not working, do not attempt to repair. Contact authorized service (see warranty card for details). The warranty covers manufacturing defects.

Can I boil milk in this kettle?

No. Boiling milk can cause a brown-black layer on the heater that is hard to remove and may damage the product. Use only water or coffee.

What is the power consumption?

The kettle has a power rating of 1000W at 220-240V, 50/60Hz. It is energy efficient for small quantities.

Is the kettle suitable for children to use?

Children aged 8+ can use it under supervision. Younger children must not use it. Keep the appliance and cord out of reach of children under 8.

USER MANUAL CM-1000B Vivax

( OHNWULpQD□JULMDOLFD□] D□SULSUHP X□NDYH

Hvala vam na odabiru Vivax Električne grijalice za pripremu kave. Nadamo se da će vam korištenje ovog uređaja pružiti užitak kao i ostali Vivax proizvodi i da će vam olakšati pripremu kave.

Molimo Vas da pročitate ove upute kako bi osigurali optimalne performanse u korištenju vašeg uređaja. Pažljivo i potpuno pročitajte ove upute prije nego krenete koristiti uređaj. Sačuvajte upute za eventualne buduće potrebe. Ako prodajete ili poklanjate ovaj uređaj, obavezno proizvodu pridružite i ove upute.

1. VAŽNA UPOZORENJA I SIGURNOSNE UPUTE

( OHNWULpQD□JUHMDOLFD□] D□SULSUHP X□NDIH

Hvala vam na izboru Vivax električne grejalice za pripremu kafe. Nadamo se da će vam upotreba ovog uređaja olakšati pripremu kafe i pružiti užitak kao i ostali Vivax proizvodi.

Pre upotrebe, pažljivo i u potpunosti pročitajte ova uputstva kako biste osigurali optimalne performanse u upotrebi vašeg uređaja. Sačuvajte uputstva za eventualnu upotrebu u budućnosti. Ako prodajete ili poklanjate ovaj uređaj, obavezno uz njega priložite i ova uputstva.

1. VAŽNA UPOZORENJA I SIGURNOSNA UPUTSTVA

Osnovnih mera opreza morate da se pridržavate tokom upotrebe ovog električnog uređaja.

Ovaj uređaj ne smeju da koristite deca od 0 do 8 godina. Ovaj aparat mogu da koriste deca starija od 8 godina i više ako su pod stalnim nadzorom. Ovaj aparat mogu da koriste osobe sa smanjenim fizičkim, osetilnim ili umnim sposobnostima ili nedostatkom iskustva i znanja ako su pod nadzorom ili su upućene kako koristiti aparat na siguran način i da razumiju opasnosti koje su u to uključene. Držite aparat i mrežni kabl van domašaja dece mlađe od 8 godina. Čišc’enje i korisničko održavanje ne smeju raditi deca

" QBSBU□&MFLUSJL□, BGFKF

Electric Coffee Maker

Thank you for preferring Vivax Electric Coffee Maker. We hope this appliance will make your life easy as all the other Vivax products.

Please read this manual thoroughly to get full performance from your appliance and keep it a safe place for further reference.

1. IMPORTANT WARNINGS

Basic safety precautions must be complied with while using an electrical appliance.

This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children unless they are older than 8 and supervised.

• The device must be used in accordance with the instructions given in the user's manual. Incorrect or faulty uses might cause injuries.
• Do not leave your appliance as plugged in. Unplug it when not in use and when it requires servicing. While unplugging, use the head of the plug instead of its cord and allow your appliance to cool down.
• Before unplugging the appliance, turn the On/Off button to the position "0" (OFF).
• Do not insert or pull the plug with wet hands.
• Never leave the electric terminals of your appliance wet. If they get wet, unplug it and do not use it before until it is completely dry.
• In order to avoid electric shock, do not immerse the cable and the plug into water or other liquids.
• If the appliance accidentally drops into water unplug it

immediately and contact the authorized service before reusing it.

• Do not keep any flammable materials like paper or plastics in or near the appliance.
• Place the appliance on a stable, at and cold surface. Do not put it on a corner of a table or a kitchen counter. Breeze or impact may cause your appliance to topple.
• Please do not touch the hot surface; use the appliance by holding the handle instead.
• Be careful about steam during use.
• Keep your appliance and its cabling away from children.
• Cleaning and user maintenance shall not be made by children unless they are older than 8 and supervised.
• Do not let children use the appliance.
• Keep children away from this product and do not allow them to pull the electrical cable or to touch the device.
• Never allow children to play with the device.
• Store the device and its cable in a place not accessible to children younger than 8 years old.
• Use only the accessories produced or recommended by the manufacturer.
• Make sure that the voltage indicated on Electric Coffee Maker corresponds to the mains voltage of your location.
• To prevent any damage to your appliance, do not use extension cords that supply insufficient current. Connect the unit to an active grounded socket.
• Do not perform any operation on your appliance except for cleaning and maintenance. Do not attempt to repair, calibrate or replace the parts of your appliance. Please contact with a qualified personnel.
• Avoid any action that would damage the cord and the plug of the appliance.
• If the supply cord is damaged, it must be replaced by the manufacturer or his service agent or equally competent

personnel to prevent any dangerous situation.

- Protect your appliance and its cable against heat, direct sunlight, moisture, sharp objects, etc.

- Do not place the appliance on and close to direct heat sources such as stoves, furnaces and ovens. Do not let the appliance contact with other devices.

- Do not fully fill the device as the boiled water that may flush.

- Do not use the appliance without water or as empty.

- Use of liquids other than water may damage the device.

- Do not immerse the appliance into water while cleaning.

- Avoid spilling any liquid on connection parts of the device.

- While using the appliance, do not put any cover on it.

- During the first use, a smell may arise from the heater of the appliance. This is normal.

- While using the coffee maker, use only by its handle.

- Make sure the appliance is stable.

- Pay attention to the surface of the device as it would be hot after use.

- Do not remove the appliance while using it.

- Your appliance is intended for household use only. Do not use it for commercial or industrial purposes.

- This appliance is intended for domestic use or similar applications like the followings:

• Staff kitchen areas in stores, offices and other working environments, - Farmer houses,
• Areas used by customers in hotels, motels, hostels, similar residence areas
• Dormitories and breakfast areas.

- Any malfunction, cracks or scratches caused as a result of dropping or hitting after the delivery of the product to the consumer are considered as user errors.

- Our company does not accept responsibility for the malfunctions caused by the above-mentioned reasons

and therefore such malfunctions are excluded from the warranty.

Caution!

Never use the stretch bags in the package of the appliance as a toy. Please keep them away from children to prevent any accident.

2 PART DESCRIPTION

Appliance Description

Electric Coffee Maker can be used for making coffee or boiling water.

Caution!

Do not put milk in coffee maker. If you boil milk in it, this leaves a brown-black layer on the heater, which can only be removed by using a hand scourer. This may damage the product. Therefore, it is not recommended to boil milk in the coffee maker.

3 USE OF APPLIANCE

Electric Coffee Maker can be used to make maximum 4 cups of coffee.

• Add water, coffee and sugar in the coffee maker as the number of cups (maximum 4 cups) preferred.
• Plug the appliance in a grounded socket.
• Turn the On/Off button to "I" (On) position.
• Mix the mixture for a short period.
• When the coffee boils, turn the On/Off button to "O" (Off) position.
  • Pour the coffee into cups.

Note: If the socket is grounded, a metal spoon can be used.

Boiling Water

You will need hot water to prepare granule coffee, teabag, linden tea, rose hip tea, fruit herbal and herbal teas.

• In order to get hot water, add water into coffee maker as much as you need (maximum 4 cups), but be careful not to over ow.
• Plug the appliance in a grounded socket.
• Turn the On/Off button to "I" (On) position.
• When the water boils, turn the On/Off button to "O" (Off) position.
• Now you can use your hot water as you wish.

4 MAINTENANCE, REPAIR AND USE

• Never try to open and repair your appliance when it does not work.
• Please do not operate the appliance in case of a break or crack when it falls or hits to a hard object. Contact the authorized service.
• Do not change the damaged cable or plug, contact the authorized service.
• Do not carry the appliance by holding its cable.
• Unplug the appliance by pulling out from the socket, not the power cord.
• Unplug the appliance when not in use.

5. CLEANING AND MAINTENANCE

• Before cleaning the appliance, turn the On/Off button to "O" (Off) position, unplug it and wait until your appliance cools down.
• Clean the inside of the coffee maker with soft sponge and detergent, then rinse it with water. Do not use abrasive or similar objects to clean the heater of the coffee maker.
• Use a dry or damp towel to clean the outside of the coffee maker. Do not use chemical or abrasive cleaners to clean the outer surface of the appliance.
• Do not immerse the appliance into water.

Caution!

Do not put the appliance in washing machine.

Descaling:

You can use a descaler without toxicant to remove limescale buildup that may occur in time.

Alternative:

Put three cups of vinegar into the appliance, Fill the rest with water and leave it overnight. Do not boil it! Empty the solution. You can use a damp towel to clean the residues that may remain inside it. After cleaning, Fill the appliance with water, boil it once and empty it. Your appliance is ready to use.

Warning! Cleaning and maintenance operations should not be done by children without supervision.

6. RECOMMENDATIONS FOR EFFICIENT USE AND ENERGY SAVING

• Unplug your appliance when not in use.
• Limescale and residues in your appliance adversely affects efficiency of the appliance. This causes more electricity consumption. The limescale and residues in the appliance must be cleaned often.

7 HANDLING AND TRANSPORTATION

The appliance should be transported in its original box and partitions or as wrapped with a soft cloth.

Incorrect packaging may cause damage to the outer surface of the appliance.

NOTE:

ANY MALFUNCTION OR DAMAGE CAUSED DURING LOADING, UNLOADING OR TRANSPORT AFTER THE DELIVERY OF PRODUCT TO THE CUSTOMER IS NOT COVERED BY THE WARRANTY.

8 TECHNICAL SPECIFICATIONS

Voltage, Frequency: 220-240V AC, 50/60Hz

Power: 1000W

Capacity: 0,4 l

Switch: On the handle On/Off switch

Ergonomic handle

Double safety system against overheating

Hidden resistance heater

9. DISPOSAL OF ELECTRICAL AND ELECTRONIC EQUIPMENT

To protect our environment and to recycle the raw materials used as completely as possible, the consumer is asked to return unserviceable equipment to the public collection system for electrical and electronic.

The symbol of the crossed indicates that this product must be returned to the collection point for electronic waste to feed it by recycling the best possible raw material recycling.

By ensuring this product you will prevent possible negative effects on the environment and human health, which could otherwise be caused due to improper disposal of that product. The recycling of materials from this product, you will help to preserve a healthy environment and natural resources.

For detailed information about the collection of EE products contact M SAN Grupa dd or the dealer where you purchased the product.

10. EU DECLARATON OF CONFORMITY

This device is manufactured in accordance with the applicable European standards and in accordance with all applicable Directives and Regulations.

EU declaration of conformity can be downloaded from the following link: www.msan.hr/dokumentacijaartiklala

POŠTOVANI!

Zahvaljemo na kupnji Vivax uređaja i nadamo se da ćete biti zadovoljni odabirom. Ako u jamstvenom periodu bude potreban popravak proizvoda, molim savjetuje se sa ovlaštenim prodavačem koji Vam je proizvod prodao ili nas kontaktirajte na dolje navedene brojeve i adrese. MOLIMO VAS DA PRIJE UPOTREBE PROIZVODA PAŽLJIVO PROČITATE TEHNIČKU DOKUMENTACIJU I UPUTE KOJI SU PRILOŽENI UZ PROIZVODI

JAMSTVENI LIST

VIVAX

HR

MODEL UREDAJA

SERIJSKI BROJ

DATUM PRODAJE

BROJ RAČUNA PRODAVATELJA

POTPIS I PEČAT PRODAVATELJA

1. Ovim jamstvom jamči proizvodač proizvoda, preko M SAN GRUPA d.d, kao uvoznika i davatelja jamstva u Republici Hrvatskoj besplatan popravak istog u skladu s važećim propisima i u skladu s uvjetima opisanim u ovom jamstvenom listu. Ovim jamstvom jamčimo da će predmet ovog jamstva raditi bez greške uzrokovane eventualnom lošom izradom i lošim materijalom izrade. Svi eventualno nastali kvarovi biti će besplatno otklonjeni u ovlaštenom servisu u jamstvenom roku.
2. UVJETI JAMSTVA Jamstveni rok počinje teći od dana kupnje proizvoda i traje 24 mjeseca za Vlvax Home velike kućanske aparate (perilice rublja, hladnjake, perilice posuđa, štednjake, ugradbenu tehniku), a 12 mjeseci za Vlvax home male kućanske aparate (uključujući mikrovalne pečnice, grijalice i radijatore).
3. U slučaju kvara na proizvodu koji je predmet ovog jamstva, obavezujemo se da ćemo isti popraviti u razumnom roku - 45 dana Ako se proizvod ne može popraviti ili se ne popravi u razumnom roku - 45 dana, biti će zamijenjen novim. Jamstvo na uređaj se produžuje za ono vrijeme koliko traje popravak uređaja.
4. Jamstvo se priznaje samo uz račun o kupnji, te uz ovaj jamstveni list koji mora biti ispravno popunjen odnosno mora sadržavati datum prodaje, pečat i polpis prodavatelja.
5. JAMSTVO NE OBUHVAĆA Redovnu provjeru, održavanje uz zamjenu dijelova koji se troše normalnom upotrebom. Prilago čavanje ili promjene za poboljšanje proizvoda za primjenu koji nisu opisane u tehničkim uputama za korištenje, osim ako je za te preinake predočena suglasnost M SAN GRUPA d.d.
6. Jamstvo se ne priznaje u sljedećim slučajevima: Ako kupac ne predoči ispravan jamstveni list i račun o kupnji. Ako se kupac nije pridrž avao uputa o korištenju proizvoda. Ako je proizvod otvaran, prepravljan ili popravljan od neovlaštene osobe. Ako su kvarovi na proizvodu nastali djelovanjem više sle kao što su: udar groma, strujni udari u električnoj mreži elementame nepogode i slično. Ako su kvarovi nastali oštećivanjem zbog nepropisane upotrebe ili nepravlinim transportiranjem. Ako je kvar nastao greškom u sustavu na koji je proizvod priključen.
7. Ovo jamstvo ne mijenja zakonska potrošačka prava važeća u Republici Hrvatskoj u odnosu na ona koja propisuje proizvođač.
8. Izjavu o sukladnosti i presliku izvorne Izjave sukladnosti (EC Declaration of Conformity) možete jednostavno preuzeti na našoj internetskoj stranici www.msan.hr/dokumentacijaartikala

Naziv tvrtke davatelja jamstva : M SAN Grupa d.d., Buzinski prilaz 10, 10010 Zagreb-Buzin, tel: [phone]

CENTRALNI SERVIS: MR SERVIS d.o.o. Dugoselska cesta 5, 10370 Rugvica, Tel. [phone] Fax: [phone] E-mail: [e-mail]
