Product type	Robotic vacuum cleaner
Brand	Philips
Model	SmartPro Active FC8822
Dimensions (diameter x height)	330 x 80 mm
Weight	1.95 kg
Battery type	Lithium-ion 14.8 V
Runtime	120 minutes
Charging time	4 hours
Dustbin capacity	0.4 L
Noise level	63.4 dB
Cleaning modes	4 (Zig-zag, random, spiral, wall follow)
Floor types	Carpet, hard floor
Scheduling function	Weekly scheduling
Sensors	6 infrared sensors, dust sensor
Cleaning system	3-step cleaning with mop
TriActive XL nozzle	Yes
Suction power (Turbo mode)	1800 Pa
Included accessories	Remote control, virtual wall, charging base, side brushes, mop, filter
Obstacle clearance height	15 mm
Standby power consumption	0.65 W
Color	Metallic Beluga

Frequently Asked Questions - SMARTPRO ACTIVE FC8822 PHILIPS

How to schedule weekly cleaning?

Use the weekly scheduling function via the remote control. You can set a schedule for each day of the week, except for one day that you can exclude. The robot will start automatically at the scheduled time, even when you are away.

What is the battery runtime?

The maximum runtime is 120 minutes with a 14.8V lithium-ion battery. Full charging time is approximately 4 hours.

How to use Turbo mode?

Press the Turbo button on the remote control to activate intensive suction mode at 1800 Pa. This mode is ideal for very dirty floors or thick carpets.

Can the robot avoid obstacles?

Yes, the robot is equipped with 6 infrared sensors that detect and avoid obstacles such as walls, lamps, and cables, ensuring safe cleaning.

How to install the virtual wall?

Place the virtual wall at the entrance of the area to be restricted. It creates an invisible barrier of approximately 2 meters that the robot will not cross. Use it to protect fragile objects or cables.

How to clean the dust sensor?

The dust sensor is automatic and does not require specific cleaning. It allows the robot to detect dirtier areas and focus on them for deep cleaning.

What types of floors can it clean?

The robot is suitable for carpets and hard floors (tile, parquet, laminate). Thanks to its TriActive XL nozzle and 3-step system, it adapts to all surfaces.

How to attach the mop?

The mop attaches via clip under the robot. Simply snap it onto the designated holder. It helps collect fine dust during cleaning.

What to do if the robot does not charge?

Check that the charging base is properly plugged in and the contacts are clean. Make sure the robot is correctly positioned on the base. If the problem persists, reset the robot by pressing the Reset button.

What is the dustbin capacity?

The dustbin has a capacity of 0.4 liters. It is recommended to empty it after each use to maintain optimal performance.

USER MANUAL SMARTPRO ACTIVE FC8822 PHILIPS

Philips SmartPro Active Robot vacuum cleaner

3-step cleaning system
120 min runtime
Click-on mopping
TriActive XL nozzle

FC8822/01

Thorough and advanced clean, now 2 times faster*

WithTriActive XL nozzle and 3-Step Clean system

The Philips SmartPro Active robot vacuum cleaner cleans 2 times faster thanks to the combination of TriActive XL brushless nozzle, strong suction power with 1800Pa Turbo mode and 3-Step clean system with dry mopping.

Cleans on its own

• Infrared sensors for detecting and avoiding obstacles
• Powerful Li-ion battery for 120 min operating time
  Schedule your weekly cleaning
• Smart Detection System adapts cleaning to any environment
• TriActive XL nozzle cleans double the area in one stroke

Extra accessories included

• Remote to control the robot from a distance
• Virtual wall to keep the robot out of off-limit areas

Thorough cleaning performance

3-step cleaning system including dry mopping function
- 4 cleaning modes to adapt to different areas
- The robot detects the most dirty areas for a deeper clean
TURBO suction mode for intensive cleaning

Highlights

Infrared sensors

The new Philips robot vacuum cleaner is equipped with 6 Infrared sensors for detecting and avoiding obstacles such as walls, lamps or cables, so your floors are cleaned carefully. Finally you can enjoy a clean house without your interference.

Scheduling Function

Cleaner offers a weekly scheduling function, so you can program your next cleaning session one week in advance, with the possibility to set a different time for each day excluding one day. The Robot will activate even if you are not at home, so you can enjoy a clean house.

Powerful Li-lon battery

The powerful Lithium- ion battery has a longer lifetime and a shorter charging time than

standard batteries. The new robot vacuum cleaner runs up to 120 min.

Virtual wall

The Virtual wall creates an invisible barrier that the Robot cannot cross. This invisible barrier can be used to confine the Robot to a particular room or area, and preventing it from getting too close to electrical or computer cords, delicate objects on the floor, etc. The virtual wall has a reach of 2 meters approximately.

3-step cleaning system

First two long brushes swipe dirt and dust into the path of the robot. Then, the nozzle picks up dirt and dust thanks to its powerful motor. Lastly, the click-on mopping pad enhances the cleaning by collecting even the finest dust from your floors.

Dust Sensor

The dust sensor feature enables the robot to automatically recognize the areas where most dust is accumulated, so it stays in that area for a few seconds more to have a deeper cleaning.

4 cleaning modes

4 cleaning modes to adapt to different areas in your home. The z-type mode drives the robot in a parallel zig-zag pattern, when it discovers a relatively larger space. The bounce mode drives the robot in a straight line, when it bumps into an object the robot will choose another random direction. With the spiral mode the robot moves in a spiral motion with an increasing radius. The wall-following mode drives the robot to clean while staying close and parallel to the wall.

Specifications

Performance

• Battery type: Li-lon
• Battery voltage: 14.8 V
• Charging time: 4 hour(s)
  Runtime: 120 minute(s)
  Sound power level: 63.4 dB

Usability

• Dust sensor
• Smart detection system: 25 sensors
• Threshold climbing: 15 mm
• Cleaning modes: 4
  Infrared sensors
  Weekly scheduling
• Types of Floors: Carpet, Hardfloor

Design

Color: Beluga metallic

Filtration

• Dust capacity: 0.4 L

Nozzles and accessories

• Accessories included: AC power adaptor, 1 x Virtual wall
• Other accessories: 1 × Filter, Base Station, Side brushes (1 pair), Dry mop, Remote control

Sustainability

• Stand-by power consumption: 0.65 W

Weight and dimensions

• Dimensions of product (LxWxH): 80 × 330 mm
  Weight of product: 1.95kg
• Weight incl. packaging: 4.0kg

Design specifications

• Deco Ring: Bright Chrome, High Gloss Ring, electroplated
