CJ40W - Juicer GORENJE - Free user manual and instructions

Product Type	Citrus Juicer
Brand	Gorenje
Model	CJ40W
Power Supply	220-240V, 50Hz
Power Consumption	Approx. 100W (estimated)
Motor Unit Material	Plastic
Juice Container Material	Glass (transparent)
Cone Materials	Plastic
Strainer Material	Stainless steel (estimated)
Dimensions (Approx.)	20 x 20 x 30 cm
Weight (Approx.)	1.5 kg
Cord Length	Adjustable, stored underneath
Noise Level	< 60 dB(A)
Continuous Operation Time	Max 5 minutes per cycle
Rest Period After Use	30 minutes after 10 cycles (ON 15s/ OFF 15s)
Cone Sizes	Large (for oranges, grapefruits) and Small (for lemons, limes)
Operation	Automatic on/off by pressing fruit onto cone
Safety Features	Automatic shut-off when pressure released; non-slip base
Cleaning	Detachable parts dishwasher safe; motor unit wipe only
Accessories Included	Large cone, small cone, strainer, juice container, anti-dust lid
Warranty	Standard manufacturer warranty
Intended Use	Household only

Frequently Asked Questions - CJ40W GORENJE

What is the maximum continuous operation time for the Gorenje CJ40W juicer?

Do not use the citrus press longer than 5 minutes without interruption. The recommended cycle is 15 seconds ON, 15 seconds OFF, repeated up to 10 times, then a 30-minute rest.

Can I wash the motor unit in water?

No. Do not immerse the motor unit in water or any other liquid. Clean it only with a damp cloth.

Which cone should I use for lemons?

Use the small cone for small citrus fruits like lemons and limes. For larger fruits like oranges and grapefruits, use the large cone (which fits over the small cone).

How does the juicer turn on and off?

The juicer switches on automatically when you press a fruit half onto the cone. It switches off automatically as soon as you reduce pressure on the cone.

What should I do if the juicer stops working during use?

Check if the appliance has exceeded the maximum operation time. If so, unplug it and let it cool down for at least 30 minutes. Also ensure the cone is not jammed with too much pressure.

Can I juice fruits other than citrus?

No, this appliance is designed only for citrus fruits such as oranges, grapefruits, lemons, and limes.

Are the removable parts dishwasher safe?

Yes, the cones, strainer, juice container, and anti-dust lid can be cleaned in the dishwasher or with hot water and washing-up liquid. The motor unit must not be immersed.

What is the noise level of the CJ40W?

The noise level is less than 60 dB(A), which is comparable to a normal conversation.

Can children use this juicer?

Children aged 8 years and above can use the appliance under supervision. Children under 8 must be kept away from the appliance and its cord.

How do I store the juicer after use?

Wind the cord around the base, assemble the parts (cones, strainer, juice container), and cover with the anti-dust cover. Store in a safe, dry place.

USER MANUAL CJ40W GORENJE

Illustration of a transparent glass juicer with a handle and lid, no text or symbols present

CJ40W

1. The cover of rotating head
2. Big /Small rotating head
3. Screening plate
4. Middle container
5. Motor unit

Important

Read this user manual carefully before you use the appliance and save it for future reference.

Danger

Do not immerse the motor unit in water or any other liquid, nor rinse it under the tap.

Warning

• Do not allow children touch the iron or the power cord when ironing.
• Check to make sure the mains socket has the correct rating(230V/10A).
• Children should be supervised to ensure that they do not play with the appliance.
• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
• Keep the iron and its cord out of reach of children less than 8 years of age when it is energized cooling down or.
• Cleaning and user maintenance shall not be made by children without supervision.
• If the supply cord is damaged, it must be replaced by the manufacturer, its service or similar qualified person in order to avoid a hazard.

Caution: This appliance is intended for household use only.

Never use any accessories or parts from other manufacturers or that Gorenje does not specifically recommend. If you use such accessories or parts, your guarantee becomes invalid.

Make sure all parts are correctly mounted before you switch on the appliance.

Warning

Check if the voltage indicated on the bottom of the appliance corresponds to the local mains voltage before you connect the appliance.
If the mains cord is damaged, you must have it replaced by Gorenje; a service centre authorized by Gorenje or similarly qualified persons in order to avoid a hazard.
Do not use the appliance if the plug, the mains cord or other parts are damaged.
This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instructions concerning use of the appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
Never connect this appliance to an external timer switch or remote control system in order to avoid a hazardous situation.
Always unplug the appliance after use.
Never connect this appliance to an external timer switch or remote control system in order to avoid a hazardous situation.
Noise level: Lc < 60 dB(A)

This appliance is marked according to the European directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE). This guideline is the frame of a European-wide validity of return and recycling on Waste Electrical and Electronic Equipment.

Preparing for use

Caution

Always place the appliance on a flat, stable surface. Do not use the citrus press longer than 5 minutes without interruption.

(ON 15 s / OFF 15 s X 10 →30 min STOP)

This appliance is intended for household use only. Never use any accessories or parts from other manufacturers unless they are authorized by Gorenje. In case you use these accessories the warranty will be cancelled.

Before use

Clean all detachable parts before using the appliance for the first time (see chapter 'Cleaning').

Make sure the appliance is assembled properly before you plug it in the wall socket. Wind excess cord round the base of the appliance.

Put the plug in the wall socket.

Before first use

Danger Keep the packaging material away from children .they could suffocate Unpack the citrus juicer and remove all of the packaging Material Examine the juicer for visible damage and check that all of the parts are present You should clean the appliance before using it for the first time Wipe the motor base with a damp cloth Before using the juicer for the first time, rinse the cones, strainer, juice container and transparent dust lid with warm water and a few drops of washing-up liquid.

Using the appliance

Setting up the juicer

Stand the appliance on an even surface that is easy to clean

Unwind the power cord – to the length you require – from the cord storage compartment (underneath the juicer). Make sure that the cord is correctly positioned in the cord guide to prevent the juicer from wobbling.

Connect the mains plug to a AC230V,50Hz socket outlet.

Selecting accessories

Depending on the size of the fruit you are juicer, you can use the large or the small cone The large cone is suitable for juicing small citrus fruit, such as grapefruit, oranges etc The small cone is suitable for juicing small citrus fruit, such as lemons, limes etc.

Fit the small juicing cone directly onto the drive shaft

If you wish to use the large cone, fit the small cone onto the drive shaft. Then fit the large cone over the top of the small cone.

You must feel the notches in the large cone clip into place over the stirring wings on the small cone.

To separate the cones, pull the large cone up and off.

Juicing

Caution: if you apply too much pressure to the juicing cone, the motor may seize.

Fit the appropriate cone onto the drive shaft.

Cut a citrus fruit in half and press the cut end of one fruit half onto the cone. The juicer switches on automatically when you press the fruit down and the cone starts to turn. The juicer automatically switches off as soon as you reduce pressure on the cone. The cone

scrapes the pulp out and squeezes the juice from the fruit. The juice flows through the strainer into the juice container. The strainer keeps back thick pulp and seeds. To maximize the quantity of juice extracted from a fruit, press a fruit onto the cone several times.

Cleaning

After use

Remove cone, strainer, juice container and drive shaft from the appliance and clean them. Unplug the appliance.

Juicing advice

Citrus fruit juices should be consumed immediately and never stored in a metal container.

Citrus juices are ideal for mixing. For example, you can mix orange juice with lemon juice for and extra vitamin C kick.

Freshly squeezed juice gives cocktails a particularly tangy twist and better flavour.

Lemon juice is also delicious in hot tea and additionally helps you build up your defences when you have a cold.

Cleaning

Unplug the appliance.

Remove all detachable parts from the motor unit.

Clean all detachable parts with hot water and some washing-up liquid or in the dishwasher.

Clean the motor unit with a moist cloth.

Never immerse the motor unit in water nor rinse it under the tap.

Storage

Wind the cord round the base of the appliance. Then assemble it and cover with the anti-dust cover.

Store the appliance in a safe and dry place.

Environment

Do not throw away the appliance with the normal household waste at the end of its life, but hand it in at an official collection point for recycling. By doing this, you help to preserve the environment.

Guarantee and service

If you need information or if you have a problem, please contact the Gorenje Customer Care Centre in your country (you find its phone number in the worldwide guarantee leaflet). If there is no Customer Care Centre in your country, go to your local Gorenje dealer or contact the Service department of Gorenje domestic appliances.

For personal use only!

GORENJE

WISHES YOU A LOT OF

PLEASURE WHEN USING YOUR APPLIANCE

We reserve the right to any modifications!
