Z29544 - Lighting FLORABEST - Free user manual and instructions

Product Type	Outdoor Solar Light
Brand	Florabest
Model	Z29544
Power Source	Solar panel and 2 x NiMH rechargeable batteries (AA, 1.2 V, 600 mAh)
Operating Voltage	2.4 V
Light Source	2 LEDs (Class 1, non-replaceable)
Protection Class	III
Protection Type	IP44 (splash proof)
Application	Outdoor illumination (gardens, paths, walls)
Operation	Automatic on/off at dusk/dawn via ON/OFF switch
Mounting	Wall-mounted using included screws and dowels
Included Accessories	2 x NiMH rechargeable batteries (AA/1.2V/600mAh), 2 screws, 2 dowels, assembly instructions
Battery Replacement	Replaceable NiMH AA size (recommended type: 1.2V, 600 mAh)
Solar Panel	Converts sunlight to electrical energy, stores in battery
Charge Time	Depends on sunlight; battery reaches max capacity after several cycles
Light Duration	Depends on charge; up to several hours with full charge
Maintenance	Clean solar panel with dry, lint-free cloth; replace batteries when performance diminishes
Safety Features	Short-circuit and explosion protection; keep away from children; do not expose to fire
Disposal	Recycle batteries per Directive 2006/66/EC; dispose of lamp at local recycling facility
Item Number	Z29544

Frequently Asked Questions - Z29544 FLORABEST

How do I install the Florabest Z29544 solar light?

First, choose a location with direct sunlight. Drill two 6 mm holes, insert the dowels, then screw the back plate to the wall. Attach the base and lamp, then set the ON/OFF switch to ON. Refer to the assembly instructions for details.

How do I replace the rechargeable batteries?

Set the switch to OFF. Unscrew the nuts on the cover, remove the cover and solar element carefully. Insert new NiMH AA batteries (1.2V, 600 mAh) with correct polarity, then reassemble.

Why won't the light turn on after a sunny day?

Check if the ON/OFF switch is set to ON. Ensure the solar panel is clean and not shaded. If the batteries are old, replace them. Also, avoid interference from artificial light sources like street lamps.

Can I use this light indoors?

No, this product is designed for outdoor use only. It requires direct sunlight to charge and is rated IP44 for splash proof conditions, not indoor use.

What type of batteries does it use?

It uses 2 x NiMH rechargeable batteries size AA, 1.2V, 600 mAh. Only replace with the same type and capacity.

How long does the light stay on?

The light duration depends on the amount of sunlight received during the day. On a full charge, it can last several hours, but this varies with season and weather.

Is the light waterproof?

It has an IP44 rating, meaning it is splash proof. It can withstand rain from all directions but should not be submerged.

How do I clean the solar panel?

Clean the solar panel with a dry, lint-free cloth. For heavier dirt, use a slightly damp cloth. Do not use abrasive or corrosive cleaners.

Can I dim the light or change the LEDs?

No, the light is not dimmable and the LEDs are non-replaceable. They are designed to last the lifetime of the product.

How should I dispose of the light and batteries?

Dispose of the lamp at your local recycling facility. Batteries must be recycled separately according to Directive 2006/66/EC. Do not throw them in household waste.

USER MANUAL Z29544 FLORABEST

Assembly and safety advice

DE AT CH

soLar-aussenLeuchte

GB / MT Assembly and safety advice Page 34

Warning symbol with explosion effect inside triangle (no text or numbers)

Description of parts......Page 35

Scope of delivery....Page 36

Technical data......Page 36

Safety instructions......Page 37

Product-specific safety instructions ......Page 38

Before assembly

Inserting / replacing rechargeable batteries ......Page 39

Assembly Page 40

Operation Page 41

Care and maintenance......Page 41

Trouble-shooting......Page 42

Disposal Page 42

Outdoor Solar Light

- Introduction

The assembly instructions are part of this product. They contain important information on safety, handling and disposal. Familiarise yourself with all the functions of the appliance before operating it for the first time. To do so, read the following assembly and safety instructions. Always use the device as described and for the stated areas of use only. Keep this manual in a safe place. Make sure that all documents accompany the device if you pass it on to anyone else.

- Proper use

This solar lamp is for outdoor use. Any other use or modification of the product constitute improper use and pose a risk of short circuits, fire, electric shocks and damage to the product. The manufacturer is not liable for damage caused by improper use. The product is not intended for commercial use.

• Description of parts

1 Cover
2 Screw (diameter approx. 4 mm)
3 Back
4 Screw for base
5 Dowel (diameter approx. 5 mm)

6 Nut for the base
7 Lamp
8 Base
9 Nut for the case
10 Solar element
11 Rechargeable battery
12 Battery compartment
13 ON/OFF switch

- Scope of delivery

Always check that the scope of delivery is complete and that the appliance is in perfect condition immediately after unpacking the contents.

1 x Solar-powered lamp
2 x NiMH rechargeable batteries, AA/1.2 V/600 mAh
2 x Screw (diameter approx. 4 mm)
2 x Dowel (diameter approx. 5 mm)
1 x Assembly instructions

- Technical data

Operating voltage: 2.4 Volt

Rechargeable battery: 2 x NiMH rechargeable battery / AA / 1.2 Volt / 600 mAh

Illuminant: 2 Light-emitting diodes (LED Class 1) (not replaceable)

Protection class: III

Protection type: IP44 (splash proof)

Safety instructions

DANGER TO LIFE AND RISK OF ACCIDENTS

FOR INFANTS AND CHILDREN! Keep batteries out of the reach of children. Do not leave the batteries lying around. There is a risk of children or animals swallowing them. Consult a doctor immediately if a battery is swallowed.

WARNING! RISK OF FATAL INJURY! During installation

keep children away from the area in which you are working. The scope of supply includes a number of screws and other small parts. These may prove lifethreating if swallowed or inhaled.

Children or persons who lack the knowledge or experience to use the device or whose physical, sensory or intellectual capacities are limited must never be allowed to use the device without supervision or instruction by a person responsible for their safety. Children must never be allowed to play with the device.
CAUTION! DANGER OF EXPLOSION! Do not operate the lamp in potentially explosive environments in which there are inflam mable vapours, gases ordusts.
■ Never leave children unattended with the packaging material. It can cause suffocation. Children often underestimate dangers. Always keep children away from the product.
This product is not a toy and should be kept out of the reach of children. Children are not aware of the dangers associated with handling electrical products.
- Do not use the article if you detect any kind of damage.

Product-specific safety instructions

■ Make sure that the solar panel is free of dirt and free of snow and ice in winter. Otherwise the performance of the solar panel will diminish.

FIRE HAZARD! Batteries must not be short-circuited. This can cause batteries to overheat, burn or burst.

EXPLOSION HAZARD! Never throw batteries into fire or water.

■ Very old batteries can leak chemical fluids which damage the product. You should therefore remove the battery if you do not need the solar lamp for any length of time.

- Only use the correct size and recommended type of rechargeable batteries (see „Technical Data“).

Before assembly, check the quality of your walls. The dowels are only appropriate for brick walls. If you are aiming to amount the lamp on another wall, please consult a specialist.

DANGER OF ELECTRIC SHOCK! DANGER OF DAMAGE TO PROPERTY! DANGER OF INJURY! Ensure that you do not strike electrical cables, gas or water pipes when you are drilling into the wall. If necessary, check the wall using a suitable detector before you drill.

- Examine the wall before installation and choose suitable installation fixings. We have supplied fixings suitable for an ordinary solid masonry wall.

- Before assembly

The solar panel installed in the article converts sunlight into electrical energy and stores it in a NiMh battery. Switches on the light as it begins to get dark. The in-built light-emitting diodes are a very long-life and energy-saving light source. The light duration depends on the amount of sunlight, the angle of light on the solar panel and the temperature (the battery capacity is temperature-dependent). A vertical angle of light at temperatures above the freezing point is ideal. The battery does not achieve maximum capacity until after several charge and discharge cycles.

- Inserting / replacing rechargeable batteries

☐ Set the ON / OFF switch 13 to "OFF".
□ Screw the nuts 9 anti-clockwise off the cover 1.
☐ Remove the cover 1 and take the solar element 10 carefully out of the lamp 7 (see Fig. B). Make sure that you do not damage the solar element 10 and/or its cable.

NOTE: The solar element 10 is connected to the battery compartment 12.

☐ Insert the rechargeable batteries 11 into the battery compartment 12. Ensure correct polarity. This is indicated in the battery compartment 12.

☐ Insert the solar element 10 back into the lamp 7.

☐ Replace the cover 1 back onto the lamp 7 and fix it in place by tightening the nuts 9 again in a clockwise direction.

- Assembly

☐ Make sure that you mount the product in a place where it is exposed to the sun.

nOtE: You will need a drill for the assembly work.

cAUtIOn! rISK OF InjUrY! Consult the directions for use that came with your drill.

■ cAUtION! WAtEr DAMAGE! Before drilling, ensure that there are no water pipes where you intend to drill.
- Examine the wall before installation and choose suitable installation fixings. We have supplied fixings suitable for an ordinary solid masonry wall.
□ Screw the lamp 7 onto the base 8 (see Fig. A).
□ Screw the nuts 6 anticlockwise off the base 8 (see Fig. C).
☐ Hold the back 3 up against the wall in order to work out the right height for mounting it onto the wall. You may need to use a spirit level to help you.
☐ Mark the boreholes with a pencil.
☐ Use a drill to bore both holes into the wall with the aid of a 6 mm drill.
☐ Place the dowels 5 into the boreholes.
☐ From the back, place the screws 4 into the holes designated for them in the back 3.
☐ Mount the back 3 onto the wall by turning the screws 2 into the dowels 5.
☐ Place the base 8 onto the back 3 in such a way that the screws 4 can also be put through the base.
☐ Screw the nuts 6 onto the screws 4 in order to fix the base 8.

● Operation (see Fig. D)

☐ Set the ON / OFF switch 13 to "ON" in order to switch the lamp 7 on in dark environment.
☐ Set the ON / OFF switch 13 to "OFF" to switch the lamp 7 off.
NOTE: The lamp does not charge in off position.

● Care and maintenance

The light-emitting diodes are non-replaceable.

The solar-powered light is maintenance-free, apart from the need to replace the rechargeable batteries.

☐ Replace the rechargeable battery when the burn time distinctly diminishes after a while despite good incoming solar radiation. Only use rechargeable batteries of the same size and the recommended type (see section on “Technical data”).
☐ Clean the solar-powered light with a dry, lint-free cloth at regular intervals. Use a slightly damp cloth to clean the product if it is more severely soiled.
☐ On no account should you use corrosive detergents.

- Trouble-shooting

NOTE: This appliance has delicate electronic components.

This means that if it is placed near an object that transmits radio signals, it could cause interference. This could be, for example, mobile telephones, walkie talkies, CB radios, remote controls and microwaves. If the display indicates a problem, move such objects away from it.

NOTE: Electrostatic charge can lead to the appliance failing. In cases of the appliance failing to work remove the batteries for a short while and then replace them.

Error Cause Solution
The light will not switch on even though the sun shone on the lamp 7 all day.	Artificial sources of light, e.g. street lighting, are interfering with the lamp 7	Mount the lamp 7 in a place where it cannot be disturbed by other sources of light.
The light does not come on or comes on only briefly.	The rechargeable batteries are broken or there was not enough daylight.	Replace the rechargeable batteries or mount the lamp 7 in a place where it can receive more sunlight.

- Disposal

The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities.

Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.

Faulty or used batteries must be recycled in accordance with Directive 2006 / 66 / EC. Please return the batteries and / or the device to the available collection points.

Batteries should not be disposed of in normal domestic waste!

Return the batteries and / or the device through the special waste collection points available.

Product description:

Outdoor Solar Light

Item No.: Z29544

Version: 09/2009

Einleitung

c/o Milomex Services

Hilltop Cottage

Barton Road

Pulloxhill

Bedfordshire

MK45 5HP

UK

© by ORFGEN Marketing
