Product type	Decorative solar stone LED lamp set (3 units)
Model	IAN 86283 / Article codes 54179, 54181
Brand	Livarno Lux
Power supply	Solar panel + NiMH rechargeable battery (1x per lamp, 1.2V, 600mAh)
Light source	4x LED per lamp (non-replaceable)
Protection class	IPX4 (splash-proof)
Charging time	Approx. 6–8 hours in direct sunlight
Operating time	Approx. 6–8 hours when fully charged
Switching	ON/OFF slide switch; automatic dusk-to-dawn operation via twilight sensor
Installation	Freestanding on ground or similar surface; no external wiring needed
Intended use	Outdoor decorative lighting in private households
Battery replacement	Replaceable with same type (NiMH 1.2V 600mAh); unscrew 4 screws, remove cover, replace battery observing polarity
Maintenance	Clean surface with soft damp cloth; do not submerge in water
Safety warnings	Keep away from children; do not cover solar panel; do not use non-rechargeable batteries; dispose of batteries separately
Warranty	3 years from date of sale
Service contact	EDI Light Service Center, Heiligkreuz 22, A-6136 Pill, Austria; phone [phone]; email [e-mail]

Frequently Asked Questions - IAN 86283 Livarno Lux

How do I turn on the solar lamp?

Locate the ON/OFF switch on the underside of the lamp. Slide it to the ON position. The lamp will then automatically switch on at dusk and off at dawn using the built-in twilight sensor. In the OFF position, the lamp stays off but the battery can still charge during the day.

How do I replace the battery?

Turn the switch to OFF. Loosen the 4 screws on the battery compartment, remove the cover and seal. Take out the old battery and insert a new fully charged NiMH 1.2V 600mAh battery, observing correct polarity (+/-). Ensure the seal is properly fitted to prevent water ingress. Tighten the screws and switch back to ON.

Why is my solar lamp not lighting up at night?

Check if the lamp is placed in a location that receives direct sunlight during the day. Ensure the ON/OFF switch is set to ON. If the battery is drained, allow a full 6–8 hours of sunlight to charge. Also, check that other light sources (street lights, porch lights) are not shining directly on the lamp at night, as this may keep the sensor from activating.

Can I use the solar lamp indoors?

The lamp is designed for outdoor use only. It requires sunlight to charge the battery and has an IPX4 splash-proof rating suitable for damp outdoor environments. Indoor use would not provide sufficient sunlight for charging.

Are the LEDs replaceable?

No, the LEDs are built-in and non-replaceable. If the LEDs fail, the entire lamp unit may need to be replaced. The battery, however, is replaceable.

How long does it take to fully charge the battery?

In direct sunlight, the battery typically takes about 6 to 8 hours to fully charge. Charging time can vary depending on weather conditions and the angle of the sunlight.

What kind of battery does the lamp use?

The lamp uses a NiMH rechargeable battery with a voltage of 1.2V and a capacity of 600mAh. Only replace it with a battery of the same type and specifications.

Can I use non-rechargeable batteries?

No, only rechargeable NiMH batteries are suitable. Using non-rechargeable batteries can be dangerous and may cause damage. The lamp is designed to charge the battery via the solar panel.

How do I clean the solar lamp?

Clean the surface of the lamp with a soft, damp cloth. Do not use abrasive cleaners or immerse the lamp in water. Ensure the battery compartment seal is intact after cleaning to maintain its splash-proof protection.

What should I do if the lamp stops working after a few months?

First, check if the battery needs replacing (see 'How do I replace the battery?'). Also ensure the solar panel is clean and not shaded. If the LEDs are damaged, they cannot be replaced. If the problem persists, contact the service address provided in the manual for warranty or repair options.

USER MANUAL IAN 86283 Livarno Lux

Three metallic circular components with reflective surfaces, displayed on a rough stone surface (no text or symbols visible)

MANUAL DE INSTRUCCIONES Y GARANTÍA

ISTRUZIONI D'USO E GARANZIA

54179, 54181

Congratulations on the purchase of your new lamp.

You have chosen a device of premium quality. The instruction manual is part of this device and contains important safety, usage and disposal instructions for the device.

Be sure to carefully read all safety and usage instructions before operation. Only use the device as described and for the purposes specified.

When giving the device to third parties, make sure that all the relevant documents are handed over together with the device.

English / Decorative solar stone LED lamp 3-unit set

Use, safety guidelines, replacing the battery 15

switching on, malfunctions 16

Normal and safe operation, technical data.... 17

Warranty, service 18

Diagram of a battery inside a casing, showing internal components and battery terminals (no text or labels)

Diagram of a battery inside a casing, showing internal components and wiring (no text or labels)

Diagram of a battery inside a casing, showing internal structure and mounting points (no text or symbols)

Use, safety guidelines, replacing the battery

Using the operating instructions

Read all the instructions in this manual carefully before assembling, mounting or switching on the light and follow them without exception.

Observing all of the guidelines guarantees safe operation and manufacturer's warranty where applicable.

Keep these instructions in a safe place for future reference.

Remember to pass these instructions on to new owners of the lights.

Lamp function

Solar LED lamp

with an ON/OFF switch

IPX4

Important safety information

Intended use

The decorative solar stone LED lamp is suitable for constant use outdoors. It is designed for use in private households and is not suitable for commercial purposes.

Do not use the solar lamp if there is visible damage. The lamp is protected against spray water, but must not be submerged in water. The solar module should not be stuck down, covered or painted.

Do not operate the decorative solar stone LED lamp with normal batteries that are non-rechargeable. Do not take the batteries apart, throw in fires or short circuit.

Danger to children and people with limited capability of using the devices

Children and people with limited capability do not recognise the dangers associated with using electrical devices. Keep away from children and people with limited capability.

Keep packaging and wrapping away from children and people who are of a limited ability to operate devices. Danger of suffocation!

Batteries can be fatal if swallowed. Keep batteries and the product out of the reach of small children. In the event of a battery being swallowed, seek medical assistance immediately.

Replacing the battery

1. The battery is designed to operate for long durations. However, it may be necessary to change the battery in the event of a long period of use. Batteries are subject to natural wear and tear and their performance can decrease.
2. Turn the switch underneath to OFF.
3. Loosen the 4 screws on the battery compartment.
4. Remove the battery compartment cover incl. the seal.
5. Remove the battery and replace it with a new, fully charged battery of the same type (see "Technical specifications"). Make sure the battery is inserted according to the right polarity (+/-). When inserting the battery, make sure that the cables are not wedged in.
6. Correctly place the battery compartment cover and seal back on (Make sure that the seal is properly fitted. This prevents water from entering the battery compartment).
7. Tighten the four screws.
8. Turn the switch back to ON.

Diagram of a battery inside a casing, showing internal components and wiring (no text or labels)

switching on, malfunctions

Observe all of the instructions and warnings. Improper use or incorrect operation can lead to serious physical injury (e.g. from electric shock or burning) and substantial material damage (e.g. from fire).

Storage and transport

Store and transport the lamp only in its original packaging. Protect packaged light from mechanical impact, moisture, frost and dust.

Comes with

3x lamps with solar panel, incl. 4x LED for each lamp

Unpacking

Take all the parts of the lamp out of the box and remove the packaging material. Put all the parts of the lamp on a soft surface in front of you, such as a carpet. Check the parts for any possible visible damage.

Commissioning

1. The decorative solar stone LED lamp can be positioned anywhere as it is not dependent on an external power supply.
   However, since the lamp is dependent on solar energy, please note the following points before positioning:
2. Choose a location where the solar module is exposed to direct sunlight during the day.
3. Avoid choosing a location that is completely or predominantly in the shade (trees, roof ridge etc.).
4. At nighttime, the solar module should not constantly be illuminated by other light sources, e.g. by a beam that illuminates a garage driveway. Please bear in mind that many light sources first switch on in the middle of the night, dependent on time or motion.
5. This lamp has a twilight sensor and an ON/OFF switch. The lamp provides light for approx. 6 to 8 hours when fully charged.
6. Before initial operation, switch the ON/OFF switch on the rear of the lamp to ON and place the LED solar lamp in the sun for.
7. Decorative solar stone LED lamp function:
   ON - The decorative solar stone LED lamp automatically switches on when the area starts to get dark. The lamp automatically switches off when the area starts to get light (If there is sufficient brightness, the battery start to charge)
   OFF - The decorative solar stone LED lamp is permanently off (If there is sufficient brightness, the battery start to charge)

Disposal of packaging

Dispose of the packaging material, sorting it according to type.

Keep packaging and wrapping away from children. Danger of suffocation!

Damage and malfunctions

LEDs do not light:

Environment too light? Check if light from other sources is hitting the solar lamp. If so, change the location of the lamp. (e.g. street lights or lamps which are controlled by time or motions)

Battery fully charged? See "Replacing the battery".

LEDs are damaged: The LEDs cannot be replaced.

The light from the LEDs is dim: Battery is not fully charged or damaged; charge the battery in the battery charger or replace with a new battery.

The power fluctuates depending on the time of year: this is due to the weather and is not a fault. The weather conditions in summer are most favorable and least favorable in winter.

Normal and safe operation, technical data

Normal and safe operation

All the information provided must be adhered to for safe operation and to avoid risking your manufacturer's warranty. Only operate the lamp with the specified battery voltage. The lamp is not a toy. Keep it away from children and people who are of a limited ability to operate devices.

Cleaning

Only clean the surface of the lamp. Use a soft, damp cloth to clean the lamp.

Disposal

Please dispose of the article in the appropriate manner following the current legal regulations. Information on this is available from the local municipal services.

This solar lamp has a NiMH battery. This must be disposed of separately and may not be thrown away with household waste.

Technical data

Article code 54179, 54181

Type

Voltage Battery (1x per lamp)

IP class IPX4

4x LED lights (not replaceable) Bulb:

Technical data Battery Accu NiMH 1,2V 600mAh

Distributor: Edi Light GmbH, Heiligkreuz 22, A-6136 Pill

IP protection class

IPX4

This lamp is suitable for use in damp locations or outdoors.

Declaration of conformity

This product meets the standards of the appropriate European and national guidelines. Corresponding explanations and documents are provided by the manufacturer. The product meets the standards of the German device and product safety law.

In the course of improving products, we reserve the right to make technical and visual alterations.

Subject to error and omissions.

Warranty, service

We provide a 3 year warranty from date of sale

Our products are manufactured in line with the latest methods and undergo precise quality testing. We guarantee the article"s faultless quality. We will remedy any material or manufacturing defects free of charge within the warranty period. Should defects contrary to expectations become apparent, carefully send the packaged article to the service address provided.

Excluded from the warranty are damages based on improper handling, as well as worn parts and consumables. These can be ordered at the owner's expense by calling the number given.

Repairs not included in the warranty (e.g. light bulbs), can also be arranged at cost price at the service address provided. The article will be repaired by the service address provided. Timely handling and return postage can only be carried out if you send it directly to this address.

If you require further information, would like to order accessories or have questions about servicing, please call our customer advice line on the number provided. Please have the article number ready for enquiries (see technical details).

Service address

Malta

ITC Ltd.

Whitehouse Buildings Mountbatten Street

MT- Blata il Bajda

E-Mail: [e-mail]

Telephone: [phone]

Warranty card

Please fill in this section in block capitals and enclose the device.

Sender:

Surname/First name:

State/Postcode/Town/Street:

Telephone number:

Article number/Article description:

Purchase date/Purchase location:

Description of fault:

Date/Signed:

No warranty case presented:

Please send the article back unrepaired against transport costs incurred.

Advise me of the costs. Repair the article at a cost.

Diagram of a battery inside a casing, showing internal components and battery terminals (no text or labels)

EDI Light Service Center

Heiligkreuz 22

A-6136 Pill

E-Mail: [e-mail]

Telefon: [phone]

Garantiekarte
