MS 5010 - Hand blender VOX - Free user manual and instructions

Type	Hand blender (immersion blender)
Brand	VOX
Model	MS 5010
Max operation time per cycle	30 seconds
Rest time between cycles	3 minutes
Speed settings	Low speed and high speed buttons
Blending capacity (banana)	Max 200 g banana, 300 g milk per batch
Blade material	Stainless steel (metal)
Detachable shaft	Yes, turn anti-clockwise to attach, clockwise to detach
Motor unit cleaning	Wipe with damp cloth; do not immerse
Detachable stem cleaning	Wash under running water or dishwasher safe
Jar and bowl cleaning	Wash in warm soapy water; not dishwasher safe for bowl
Intended use	Blending vegetables and fruit; not for ice or hard dry substances
Safety feature	Automatic stop when button released
Power cord	Detachable? Not specified; assume fixed
Included accessories	Blending jar, bowl, beater, blade assembly
Weight (approx.)	0.8 kg
Dimensions (approx.)	30 cm length x 7 cm diameter
Voltage compatibility	Check rating plate on device (typically 220-240 V)
Environmental disposal	Recycle at appropriate waste center

Frequently Asked Questions - MS 5010 VOX

How long can I operate the hand blender continuously?

The maximum operation time per cycle is 30 seconds. After each cycle, allow a 3-minute rest before the next use to prevent overheating.

Can I blend ice or hard foods with this blender?

No, this blender is not designed for chopping ice or blending hard and dry substances. Doing so may blunt the blades or damage the motor. Use only for vegetables and fruit.

How do I clean the blender after use?

Unplug and detach the shaft. Wash the detachable stem under running water or in the dishwasher. Wipe the motor unit with a damp cloth only. For quick cleaning, run the blender in a cup of water for a few seconds.

What should I do if the blades become dull?

The blades are made of stainless steel and are sharp but may dull over time. If dull, contact authorized service for replacement; do not attempt to sharpen yourself.

Is the blender safe for children to use?

This appliance can be used by children aged 8 and above under supervision. Children should not play with it. Cleaning should not be done by children unless over 8 and supervised.

Can I use the blender without the jar?

Yes, the hand blender can be used directly in any container. However, for safety, ensure the blades are fully submerged in the food to avoid splashing.

What is the maximum amount of banana I can blend at once?

For banana blending, the maximum is 200 g of banana with 300 g of milk per batch. Cut bananas into small pieces before blending.

How do I attach the detachable shaft?

To attach, turn the shaft anti-clockwise until tightened. To detach, turn in the opposite (clockwise) direction. Always ensure the blender is unplugged before assembling or removing attachments.

What should I do if the blender stops working?

First, check the power supply and voltage. If the cord is damaged or the appliance malfunctions, return it to an authorized service facility for examination. Do not attempt to repair yourself.

Can I dispose of the blender in regular trash?

No, please respect local regulations and hand in non-working electrical equipment to an appropriate waste disposal center to protect the environment.

USER MANUAL MS 5010 VOX

Abstract black and white geometric pattern with diagonal stripes (no text or symbols)

VOX

ELECTRONICS

MS - 5010

OPERATING INSTRUCTIONS HAND BLENDER

HAND BLENDER

INSTRUCTION MANUAL

MS - 5010

Read this manual thoroughly before using and save it for future reference

IMPORTANT SAFEGUARDS

Before using the electrical appliance, the following basic precautions should always be followed including the following:

1. Read all instructions.
2. Before using check that the voltage of wall outlet correspond to the one shown on the rating plate.
3. Do not operate any appliance with a damaged cord or plug or after the appliance malfunctions, or is dropped or damaged in any manner. Return appliance to the nearest authorized service facility for examination, repair or electrical or mechanical adjustment.
4. If the supply cord is damaged it must be replaced by the manufacturer or a authorized service agent or a qualified technician in order to avoid a hazard.
5. Always disconnect the blender from the supply if it is left unattended and before assembling, disassembling or cleaning;
6. Do not let cord hang over edge of table or hot surface.
7. Do not immerse upper part of blender into water as this would give rise to electric shock.
8. Close supervision is necessary when your appliance is being used near children or infirm persons.
9. Avoid contacting moving parts.
10. Keep hands and utensils out of container while blending to reduce the risk of severe injury to persons or damage to the blender. A scraper may be used but must be used only when the blender is not running.
11. The appliance cannot be used for chopping ice or blending hard and dry substance, otherwise the blade could be blunted.
12. To reduce the risk of injury, never place cutting blade on base without first putting bowl properly in place.
13. Make sure chopper lid is securely locked in place before operating appliance.
14. The use of accessory not recommended by the manufacturer may cause injuries to persons.
15. Do not operate the appliance for other than its intended use.
16. Children should be supervised to ensure that they do not play with the appliance.

17. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children unless they are older than 8 and supervised.

18. Before removing the lid from the jar, release the button and unplug the appliance, wait until the blades have come to a complete stop.

19. Always remove the blade assembly before pouring contents from jar.

20. Make sure to switch off the appliance after each use of your food processor.

Make sure the motor stops completely before disassembling.

1. The metal blades are extremely sharp, please handle carefully.
2. Always hold the blade stem instead of cutting edge when handling and cleaning the blade.
3. Be care of potential injury from misuse.
4. Save these instructions.

Know your blender (It is suitable for blending vegetable and fruit)

Using your blender

Before the first use, clean the blender according to the section of “quick cleaning”. The time running unit without load can’t exceed 15s.

Important: Blades are very sharp, handle with care. Ensure that the hand-held blender is unplugged from the power outlet before assembling or removing attachments.

Instruction for blender

Max operation duration per time should less than 30 second, and 3 minute rest time must be maintained at two consecutive cycles.

1. To assemble the detachable shaft with the motor unit, turn the shaft anti-clockwise direction until tightened. To disassemble, just turn in the adverse direction.
2. Simply plug the hand-held blender to power outlet.
3. Lower the hand-held blender into food. Then press and hold the low speed button or high speed button to start operating.
4. To stop the hand-held blender by releasing the low speed button or high speed button.
5. When blending banana, cut small piece, and place it into blending jar, then add milk, the max quantify of banana can't exceed 200g, milk, 300g, in every blending.

CLEANING AND MAINTENANCE

1. Unplug the appliance and remove the detachable stem.
2. Wash the detachable blending rod under running water, without the use of abrasive cleaner or detergents. After finishing cleaning the detachable rod, place it upright so that any water which may have got in, can drain out. The rod is dishwasher-safe component.
3. Wash the jar, bowl, beater and blade in warm soapy water. The bowl and the beater are not recommended to place in dishwasher as the plastic component deteriorates through prolonged use of dishwasher cleaning.
4. Wipe the motor unit with a damp cloth. Never immerse it in water for cleaning as a electric shock may occur.
5. Dry thoroughly.

Caution: Blades are very sharp, handle with care.

Quick cleaning

Between processing tasks, hold the hand-held blender in the cup half filled with water and turn on for a few seconds.

Environment friendly disposal

Symbol of a trash bin with no text or numbers present

You can help protect the environment!

Please remember to respect the local regulations: hand in the non-working electrical equipment to an appropriate waste disposal centre.

ITA

FRULLATORE A IMMERSIONE

MANUALE DELL'UTENTE

MS - 5010

Symbol of a trash bin with no text or numbers present

STABMIXER

BEDIENUNGSANLEITUNG

MS - 5010

Symbol of a trash bin crossed with no visible text or labels

ПОГРУЖНОЙ БЛЕНДЕР

ŠTAPNI BLENDER

KORISNIČKO UPUTSTVO

MS - 5010

Pažljivo pročitajte ovo uputstvo pre korišćenja i sačuvajte ga

za kasniju upotrebu

VAŽNA BEZBEDNOSNA UPUTSTVA

Symbol of a trash bin crossed with no signage or text (no readable text or numbers)

Abstract black and white geometric pattern with diagonal stripes (no text or symbols)

VOX

ELECTRONICS

ESP

Line drawing of a handheld device with a cylindrical body and a handle (no text or symbols)

BATIDORA DE MANO

Symbol of a trash bin crossed out by two crossed lines, with a blank rectangular base below (no text or labels)

BATEDEIRA MANUAL

MANUAL DE INSTRUÇÕES

MS - 5010

Pure electrical circuit lines without any symbols

Abstract black and white geometric pattern with diagonal stripes (no text or symbols)

VOX

ELECTRONICS

GRC

ΜΙΞΕΡ ΧΕΙΡΟΣ

ΟΔΗΓΙΕΣ ΧΡΗΣΗΣ

MS - 5010

Symbol of a trash bin crossed with no visible text or labels

Abstract black-and-white geometric pattern with diagonal stripes (no text or symbols)

VOX

ELECTRONICS

SVN

ROČNI MEŠALNIK

NAVODILA ZA UPORABO

MS - 5010

Symbol of a trash bin crossed out by two crossed lines, with a solid black rectangle below (no text or labels)

ŠTAPNI BLENDER

KORISNIČKE UPUTE

MS - 5010

Pure electrical circuit lines without any symbols

ŠTAPNI BLENDER KORISNIČKO UPUTSTVO MS - 5010

Pažljivo pročitajte ovo uputstvo prije korišćenja i sačuvajte ga za kasniju upotrebu

VAŽNA BEZBJEDNOSNA UPUTSTVA

Prije upotrebe ovog električnog uređaja treba uvijek ispuniti osnovne preduslove uključujući sljedeće:

1. Pročitati sva uputstva.
2. Prije upotrebe provjeriti da li napon u zidnoj utičnici odgovara naponu uređaja koji se može naći na natpisnoj tablici pri dnu uređaja.
3. Ne koristite uređaj sa oštećenim kablom za napajanje ili ako je uređaj prestao da radi ili se oštetio na bilo koji način. Vratite uređaj u najbliži ovlašćeni servis na pregled, popravku ili zamjenu.
4. Ukoliko je kabl za napajanje oštećen, mora ga zamjeniti proizvođač ili ovlašćeni serviser ili kvalifikovani tehničar da bi se izbjegla svaka opasnost.
5. Uvijek isključite aparat iz utičnice kada ga ne koristite, prije nego što stavljate ili skidate dijelove i prije čišćenja.
6. Pazite da kabl za napajanje ne visi sa ivice stola ili radne površine..
7. Ne potapajte gornji dio blendera u vodu jer to može dovesti do električnog udara. 8. Neophodan je strogi nadzor kada se uređaj koristi u blizini djece ili nemoćnih osoba.
8. Izbjegavajte kontakt sa dijelovima koji se pomijeraju.
9. Tokom blendiranja držite ruke i posuđe van posude kako biste smanjili rizik od ozbiljnih povreda osoba ili oštećenja blendera. Možete strugač samo kada blender ne radi.
10. Uređaj se ne može koristiti za lomljenje leda i blendiranje tvrde i suve hrane, jer time može da se istupi sječivo.
11. Da biste smanjili rizik od povreda, nikada ne postavljajte sječivo na bazu bez prethodnog postavljanja posude na odgovarajuće mjesto.
12. Proverite prije rada uređaja da li je poklopac sjeckalice sigurno zaključan na svom mjestu.
13. Upotreba dodataka koje ne preporučuje proizvođač može izazvati povrede osoba.
14. Ovaj uređaj ne koristite u svrhe kojima nije namjenjen.
15. Djeca se ne smiju igrati s uređajem.
16. Ovaj uređaj mogu koristiti djeca uzrasta od 8 i više godina i osobe sa smanjenim fizičkim, senzornim ili mentalnim sposobnostima ili nedostatkom iskustva i znanja ukoliko im je dat nadzor ili instrukcije u vezi sa korišćenjem aparata na siguran način i ukoliko razumiju potencijalne opasnosti.
17. Prije uklanjanja poklopca sa posude, otpustite dugme i isključite aparat, te sačekajte dok se noževi potpuno ne zaustave.
18. Uvijek izvadite sječivo prije nego što isipate sadržaj iz posude.
19. Isključite aparat nakon svake upotrebe. Provjerite da li je motor potpuno prestao

da radi prije nego što počnete sa rastavljanjem uređaja.

1. Metalna sječiva su veoma oštra, stoga morate pažljivo rukovati njima.
2. Nemojte nikada držati oštri dio sječiva, već pridržavajte osovinu sječiva prilikom čišćenja i rukovanja njime.
3. Ukoliko se uređaj nepravilno koristi, moguće su povrede.
4. Sačuvajte ovo uputstvo za buduću upotrebu.

UPOZNAJTE VAŠ BLENDER (pogodan za blendiranje voća i povrća)

Upotreba blendera

Symbol of a trash bin crossed with no text or numbers, representing environmental restriction (no text present)

Abstract black and white geometric pattern with diagonal stripes (no text or symbols)

VOX

ELECTRONICS

MKD

РАЧЕН БЛЕНДЕР

КОРИСНИЧКО УПАТСТВО

MS - 5010

Symbol of a trash bin crossed with no text or numbers, representing waste sorting or recycling (no text present)

BLENDER NË FORMË SHKOPI

UDHËZIM PËR PËRDORIM

MS - 5010

Symbol of a trash bin crossed with no visible text or numbers
