IAN 270087 - Uncategorized ULTIMATE SPEED - Free user manual and instructions

Product Type	Car Seat Cover Set
Brand	Ultimate Speed
Model	IAN 270087
Intended Use	For driver's seat, passenger's seat, and back seats of cars (according to enclosed type list)
Scope of Delivery	2 front seat covers (1 or 2 parts), 5 headrest covers, 1 rear backrest cover, 1 back seat cover, metal hooks, type list
Safety Certification	TÜV tested
Side Airbag Compatibility	Yes, with marked "airbag" label on outer side
Installation Tools Required	Pointed scissors
Care Instructions	Hand wash; do not bleach; do not tumble dry; do not iron; do not dry clean
Disposal	Household waste; packaging according to local regulations
Guarantee	3 years from date of purchase
Service Contact	Walser Customer Service Germany (Walser GmbH)
Compatibility	Fits car models listed on packaging or enclosed type list
Material	Polyester blend (typical for such covers, not explicitly stated)
Number of Pieces	Up to 9 pieces (depending on design)

Frequently Asked Questions - IAN 270087 ULTIMATE SPEED

Are these car seat covers compatible with side airbags?

Yes, the covers are designed with an airbag label that must be positioned on the outer side of the backrest (door side) for proper deployment. Incorrect installation can impede airbag function.

How do I install the front seat covers?

Remove headrests, pull cover down over backrest, ensure side airbag label is outward, pull strap between seat and backrest, close fastener, cover seat front to back, and fasten metal hooks to rubber loops under the seat. Refer to the manual figures 1-10 for detailed steps.

Can I wash these seat covers in a washing machine?

No, the covers must be washed by hand only. Do not use bleach, tumble dry, iron, or dry clean. Follow the care instructions to avoid damage.

What is the warranty period for Ultimate Speed IAN 270087?

The product comes with a 3-year guarantee from the date of purchase. Keep the till receipt as proof of purchase.

Do I need to cut holes for armrests or seat adjustments?

Yes, openings for backrest releases, adjustment levers, side levers, and armrests must be cut out using pointed scissors. Ensure cuts are not too large to maintain a snug fit.

Are the covers suitable for all car models?

They fit only cars listed on the packaging or included type list. Check the list before purchase to ensure compatibility.

How do I install the rear seat covers?

Tilt back seat forward if needed, pull cover towards back, fasten rubber loops to metal hooks, cut openings for seat belts, and use triple zip fasteners to adjust width. See manual figures 27-45.

Can I install the covers without removing the headrests?

No, headrests must be removed before installation. Some car models may require professional disassembly.

What should I do if the cover is displaced after installation?

Reposition the cover immediately. If excessive wear prevents repositioning, remove or replace the cover to maintain safety and fit.

Where can I get service or support?

Contact Walser Customer Service Germany (Walser GmbH) via the service hotline or service point provided in the manual.

USER MANUAL IAN 270087 ULTIMATE SPEED

Interior view of a car seat with patterned backrests and side panels, no visible text or symbols on the main subjects.

CAR SEAT COVER SET

GB

CAR SEAT COVER SET

Assembly and safety advice

HU

AUTÓS ÜLÉSHUZAT

Before reading, unfold both pages containing illustrations and familiarise yourself with all functions of the product.

PL

GB Assembly and safety advice Page 5

PL	Wsk	azówki dotyczące montażu oraz bezpieczeństwa	Strona	7
HU	Szerelési- és biztonsági utasítások	Oldal 9
SI	Navodila za montażo in varnost	Stran 11
CZ	Pokyny k montáži a bezpečnostní pokyny		Strana	13
SK	Pokyny pre montáž a bezpečnosť		Strana	15
DE/AT/CH	Montage- und Sicherheitshinweise		Seite	17

Car seat cover set

- Introduction

We congratulate you on your purchase. You have chosen a high quality product. The instructions for use are to be considered as part of this product. Before using the product, please familiarise yourself with all the safety information and instructions for use. Only use the product as instructed and only for the stated areas of use. If you pass the product on to anyone else, please ensure that you also pass on all the documentation with it.

- Intended use

Set of car seat covers for the driver's seat, passenger's seat and the back seats of cars (according to the enclosed type list).

- Scope of delivery

Illustration of an airplane seat with an Airbag on top (no text or symbols on the diagram itself)

2 x covers for front seats (in 1 or 2 - 5 x covers for headrests

2 parts according to design) (according to design)

Illustration of a dark gray rectangular object with vertical ridges, resembling a stylized battery or panel (no text or symbols)

1 x cover for rear backrest (in 1 1 x cover for back seat (not sepa to 5 parts according to design) rable)

Metal hooks (located in the List of types headrest covers)

● Safety instructions

Correct installation res. fastening of the seat covers to the vehicle is essential to guarantee the safety of the user. Please pay attention to the following information when installing the seat covers:

■

WARNING! DANGER OF SUFFOCATION! Keep

the packaging out of reach of small children.

■ Installation is permissible only in cars that are indicated in the list of types on the packaging or in the enclosed, detailed list of types.

- Correct assignment of the seat (driver and front passenger seat). The covers are assigned by the marking "airbag" attached to the seat cover. This marking must be attached to the outer side of the backrest (see fig. 1.0).

Two gray car seats with one seat labeled 'AIRBAG' on the backrest (no other text or symbols)

Fig. 1.0

Headrest inserts, adjustment levers / wheels for release of backrests or armrests may not be covered with the seat cover. Allowances must be made for appropriate inserts. Please observe the instructions given in section "Installation".
Displaced seat covers must be repositioned. If this is no longer possible due to a advanced state of wear and tear, the cover must be removed or replaced.
■ Manipulation of the opening of the seat covers is not permissible (no covering, sewing up or repairs by yourself).

This protective cover has been tested by TÜV Rhineland Group.

⚠️ CAUTION! If the seat covers are installed incorrectly, the proper extension and inflation of the seat air bag cannot be guaranteed in the case of a collision.

- Installation

■ You need a pair of pointed scissors.

● Installation of seat covers

Important: Please read the information below before installing the seat covers!

Fig. 1: Remove headrests (in some car models the headrests must be dismantled in a garage).
Fig. 2: Cover the backrest by pulling the cover downwards.
Fig. 3: Pay attention to the correct assignment of the side airbag label (right / left seat)! The side airbag label must be located at the outside (door side) of the respective seat.
Fig. 4: Pull the strap through between the seat and the backrest.
Fig. 5: Then close the fastener.
Fig. 6: Cover the seat from the front to the back.
Fig. 7: Fasten the metal hooks to the rubber loops.
Fig. 8+9: Pull the rear rubber loops between the seat and backrest (as you did with the strap of the backrest cover). Fasten the metal hooks under the seat according to the car model (e.g. to the existing metal rods - ATTENTION Do not fasten to airbag cables!)
Fig. 10: Or fasten all rubber loops together.

ATTENTION!

Openings for backrest releases, adjustment levers, side levers etc. (as described under fig. 11-21) must be cut out.

If your seat is equipped with armrests, proceed as described under fig. 11. Otherwise go to fig. 15.

Fig. 11: Pull the cover down as far as the armrest. The cover must be tightly fitting on top.

Fig 12: Cut the cover in the position of the armrest. The cut-out may not be too large.

Fig. 13: Push up the armrest and pull it through the cut-out opening of the cover.

Fig. 14: Pull the strap through between the seat and the backrest and close with the fastener.

If your seat is equipped with side levers, proceed as described under fig. 15. Otherwise go to fig. 19.

Fig. 15: Cover the seat as described under section 2. The cover must be tightly fitting on top.

Fig. 16: Cut the cover in the position of the side lever. The cut-out may not be too large.

Fig. 17+18: With the aid of scissors, push the cover under the guide fitting.

If your seat is equipped with seat frame cladding, proceed as described under fig. 19. Otherwise go to fig. 22.

Fig. 19: (for Renault) Open the seat frame cladding under the seat.

Fig. 20: (for Mercedes) Open the seat frame cladding under the seat.

Fig. 21: Fold the seat frame cladding under the seat cover. Pull the strap through between the seat and the backrest. Then close the fastener at the back.

Fig. 22: Cover the headrests.

Fig. 23+24: Position the mounting strip directly above the holes for insertion of the headrest. Cut open the mounting strip in the exact positions of the headrest holes. With the aid of the integrated mounting strip, it is not possible for the material to tear.

Fig. 25+26: Push the cover beneath the plastic of the headrest guide covering. In a few isolated car models, it could be the case that these models have no headrest guide covering.

Fig. 27+28: Pull the cover for the back seat towards the back of the seat. If necessary, tilt the back seat forward and fasten the rubber loops at the back to the metal hooks (according to the car model).

Fig. 29: Position the cover exactly in the location of the seat belt.

Fig. 30: Carefully cut the cover in the position of the seat belt.

Fig. 31: Push the cover under the seat belt holder.

Fig. 32: Pull the cover under the backrest. The cover must be under the seat belt!

Fig. 33: Cut the cover in the position of the belt guide.

Fig. 34+35: Push the cover beneath the plastic of the belt guide.

Fig. 36: The backrest cover is universally suitable for all back seats due to the triple zip fastener division. The zip-in part can be used according to the width of the rear backrest.

Fig. 37: Fasten the rubber loops at the back to the metal hooks.

If your your back seat is equipped with armrests, proceed as described under fig. 38. Otherwise go to fig. 40.

Fig. 38: Open the zip fasteners. Fold out the armrest. Close the zip fastener up to the armrest.

Fig. 39: Complete covered armrest.

Fig. 40: In case of divided back seats, open the variable zip fasteners with the slider facing upwards if necessary.

Fig. 41: Remove the rear headrests.

Fig. 42: Cover the rear headrests.

Fig. 43: Cut the backrest cover in the position of the headrest in an x-shaped form.

Fig. 44+45: Push the cover under the plastic.

● Instructions for care and disposal

■ Wash the covers by hand

- Do not use bleach

■ Do not dry in a tumbler

Do not iron

Do not dry clean

■ The seat covers can be disposed of in the household waste.
- Please dispose of the packaging in accordance with the local regulations.

● Service & guarantee

You will receive a 3-year guarantee on this product from the date of purchase. The product has been carefully produced and conscientiously tested before delivery.

Please retain the till receipt as proof of purchase.

Please use the service hotline set up for you or contact the service point.

Service address:

Walser Customer Service Germany

Walser GmbH
