IAN 86214 - Uncategorized ULTIMATE SPEED - Free user manual and instructions

Product Type	Car Seat Cover Set
Brand	Ultimate Speed
Model	IAN 86214
Material	Velour (fabric)
Compatible Vehicles	According to enclosed type list; see packaging
Set Includes	2 front seat covers, 5 headrest covers, 1 rear backrest cover (1-5 parts), 1 back seat cover, metal hooks
Side Airbag Compatible	Yes, with designated label on outer side
Safety Certification	TÜV Rhineland Group tested
Installation Required Tools	Pointed scissors
Washing Method	Hand wash only
Bleach	Do not use bleach
Tumble Drying	Do not tumble dry
Ironing	Do not iron
Dry Cleaning	Do not dry clean
Disposal	Household waste permitted; packaging per local regulations
Warranty/Service	Contact manufacturer via Walser Customer Service Germany first
User Repairability	No; manipulation of cover opening not allowed
Intended Use	Driver, passenger, and rear seats (per vehicle type list)

Frequently Asked Questions - IAN 86214 ULTIMATE SPEED

How do I ensure the side airbag functions correctly with these seat covers?

The cover has a side airbag label that must be positioned on the outer side of the backrest (door side). Incorrect installation can prevent proper airbag deployment.

Can I wash the seat covers in a washing machine?

No, the covers must be hand washed only. Do not use bleach, tumble drying, ironing, or dry cleaning.

How do I cut openings for armrests or side levers?

Use pointed scissors to cut a small opening at the exact position of the armrest or lever. The cut-out should not be too large to ensure a snug fit.

Are these covers compatible with all car models?

No, only for cars listed in the enclosed type list. Check the packaging or list before installation.

What should I do if the seat covers become displaced over time?

Reposition the covers immediately. If wear prevents proper fitting, remove or replace the covers.

How do I install the rear seat covers?

Fit the rear backrest cover from the back, cut openings for seat belts and belt guides, and fasten rubber loops to metal hooks. For split rear seats, use the triple zip fastener to adjust width.

Can I cover the headrests?

Yes, remove headrests, cover them separately, then reinstall. Cut an x-shaped opening in the backrest cover for the headrest posts and push under plastic guides.

Is it safe to attach metal hooks to any part under the seat?

No, do not fasten to airbag cables. Only attach to existing metal rods or designated points per car model.

How do I handle seats with seat frame cladding (e.g., Renault or Mercedes)?

Open the cladding under the seat, fold it under the cover, then pull straps through between seat and backrest and close fasteners.

What if my car has integrated seat belts?

The cover is designed to be placed under the seat belt holder. Cut carefully at the belt position and push the cover under the belt guide plastic.

USER MANUAL IAN 86214 ULTIMATE SPEED

Black car seat with gray trim and seat covers, displayed in a studio setting (no text or symbols on the seats)

"VELOURS" CAR SEAT COVER SET

GB

„VELOURS“ CAR SEAT COVER SET

Assembly and safety advice

IT CH

AUTÓS ÜLÉSHUZAT "VELOURS"

Before reading, unfold both pages containing illustrations and familiarise yourself with all functions of the product.

PL

GB Assembly and safety advice Page 5

PL	Wskazówki dotyczące montażu oraz bezpieczeństwa	Strona	7
HU	Szerelési- és biztonsági utasítások	Oldal	9
SI	Navodila za montażo in varnost	Stran	11
CZ	Pokyny k montáži a bezpečnostní pokyny	Strana	13
SK	Pokyny pre montáž a bezpečnosť		Strana 15
DE/AT/CH	Montage- und Sicherheitshinweise		Seite 17

Car seat cover set

- Introduction

We congratulate you on your purchase. You have chosen a high quality product. The instructions for use are to be considered as part of this product. Before using the product, please familiarise yourself with all the safety information and instructions for use. Only use the product as instructed and only for the stated areas of use. If you pass the product on to anyone else, please ensure that you also pass on all the documentation with it.

- Intended use

Set of car seat covers for the driver's seat, passenger's seat and the back seats of cars (according to the enclosed type list).

- Scope of delivery

Illustration of an airplane seat with an Airbag on top (no text or symbols on the diagram itself)

2 x covers for front seats (in 1 or 2 - 5 x covers for headrests

2 parts according to design) (according to design)

Illustration of a dark gray rectangular object with vertical ridges, resembling a battery or panel (no text or symbols)

1 x cover for rear backrest (in 1 1 x cover for back seat (not sepa to 5 parts according to design) rable)

Metal hooks (located in the List of types headrest covers)

● Safety instructions

Correct installation res. fastening of the seat covers to the vehicle is essential to guarantee the safety of the user. Please pay attention to the following information when installing the seat covers:

■

WARNING! DANGER OF SUFFOCATION! Keep

the packaging out of reach of small children.

■ Installation is permissible only in cars that are indicated in the list of types on the packaging or in the enclosed, detailed list of types.

- Correct assignment of the seat (driver and front passenger seat). The covers are assigned by the marking "airbag" attached to the seat cover. This marking must be attached to the outer side of the backrest (see fig. 1.0).

Illustration of two gray car seats with dashed outlines and a circular label on the seat (no text or symbols on the seats)

Fig. 1.0

Headrest inserts, adjustment levers / wheels for release of backrests or armrests may not be covered with the seat cover. Allowances must be made for appropriate inserts. Please observe the instructions given in section "Installation".
Displaced seat covers must be repositioned. If this is no longer possible due to a advanced state of wear and tear, the cover must be removed or replaced.
■ Manipulation of the opening of the seat covers is not permissible (no covering, sewing up or repairs by yourself).

This protective cover has been tested by TÜV Rhineland Group.

⚠️ CAUTION! If the seat covers are installed incorrectly, the proper extension and inflation of the seat air bag cannot be guaranteed in the case of a collision.

- Installation

■ You need a pair of pointed scissors.

● Installation of seat covers

Important: Please read the information below before installing the seat covers!

Fig. 1: Remove headrests (in some car models the headrests must be dismantled in a garage).
Fig. 2: Cover the backrest by pulling the cover downwards.
Fig. 3: Pay attention to the correct assignment of the side airbag label (right / left seat)! The side airbag label must be located at the outside (door side) of the respective seat.
Fig. 4: Pull the strap through between the seat and the backrest.
Fig. 5: Then close the fastener.
Fig. 6: Cover the seat from the front to the back.
Fig. 7: Fasten the metal hooks to the rubber loops.
Fig. 8+9: Pull the rear rubber loops between the seat and backrest (as you did with the strap of the backrest cover). Fasten the metal hooks under the seat according to the car model (e.g. to the existing metal rods - ATTENTION Do not fasten to airbag cables!)
Fig. 10: Or fasten all rubber loops together.

ATTENTION!

Openings for backrest releases, adjustment levers, side levers etc. (as described under fig. 11-21) must be cut out.

If your seat is equipped with armrests, proceed as described under fig. 11. Otherwise go to fig. 15.

Fig. 11: Pull the cover down as far as the armrest. The cover must be tightly fitting on top.

Fig 12: Cut the cover in the position of the armrest. The cut-out may not be too large.

Fig. 13: Push up the armrest and pull it through the cut-out opening of the cover.

Fig. 14: Pull the strap through between the seat and the backrest and close with the fastener.

If your seat is equipped with side levers, proceed as described under fig. 15. Otherwise go to fig. 19.

Fig. 15: Cover the seat as described under section 2. The cover must be tightly fitting on top.

Fig. 16: Cut the cover in the position of the side lever. The cut-out may not be too large.

Fig. 17+18: With the aid of scissors, push the cover under the guide fitting.

If your seat is equipped with seat frame cladding, proceed as described under fig. 19. Otherwise go to fig. 22.

Fig. 19: (for Renault) Open the seat frame cladding under the seat.

Fig. 20: (for Mercedes) Open the seat frame cladding under the seat.

Fig. 21: Fold the seat frame cladding under the seat cover. Pull the strap through between the seat and the backrest. Then close the fastener at the back.

Fig. 22: Cover the headrests.

Fig. 23+24: Position the mounting strip directly above the holes for insertion of the headrest. Cut open the mounting strip in the exact positions of the headrest holes. With the aid of the integrated mounting strip, it is not possible for the material to tear.

Fig. 25+26: Push the cover beneath the plastic of the headrest guide covering. In a few isolated car models, it could be the case that these models have no headrest guide covering.

Fig. 27+28: Pull the cover for the back seat towards the back of the seat. If necessary, tilt the back seat forward and fasten the rubber loops at the back to the metal hooks (according to the car model).

Fig. 29: Position the cover exactly in the location of the seat belt.

Fig. 30: Carefully cut the cover in the position of the seat belt.

Fig. 31: Push the cover under the seat belt holder.

Fig. 32: Pull the cover under the backrest. The cover must be under the seat belt!

Fig. 33: Cut the cover in the position of the belt guide.

Fig. 34+35: Push the cover beneath the plastic of the belt guide.

Fig. 36: The backrest cover is universally suitable for all back seats due to the triple zip fastener division. The zip-in part can be used according to the width of the rear backrest.

Fig. 37: Fasten the rubber loops at the back to the metal hooks.

If your your back seat is equipped with armrests, proceed as described under fig. 38. Otherwise go to fig. 40.

Fig. 38: Open the zip fasteners. Fold out the armrest. Close the zip fastener up to the armrest.

Fig. 39: Complete covered armrest.

Fig. 40: In case of divided back seats, open the variable zip fasteners with the slider facing upwards if necessary.

Fig. 41: Remove the rear headrests.

Fig. 42: Cover the rear headrests.

Fig. 43: Cut the backrest cover in the position of the headrest in an x-shaped form.

Fig. 44+45: Push the cover under the plastic.

● Instructions for care and disposal

■ Wash the covers by hand

- Do not use bleach

■ Do not dry in a tumbler

Do not iron

■ Do not dry clean

■ The seat covers can be disposed of in the household waste.

- Please dispose of the packaging in accordance with the local regulations.

- Service

Please contact our Service Hotline in the first instance, before you return the seat covers to the manufacturer.

Service address:

Walser Customer Service Germany

Walser GmbH

Illustration of an airbag mounted on a chair (no text or symbols)

Illustration of two car seats with side-mounted airbags (no text or symbols)

Rys. 1.0

Walser Customer Service Germany

Walser GmbH

Illustration of a car seat with an airbag labeled 'AIRBAG' on the lid (no other text or symbols)

Illustration of two gray car seats with side-mounted airbags (no text or symbols)

1.0 ábra

Illustration of a car seat with an airbag labeled on the lid (no additional text or symbols)

Simple illustration of a rectangular object with vertical bars, no text or symbols present.

Illustration of two gray car seats with side panels and a circular button labeled 'AIR BING' (no text or symbols on the seats themselves)

Slika 1.0

Walser Customer Service Germany

Walser GmbH

Illustration of a gray airbag device with a circular label (no text or symbols on the device itself)

Simple illustration of a dark rectangular object with vertical ridges, resembling a stylized battery or panel (no text or symbols)

Illustration of two gray car seats with side panels, one bearing a white circular object labeled 'AIRBING' (no other text or symbols)

Obr. 1.0

Walser Customer Service Germany

Walser GmbH

Illustration of an airplane seat with a circular label labeled 'AIRBAG' on the lid (no other text or symbols)

Illustration of a rectangular object with vertical slats, resembling a battery or panel (no text or symbols)

Illustration of two car seats with visible seatbelt and airbag placement (no text or symbols)

Obr. 1.0

Walser Customer Service Germany

Walser GmbH

Illustration of an airplane seat with an Airbag on top (no text or symbols on the diagram itself)

Illustration of a dark rectangular object with vertical ridges, resembling a battery or panel (no text or symbols)

Illustration of two gray car seats with side panels and a white circular label on the seat (no text or symbols on the seats)

Abb. 1.0

Walser Customer Service Germany

Walser GmbH
