USER MANUAL PW 1027 Orbegozo

Exterior view of a modern office air conditioner fan with visible blades and mounting base (no text or symbols on the fan itself)

PW 1019 - PW 1020 - PW 1021

Sonifer,S.A.

Read this manual carefully before running this appliance and save it for reference in order to obtain the best results and ensure safe use.

Exploded diagram of a mechanical device with numbered parts for identification

ALMACENAMIENTO DEL VENTILADOR

1. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children must never play with the appliance. Cleaning and user maintenance must never be carried out by children without supervision.

2. Children should be supervised to ensure that they do not play with the appliance.

3. Keep the appliance and the cable cord out of the reach of children less than 8 years old.
4. WARNING: In order to ensure your children's safety, please keep all packaging (plastic bags, boxes, polystyrene etc.) out of their reach.
5. If the supply cord is damaged it must be repaired by the Authorized Service Agent to avoid a hazard.

6. Never pull on the cord when unplugging.

7. Do not use the unit with a damaged cord or plug, or if it is not working properly.

8. Do not handle the appliance with wet hands.
9. Never immerse the appliance in water or any other liquid.
10. Make sure the appliance has been unplugged before cleaning.
11. This appliance must be installed following the national regulations for electrical installations.
12. This appliance is for household use only.
13. In case that you need a copy of the instruction manual, you can ask for it writing an email to [e-mail]
14. WARNING: In case of misuse, there is a risk of possible injury.

Specific safeguards

• Never insert fingers, pencils or any other object through the grille when fan is running.
• Disconnect the plug when moving from one location to another.
• Disconnect plug when removing grilles for cleaning.

- Be sure fan is on a stable, even surface when operating to avoid overturning.

- DO NOT use fan in window. Rain may create an electrical hazard. Do not leave the fan operating adjacent to an area where water has been collected to avoid the potential of electrical hazard.

- The appliance is designed exclusively for private use and for the envisaged purpose. This appliance is not for commercial use. Do not use it outdoors (except if it is designed to be used outdoors). Keep it away from sources of heat, direct sunlight, humidity (never dip it into any liquid) and sharp edges. Do not use the appliance with wet hands. If the appliance is humid or wet, unplug it immediately.

• To protect children from the dangers posed by electrical appliances, make sure that the cable is hanging low and that children do not have access to the appliance.

- Check the appliance and the cable for damage on a regular basis. Do not use the appliance if it is damaged.

- Do not try to repair the appliance on your own. Always contact an authorized technician. To avoid the

exposure to danger, always have a faulty cable be replaced only by the manufacturer or by our customer service.

• Use only original spare parts.

ASSEMBLY INSTRUCTIONS

Carefully unpack the contents of this carton.

OPERATING INSTRUCTIONS

1. Set the fan base on a dry, level surface.

2. Please make sure the ON/Speed knob is in the off position. Plug cord into any standard AC outlet connected to the AC adapter) or USB port (using USB port).

ILLUSTRATION

1. Screw

2. Rubber feet

3. Upper grill

4. Front Grill

5. Base

6. Cord

7. Blades

8. Motor

9. Interruptor

Labeled diagram of a mechanical device with numbered parts for identification

FAN STORAGE

We recommend to protect your fan from dust during the off-season stored in the original (or an appropriately sized) box.

CLEANING AND MAINTENANCE

Follow these instructions to correctly amd safely care for you power fan.Please remember :

-Always unplug the fan before cleaning or disassembling.
- Do not allow water to drip on or into the fan motor housing.
- Do not use any of the following as a cleaner: gasoline, thinner, or benzine.

Disposal of old electrical appliances.

The European directive 2002/96/EC on Waste Electrical and Electronic Equipment (WEEE), requires that old household electrical appliances must not be disposed of in the normal unsorted municipal waste stream. Old appliances must be collected separately in order to optimize the recovery and recycling of the materials they contain, and reduce the impact on human health and the environment.

The crossed out "wheeled bin" symbol on the product reminds you of your obligation, that when you dispose of the appliance, it must be separately collected.

Consumers should contact their local authority or retailer for information concerning the correct disposal of their old appliance.

DECLARATION OF CONFORMITY: This device complies with the requirements of the Low Voltage Directive 2006/95/EC and the requirements of the EMC directive 2004/108/EC.

ENTRETIEN ET MAINTENANCE

Technical diagram of a mechanical device with numbered parts for identification

RANGEMENT DU VENTILATEUR

Diagram of a mechanical device with numbered parts, showing exploded view and assembly structure
