USER MANUAL SKMR 1000 A1 SILVERCREST

Labeled diagram of a coffee maker with numbered parts for identification

Inhalt

1. Overview 14
2. Intended purpose 15
3. Safety information 15
4. Items supplied 18
5. Before using for the first time 18
6. How to use 18
7. Operation 18

7.1 Drip stopper.... 18
7.2 Filling volumes.... 18
7.3 Brewing coffee 18

1. Cleaning 19

8.1 After every use 19
8.2 Descaling.... 20

1. Storage 20

2. Disposal 21

3. Trouble-shooting 21
4. Technical specifications 22
5. Warranty of the HOYER Handel GmbH 22

1. Overview

1 Cover handle
2 Cover
3 Water level indicator

10 MAX: maximum approx. 10 cups

4 Water tank
5 Power cable with mains plug
6 On/off button
7 Hot plate
8 Coffee spoon
9 Pot

10 Lid of the pot
11 Anti-drip valve
12 Filter holder
13 Handle of the filter holder
14 Permanent filter
15 Handle of the permanent filter

Thank you for your trust!

Congratulations on the purchase of your new coffee machine.

For safe handling of the device and in order to get to know the entire range of features:

• Read these operating instructions thoroughly prior to initial use.
• Above all, observe the safety information!
• The device should only be used as described in these operating instructions.
• Keep this copy of the operating instructions for reference.
• If you pass the device on to someone else, please include this copy of the operating instructions. The operating instructions are a part of the product.

We hope you enjoy using your new coffee machine!

NOTE: the device is supplied in different colours. The operation is identical for all colour variants.

Symbols on the device

	The food-safe material of devices with this symbol will not change the taste or smell of food.
	This symbol warns you against touching the hot surface.

2. Intended purpose

The coffee machine is intended only for the production of filter coffee.

The device is designed for private, domestic use. The device must only be used indoors. This device must not be used for commercial purposes.

Foreseeable misuse

WARNING! Risk of material damage!

- Never put fluids other than fresh drinking water into the water tank 4!

3. Safety information

Warnings

If necessary, the following warnings are used in these operating instructions:

DANGER! High risk: failure to observe this warning may result in injury to life and limb.

WARNING! Moderate risk: failure to observe this warning may result in injury or serious material damage.

CAUTION: low risk: ignoring this warning may result in minor injuries or damage to property.

NOTE: circumstances and specifics that must be observed when handling the device.

Instructions for safe operation

• This device can be used by children from the age of 8 and people with restricted physical, sensory or intellectual abilities or a lack of experience or knowledge if they are supervised or have been instructed in how to use this device safely and if they have understood the resulting dangers.
• Children must not play with the device.
• Cleaning and user maintenance must not be carried out by children unless they are 8 years or older and supervised.
• Children under the age of 8 must be kept away from the device and the power cable.
• The device must be disconnected from the mains if left unattended and prior to assembly, disassembly or cleaning.
• This device is also intended for use in households and similar applications, such as ...

... in kitchens for staff in shops, offices and other commercial settings;

... on agricultural properties;

... by customers in hotels, motels and other residential facilities; ... in bed-and-breakfast establishments.

• This device is not intended to be operated using an external timer or a separate remote control system.
• The coffee machine, the power cable and the mains plug must not be immersed in water or other liquids.
• If the power cable of this device should become damaged, it must be replaced by the manufacturer, the manufacturer's customer service department or a similarly qualified specialist in order to avoid any hazards.
• Remember that the surface of the hot plate remains hot after use.
• Please take note of the chapter on cleaning (see "Cleaning" on page 19).
• Misuse may result in injuries.
• Make sure that no liquid overflows onto the device plug connection.
• The device must not be placed in a cupboard when in use.

DANGER for children!

- Packing materials are not children's toys. Children should not be allowed to play with the plastic bags: there is a danger of suffocation.

DANGER to and from pets and livestock!

Electrical devices can represent a danger to pets and livestock. In addition, animals can also cause damage to the device. For this reason you should keep animals away from electrical devices at all times.

DANGER! Risk of electric shock due to moisture!

• Protect the device from moisture, water drops and water splashes: failure to observe this instruction may result in an electric shock hazard.
• Fill the water tank at most up to the 10 MAX marking.
• If liquids get into the device, remove the mains plug immediately. Only then is it safe to remove the device. Have the device checked before reusing.

DANGER! Risk of electric shock!

• Do not use the device if the device or the power cable has any visible damage, or if the device has previously been dropped.
• Only connect the mains plug to a properly installed and easily accessible wall socket with earthing contact whose voltage corresponds to the specifications on the rating plate. The wall socket must still be easily accessible after the device is plugged in.

• Ensure that the power cable cannot be damaged by sharp edges or hot spots. Do not wrap the power cable around the device.

• The device is not fully disconnected from the power supply, even after it is switched off. In order to fully disconnect it, pull out the mains plug.

• When using the device, ensure that the power cable cannot be trapped or crushed.
• When removing the mains plug from the wall socket, always pull on the plug and never the cable.
• Pull the mains plug out of the wall socket:
• when a malfunction occurs
• when you are not using the coffee machine
• prior to cleaning the coffee machine
• during thunderstorms
• In order to avoid any hazards, do not make modifications to the device.

DANGER! Risk of injury through scalding!

- During the brewing process, hot steam escapes upwards through the cover. The cover becomes hot. Never touch it or put your hands or other body parts in the steam.

WARNING! Risk of material damage!

The device is fitted with non-slip plastic feet. As furniture is coated with a variety of different varnishes and acrylics, and treated with different cleaning agents, it cannot be completely ruled out that components are contained in some of these substances that could damage and soften the plastic feet. If necessary, place a non-slip mat under the device.
- Never put fluids other than fresh drinking water into the coffee machine!
- Place the device on a stable, level surface.
- Do not use any astringent or abrasive cleaning agents.

4. Items supplied

1 coffee machine
1 pot 9
1 filter holder 12
1 permanent filter 14
1 coffee spoon 8
1 copy of the operating instructions (online)
1 copy of the short manual (included)

5. Before using for the first time

• Remove all packing material.
• Check to ensure that all parts are present and undamaged.
• Clean the device prior to its first use! (see "Cleaning" on page 19)

6. How to use

DANGER! Risk of electric shock!

- Only connect the device to an easily accessible wall socket with earthing contacts whose voltage corresponds to the specifications on the rating plate. The wall socket must still be easily accessible after connection.

1. Place the device on a dry, level, non-slip surface.
2. Fill the water tank 4 of the coffee machine up to the 8 marking with fresh, cold tap water, and then start the brewing process by pressing the button ⏻6.
3. Pour away the water and repeat this process once.
4. Wait until the coffee machine has cooled down. Then it is safe to use the device again.

7. Operation

DANGER! Risk of injury through scalding!

- During the brewing process, hot steam escapes upwards through the cover 2. The cover becomes hot. Never touch it or put your hands or other body parts in the steam.

WARNING! Risk of material damage!

• Only fill the coffee machine up to the maximum filling level (10 MAX).
• Fill in water at least up to the 4 marking on the water level indicator 3. Otherwise the device may overheat.
• Never put fluids other than fresh drinking water into the coffee machine.

7.1 Drip stopper

The filter holder 12 has an anti-drip valve 11. This ensures that no coffee drips out of the filter when you remove the pot 9.

In order to ensure that the anti-drip valve 11 opens during the brewing process, it is important that the filter holder 12 is inserted correctly and the pot 9 with its lid 10 closed is positioned completely in the coffee machine.

7.2 Filling volumes

Always fill the water tank 4 at least up to the marking for 4 cups (4). The maximum filling level reaches the 10 MAX marking (for approx. 10 cups).

7.3 Brewing coffee

1. Fill fresh, cold tap water into the pot 9. (Hot or carbonated water can result in malfunctions.)

2. Open the coffee machine cover 2 using the handle 1.

3. Now fill the water into the water tank 4 up to the desired number of cups (max 10, for approx. 10 cups).

4. Pour away any excess water.
5. Hold the filter holder 12 by its handle 13 and lower it into the coffee machine.
6. Fold the handle 13 of the filter holder 12 so that it is flush with its edge.
7. Place the permanent filter 14 into the filter holder 12.
8. Fold down the handle 15 of the permanent filter 14.
9. Place coffee powder into the permanent filter 14. Use ground coffee powder for filter coffee. If you grind the coffee yourself, grind it to a medium degree of grinding.

NOTE: you can also use a paper filter. In this case, the permanent filter 14 must not be inserted, however. Place a paper filter (size 1x4) with folded sides directly into the filter holder 12. When it is folded, the paper filter fits better in the filter holder 12 and the seams are prevented from tearing.

1. Close the cover 2.
2. It is important that the pot 9 has a closed lid 10 when it is placed on the hot plate 7.
3. Press the button ⏻ 6. It lights up. The brewing process will start after a short time.
4. After the brewing process is complete, the hot plate 7 remains active for approx. 40 minutes and the button ⏻6 is lit. The hot plate 7 then switches itself off and the button ⏻6 goes out.

NOTE: by pressing the button ⏻ 6, you can cancel the brewing process and switch off the hot plate 7 sooner at any time.

8. Cleaning

DANGER! Risk of electric shock!

• Pull out the mains plug 5 from the wall socket before cleaning the coffee machine.
• The coffee machine and the power cable with mains plug 5 must not be immersed in water or other liquids.

DANGER! Risk of injury through scalding!

- The coffee machine becomes very hot during operation. Allow it to cool down before cleaning.

WARNING! Risk of material damage!

- Do not use any astringent or abrasive cleaning agents.

8.1 After every use

Clean the device after every use, if possible.

1. Pull the mains plug 5 out of the wall socket.
2. Open the coffee machine cover 2 using the handle 1.
3. Only for the permanent filter 14: open the handle 15 of the permanent filter, remove the permanent filter and rinse it out under running water.
4. Fold up the handle 13 of the filter holder 12 and remove the filter holder.
5. Only for paper filters: dispose of the used paper filter.
6. Rinse out the filter holder 12 with warm water.

7. Rinse the pot 9 and its lid 10 with clear water. Only in the case of stubborn residues should you use a little mild detergent and a soft washing-up brush. Then rinse all parts thoroughly with clear water.

8. Wipe down the coffee machine and the power cable 5 with a damp cloth when required. Dry with a dry cloth.

9. Allow all parts to dry completely before you put them away or use the device again.

Dishwasher

The following parts are dishwasher-safe:

• Permanent filter 14
• F i l t e r h o l d
• Coffee spoon 8

8.2 Descaling

Time intervals for descaling

The intervals for descaling are dependent on the hardness of the water, and how often you use the device. Where the hardness of the water is medium or high, we recommend descaling monthly.

If using tap water, you can find out the hardness of the water in the area where you live by inquiring at your local waterworks.

After some time, the boiling process will result in limescale being deposited in parts of the coffee machine (depending on the hardness of the water used). You should remove this at regular intervals, because otherwise the power consumption of the device will increase.

1. Switch off the coffee machine and allow it to cool down completely.

2. Pour the descaling agent into the water tank 4. Use a liquid, environmentally friendly descaling agent based on citric acid, and follow the instructions of the manufacturer.

3. Fill the water tank 4 to the 8 cup marking.

4. Close the cover 2 of the water tank 4.

5. It is very important that the pot 9 has a closed lid 10 when it is placed on the hot plate 7.

6. Press the button ⏻ 6. It lights up. The brewing process will start after a short time.

7. Allow about half of the descaling solution to pass through and switch the device off again by pressing the button ⏻ 6. The button goes out.
8. Leave the descaling agent to work for approx. 30 minutes.
9. Switch on the coffee machine by press- e ring the button ⏻ 6. It lights up. Allow the rest of the descaling solution to run through.
10. At the end of the brewing process, switch the coffee machine off by pressing the button ⏻ 6. The button goes out.
11. Empty the pot 9 and rinse it with water.
12. Fill the water tank 4 with clear water up to the 8 cup marking a further two times and start the brewing process.

9. Storage

DANGER for children!

- Keep the device out of the reach of children.

1. Clean the permanent filter 14 and rinse out the filter holder 12 and the pot 9.
2. Leave the cleaned coffee machine and the cleaned accessories to dry before you assemble them and put them away.

10. Disposal

This product is subject to the provisions of European Directive 2012/19/EC. The symbol showing a wheelie bin crossed through indicates that the product requires separate refuse collection in the European Union. This applies to the product and all accessories marked with this symbol. Products identified with this symbol may not be discarded with normal household waste, but must be taken to a collection point for recycling electric and electronic appliances.

This recycling symbol marks e.g. an object or parts of the material as valuable for recycling. Recycling helps to reduce the consumption of raw materials and protect the envi

Packaging

When disposing of the packaging, make sure you comply with the environmental regulations applicable in your country.

11. Trouble-shooting

If your device fails to function as required, please try this checklist first. Perhaps there is only a minor problem, and you can solve it yourself.

DANGER! Risk of electric shock!

- Do not attempt to repair the device yourself under any circumstances.

Fault	Possible causes /Actions
No function	Has the device been connected to the power supply?Check the connection.
The quality of the coffee brewed is becoming worse.	The coffee machine needs to be descaled.
The brewing process takes longer for the same volume.
The cover 2 cannot be closed.	Is the filter holder 12 correctly inserted and is the handle 13 folded down?
The filter overflows during the brewing process.	Is the lid 10 of the pot 9 closed?Is the pot 9 completely on the hot plate 7?Is the filter holder 12 inserted correctly?

12. Technical specifications

Model: SKMR 1000 A1
Mains voltage: 2	20 - 240 V ~ 50 - 60 Hz
Protection class: I
Power rating: 1000 W

Symbols used

	Geprüfte Sicherheit (certified safety): devices must comply with the generally acknowledged rules of technology and the German Product Safety Act (Produkt-sicherheitsgesetz - ProdSG). (Not for UK)
	With the CE marking, HOYER Handel GmbH declares the conformity with EU guidelines.
	This symbol reminds you to dispose of the packaging in an environmentally friendly manner.
PAP	Recyclable materials are marked with the recycling symbol (3 arrows). The material can be specified by the recycling number in the centre (here: 21) and/or an abbreviation (here: PAP).
~	AC voltage
	The symbol identifies parts that can be cleaned in the dishwasher.
	It is a recyclable product which is subject to an extended producer responsibility and for which the rules of waste separation apply.

Subject to technical modifications.

13. Warranty of the HOYER Handel GmbH

Dear Customer, your device is provided with a 3 year warranty starting with the purchase date. In the event of product defects, you are entitled to statutory rights against the vendor. These statutory rights are not restricted by our warranty presented in the following.

Warranty conditions

The warranty period starts with the purchase date. Please keep the original purchase receipt in a safe place. This document is required to verify the purchase.

If within three years from the purchase date of this product a material or factory defect occurs, the product will be repaired or replaced by us – at our discretion – free of charge to you, or the purchase price will be refunded. This warranty implies that within the period of three years the defective device and the purchase receipt are presented, including a brief written description of the defect and the time it occurred.

If the defect is covered by our warranty, the repaired or a new product will be returned to you. No new warranty period starts with a repair or replacement of the product.

Warranty period and statutory claims for defects

The warranty period is not extended when the warranty has been claimed. This also applies to replaced and repaired parts. Any damages and defects already existing at the time of purchase must be reported immediately upon unpacking. Repairs arising after the expiration of the warranty period are subject to a charge.

Warranty coverage

The device was produced carefully according to strict quality guidelines and tested diligently prior to delivery.

The warranty applies to material or factory defects.

Excluded from the warranty are wear parts subject to normal wear and damages to fragile parts, e.g. switches, lamps or other parts manufactured from glass.

This warranty expires if the product is damaged, not used as intended or not serviced. For the proper operation of the product, all instructions listed in the operating instructions must be observed carefully. Any form of use and handling that is advised against in the operating instructions or warned against must always be avoided.

The product is only intended for private and not for commercial use. In the case of incorrect and improper treatment, use of force and interventions not performed by our authorised Service Centre, the warranty shall cease.

Handling in case of a warranty claim

In order to ensure prompt processing of your matter, please observe the following notes:

- Please keep the article number IAN: 471972_2410 / 482031_2410 / 482032_2410 and the purchase receipt as a purchase verification for all inquiries.

- The article number can be found on the rating plate, an engraving, the title page of your instructions (in the bottom left), or as a label on the rear or underside of the device.

- If faulty operation or other defects occur, first contact the Service Centre listed in the following by telephone or email.

- Then, you are able to send a product reported as defective free of charge to the service address specified to you, including the purchase receipt and the information on the defect and when it occurred.

At www.lidl-service.com you can download this and many other manuals, product videos and installation software.

PDF ONLINE www.lidl-service.com

This QR code takes you directly to the Lidl Service website (www.lidl-service.com), where you can enter the article number (IAN) 471972_2410 / 482031_2410 / 482032_2410 to open your user instructions.

Service Centre

GB Service Great Britain Tel.: [phone] E-Mail: [e-mail]

IE Service Ireland Tel.: [phone] E-Mail: [e-mail]

MT Service Malta Tel.: [phone] E-Mail: [e-mail]

CY Service Cyprus Tel.: [phone] E-Mail: [e-mail]

IAN: 471972_2410 / 482031_2410 / 482032_2410

Supplier

Please note that the following address is no service address. First contact the aforementioned Service Centre.
