SSB 75 A2 - Chocolate fountain SILVERCREST - Free user manual and instructions

USER MANUAL SSB 75 A2 SILVERCREST

PDF ONLINE www.lidl-service.com

Black and white photo of a SilverCrist coffee maker with a conical lid, no visible text or symbols on the device itself.

ELEKTRISCHER SCHOKOBRUNNEN/ELECTRIC CHOCOLATE FOUNTAIN/FONTAINE À CHOCOLAT ÉLECTRIQUE SSB 75 A2

DE AT CH

ELEKTRISCHER

SCHOKOBRUNNEN

Operation and safety notes

FR BE

GB/IE Operation and safety notes Page 14

Warnings and symbols used....Page 15

Introduction Page 16

Intended use ...... Page 16

Scope of delivery.... Page 16

Description of parts ...... Page 16

Technical data Page 16

Safety instructions.... Page 16

Before first use.... Page 19

First use ...... Page 19

Assembly Page 19

Operation.... Page 19

Cleaning and care Page 20

Storage Page 20

Disposal Page 20

Warranty Page 21

Warranty claim procedure.... Page 21

Service Page 21

Warnings and symbols usedThe following warnings are used in this user manual and on the packaging:
	DANGER! This symbol in combination with the signal word “Danger” marks a high-risk hazard that if not prevented could result in death or serious injury.		Danger - risk of electric shock!
	WARNING! This symbol in combination with the signal word “Warning” marks a medium-risk hazard that if not prevented could result in death or serious injury.		Use the product in dry indoor spaces only.
	CAUTION! This symbol in combination with the signal word “Caution” marks a low-risk hazard that if not prevented could result in minor or moderate injury.		NOTE: This symbol in combination with “Note” provides additional useful information.
			Food safeThis product has no adverse effect on taste or smell.
	ATTENTION! This symbol with the signal word “Attention” indicates a possible property damage.		Hertz (supply frequency)
	Alternating current/voltage		CE mark indicates conformity with relevant EU directives applicable for this product.
	Watt Symbol for protective earth
	The removable parts 1, 2 and 3 are suitable for dishwasher.		Caution, hot surface!
	Safety informationInstructions for use

ELECTRIC CHOCOLATE FOUNTAIN

Introduction

We congratulate you on the purchase of your new product. You have chosen a high quality product. The instructions for use are part of the product. They contain important information concerning safety, use and disposal. Before using the product, please familiarise yourself with all of the safety information and instructions for use. Only use the product as described and for the specified applications. If you pass the product on to anyone else, please ensure that you also pass on all the documentation with it.

- Intended use

The product is intended for melting chocolate and to serve as a chocolate fountain. Do not use the product for any other purpose.

The product is designed only for use in private households and must not be used commercial areas.

- Scope of delivery

1 Base
3 Rising tube parts (pre-assembled)
1 Rising tube mounting
1 Chocolate screw

● Description of parts

1 Rising tube
2 Rising tube mounting
3 Chocolate screw
4 Bowl
5 Base with motor and heating element
6 Red power indicator light
7 Control switch
8 setting (heat)
9 Setting (motor and heat)
10 Power cord with power plug

• Technical data

Nominal voltage: 220~	240 V~, 50 Hz
Power consumption: 75 W
Power consumption in off mode: 0.0 W
Protection class: I

Safety instructions

BEFORE USING THE PRODUCT, PLEASE FAMILIARISE YOURSELF WITH ALL OF THE SAFETY INFORMATION AND INSTRUCTIONS FOR USE! WHEN PASSING THIS PRODUCT ON TO OTHERS, PLEASE ALSO INCLUDE ALL THE DOCUMENTS!

In the case of damage resulting from non-compliance with these operating instructions the warranty claim becomes invalid!

No liability is accepted for consequential damage! In the case of material damage or personal injury caused by incorrect handling or non-compliance with the safety instructions, no liability is accepted!

Children and persons with disabilities

⚠ WARNING! RISK OF LOSS OF LIFE OR ACCIDENT TO INFANTS AND CHILDREN!

Never leave children unsupervised with the packaging material. The packaging material represents a danger of suffocation.

Children frequently underestimate the dangers. Always keep children away from the packaging material.

This product can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities, or lack of experience and knowledge if they have been given supervision or instruction concerning use of the product in a safe way and understand the hazards involved. Cleaning and user maintenance shall not be made by children unless they are older than 8 and supervised.

■ Children shall not play with the product.

- Keep the product and its power cord out of reach of children aged less than 8 years.

Intended use

⚠ WARNING! Misuse may lead to injury. Use this product solely in accordance with these instructions. Do not attempt to modify the product in any way.

■ This product is intended to be used in household and similar applications such as:

–staff kitchen areas in shops, offices and other working environments; –farm houses; –by clients in hotels, motels and other residential type environments; –bed and breakfast type environments.

Electrical safety

⚠️ DANGER! Risk of electric shock! Never attempt to repair the product yourself. In case of malfunction, repairs are to be conducted by qualified personnel only.

⚠️ DANGER! Risk of electric shock! Do not immerse the product in water or other liquids. Never hold the product under running water.

DANGER! Risk of electric shock! Never use a damaged product. Disconnect the power plug from the power supply

and contact your retailer if the product is damaged.

■ The product is not to be used if it has been dropped, if there are visible signs of damage.

Before connecting the power plug to the power supply, check that the voltage and current rating corresponds with the power supply details shown on the product's rating label.

■ Regularly check the power plug and the power cord for damages. If the power cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard.

■ Protect the power cord against damages. Do not let it hang over sharp edges, do not squeeze or bend it. Keep the power cord away from hot surfaces and open flames.

Operation

⚠️ CAUTION! Risk of burns!

During use the product gets hot. Do not touch the heating area while in use nor immediately after use.

- Do not move the product while it is in operation.

■ The heating area surface is subject to residual heat after use.

Cleaning and storage

⚠ WARNING! Risk of electric shock! Disconnect the power plug from the power supply before cleaning work and when not in use.

⚠️ CAUTION! Risk of burns!

Do not clean the product right after operation. Let the product cool down first.

- Clean the product after use (see "Cleaning and care"). - Do not pull the power plug out of the electrical outlet by the power cord.

■ Protect the product, its power cord and power plug against dust, direct sunlight, dripping and splashing water.

■ Store the product in a cool, dry place, protected from moisture and out of the reach of children.

■ Protect the product against heat. Do not place the product close to open flames or heat sources such as stoves or heating products.

Before first use

1. Remove the packaging material. Check if all parts are complete.
2. Clean the product (see "Cleaning and care").

- First use

NOTE: The first time the product is heated up, a faint odour may be present. This is due to manufacturing residues. Ensure sufficient ventilation.
□ Removing production residues: Operate the product at ⚙ setting 9 for approx. 15–30 minutes.

Assembly

1. Place the rising tube mounting 2 and the rising tube 1 on the 3 pins on top of the bowl 4.
2. Insert the chocolate screw 3 into the rising tube 1 so that the opening in the chocolate screw is pointing down.
3. Turn the chocolate screw 3 until it is fixed around the motor shaft on top of the bowl 4.

Operation

1. Place the product on a flat, stable surface.
2. Connect the power plug 10 to the power supply.
3. Test run: Set the control switch 7 to 9 to start the rotation of the chocolate screw 3. If the chocolate screw does not rotate, assemble the chocolate screw properly to the bowl 4 (see „Assembly”).
4. Turning the product off: Set the control switch 7 to 0.

Off mode

The product returns to off mode when the control switch 7 is set back to 0 during operation. The red power indicator light 6 goes off.

☐ Entering off mode: Set the control switch 7 to 0.
☐ Leaving off mode: Set the control switch 7 to 8 or 9. The red power indicator light 6 lights up.

Melting chocolate

CAUTION! Risk of burns! During heating the bowl 4 may get hot. Do not touch the bowl to prevent injury.

NOTE:

☐ Chocolate is available in various compositions. Some chocolate can be liquified more easily than others. Add vegetable oil to prevent the melted chocolate from becoming sticky.

☐ You can also pre-melt the chocolate in a microwave, pot or pan. This must be done at low temperature and constant supervision. Otherwise, the chocolate may scorch. Before pouring the melted chocolate into the bowl 4, add vegetable oil and stir the mixture well.
☐ Add approx. 80 ml of vegetable oil to every 300 g of chocolate for the correct viscosity. The smaller the pieces, the faster the chocolate melts. We recommend a maximum size of 3 cm × 3 cm × 1 cm per piece.

1. Set the control switch 7 to 8.
2. Fill the bowl 4 with the desired amount of chocolate. Do not add more than 300 g of chocolate. Add vegetable oil if necessary.
3. Let the chocolate melt. If necessary, stir with a spatula or spoon.

Using the fountain

NOTE:

☐ Melt the chocolate before you start the rotation of the chocolate screw 3. Otherwise, the chocolate screw may get stuck.
☐ The maximum continuous operation time is 3 hours. Do not operate the product for a longer time to prevent overheating and damaging the motor unit.
Once the bowl 4 is filled to the brim with liquid chocolate: Set the control switch 7 to 9 to start the rotation of the chocolate screw 3.

☐ Use a fork or a skewers to dip cuts of fruit or marshmallows into the melted chocolate. Cookies, pancakes or pieces of cake are well suited for a chocolate fountain as well.

● Cleaning and care

⚠ WARNING! Risk of electric shock!

Before cleaning: Always disconnect the power plug 10 from the power supply.

⚠ WARNING! Risk of electric shock!

Do not immerse the product's electrical

components in water or other liquids. Never hold the product under running water.

CAUTION! Risk of burns! Do not clean the product right after operation. Let the product cool down first.

Do not use any abrasive, aggressive cleaners, hard brushes, or sharp objects to clean the product or its accessories, as these could damage the product.

- Do not let any liquids enter the product interior.

Part Cleaning method
4 Bowl5 Base	1. Wipe with a damp cloth.□ If necessary, use a mild washing-up liquid.Afterwards, wipe with a cloth moistened only with clear water to remove any detergent residue.2. Wipe dry with a soft dry cloth.
1 Rising tube2 Rising tube mounting3 Chocolate screw	□ Clean in warm, soapy water and dry.■ Suitable for dishwashers
□ After cleaning: Let all parts dry.

Storage

CAUTION! Risk of burns! Do not store the product right after operation. Let the product cool down first.

□ Clean and dry the product before storage.
☐ Do not knot or kink the power cord 10.
☐ Store the product in a dry and clean place.
□ Store the product away from children.

Disposal

The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities.

Observe the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1-7:plastics/20-22: paper and fibreboard/80-98: composite materials.

Product:

The product incl. accessories and packaging materials are recyclable and are subject to extended producer responsibility. Dispose them separately, following the illustrated Info-tri (sorting information), for better waste treatment.

The Triman logo is valid in France only.

Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.

protect the environment, please

dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.

Warranty

The product has been manufactured to strict quality guidelines and meticulously examined before delivery. In the event of material or manufacturing defects you have legal rights against the retailer of this product. Your legal rights are not limited in any way by our warranty detailed below.

The warranty for this product is 3 years from the date of purchase. The warranty period begins on the date of purchase. Keep the original sales receipt in a safe location as this document is required as proof of purchase.

Any damage or defects already present at the time of purchase must be reported without delay after unpacking the product.

Should the product show any fault in materials or manufacture within 3 years from the date of purchase, we will repair or replace it – at our choice – free of charge to you. The warranty period is not extended as a result of a claim being granted. This also applies to replaced and repaired parts.

This warranty becomes void if the product has been damaged, or used or maintained improperly.

The warranty covers material or manufacturing defects. This warranty does not cover product parts subject to normal wear and tear, thus considered consumables (e.g. batteries, rechargeable batteries, tubes, cartridges), nor damage to fragile parts, e.g. switches or glass parts.

● Warranty claim procedure

To ensure quick processing of your claim, observe the following instructions:

Make sure to have the original sales receipt and the item number (IAN 485022_2501) available as proof of purchase.

You can find the item number on the rating plate, an engraving on the product, on the front page of the instruction manual (bottom left), or as a sticker on the rear or bottom of the product.

If functional or other defects occur, contact the service department listed below either by telephone or by e-mail.

Once the product has been recorded as defective you can return it free of charge to the service address that will be provided to you. Ensure to enclose the proof of purchase (sales receipt) and a short, written description outlining the details of the defect and when it occurred.
