USER MANUAL RV-SJ-6000 Vevor

Technical Support and E-Warranty Certificate www.vevor.com/support

RV STACK JACK

MODEL: RV-SJ-6000

We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represent estimate of savings you might benefit from buying certain tools with us compared top brands and doses not necessarily mean to cover all categories of tools offered are kindly reminded to verify carefully when you are placing an order with us actually saving half in comparison with the top major brands.

VEVOR®

TOUGH TOOLS, HALF PRICE

RV STACK JACI

MODEL:RV-SJ-6000

Five identical metallic conical devices with vertical supports and arrows, arranged in a row (no text or symbols visible)

NEED HELP? CONTACT US!

Have product questions? Need technical support? Please feel f

contact us: Technical Support and E-Warranty Certificate

www.vevor.com/support

This is the original instruction, please read all manual instruction carefully before operating. VEVOR reserves a clear interpretation user manual. The appearance of the product shall be subject to product you received. Please forgive us that we won't inform you there are any technology or software updates on our product.

Warning-To reduce the risk of injury, the user must re-instructions manual carefully.

PRODUCT ADVANTAGES

1. The frame is made of high-quality aluminum and is not easy to rust outd

2. Camper stabilizer jacks have good size and are easy to store.

3. It can be used with leveling blocks.

4. The Max. Capacity: 6000lbs per stabilizing Jack.

5. The cushion rubbers can avoid direct contact between jacks and the chassis protect the paint surface of the chassis, and avoid hearing the noise generated by metal friction.

6. Four RV jacks must be used together. During the process of adjusting the height, ensure that the height of all four RV jacks is similar to avoid ex-force on a single jack.

7. When using on soft ground, it is recommended to place strong wooden boards or platforms under the RV jacks.

PRODUCT PAREMETERS

Model	RV-SJ-6000
Height Range	11-17 in (or 280-435mm)
Rated Load	4000 lbs (or 1814kg)
Maximum Load	6000 lbs (or 2720kg)
Quantity Per Box	4 pcs

ASSEMBLY PREPARATION

NO	PART NAME	QTY
1	Frame base	1
2	Nut	1
3	Screw	1
4	Crossbar	1
5	Cushion rubber	1

When unpacking this product, check to make sure the parts listed below are included and carefully inspect for any damage that may have occurred during transit. If any part is missing or damaged, do not attempt to assemble or use product.

SAFETY INSTRUCTIONS

WARNING:

Read carefully and understand all instructions before operating. Failure to follow the safety rules and other basic safety precautions may result in serious person injury.

1. Stay alert. Watch what you are doing and use common sense when operate the tool. Do not use the tool while tired or under the influence of drugs, alcohol, or medication. A moment of inattention while operating the tool increases the risk of injury to persons.
2. Dress properly. Do not wear loose clothing or jewelry. Contain long hair, hair, clothing, and gloves away from moving parts. Loose clothes, jewelry, long hair increases the risk of injury to persons as a result of being ca moving parts.
3. Do not overreach. Keep proper footing and balance at all times. Proper footing and balance enable better control of the tool in unexpected situat

4. Use safety equipment. Wear ANSI-approved safety goggles and heavy-duty work gloves during use.

5. Do not force the tool. Use the correct tool for the application. The correct will do the job better and safer at the rate for which the tool is design

6. Store the tool when it is idle, out of reach of children, and other untrained persons. A tool is dangerous in the hands of untrained users.
7. Check for misalignment or binding of moving parts, breakage of parts, and any other condition that affects the tool's operation. If damaged, have the serviced before using. Many accidents are caused by poorly maintained to
8. Use only accessories that are identified by the manufacturer for the specific tool model. Use of an accessory not intended for use with the specific model increases the risk of injury to persons.
9. Inspect repair after use. Repairs to structural or frame members must be inspected by a qualified technician to ensure that the structure is still strong enough to safely fulfill its function.
10. Tool service must be performed only by qualified repair personnel.
11. When servicing a tool, use only identical replacement parts. Use only authorized parts.
12. Only qualified and authorized persons are allowed to operate the RV stand jack.
13. Use as intended only. This product is not a toy. Do not allow children with or near this item.

SAVE THESE INSTRUCTIONS

INSTALLATION INSTRUCTIONS

1. Not suitable for uneven and easily sunken surfaces;
2. The base and nut can only be used after fully fitting;
3. The overall lifting range is 11 inches to 17 inches;
4. The working load-bearing pressure is less than 6000 pounds;
5. Usage: It can only be applied vertically and cannot be pressed laterally.

Notice:

a. Place the product in a stable area first.
b. Adjust the screw to the appropriate height.
c. Insert the screw into the hole and lock it with a crossbar adjuster to use

MAINTENANCE

1. Keep the surface of this tool and its accessories free of hydraulic fluid air grease. Use only a mild detergent and a damp cloth when cleaning. Do use a flammable or combustible solvent to clean this tool or its accesso
2. Before each use, examine the general condition of the tool and its accessories. Check for loose components, misalignment, binding of moving parts, broken parts, and any other condition that may affect its safe ope Do not use a damaged tool or its damaged accessories.
3. Stop using the equipment immediately if any of the problems occur, as it cause personal injury. Any repairs or replacement must be done by a q person or an authorized service center only.
