MQ 1000 - Insect repellent Orbegozo - Free user manual and instructions

Product type	Electric fly killer / insect killer
Brand	Orbegozo
Model	MQ 1000
Usage	Indoor only
Light source	UV lamp to attract insects
Destruction method	High voltage metal grid (electrocution)
Power supply	Mains 220-240 V, 50/60 Hz
Estimated power	20 W
Main material	ABS plastic and metal grid
Approximate dimensions	30 x 20 x 20 cm
Approximate weight	1 kg
Estimated coverage area	Up to 50 m²
Collection tray	Yes, removable for cleaning
Switch	Yes, on/off
Recommended operation	Continuously for 24 hours, preferably at night and away from other light sources
Exterior cleaning	Slightly damp cloth
Interior cleaning	Small brush (once a week)
Safety	Do not open the device, do not insert objects, unplug before maintenance
Lamp replacement	By authorized technical service only
Warranty	Legal warranty according to current regulations
Technical service	https://orbegozo.com/asistencia-tecnica/
Compliance	Low Voltage Directive 2014/35/EU, EMC Directive 2014/30/EU
Disposal	Do not dispose of with household waste, follow the WEEE directive
Typical color	White and black
Included accessories	User manual

Frequently Asked Questions - MQ 1000 Orbegozo

How does the Orbegozo MQ 1000 fly killer work?

The device uses a UV lamp to attract insects (mosquitoes, flies, moths). Once attracted, they are electrocuted by a high voltage metal grid. The insects then fall into a removable collection tray.

Can I use the device outdoors?

No, this device is designed for indoor use only. It should not be exposed to humidity or rain.

How to safely clean the device?

Before cleaning, unplug the device. Clean the exterior with a slightly damp cloth. Remove the collection tray and empty it. Use a small brush to gently clean the inner grid. Never use chemicals or metal objects.

How often should I clean the collection tray?

It is recommended to clean the collection tray once a week to maintain efficiency and hygiene.

Where to place the device for best effectiveness?

Place the device in a dark room, away from other light sources. Turn off the room lights 10 to 20 minutes before turning on the device. It works best at night. Avoid drafts.

How long should the device remain on?

It is recommended to use it continuously for 24 hours for maximum effectiveness. You can leave it on overnight.

Does the UV lamp need to be replaced?

Yes, the UV lamp has a limited lifespan. For technical reasons, its replacement must be carried out by an authorized technical service.

What types of insects are attracted by the device?

The device mainly attracts mosquitoes, flies, moths and other flying insects that are nocturnal or attracted to UV light.

Does the device make noise?

The device operates silently. You may hear a slight crackling when an insect is electrocuted.

What to do in case of malfunction?

Consult the user manual. If the problem persists, contact Orbegozo technical service via https://orbegozo.com/contacto/ . Keep your receipt for warranty.

USER MANUAL MQ 1000 Orbegozo

Teal and white portable air purifier device with visible vent slots and a small plug (no text or symbols)

MQ 1000

Sonifer,S.A.

Read this manual carefully before running this appliance and save it for reference in order to obtain the best results and ensure safe use.

Read the operating instructions carefully before putting the appliance into operation and keep the instructions including the warranty, the receipt and, if possible, the box with the internal packing. If you give this device to other people, please also pass on the operating instructions.

General Safety Instructions

1. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children must never play with the appliance. Cleaning and user maintenance must never be carried out by children without supervision.
2. Children should be supervised to ensure that they do not play with the appliance.
3. Keep the appliance and the cable cord out of the reach of children less than 8 years old.

4. WARNING: In order to ensure your children's safety, please keep all packaging (plastic bags, boxes, polystyrene etc.) out of their reach.

5. If the supply cord is damaged it must be repaired by the Authorized Service Agent.

6. Never pull on the cord when unplugging.
7. Do not use the unit with a damaged cord or plug, or if it is not working properly.
8. Do not handle the appliance with wet hands.
9. IMPORTANT: Never immerse the appliance in water or any other liquid.
10. Make sure the appliance has been unplugged before cleaning.
11. This appliance must be installed following the national regulations for electrical installations.
12. This appliance is for household use only.
13. In case that you need a copy of the instruction manual, you can find it in www.orbegozo.com.
14. WARNING: In case of misuse, there is a risk of possible injury.
15. ⚠️ WARNING: High voltage.
16. It must no be used in places where it could be flammable steam or explosive dust.
17. This appliance is not suitable for using in stables or similar places.
18. This appliance is only suitable for indoor use.

19. Do not open the appliance neither try to manipulate the inner sides.

20. Do not insert the fingers neither metallic parts through the grid.

INSTRUCTIONS FOR USE

The mosquito killer uses light to attract insects such as flies, moths, mosquitoes and other pests. The high voltage metal grids will electrocute the insects.

Plug it into a power socket and turn on the switch. Turn off the room light for 10 to 20 minutes before turning on the mosquito killer. It is recommended to use it continuously for 24 hours. It works best at night and away from light sources. For indoor use only.

MAINTENANCE AND CLEANING

Before any operation, make sure the unit is disconnected from the mains.

Use a slightly damp cloth for exterior cleaning.

Clean the insect collection tray frequently. To do this, remove it by pulling it out.

Clean the interior areas and the grid once a week. Use a small brush for this. Do not use chemical or abrasive products, metal scouring pads or other items that may damage the surface when cleaning.

LAMP REPLACEMENT

Due to the technology used in these appliances, the lamps must be replaced by our technical service.

DISPOSAL OF OLD ELECTRICAL APPLIANCES

The European directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE), requires that old household electrical appliances must not be disposed of in the normal unsorted municipal waste stream. Old appliances must be collected separately in order to optimize the recovery and recycling of the materials they contain, and reduce the impact on human health and the environment. The crossed out "wheeled bin" symbol on the product reminds you of your obligation, that when you dispose of the appliance, it must be separately collected. Consumers should contact their local authority or retailer for information concerning the correct disposal of their old appliance.

DECLARATION OF CONFORMITY:

This device complies with the requirements of the Low Voltage Directive 2014/35/EU and the requirements of the EMC directive 2014/30/EU.

GUARANTEE

This appliance is covered and is entitled to the legal guarantee in accordance with the legislation in force from the date of purchase. Keep the purchase receipt to be able to claim your right to the guarantee. To find the closest service to your location, contact through the following web link: https://orbegozo.com/asistencia-tecnica/

For any type of query, doubt or incident, you can contact us through our email shown on the main page of this manual or through our technical assistance service at https://orbegozo.com/contacto/

Orbegozo is not responsible for components and accessories that are subject to wear and tear due to use, as well as perishable compounds or those that have deteriorated due to improper use. Nor will it be held responsible if the owner has technically modified the device. Check the legal conditions on our website.
