USER MANUAL 7.4 SHM A1 SILVERCREST

Black Silver Crest brand hairdryer with a control panel, shown alongside an inset image of its mechanical component (no text or symbols on the device itself)

MINI-AKKU-HANDSTAUBSAUGER/MINI CORDLESS HANDHELD VACUUM CLEANER/MINI ASPIRATEUR À MAIN SANS FIL 7.4 SHM A1

DE AT CH

MINI-AKKU-HANDSTAUBSAUGER

MINI CORDLESS HANDHELD VACUUM CLEANER

Operation and safety notes

NL BE

MINI ACCU-HANDSTOFZUIGER

GB IE Before reading, unfold the page containing the illustrations and familiarise yourself with all functions of the device.

GB/IE Operation and safety notes Page 15

Black self-assembled device labeled 'SUV/RCAST' with a numbered arrow pointing to it (no additional text or symbols visible)

C SILVERCREST 4 10

QR code image containing encoded data, no visible human-readable text

IAN 453696\_2304

Intended use....Page 16

Trademark notice Page 16

Description of parts....Page 16

Scope of delivery....Page 17

Technical data......Page 17

Safety notices....Page 17

Safety instructions for rechargeable batteries....Page 19

Initial use....Page 19

Charging the rechargeable battery....Page 19

Using the product......Page 20

Cleaning and care....Page 20

Disposal Page 20

Warranty/Service......Page 21

Declaration of conformity....Page 22

List of pictograms used
	Observe the warnings and safety instructions!		Caution! Danger of explosion!
	Read the instructions!		SMPS (Switched Mode Power Supply)
	This product is only suitable for use indoors, in dry and enclosed spaces.		Polarity of the mains connection
:	Direct current/voltage EU compliant
	Alternating current/voltage		Dispose of the packaging and product in an environmentally-friendly manner!
	Never leave children unsupervised with the packaging material or the product.		36-month warranty
	Short-circuit proof safety transformer	[W2X4]	Safety notices Instructions for use
	Wear safety gloves!

Mini cordless handheld vacuum cleaner 7.4 SHM A1

- Introduction

We congratulate you on the purchase of your new product. You have chosen a high quality product. The instructions for

use are part of the product. They contain important information concerning safety, use and disposal.

Before using the product, please familiarise yourself with all of the safety information and instructions for use. Only use the product as described and for the specified applications. If you pass the product on to anyone else, please ensure that you also pass on all the documentation with it.

Intended use

This product is suitable for vacuuming up loose, dry dirt, e.g. dust, lint or crumbs in vehicles, homes, or offices. Only use the product indoors. The product

is exclusively intended for private, non-commercial use. Only use the product for the intended purpose. Any use other than previously mentioned or product modification is prohibited and can result in injuries and/or product damage. The manufacturer assumes no liability for damage arising from improper use.

Trademark notice

• The trademark and the brand name SilverCrest are the property of their respective owner.
• Any other names and products may be trademarks or registered trademarks of their respective owners.

• Description of parts

1 Handle (rotating)
2 ON/OFF button
3 LED charge indicator
4 Exhaust opening
5 Dust collector
6 USB-C charging socket

7 LED light
8 2-in-1 nozzle
9 USB cable with type C connector
10 Attachment (inflation function) (9 mm)
11 Attachment (inflation function) (6 mm)
12 HEPA filter

- Scope of delivery

Verify that the contents are complete and that the product is in perfect condition immediately after unpacking.

1 mini cordless handheld vacuum cleaner
1 USB cable with type C connector
1 2-in-1 nozzle (attachment)
2 attachments (inflation function)
1 set of instructions for use

- Technical data

Output: 50 Watt

Battery capacity: 2000 mAh, 7.4 V

(14.8 Wh)

Operating time: approx. 18 minutes

Suction power: 5.5 kPa

Charging time: approx. 3 h

USB cable with type

C connector: 50 cm length

Sound power level: 75 dB

Dust collector volume: 150 ml

HEPA filter: Class 10

Dimensions:

unfolded: 280 x 60 x 87 mm

folded: 169 x 60 x 87 mm

Safety notices

KEEP ALL SAFETY NOTICES AND INSTRUCTIONS FOR FUTURE REFERENCE!

WARNING! DANGER TO LIFE AND RISK OF ACCIDENTS FOR INFANTS AND CHILDREN!

Never leave children unsupervised with the packaging material. There is a risk of suffocation. Keep children away from the product.

This product may be used by children aged 8 years and up, as well as by persons with reduced physical, sensory or mental capacities, or those lacking experience and/or knowledge, as long as they are supervised or instructed in the safe use of the product and they understand the associated risks.

- Do not allow children to play with the product. Never allow children to clean or maintain the product without supervision.

- Do not use the product if due to - falling, - damage, - ingress water, - outdoor use

proper operation cannot be guaranteed. Have the product repaired by the manufacturer or its customer service department.

• Do not use the product in wet or moist environments (locations where there is a risk of the product coming into contact with liquids or being immersed in water). The product is not waterproof.
• Do not use the product near open fire.
  Do not use the product in temperatures above +40 °C or below +10 °C.
  ■ Use particular caution when using the product on stairs.
• Keep hair, clothing and fingers away from the openings and operating parts of the product.
  Do not allow the product to vacuum up chemical particles, e.g. stone dust, plaster, cement or similar particles.
• Do not allow the product to vacuum up flammable materials, for example fuel or toner from printers or photocopiers.

• Do not allow the product to vacuum up burning items, for example cigarettes, matches, ashes or other objects which could cause a fire.

• Do not allow the product to vacuum up sharp objects or glass shards.

• Do not use the product if the suction opening is blocked. Remove dust, hair, cotton wool, etc., to allow air to flow freely in the suction opening.
• Do not place the product next to radiators, ovens, or other hot appliances.
• Do not switch accessories while the product is in use.
  ■ Before using the product, ensure the dust collector and the HEPA filter are installed correctly.
  ■ Regularly check and clean the HEPA filter and the dust collector to extend the life of your product.
  ■ Never use the product without the filter to prevent damaging the motor and thereby shortening the life of the product.
  ■ Fully charge the product at least once a month to prevent deep discharge and thus battery damage.
  ■Discontinue using the product if the plastic parts are cracked or deformed. Always replace damaged parts with genuine spare parts.
  ■ Ensure that the USB cable does not get stuck in cupboard doors

and that it is not pulled over hot surfaces. This could damage the USB cable's insulation.

Safetyinstructions for rechargeable batteries

■ Never open the product. Repairs may only be conducted by qualified experts.

E XPLOSION HAZARD!

Do not throw the device

into fire.

- Avoid extreme environmental conditions and temperatures which could affect rechargeable batteries, e.g. radiators/direct sunlight.

WEAR PROTECTIVE

GLOVES! If rechargeable batteries have leaked, avoid contact between skin, eyes and mucous membranes and the chemicals! Flush out the affected areas with clean water and seek immediate medical attention!

■ Never cover the product whilst it is operational or whilst it is charging. The product may otherwise overheat.

■ Never attempt to recharge non-rechargeable batteries.

This product features a built-in rechargeable battery which cannot be replaced by the user. The rechargeable battery must be removed or replaced by the manufacturer or their service centre or a similarly qualified person to avoid hazards. When disposing of the product, you must indicate this product contains a rechargeable battery.

- Initial use

Before initial use, remove all parts from the packaging, check that they are complete and intact and dispose of the packaging material.
● Charging the rechargeable battery

Note: Fully charge the battery before first use. It takes approx. 3 hours to charge.

■ Only use power supplies with an output voltage of 5 V and an output current of at least 1 A to charge the product.

Plug the USB cable with type C connector into the USB C charging socket 6 on the product. Insert the other end of the USB cable with type C connector 9 into the port of a USB adapter (not included).

Note: During the charging process, the three LEDs of the charge indicator 3 flash.

☐ The three LEDs of the LED charge indicator 3 stop flashing and light up consistently. Remove the USB cable with type C connector 9 as soon as the product is fully charged.

Note: Charge the battery if the suction becomes noticeably weaker and the number of illuminated LEDs in the LED charge indicator 3 decreases.

• Using the product

Note: The suction opening must always be clear and should not be clogged. Otherwise the motor may overheat and become damaged.

Switch the product on by holding the ON/OFF button 2 for 3 seconds. The LEDs of the LED charge indicator 3 light up.

□ Inflate the desired item.
After use, press the ON/OFF button again to switch the product off. The LED lights 7 switch off.
Remove the attachment, 10, 11 from the exhaust opening 4.

Cleaning and care

Before using the product, ensure the HEPA filter 12 and the dust collector 5 are installed correctly. To do so, remove the dust collector 5 by turning it anticlockwise and removing it (Fig. A/I).
☐ Ensure that the HEPA filte2 is correctly positioned in the dust collector 5 (Fig. A/II).
Afterwards, attach the dust collector by turning it clockwise until it audibly locks into place (Fig. A/III).
If desired, attach the 2-in-1 nozzle into the suction opening. This is suitable for cleaning, for example, lamps, keyboards, or air vents in the centre consoles of cars.

Note: If you do not need the brush, push it down until it locks into place in the appropriate recess.

☐ Switch the product on by holding the ON/OFF button 2 for 3 seconds. The LEDs of the LED charge indicator 3 light up.

Note: Push the ON/OFF button 2 briefly to switch on the LED lights 7. The LED lights 7 can only be switched on before the vacuum is operated.

Note: The handle 1 can be rotated by 180^ to vacuum difficult-to-reach corners (Fig. B).

After use, press the ON/OFF button again to switch the product off. The LED lights 7 switch off.

Using attachments 10, 11:

The product has an inflation feature. The included attachments 10, 11 make it possible to use the motor's exhaust air. This allows you to inflate balloons or other inflatable toys, for example.

☐ Insert the desired attachment, 11 into the exhaust opening 4 (Fig. C).

• Do not use aggressive, chemical, or abrasive cleaners. These can corrode the surface of the product.
• Do not wash the product with water; it is not waterproof.
  Emptying the dust collector ^5 : remove the dust collector 5 by turning it anticlockwise and removing it (Fig. A/I). Remove the HEPA-Filter 12. After emptying the dust collector 5 reinstall the HEPA filter 12 back into the dust collector 5 (fig. A/II). Afterwards, attach the dust collector 5 by turning it clockwise until it audibly locks into place (Fig. A/III).
  ☐ Clean the housing and the 2-in-1 nozzle with a dampened cloth. For stubborn soiling use a mild detergent on the cloth.
  Store the product in a dust-free and dry location.

●Disposal

The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities.

Observe the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1-7: plastics/20-22: paper and fibre-board/80-98: composite materials.

Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.

To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.

The product incl. accessories and packaging materials are recyclable and are subject to extended producer responsibility. Dispose them separately, following the illustrated Info-tri (sorting information), for better waste treatment. The Triman logo is valid in France only.

Faulty or used batteries/rechargeable batteries must be recycled in accordance with Directive 2006/66/EC and its amendments. Please return the batteries/rechargeable batteries and/or the product to the available collection points.

Environmental damage through incorrect disposal of the batteries/rechargeable batteries!

Batteries/rechargeable batteries may not be disposed of with the usual domestic waste. They may contain toxic heavy metals and are subject to hazardous waste treatment rules and regulations. The chemical symbols for heavy metals are as follows: Cd = cadmium, Hg = mercury, Pb = lead. That is why you should dispose of used batteries/rechargeable batteries at a local collection point.

- Warranty/Service

Dear customer,

Our products are submitted to strict quality control. However, we do apologise if this device does not work properly and ask you to contact our Customer Service Department listed below. Please feel free to phone us using the Service Hotline specified. Warranty claims are subject to - without limiting your legal rights.

The following:

1. Warranty claims must be filed within a period of max. 3 years from the date of purchase.
   Our warranty services are limited to correcting defects in material and manufacture, or replacement of the device. Our warranty service is free of charge to you.
2. Warranty claims must always be filed promptly upon discovery.
3. Warranty claims will not be accepted after the warranty period has expired.
4. Please keep your receipt as proof of purchase.

Not covered by warranty:

• improper or incorrect handling
• failure to observe the safety notes for the device
• using force
• changes not performed by an authorised service centre
• damage due to return in packaging not safe for transport (the sales packaging of this product is not suitable for separate shipping)
• Self-induced damage due to e.g. impact, shock, drops
• Failure to observe the instructions for use
• normal wear
• unauthorised repairs
  You may request the instructions for use in PDF format from our Customer Service Department.

Service GB IE

Tel.: [phone]

E-Mail: [e-mail]

QR code image containing encoded data, no visible human-readable text

IAN 453696\_2304

Please have your receipt and item number (IAN 453696_2304) ready as your proof of purchase when enquiring about the product.

Hotline hours: Monday to Friday 09:00 to 18:00 (CET)

● Declaration of conformity

This product fulfils the requirements of the applicable European and national directives. This is confirmed by the CE mark. The relevant declarations are held by the manufacturer.

CE

QR code image containing encoded data, no visible human-readable text

IAN 453696\_2304
