HG10584A - Kitchen scale SILVERCREST - Free user manual and instructions

USER MANUAL HG10584A SILVERCREST

PDF ONLINE www.lidl-service.com

DIGITALE KÜCHENWAAGE/DIGITAL KITCHEN SCALES/BALANCE DE CUISINE NUMÉRIQUE

DE AT CH

DIGITALEKÜCHENWAAGE

Kurzanleitung

FR BE

Küchenwaage (Abb. B+C):

Black circular icon with white human and child figures, no text or symbols present

Description of parts....Page 14

Technical data......Page 14

Scope of delivery....Page 15

Safety notices Page 15

General safety instructions....Page 15

Safety instructions for batteries/rechargeable batteries......Page 16

Before first use....Page 18

Replacing the battery....Page 18

Cleaning and care....Page 18

Disposal Page 18

Service Page 19

List of pictograms used
	Press the weight surface with a certain force to activate the product.
	Direct current/voltage
	CE mark indicates conformity with relevant EU directives applicable for this product.
[S40Y]	Safety informationInstructions for use

Digital kitchen scales

- Introduction

This document is a shorter printed version of the complete instruction manual. By scanning the QR code, you will be taken straight to

the Lidl service website (www.lidl-service.com) where you can view and download the complete instruction manual by entering the article number (IAN) 434266_2304.

The short guide forms an integral part of this product. Prior to using the product, familiarize yourself with all operation and safety notes. Keep the short manual well preserved and if you hand the product on to third parties, all documentation should be passed on as well.

PDF ONLINE www.lidl-service.com

- Proper use

This product is designed to weigh out and tare quantities of food. The product is designed only for use in private household and must not be used in medicinal or commercial areas. The manufacturer is not liable to damage caused by improper use.

• Description of parts

Kitchen scale (Figs. B+C):

1 Weighing surface
2 LC display
3 Button TARE
4 Button UNIT

5 Battery compartment
6 Hanger
7 Screw

LC display (Fig. D):

8 Numerical display
9 Unit symbol

10 Minus symbol -
11 "Tare" symbol T

- Technical data

Max. measuring range: 5000 g/176 oz/11 lb/

5000 ml/175 fl'oz

Graduation: 1 g/0.05 oz/0 lb:0.1 oz/1 ml/0.05 fl'oz

Battery: button cell, type CR2032, 1 x 3 V===

Rated current: 10 mA Model numbers: see figure A

- Scope of delivery

Check that all the items are present and that the product and all its parts have no defects immediately after unpacking. Do not under any circumstances use the product if the package contents are incomplete.

1 Kitchen scale

1 Set of instructions

1 Battery (best before 01/2025)

for use

Safety notices

KEEP ALL THE SAFETY ADVICE AND INSTRUCTIONS IN A SAFE PLACE FOR FUTURE REFERENCE!

General safety instructions

WARNING! DANGER OF DEATH AND

ACCIDENTS FOR TODDLERS AND CHILDREN! Never leave children unsupervised with the

packaging material. The packaging material represents a danger of suffocation. Children frequently underestimate the dangers. Always keep children away from the packaging material.

This product can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the product in a safe way and understand the hazards involved. Children shall not play with the product. Cleaning and user maintenance shall not be made by children without supervision.

CAUTION! RISK OF INJURY! Do not place

more than 5 kg on the product. This could damage the product.

■ Do not expose the product to

• extreme temperatures,
• direct sunlight,
• magnetic fields,
• moisture.

These can damage the product.

This product has delicate electronic components. This means that if it is placed near an object that transmits radio signals, it could cause interference. This could be, for example, mobile telephones, walkie talkies, CB radios, remote controls and microwaves. If the display indicates a problem, move such objects away from it.
Electromagneticinterference/high-frequency emissions can lead to the product failing. In cases of the product failing to work, remove the battery for a short while and then replace it. Do this as described in the "Replacing the battery" section.
■ Protect the product from electrostatic charge/discharge. This could hinder the internal data exchange, which causes errors in the LC display 2.
- Check the product for damage before use. Never use a damaged product.
FOOD-SAFE!The taste and smell of your food are not detrimentally affected by this product.

Safetyinstructionsfor batteries/rechargeable batteries

■ DANGER TO LIFE! Keep batteries/rechargeable batteries out of reach of children. If accidentally swallowed seek immediate medical attention.
■ Swallowing may lead to burns, perforation of soft tissue, and death. Severe burns can occur within 2 hours of ingestion.
DANGER OF EXPLOSION! Never recharge

non-rechargeable batteries. Do not short-circuit batteries/rechargeable batteries and/or open them. Overheating, fire or bursting can be the result.

■ Never throw batteries/rechargeable batteries into fire or water.
- Do not exert mechanical loads to batteries/rechargeable batteries.
Do not short-circuit the terminals.
■ Remove exhausted batteries/rechargeable batteries from the product and ensure their safe disposal.

■ Rechargeable batteries are to be removed from the product before being charged.

Risk of leakage of batteries/rechargeable batteries

• Avoid extreme environmental conditions and temperatures, which could affect batteries/rechargeable batteries, e.g. radiators/direct sunlight.
  If batteries/rechargeable batteries have leaked, avoid contact with skin, eyes and mucous membranes with the chemicals! Flush immediately the affected areas with fresh water and seek medical attention!

WEAR PROTECTIVE GLOVES! Leaked or

damagedbatteries/rechargeable batteries can cause burns on contact with the skin. Wear suitable protective gloves at all times if such an event occurs.
In the event of a leakage of batteries/rechargeable batteries, immediately remove them from the product to prevent damage.

■ Remove batteries/rechargeable batteries if the product will not be used for a longer period.

Risk of damage of the product

■ Only use the specified type of battery/rechargeable battery!
- Insert batteries/rechargeable batteries according to polarity marks (+) and (-) on the battery/rechargeable battery and the product.
Use a dry lint-free cloth or cotton swab to clean the contacts on the battery/rechargeable battery and in the battery compartment before inserting!
■ Remove exhausted batteries/rechargeable batteries from the product immediately.
■ ATTENTION! Contains button cells that can be swallowed! Danger of suffocation!

WARNING! KEEP OUT OF REACH OF CHILDREN! Swallowing can lead to chemical burns, perforation of soft tissue, and death. Severe burns can occur within 2 hours of ingestion. Seek medical attention immediately.

● Before first use (Fig. C)

☐ Remove all packaging materials from the product.
Turn the product over and place it on a soft underlay to avoid scratching the surface. Loosen the screw 7 located at the cover of the battery compartment 5 on the back of the product.
Open the cover of the battery compartment on the back of the product.
☐ Pull out the insulation strip from the battery compartment 5.
☐ Close the cover of the battery compartment 5 and tighten the screw 7.

● Replacing the battery (Fig. C)

Turn the product over and place it on a soft underlay to avoid scratching the surface. Loosen the screw 7 located at the cover of the battery compartment 5 on the back of the product.
Open the cover of the battery compartment on the back of the product.
☐ Remove the used battery, if present.
☐ Insert a battery type CR2032 in the battery compartment 5.

Note: Make sure you insert the batteries with the correct polarity. This is indicated on the cover of the battery compartment 5.

☐ Close the cover of the battery compartment 5 and tighten the screw 7.

- Cleaning and care

Note: For storage you can hang the product using the hanger 6 (see Fig. C).

■ Never immerse the product in water or other liquids. This can damage the product.

□ Clean the product with a slightly dampened, fluff-free cloth. To remove more stubborn dirt, you can also dampen the cloth with a weak soap solution.
☐ You can remove leaked battery fluids with a dry, absorbent cloth.

●Disposal

The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities.

Observe the marking of the packaging materials for waste separation, which are marked with abbreviations (a) and numbers (b) with following meaning: 1–7: plastics/20–22: paper and fibreboard/80–98: composite materials.

Contact your local refuse disposal authority for more details of how to dispose of your worn-out product.

To help protect the environment, please dispose of the product properly when it has reached the end of its useful life and not in the household waste. Information on collection points and their opening hours can be obtained from your local authority.

The product incl. accessories and packaging materials are recyclable and are subject to extended producer responsibility. Dispose them separately, following the

illustrated Info-tri (sorting information), for better waste treatment. The Triman logo is valid in France only.

Faulty or used batteries/rechargeable batteries must be recycled in accordance with Directive 2006/66/EC and its amendments. Please return the batteries/rechargeable batteries and/or the product to the available collection points.

Environmental damage through incorrect disposal of the batteries/rechargeable batteries!

Batteries/rechargeable batteries may not be disposed of with the usual domestic waste. They may contain toxic heavy metals and are subject to hazardous waste treatment rules and regulations. The chemical symbols for heavy metals are as follows: Cd = cadmium, Hg = mercury, Pb = lead. That is why you should dispose of used batteries/rechargeable batteries at a local collection point.

- Service

GB Service Great Britain

Tel.: [phone]

E-Mail: [e-mail]

IE Service Ireland

Tel.:[phone]

E-Mail: [e-mail]
