USER MANUAL Camspot 4.0 PTZ Overmax

White OVERMAX surveillance camera with two antennas and a curved antenna (no text or symbols on device body)

OVERMAX

CE

EN: The product complies with requirements of EU directives.

Pursuant to the Directive 2012/19/EU, this product is subject to selective collection. The product must not be disposed of along with domestic waste as it may pose a threat to the environment and human health. The worn-out product must be handed over to the electrics and electronics recycling center.

Line drawing of a surveillance camera with two blades and a circular badge labeled '1' (no text or symbols on the device itself)

Line drawings of screw and pin components (no text or symbols)

2

Simple line drawing of a mechanical or electrical component with a curved cable (no text or symbols)

3

B

OVEIMAX 2 4 5 3 1 10

Technical diagram of a device with numbered components labeled 6, 7, 8, and 9

Tuya Smart app Overmax Con

1

QR code with embedded yellow 'COINT' logo in center, likely linking to a digital service or website.

QR code image containing encoded data, no visible human-readable text

CONTROL

Line drawing of a surveillance camera with two blades mounted on a wall, showing sensor placement (no text or symbols)

Wprowadzenie

Drogi Kliencie!

PL

https://ipc-eu.ismartlife.me/login

Montaž

Thank you for placing trust in us and choosing Overmax.

EN

Thanks to high-quality materials and modern solutions, we provide you with a product perfect for everyday use. We are convinced that the product will satisfy your requirements as it has been manufactured with utmost care. Before you use the product, please read this manual carefully.

Should you have any remarks or questions concerning the product, please do not hesitate to contact us: [e-mail]

Attention! Plug on the power supply cord is used as the disconnect device - during installation, ensure that the socket-outlet is easily accessible.

The set (fig. A)

1. Camera
2. Screws x4 and mounting pins x4
3. Power supply (5.0V DC 1.5A) / USB-C cable

Device description (fig. B)

1. Reset
2. Power cord
3. Microphone
4. Antenna
5. Light sensor
6. Bracket
7. White light / Infrared diodes
8. Speaker
9. MicroSD card slot
10. Lens

1. Downloading by application (fig. 1)

Search for the „Overmax Control” app in the iOS Store / Google Play

or scan the QR code and download the app. You can download it for iOS and Android.

The device works also with the Tuya Smart app.

2. Registering a new user (fig. 2 and 3)

• To register for the application, click on the „Register” box and then read and accept the Privacy Policy.
• Enter your email address to receive your verification code.
• Enter your verification code in the blank field.
• Enter your individual password and select "Finish".

EN

3. Logging in to an existing account

• In order to log in to an existing account, select “Log in using an existing account” (fig. 2).
• Select the appropriate country/region.
• Enter your email address and password, then log in.

4. Manually adding the device in the application (fig. 4)

The product only supports 2.4GHz Wi-Fi and does not support 5GHz Wi-Fi. Before setting up Wi-Fi, set your router parameters. The Wi-Fi password should not contain special characters.

• Make sure the router and camera are as close together as possible to allow for quick setup of the device.
- Connect your mobile device to the local Wi-Fi network to which the camera will be connected, then select “My home”. Select “Add device” and “Add manually”, then select the “Camspot 4.0 PTZ” device.
- Select your Wi-Fi network and enter your password.
- You can add the device using Auto Scan, which allows your phone to automatically search for nearby Wi-Fi enabled devices.
- Press and hold the „Reset” button for 5 seconds to restore the factory settings. Click „Next step” and continue.

EN

• To pair the camera, scan the QR code from the phone screen through the camera lens, holding the camera 15-20cm away. Try to hold your mobile phone in a stable position while scanning.
• When you hear the sound signal, click „I heard the sound”. Wait for the device to complete the configuration.
• After adding the device, click „Finish” to finish adding the device (fig. 5).

5. Description of the mobile application functions (fig. 6)

Real-time preview interface:

1. HD/SD - change recording resolution FullHD / HD
2. Volume control
3. Zoom
4. Full screen
5. Photo
6. Two-way audio communication
7. Video recording
8. Play (microSD card FAT32 required, max. 128 GB)
9. Gallery
10. Bright/dark application mode
11. Private mode (allows you to limit data transfer by turning off the camera)
12. Night mode
13. Motion tracking
14. Motion sensor
15. Sound sensor
16. Control
17. Locations
18. Cloud
19. Smart functions
20. Patrol function
21. Alarm (switches off automatically after 10 seconds)
22. Edition

In order to access the camera view via a web browser, turn on the „Overmax Control” application, click on add the device, then scan the QR code displayed in the browser of your computer.

Live camera preview at: https://ipc-eu.ismartlife.me/login

Mounting

EN

- To mount the camera on a wall, screw the camera bracket to the ceiling/wall (fig. 7).

Google Assistant/Alexa function

• If you wish to use this function, you will need to download the Tuya Smart app.
• The Tuya Smart app is free and available for Android (Google Play) and iOS (App Store) devices.

Record saving

Videos recorded on the memory card must at first be saved in the mobile device memory through OverMax Control application. Data on the card are encoded so if you fail to save them in the device memory, you will not be able to read them afterwards.

Troubleshooting

Question Answer
How do I restore the factory settings on my device?	Remove the camera from the device list in the app or press and hold the reset button for 8 seconds until you hear the sound.
After selecting the 2.4GHz Wi-Fi network and entering the correct password, the camera still cannot connect.	Make sure your phone and camera are connected to the same network.Make sure that the DHCP protocol is enabled. Press and hold the reset button for 5 seconds to reset the device.Make sure the Wi-Fi signal strength is high.

EN

How can I change the router the camera is connected to?	Remove the camera from the device list in the app or press and hold the reset button for 8 seconds until you hear the sound. Then reconfigure the device.
The microSD card is not recognized by the device.	The SD card must be removed from the device when it is switched off, otherwise damage to the memory card and/or the camera motherboard may result.The process of inserting or removing the card should be done when the camera is disconnected from the power source.Check the camera settings and make sure you have enabled saving to a microSD card.The device can support up to 128GB cards.Make sure the card is not damaged and supports the FAT32 format.Recommended Internet connection value: download: 16 mbps upload: 16 mbpsThe memory card must be a minimum of Class 10 and be suitable for continuous recording.
Why am I not receiving a notification when the device detects movement?	Make sure your phone and app have push notifications enabled.

Illustrations are provided for information purposes only. The actual appearance of the products may differ from the images shown.

Einführung

Live-Kameravorschau unter dem Link:

https://ipc-eu.ismartlife.me/login

Montage

https://ipc-eu.ismartlife.me/login

IT

Montaggio

https://ipc-eu.ismartlife.me/login

Installation

https://ipc-eu.ismartlife.me/login

ES

Instalación

1. Via app downloaden (afb. 1)

Zoek naar „Overmax Control“ app in de iOS Store / Google Play

Real-time interface:

https://ipc-eu.ismartlife.me/login

Rögzítés

https://ipc-eu.ismartlife.me/login

Instalace

Google Assistant / Alexa

Google Assistant / Alexa

Blank white image with no visible content, text, or symbols

Completely blank white image with no visible content, text, or symbols.

Completely blank white image with no visible content, text, or symbols.

Completely blank white image with no visible content, text, or symbols.

Blank white image with no visible content, text, or symbols.

Blank white image with no visible content, text, or symbols.

Blank white image with no visible content, text, or symbols.

Blank white image with no visible content, text, or symbols.

Blank white image with no visible content, text, or symbols.

Blank white image with no visible content, text, or symbols

Blank white image with no visible content, text, or symbols.

Blank white image with no visible content, text, or symbols.

Blank white image with no visible content, text, or symbols.

Blank white image with no visible content, text, or symbols.

Blank white image with no visible content, text, or symbols

Blank white image with no visible content, text, or symbols.

Blank white image with no visible content, text, or symbols.

Blank white image with no visible content, text, or symbols.

Blank white image with no visible content, text, or symbols.

Blank white image with no visible content, text, or symbols

Blank white image with no visible content, text, or symbols.

Blank white image with no visible content, text, or symbols

Blank white image with no visible content, text, or symbols.

Blank white image with no visible content, text, or symbols.

Blank white image with no visible content, text, or symbols.

Blank white image with no visible content, text, or symbols.

Blank white image with no visible content, text, or symbols

Blank white image with no visible content, text, or symbols.

Blank white image with no visible content, text, or symbols

Blank white image with no visible content, text, or symbols.

Blank white image with no visible content, text, or symbols

Blank white image with no visible content, text, or symbols.

Blank white image with no visible content, text, or symbols.

Blank white image with no visible content, text, or symbols

Blank white image with no visible content, text, or symbols

Blank white image with no visible content, text, or symbols

Blank white image with no visible content, text, or symbols.

Blank white image with no visible content, text, or symbols

Blank white image with no visible content, text, or symbols.

Blank white image with no visible content, text, or symbols.

Blank white image with no visible content, text, or symbols

Blank white image with no visible content, text, or symbols.

Blank white image with no visible content, text, or symbols

Blank white image with no visible content, text, or symbols.

Blank white image with no visible content, text, or symbols

Blank white image with no visible content, text, or symbols

Blank white image with no visible content, text, or symbols.

Blank white image with no visible content, text, or symbols

Blank white image with no visible content, text, or symbols.

Blank white image with no visible content, text, or symbols

Blank white image with no visible content, text, or symbols.

Blank white image with no visible content, text, or symbols

Blank white image with no visible content, text, or symbols

Blank white image with no visible content, text, or symbols.

Blank white image with no visible content, text, or symbols

Blank white image with no visible content, text, or symbols.

Blank white image with no visible content, text, or symbols

Blank light blue image with no visible content, text, or symbols

Blank white image with no visible content, text, or symbols

PL	Częstotliwość: 2.412 -2.472 GHzMoc wyjściowa RF: 12.4 dBm Max.
EN	Frequency: 2.412 -2.472 GHzRF output power: 12.4 dBm Max.
DE	Frequenz: 2.412 -2.472 GHzRF-Ausgangsleistung: 12.4 dBm Max.
IT	Frequenza: 2.412 -2.472 GHzPotenza di uscita RF: 12.4 dBm Max.
FR	Fréquence : 2.412 -2.472 GHzPuissance de sortie RF : 12.4 dBm Max.
ES	Frecuencia: 2.412 -2.472 GHzPotencia de salida de RF: 12.4 dBm Max.
NL	Frequentie: 2.412 -2.472 GHzRF-uitgangsvermogen: 12.4 dBm Max.
UA	Частота: 2,412 -2,472 ГГЦВихідна потужність RF: 12.4 дБм Max.
LT	Dažnis: 2.412 -2.472 GHzRF išvesties galia: 12.4 dBm Max.
HR	Frekvencija: 2.412 -2.472 GHzIzlazna snaga RF:12.4 dBm Max.
HU	Frekvencia: 2.412 -2.472 GHzRF kimeneti teljesítmény: 12.4 dBm Max.
CS	Frekvence: 2,412 -2,472 GHzRF výstupní výkon: 12,4 dBm Max.
SK	Frekvencia: 2,412 -2,472 GHzRF výstupný výkon: 12,4 dBm Max.
