USER MANUAL S4 hoogo
Legende
| Item | hoogo S4 and accessories |
| 1 Floor | nozzle with LED |
| 2 Lid (dust container) | |
| 3 Dust | container |
| 4 Release catch (dust container) | |
| 5 Cyclone unit with filters | |
| 6 Suction tube | |
| 7 Motor protection filter/internal filter | |
| 8 Handle | |
| 9 Hand grip | |
| 10 Rechargeable battery | |
| 11 LED display | |
| 12 Mode selector switch | |
| 13 Release sensing device (rechargeable battery) | |
| 14 On/off sensing device | |
| 15 Exhaust filter with release sensing device | |
| 16 Wall mount | |
| 17 Mains adapter | |
| 18 Electrical upholstery and mite brush | |
| 19 Crevice nozzle | |
| 20 Combined upholstery and furniture nozzle | |
| 21 Universal brush roller | |
| 22 | Special brush for delicate floors and hair |
Technical data
| Characteristics Values | |
| Brand | hoogo |
| Type | S4 |
| Article number | SC402 |
| Mains adapter power supply | 100-240V~ 50/60Hz |
| Mains adapter output voltage | 30 V |
| Mains adapter protection class | II |
| Voltage/charging the lithium-ion battery | 25.2 V / 2,500 mAh |
| Charging time | approx. 2.5 hours (80 %) approx. 3.5 hours (100 %) |
| Highspeed Digital Motor 400 | W |
| Suction power regulation Eco | - Standard - Power |
| Running time in minutes | Eco: approx. 60Standard: approx. 30Power: approx. 10 |
| Filter | HEPA 13 high-performance filter |
| Dust container volume approx. | 400 ml |
Only for use with a mains adapter: ZD024D300080EU
Table of contents
1 General 27
2 Safety instructions....28
3 Prepare use....29
4 Operation 34
5 Cleaning and maintenance....38
6 Spare parts and accessories 42
7 Rectification of faults....42
8 Disposal 44
9 Warranty....45
Many thanks
Dear customer,
thank you for deciding to purchase a hoogo product.
We hope that you enjoy using the appliance and would like to say thank you for purchasing it.
You can find further information about your product in these operating instructions and on our website www.hoogo.world.
You can contact our service team using the contact details provided on page 1.
1 General
These instructions for use contain important information for your safety as well as on the use of the appliance.
- Read the instructions for use in-full and attentively prior to initial use. Failure to observe the instructions for use may result in injury to persons or damages to property as well as loss of warranty.
- Store these instructions for use at an easily accessible location in the vicinity of the appliance.
• Always provide third parties these instructions for use together with the appliance.
1.1 Target group
- This appliance and its accessories may only be operated by children above 8 years of age and persons with reduced physical, sensory or mental abilities as well as also in-general in case of lacking experience and/or knowledge if they are previously instructed by experienced adults regarding potential danger and safe use or are supervised during use.
- All use and work on and with the appliance as well as playing within its proximity is prohibited for children under 8 years of age.
1.2 Intended use
The 2-in-1 battery-operated vacuum cleaner hoogo S4 is exclusively intended for dust removal in domestic surroundings. The 2-in-1 battery-operated vacuum cleaner hoogo S4 (in the following also referred to as the appliance) may only be used with the Mytek accessories belonging to it.
Use the appliance exclusively in the household for vacuum cleaning even, dry, normally soiled hard floors, short pile carpets or sets which withstand the burdens of the rotating brush without damages. Dependent on the brush attachment selected, the appliance can also be used to vacuum furniture. All further use is deemed as not intended and is prohibited. The appliance is not suitable for the removal of dangerous dust or liquid.
The appliance and its accessories do not have any moisture protection. Only use it in dry indoor rooms.
1.3 Predictable misuse
All different use or use above and beyond the intended use is deemed as unintended use.
The manufacturer is not liable for damages resulting from this. In case of alterations or incorrect assembly, installation, commissioning, operation, servicing or repairs, the manufacturer assumes no liability.
Exclusively original parts from the manufacturer are permissible as spare parts and accessories. Spare parts and accessories not delivered by the manufacturer are not tested for operation and may influence operational safety. The manufacturer assumes no liability for damages arising from the use of non-permissible spare parts and accessories.
Reasonably predictable misuse includes in particular:
• Operation without a collecting vessel
• Operation with an incorrection positioned collecting vessel
- Out door use and/or use in the rain
- Operation with incorrect operation: Vacuuming unwanted items off humans and animals. In particular, fur, hair, fingers and other parts of the body
• Operation with a floor nozzle above head height
• Operation without a brush roller
• Operation with an open lid
• Operation without a filter
2 Safety instructions
2.1 Basic safety measures
If you abuse the following basic safety measures, this may result in severe injury to persons or damages to property!
- The product:
- Use exclusively in accordance with the intended purpose
- Never commission despite recognisable damages
- Never make technical alterations
- Never operate when incompletely assembled
- Never operate without the required covers
- The safety measures are the prerequisite for safe, disturbance-free operation and for the achievement of the specified product properties.
2.2 Structuring warning information
Safety information protects against injury to persons or damages to property. The measures described for risk avoidance must be adhered to.
WARNING
Marks an exceptionally high danger situation. If this information is not observed, severe, irreversible or lethal injuries may be incurred.
ATTENTION
Marks a danger situation. If this information is not observed, minor or moderate injuries may be incurred.
INFORMATION
Marks risk of accidental loss, destruction or deterioration. If this information is not observed, loss, destruction or deterioration may be incurred.
2.3 General safety instructions
WARNING
Danger of explosion, bursting!
Appliance and rechargeable battery are heat-sensitive.
▶ Neither subject the appliance and rechargeable battery to fire nor to temperatures exceeding 45^ C.
WARNING
Danger of suffocation, choking!
It is possible that packaging material and small parts can be inhaled, swallowed or misused for playing with.
▶ Secure packaging and small parts against use.
3 Prepare use
Follow the instructions listed to prepare the appliance for use.
- Check the network adapter cable for possible damages prior to use.
- Never use a network adapter with a damaged plug or cable.
- Only connect the network adapter to sockets which use the electrical voltage defined on the network adapter.
- In case of incorrect treatment of rechargeable batteries, risk of injury exists.
- Only use the charger provided to charge the rechargeable battery pack.
3.1 Unpacking
The packaging protects the vacuum cleaner against transport damages. Keep the packaging for transport purposes. Disposal information is provided at the end of the instructions.
Follow the action steps listed to unpack the appliance.
- Unpack the appliance and its accessory components.
- Check the completeness and intactness of the unpacked contents.
In case of transport damages or missing parts, turn to your dealer without delay.
3.2 Become acquainted with the displays
The appliance has an LED display (Fig. 1, p. 2, no. 11) on the handle with the following functions:
Charge control lamp
- Flashes when the rechargeable battery is being charged
- Is permanently lit when the rechargeable battery is charged
Battery display
- Is lit, dependent on the appliance's charge status
- If the appliance is fully charged, five LEDs are lit
3.3 Assembly
3.3.1 Assembling the wall mount
- Hold the wall mount (Fig. 1, no. 16) on the wall and mark two holes at the attachment points.
- Drill two holes ( approx. 8 mm) at the locations marked and insert the two dowels provided into the drill holes.
- Attach the wall mount using the two screws provided.
3.3.2 Assembling the handle
Before you assemble one of the nozzles, you must assemble the handle.
- Insert the handle (Fig. 1, no. 8) into the upper end of the suction tube (Fig. 1, no. 6) until the adapter engages audibly and noticeably.
3.3.3 Assembling the nozzles
ATTENTION
Danger of injury!
Unintended activation of the appliance may result in injury.
▶ Switch the appliance off before assembling the nozzles.
▶ Secure the appliance against unintended activation before assembling the nozzles.
INFORMATION
Property damages!
Incorrect use of the nozzles may result in damaging your flooring.
▶ Before vacuuming, inform yourself regarding the requirements of your flooring. Observe the recommendations made by the flooring manufacturers.
Assembling the floor nozzle
- Insert the floor nozzle (Fig. 1, no. 1) onto the lower end of the suction tube (Fig. 1, no. 6) until it engages audibly and noticeably.
Exchanging the floor nozzle brush
The electrical floor nozzle can be operated with two different brush rollers
• Universal brush roller (Fig. 1, no. 21)
- Special brush (Fig. 1, no. 22) for sensitive floors, hair and animal hair
Follow the action steps listed to exchange the brush.
- Press the lower locking mechanism on the lower end of the suction tube (Fig. 1, no. 6) to release the floor nozzle (Fig. 1, no. 1).
- Pull the floor nozzle off the suction tube.
- Release the brush locking mechanism on the side of the floor nozzle. If the locking mechanism cannot be released, use a coin as a help (Fig. 3A "Cleaning", p. 119).
- Remove the inserted brush (Fig. 3B).
- Insert the desired brush.
- Close the locking mechanism.
- Insert the floor nozzle onto the lower end of the suction tube.
Assembling further nozzles
You can extend the functional scope of your appliance by exchanging the floor nozzle.
In addition to the floor nozzle, an electrical upholstery and mite brush (Fig. 1, no. 18), a crevice nozzle (Fig. 1, no. 19) and a combined upholstery and furniture nozzle (Fig. 1, no. 20) belong to the scope of delivery of your appliance.
- Electrical upholstery and mite brush (Fig. 1, no. 18): Use the electrical upholstery and mite brush to brush out fibres and mites and to ease cleaning upholstery and furniture.
- Crevice nozzle (Fig. 1, no. 19): Use the crevice nozzle to vacuum dust out of locations which are difficult to access.
- Combined upholstery and furniture nozzle (Fig. 1, no. 20): Use the upholstery and furniture nozzle to remove dust from items with sensitive surfaces.
Follow the action steps listed to assemble other nozzles.
- Press the lower locking mechanism on the lower end of the suction tube (Fig. 1, no. 6) to release the floor nozzle (Fig. 1, no. 1).
-
Pull the floor nozzle off the suction tube.
-
Insert the desired nozzle onto the end of the suction tube until it engages audibly and noticeably.
The accessory nozzles can alternatively be attached to the handle.
3.3.4 Charging the rechargeable battery
WARNING
Risk of electric shock!
In case of non-intended use or damages, short-circuits and contact with dangerous voltages may occur.
▶ Test the appliance and accessories for damages, in particular the mains adapter before all work on or with the appliance.
▶ Only operate the appliance and its accessories in a perfect state.
ATTENTION
Danger of short circuit of the rechargeable battery!
▶ Never contact both poles simultaneously with electrically conducting items.
▶ Do not immerse the rechargeable battery in liquid.
INFORMATION
Property damages and loss of warranty!
The product is only approved for use with the mains adapter provided.
▶ Only use the mains adapter provided.
INFORMATION
Property damages!
The mains adapter and cable are prone to damages.
▶ Only unplug the mains adapter from the connector casing and never at the cable from the wall socket.
▶ Neither bend, clamp nor drive over the mains adapter cable.
INFORMATION
Risk of stumbling!
▶ Lay the mains adapter cable safely, avoiding sharp edges and bends.
The appliance is charged with electrical current. Here, the basic danger of an electric shock exists. Therefore, pay attention to the following:
- Check the appliance and mains adapter for damages before use. Never use a faulty appliance or an appliance with a faulty mains adapter.
- Only connect the mains adapter to wall sockets with electrical current equivalent to that defined on the name plate of the appliance.
Charge the rechargeable battery completely prior to initial use. It is best to charge the rechargeable battery before each use, above-all if not used for a longer period. This increases the working life of the rechargeable battery and enables long cleaning cycles.
Charging the rechargeable battery
- Insert the mains adapter plug provided (Fig. 1, no. 17) into the connector socket on the appliance.
- Connect the mains adapter provided to the wall socket.
⇒ The LEDs on the appliance handle (Fig. 1, no. 11) start flashing. The more LEDs which flash the further the charging process has progressed.
- Wait until all the LEDs are lit for five minutes.
⇒ Then, the rechargeable battery is fully charged. - Unplug the mains adapter from the wall socket.
- Unplug the mains adapter plug from the connector socket on the appliance.
4 Operation
WARNING
Risk of electric shock!
Damp and moisture in the appliance may cause contact with dangerous voltage.
▶ Neither touch the appliance nor the mains adapter with wet hands.
▶ Neither immerse the appliance nor the mains adapter in liquid.
▶ Protect the appliance and accessories against moisture.
ATTENTION
Danger of injury!
If you drop the appliance or it falls over accidentally, injuries may be incurred.
▶ Do not drop the appliance when in use.
▶ When not in use, secure the appliance against falling over.
4.1 Vacuum cleaning
WARNING
Danger of injury!
The use of a damaged appliance may result in injury.
▶ Test the appliance prior to each use.
▶ Do not use any damaged appliances.
ATTENTION
Danger of injury!
The installed brush roller rotates at a high speed and can cause injuries.
▶ Do not position yourself beneath the brush roller with any parts of your body.
ATTENTION
Glare!
The LEDs on the floor nozzle cannot be exchanged and illuminate the working area.
▶ Do not stare directly into the LEDs.
INFORMATION
Property damages!
The brush roller can suck in items, damage them or wrap them around itself, resulting in blocking and overheating the motor.
▶ Do not vacuum in the vicinity of cables and leads.
▶ Do not vacuum any shag-pile carpets or loose threads.
INFORMATION
Property damages!
The appliance may be damaged if a filter is incorrectly inserted or blocked.
▶ Ensure that the filter is inserted correctly.
▶ Ensure that no openings are blocked.
▶ Ensure that the filter is intact and dry.
The appliance has an eco mode, a standard mode and a power mode.
- Eco mode: Use eco mode to remove slight soiling. The appliance uses less energy and the rechargeable battery operating time is increased.
- Standard mode: Use standard mode to remove normal soiling.
• Power mode: Use power mode of more suction power is required. The appliance runs at top performance.
4.1.1 Activating eco mode
- Remove the appliance from the wall mount (Fig. 1, no. 16).
- Ensure that the handle and desired nozzle are assembled correctly ("3.3.2 Assembling the handle" on
page 30, "3.3.3 Assembling the nozzles" on page 31).
3. Press the on/off switch (Fig. 1, no. 14). The LEDs on the appliance handle (Fig. 1, no. 11) are lit.
4.1.2 Activating standard mode
- Switch eco mode on for the appliance ("4.1.1 Activating eco mode" on page 36).
- Press the mode selection switch (Fig. 1, no. 12) once to select standard mode.
4.1.3 Activating power mode
- Switch eco mode on for the appliance ("4.1.1 Activating eco mode" on page 36).
- Press the mode selection switch (Fig. 1, no. 12) twice to select power mode.
4.2 Deactivation
- Press the on/off switch (Fig. 1, no. 14). The LEDs on the appliance handle (Fig. 1, no. 11) go off.
4.3 Keeping and storage
ATTENTION
Property damages!
The appliance may be damaged by heat.
▶ Do not place the appliance directly next to heat sources (e.g. heating or ovens.).
▶ Avoid direct insolation.
4.3.1 Keeping the appliance
INFORMATION
Property damages!
Constant charging may damage the appliance.
▶ Do not insert the mains adapter plug provided into the connector socket on the appliance permanently when stored.
- Ensure that the appliance is switched off ("4.2 De-activation" on page 36).
- Hang the appliance on the intended wall mount (Fig. 1, no. 16).
4.3.2 Storing the appliance
Follow the action steps listed to prepare the appliance for longer-term storage.
- Ensure that the appliance is switched off ("4.2 Deactivation" on page 36).
- Empty the dust container („5.1 Emptying the dust container“ on page 38).
- Clean the dust container („5.2 Cleaning the dust container“ on page 39).
- Clean the exhaust filter („5.3 Cleaning the exhaust filter“ on page 40).
4.4 Transport and disassembly
For comfortable transport, you can remove the suction tube from the handle and nozzle used.
- Ensure that the appliance is switched off ("4.2 Deactivation" on page 36).
- Press the locking mechanism on the lower end of the suction tube (Fig. 1, no. 6) to release the handle (Fig. 1, no. 8).
- Pull the handle out of the suction tube.
- Press the locking mechanism on the floor nozzle (Fig. 1, no. 1) to release the floor nozzle from the lower end of the suction tube.
- Pull the nozzle used off the suction tube.
5 Cleaning and maintenance
WARNING
Risk of electric shock!
Damp and moisture in the appliance may cause contact with dangerous voltage.
▶ Neither touch the appliance nor the mains adapter with wet hands.
▶ Neither immerse the appliance nor the mains adapter in liquid.
▶ Protect the appliance and accessories against moisture.
ATTENTION
Danger of injury!
Unintended activation of the appliance may result in injury.
▶ Switch the appliance off before cleaning and maintenance work.
▶ Secure the appliance against unintended activation before cleaning and maintenance work.
5.1 Emptying the dust container
INFORMATION
Property damages!
The dust container can only receive a limited quantity of dirt. The appliance can be damaged by dust.
▶ Empty the dust container regularly, ideally after each use, however at the latest when vacuuming performance worsens significantly.
▶ Observe the MAX marking on the dust container, which must not be exceeded.
Follow the action steps listed to empty the dust container.
- Ensure that the appliance is switched off ("4.2 Deactivation" on page 36).
- Press the upper locking mechanism on the suction tube (Fig. 1, no. 6) to release the handle (Fig. 1, no. 8).
- Pull the handle out of the suction tube.
- Turn the dust container clockwise to release it (Fig. 1, no. 3).
- Remove the dust container from the handle.
- Hold the dust container deep in a dustbin.
- Press the unlocking mechanism (Fig. 1, no. 4) to open the dust container lid (Fig. 1, no. 2). The dust container lid opens and the dust drops into the dustbin.
- Beat the dust container empty gently.
- Use a dry cloth or a brush with soft bristles to remove dust deposits from the dust container.
- Close the lid of the dust container.
- Place the dust container on the handle. For this, turn the dust container anticlockwise into the locking mechanism until it engages audibly and noticeably.
- Check the correct positioning of the dust container.
5.2 Cleaning the dust container
INFORMATION
Loss of vacuuming performance!
The cyclone unit and inner filter may become blocked during use. Vacuuming performance deteriorates.
▶ Clean the dust container, the cyclone unit and internal filter regularly, however at the latest when vacuuming performance worsens significantly.
▶ If necessary, replace the internal filter in order to retain maximum vacuuming performance.
Follow the action steps listed to clean the dust container.
- Ensure that the appliance is switched off ("4.2 Deactivation" on page 36).
- Empty the dust container („5.1 Emptying the dust container“ on page 38).
-
Leave the dust container (Fig. 1, no. 3) dismantled.
-
Pull the cyclone unit (Fig. 1, no. 5) together with the internal filter (Fig. 1, no. 7) out of the part of the dust container located on the handle (Fig. 2A "Cleaning", p. 119).
- Remove the internal filter from the cyclone unit (Fig. 2B).
- Beat both filters above the dustbin and rinse the filters using clear water (Fig. 2C).
- Let the filters dry completely in the fresh air or on a radiator (Fig. 2D). Let the filters dry for at least 24 hours on a radiator. Drying in the fresh air may take up to 72 hours. If necessary, use replacement filters during this period. They can be ordered on the Internet or via our service department ("6 Spare parts and accessories" on page 42).
- Insert the internal filter into the cyclone unit.
- Place the cyclone unit back into the part of the dust container located on the handle until it is firmly positioned.
- Place the dust container on the handle. For this, turn the dust container into the locking mechanism until it engages audibly and noticeably.
- Check the correct positioning of the dust container.
5.3 Cleaning the exhaust filter
INFORMATION
Property damages!
The exhaust filter can be damaged by water and heavy soiling.
▶ Clean the exhaust filter only dry by beating it and brushing it carefully.
▶ Clean the filter regularly, however at the latest when vacuuming performance worsens significantly.
Follow the action steps listed to clean the exhaust container.
- Press the exhaust filter locking mechanism (Fig. 1, no. 15), to release it.
- Remove the exhaust filter.
- Beat the exhaust filter empty.
- Brush the exhaust filter carefully with a soft brush (e.g. the furniture brush provided within the scope of delivery).
- Re-insert the exhaust filter into the appliance. Press the exhaust filter for it into position until it engages audibly.
5.4 Cleaning the brush roller
INFORMATION
Property damages!
Soiling can influence the rotation of the brush roller.
▶ Clean the brush roller regularly.
Follow the action steps listed to clean the brush roller.
- Ensure that the appliance is switched off („4.2 De-activation“ on page 36).
- Press the lower locking mechanism on the lower end of the suction tube (Fig. 1, no. 6) to release the floor nozzle (Fig. 1, no. 1).
- Pull the floor nozzle off the suction tube.
- Release the brush locking mechanism. If the locking mechanism cannot be released, use a coin as a help (Fig. 3A "Cleaning", p. 119).
- Remove the brush roller (Fig. 3B).
- Free the brush roller of dirt. If the dirt cannot be removed, use tweezers or a pair of scissors.
- Insert the cleaned brush roller into the floor nozzle.
-
Close the locking mechanism.
-
Insert the floor nozzle onto the lower end of the suction tube.
5.5 Replacing the rechargeable battery
ATTENTION
Detrimental to health!
In case of unintended use or overageing, the rechargeable battery may lose acidic liquid.
▶ Use protective gloves for cleaning and disposal and avoid skin contact with rechargeable battery liquid.
▶ Rinse parts of the body with contact using water.
▶ In case of after-effects, consult a physician.
ATTENTION
Danger of short circuit of the rechargeable battery!
▶ Never contact both poles simultaneously with electrically conducting items.
▶ Do not immerse the rechargeable battery in liquid.
Follow the action steps listed to replace the rechargeable battery.
- Ensure that the appliance is switched off ("4.2 Deactivation" on page 36).
- Press the rechargeable battery locking mechanisms (Fig. 1, no. 13) together.
- Pull the rechargeable battery out of the rechargeable battery compartment (Fig. 1, no. 10).
- Insert the new rechargeable battery („6 Spare parts and accessories“ on page 42) into the rechargeable battery compartment.
- Close the rechargeable battery compartment.
- Check the correct positioning of the rechargeable battery.
6 Spare parts and accessories
You can order spare parts and accessories for the 2-in-1 battery-operated vacuum cleaner hoogo S4 in the Internet under www.hoogo.world or via our service ("International Services" on page 1).
| Accessory/Spare part Order number | |
| Motor protection filter | SC402045 |
| Exhaust filter | SC402040 |
| Battery 25.2 V | SC402065 |
| Mains adapter | SC402075 |
| Brush roller (universal) | SC402010 |
| Brush roller (for delicate floors and hair) | SC402011 |
7 Rectification of faults
WARNING
Risk of electric shock!
Damp and moisture in the appliance may cause contact with dangerous voltage.
▶ Neither touch the appliance nor the mains adapter with wet hands.
▶ Neither immerse the appliance nor the mains adapter in liquid.
▶ Protect the appliance and accessories against moisture.
ATTENTION
Danger of injury!
Unintended activation of the appliance may result in injury.
▶ Switch the appliance off before rectifying faults.
▶ Secure the appliance against unintended activation before rectifying faults.
The appliance may only be used if it is fully in order. If the appliance or part of it is faulty, it must be decommissioned and expertly repaired or disposed of.
Try to rectify minor faults yourself. Observe the pertinent safety regulations in the operating instructions here.
If the fault cannot be rectified, decommission the appliance and inform the manufacturer's qualified staff for fault rectification (International Services" on page 1).
The following table shows an overview of the most important faults as well as their possible causes and rectification measures.
| Problem Possible cause Solution | ||
| The appliance cannot be switched on. | The rechargeable battery is fully empty. | Switch the appliance off and charge the rechargeable battery („3.3.4 Charging the rechargeable battery" on page 32). |
| The brush roller rotates slowly and/or unevenly. | The brush roller is soiled. | Clean the brush roller regularly („5.4 Cleaning the brush roller" on page 41). |
| The appliance cannot be charged. The LEDs are not lit. | The mains adapter is not correctly inserted. | Check whether the mains adapter plug and the mains adapter are correctly in their sockets. |
| The rechargeable battery is not correctly inserted in the appliance. | Disconnect the mains adapter and check whether the rechargeable battery is correctly placed in the appliance. Reconnect the mains adapter. | |
| The appliance only cleans a little of the dirt. | The dust container is overfilled. | Empty the dust container („5.1 Emptying the dust container" on page 38). |
| The filters are soiled. | Clean the filters („5.2 Cleaning the dust container" on page 39). | |
| The nozzle used is inappropriate for the surface. | Use the fitting nozzle for your surface („3.3.3 Assembling the nozzles" on page 31). | |
| An odour develops and/or dust is lost from the appliance when vacuuming. | Parts of the dust container of accessories disman-tled for filter cleaning or changing accessories were not correctly reinstalled or closed. | Check all parts for a firm fit and hold. |
8 Disposal
ATTENTION
Detrimental to health!
In case of unintended use or overageing, the rechargeable battery may lose acidic liquid.
▶ Use protective gloves for cleaning and disposal and avoid skin contact with rechargeable battery liquid.
▶ Rinse parts of the body with contact using water.
▶ In case of after-effects, consult a physician.
INFORMATION
Environmental danger!
The rechargeable battery may not be disposed of as domestic waste.
▶ Dispose of the rechargeable battery after removal at regional collection points designated for this purpose.
Warranty
This appliance is marked in accordance with the requirements of Directive 2012/19/EU for Waste Electrical and Electronic Equipment - WEEE.
The Directive provides the framework for an EU-wide take-back and recovery of the old appliances.
This appliance was manufactured from recyclable or reusable materials. Its disposal must be made in accordance with the local regulations for waste management. Make the appliance unusable prior to scrapping buy cutting off the power supply cable. You can request further information regarding the treatment, recovery and reuse of electrical appliances from the local waste disposal company, the next recycling centre or your dealer where you purchased the appliance.
The packaging protects the appliance against transport damages. The packaging materials are selected in accordance with environmentally compatible and technical disposal criteria and therefore recyclable. Dispose of these also in an environmentally compatible manner and homogeneously in the collection systems provided.
9 Warranty
INFORMATION
If you incur problems with the appliance, please call the service centre.
Our products are subject to stringent quality control. Should this appliance nonetheless not function faultlessly, we regret this deeply and request you to turn to the service address provided. Our service hotline is also happy to help you on the telephone. The following applies for the assertion of warranty claims – without your legal rights being restricted:
- You can only stake warranty claims within a max. period of 2 years as of the purchase date. Our warranty service is restricted to the rectification of material and manufacturing faults or replacement of the appliance. Our warranty service is free of charge to you.
- Warranty claims must be staked respectively without delay after gaining knowledge of them.
- The assertion of warranty claims after the warranty period has elapsed is excluded unless the warranty
claims are made within a period of 2 weeks after expiry of the warranty period.
- Please send faulty appliances with the warranty card and the receipt post-paid to the service address. If the fault lies within the scope of our warranty service, you will receive a repaired or new device back. No new warrant period begins with the repair or replacement of the appliance. The warranty period of 2 years as of the date of purchase remains decisive. This also applies in case of on-site service.
Please observe that our warranty is null and void in case of abusive or incorrect treatment, failure to observe the valid safety precautions for the appliance, use of force or intervention not carried out by the service address authorised by us. We rectify faults or damages to the appliance not (or no longer) covered by the warranty against reimbursement of the costs. Please turn to our Service Centre for this. It is only necessary to return the appliance to our service address if the service hotline is unable to solve the problem.
9.1 Warranty
The respective implementation of EU Directive 2011/83/EU as national law is the valid minimum warranty standard in as far as you purchased the appliance as a consumer within the European Union.
The valid minimum warranty rights in the respective country are valid for non-EU countries. Batteries and rechargeable batteries which show faults due to normal wear and tear or incorrect handling or whose period of use has been reduced are excepted from warranty.
We reserve the right to make technical and design alterations within the scope of constant product improvements.
© Mytek GmbH
Légende
Sinninger Straße 44, 48282 Emsdetten, Germany
T:+49 2572 96 70 355
info@mytek.org
