USER MANUAL STELO WRK2000 Eldom

Black kitchen stand mixer with whisk inside a bowl, no visible text or symbols

/EN/ The disposal of used electrical and electronic equipment (applies to European Union countries and other European countries with separate waste-collection systems).

This symbol on the product or its packaging indicates that it should not be classified as household waste. It should be handed over to an appropriate company dealing with the collection and recycling of electrical and electronic equipment. The correct disposal of the product will prevent potential negative consequences for the environment and human health resulting from hazardous substances present in the product. Electrical devices must be handed over to restrict their re-use and further treatment. If the device contains batte ries, remove them, and hand them over to a storage point separately. DO NOT THROW EQUIPMENT INTO THE MUNICIPAL WASTE BIN. Material recycling helps to preserve natural resources. For detailed information on how to recycle this product, please contact your local authority, the recycling company, or the shop where you bought it.

Technical diagram showing three views of a kitchen mixer with labeled parts and directional arrows indicating motion.

Three-step line drawing of a kitchen mixer with control panel, showing step-by-step assembly (no text or symbols)

WSKAZÓWKI BEZPIECZEŃSTWA

IMPORTANT: When using an electrical appliance, basic safety precautions should always be followed to reduce the risk of fire, electric shock and/or personal injury, including the following.

Carefully read the entire contents of this manual before first use.

Keep all warnings and safety instructions for future reference.

1. Connect the connection cable to an outlet with the parameters as specified in the manual.
2. Take care not to include too many consumers in one circuit of electricity.
3. Always disconnect the device from the mains by pulling the plug, not the power cord.
4. Do not immerse the cord or the device in water.
5. The device is intended for domestic use only.
6. Remove and safely discard all packaging materials and labels before using the device for the first time.
7. Do not use outdoors.
8. Do not leave children unattended near the device.
9. Do not place the device or run the power cord near heat sources.
10. Before turning on the device, make sure that all its components are properly installed.
11. Do not open the base arm (5) while the device is in operation.
12. Do not touch the installed cap while the device is in operation, and you can only touch it after it has been switched off from the mains.
13. Do not exceed the permissible continuous operation time of the device.

14. Always turn off the device from the power supply when finished working.

15. Do not grip the device with wet hands.

16. Unplug the device from the mains before cleaning.
17. The device can only be used with the originally attached accessories.
18. This equipment may be used by children at least 8 years old and by persons with reduced physical and mental abilities and persons with inexperience and lack of familiarity with the equipment, if supervision or instruction is provided on how to use the equipment in a safe manner, so that the associated risks are understood. Children should not play with the equipment. Unsupervised children should not perform cleaning and maintenance on the equipment.
19. The equipment should not be left unattended when in use. Children should be supervised to ensure that they do not play with the equipment.
20. Do not place the device near the edge of a bench or table during operation. Make sure the surface is level, clean and free of water and other substances. Vibration during operation may cause the device to move.
    21.Do not use the device on a sink drainer.
21. Be careful when removing food from the bowl, making sure that the motor and mounted attachment are completely stopped.
22. The mounted cap should be released from the head before removing food from the bowl.
23. Always make sure the speed dial is in the "0" position and unplug from the electrical outlet before attempting to move the unit, before assembling or disassembling it when not in use, and before cleaning or storing it.
24. Ensure that the arm is locked in the closed (horizontal) position when the unit is not in use and before storing.

25. Do not place any part of the appliance in the microwave oven.

26. Do not use the device for purposes other than those described in the instructions to avoid injury from improper use.

27. Fully unravel the power cord before use.
28. Do not use if the power cord is damaged, if the appliance has fallen or otherwise been damaged.
29. Only an authorized service center can repair the equipment. Any upgrades or use of other than the original spare parts or components of the device is prohibited and endangers the safety of use.
30. Eldom Sp. z o. o. shall not be held responsible for any damage caused by improper use of the device.

WARNING:

Before connecting the tips, make sure that the speed dial is in the "0" position and the cord is not plugged into the power outlet.

WARNING: Plastic bag can be dangerous, to avoid danger of suffocation keep this bag away from babies and children.

EN

1. Variable speed switch
2. Lock button
3. Base
4. Head
5. Base arm
6. Cover
7. Mixing attachment
8. Kneading attachment
9. Whisking attachment
10. Spatula
11. Bowl

TECHNICAL DATA

— power: 1900 W
– maximum power (MBP): 2200 W
– supply voltage: 220-240 V\~ 50-60 Hz
– max. time of continuous operation: 10 minutes
– time before recommencing operation: 20 minutes
- bowl capacity: 6,2 litres

The speed range depends on the type of socket used - fig.1.

INTENDED USE OF PLANETARY MIXER ELDOM WRK2000

Different speeds, attachments for kneading and mixing dough, and for whisking make this planetary mixer an indispensable aid in many time-consuming and cumbersome kitchen tasks. The processor is efficient, durable, easy to use and to keep clean, as well as safe, provided that the SAFETY TIPS are observed.

INSTALLATION

Before using the unit, make sure that the unit, plug and power cord are in working order and that all parts of the packaging have been removed.

• place the unit on a flat, firm and stable surface,
• make sure the unit is unplugged and the on/off switch (1) is in the "0" position,
- press the locking button (2) and tilt the base arm (5) until it locks in place (fig. 2),
• install the cover (6) onto the base arm (5) from below (fig. 3),
- place the bowl (11) on the base (3) in its designated place and lock it by turning to the right,
- install one of the attachments (7, 8, 9) on the head (4) - to do this, slide the attachment onto the head and lock it by turning to the left (fig. 5, 6),
• press the button (2) and lower the base arm (5) (fig. 7).

HOW TO USE

• before commissioning, ensure that all components are correctly assembled,
- connect the appliance to a power supply conforming to the parameters given above,
- the robot starts working when the speed is selected with the switch (1), by changing its position you can obtain 6 different speeds,
- the appliance is equipped with a "slow start" function, which means that it reaches the appropriate speed after a few seconds,
- products can be added either before the bowl is mounted on the base or while the appliance is running, through the dedicated opening in the lid (6).

NOTE

Choose the correct speed depending on the attachment used - pic. 1.

The speed should also be matched to the consistency of the products being processed.

• when you have finished working, turn the switch (1) to position "0" and wait for the attached attachment to stop,
  • then swivel the base arm (5) by pressing the locking button (2),

NOTE

Be careful when opening the base arm (5).

It is advisable to hold it from above so that it does not open too abruptly.

• remove the cap by turning it to the right,
• unlock the bowl (11) by turning it to the left and remove it from the base (3).

NOTE

The appliance will not switch on if the base arm (5) is not lowered and locked.

The unit will also not switch on if the switch (1) is not in the "0" position when the arm (5) is lowered. To switch on the robot in this situation, turn the switch (1) first to the "0" position after lowering the arm and then select the speed.

Raising the base arm (5) during operation will stop the unit.

NOTE

The continuous running time of the appliance must be observed.

Exceeding the running time and not taking sufficient breaks from the appliance may lead to irreparable damage to the motor and void the warranty.

If the appliance is blocked during operation, before cleaning, disconnect it from the mains. and wait for the mounted attachment to stop.

• If the device slows down while blending or whisking, stop operation and dilute the blended or whisked product if possible.
• To prevent products from spilling out of the bowl during blending, do not fill it beyond 2/3 of its capacity. Place the device on a flat, firm, stable surface.
• Remove the lid (6) when finished working.

CLEANING AND MAINTENANCE

• Clean the device immediately after use.
- Before cleaning, turn off the device (turn the switch (1) to the "0" position) and unplug it from the mains.
• Never immerse the device in water or rinse it under a stream of running water.
• The outer surfaces can be cleaned with a damp cloth and then wiped dry.
• Do not use abrasives, cleaning powders, acetone, alcohol, etc. to clean the device.
- Clean accessories with water and a little dishwashing liquid and rinse thoroughly under running water.
• The accessories (6, 7, 8, 9, 10, 11) are dishwasher safe, placing them away from the heater.

The maximum temperature is 50°C.

STORAGE

• Store the device cleaned and dry, out of the reach of children.

WARRANTY

• This appliance is designed for domestic use only.
• It cannot be used for professional purposes or for other than the intended use.
• Improper use will nullify the guarantee.
