95.2019.54 - Measuring equipment TFA - Free user manual and instructions

Product type	Digital thermo-hygrometer
Brand	TFA
Model	95.2019.54
Housing dimensions	61 x 24 (31) x 61 (65) mm
Weight	44 g (device only)
Power supply	1 x 1.5 V AAA battery (not included)
Temperature measurement range	0°C to +50°C
Temperature accuracy	±1°C
Humidity measurement range	10 to 99 % rH
Measurement update	Every second
Display	Digital screen with temperature (top) and humidity (bottom)
Commissioning	Remove the protective film, open the battery compartment, insert the battery
Placement	Magnetic bracket for wall mounting or placement on a flat surface
Maintenance and cleaning	Soft, damp cloth, without solvents or abrasives
Safety instructions	Keep batteries out of reach of children, do not disassemble or repair yourself, do not expose to extreme temperatures
Spare parts and repairability	No spare parts available, device not user-serviceable
Waste disposal	Do not dispose of device and used batteries in household waste, take to a recycling center
Intended use	Indoor temperature and humidity measurement

Frequently Asked Questions - 95.2019.54 TFA

How to install the battery in the TFA 95.2019.54 thermo-hygrometer?

Open the battery compartment on the back of the device. Insert a 1.5 V AAA battery, observing the indicated polarity (+/-). Close the compartment. The device turns on automatically.

What to do if the screen shows nothing?

First check the battery polarity. If the screen remains blank, replace the battery with a new 1.5 V AAA.

How to mount the device on the wall?

Use the included magnetic bracket. Clean the surface, then attach the adhesive to the back of the bracket. Place the bracket at the desired location. The device attaches magnetically to the bracket.

What is the temperature measurement range?

The temperature measurement range is 0°C to +50°C with an accuracy of ±1°C.

What do the displays 'LL' or 'HH' mean?

The displays LL or HH indicate that the measured value is outside the measurement range. For example, LL for temperature too low, HH for too high.

How to clean the device?

Use a soft, damp cloth. Do not use solvents or abrasive products that could damage the screen or housing.

Can the device be used outdoors?

No, this device is designed for indoor use only. Avoid exposure to moisture and extreme temperatures.

How to dispose of the device at end of life?

Do not dispose of the device or batteries in household waste. Take them to a recycling center or an approved collection point in accordance with WEEE regulations.

Is it possible to repair the device yourself?

No, the device must not be disassembled or repaired by the user. Any unauthorized intervention voids the warranty. In case of issues, contact customer service.

What is the measurement update frequency?

The temperature and humidity measurements are updated every second, providing real-time display.

USER MANUAL 95.2019.54 TFA

Kat. Nr. 30.5051

CE

RoHS

Technical line drawing of a device casing with internal components and a side view (no text or symbols)

Position Option 2

Digitales Thermo-Hygrometer

Thank you for choosing this product from TFA.

1. Before you start using it

• Please make sure to read the instruction manual carefully.
• Following and respecting the Instructions in your manual will prevent damage to your instrument and loss of your statutory rights arising from defects due to incorrect use. We shall not be liable for any damage occurring as a result of non-following of these instructions.
• Likewise, we take no responsibility for any Incorrect readings and for any consequences which may result from them.
• Please take particular note of the safety advice!
• Please keep this instruction manual for future reference.

2. For your safety

• The device should only be used as described within these instructions.
• Unauthorized repairs, modifications or changes to the product are prohibited.

Digital thermo-hygrometer

Caution! Risk of injury:

• Keep this device and the battery out of the reach of children.
• Batteries contain harmful acids and may be hazardous if swallowed. If a battery is swallowed, this can lead to serious internal burns and death within two hours. If you suspect a battery could have been swallowed or otherwise caught in the body, seek medical help immediately.
• Batteries must not be thrown into a fire, short-circuited, taken apart or recharged. Risk of explosion!
• Low batteries should be changed as soon as possible to prevent damage caused by leaking. Wear chemical-resistant protective gloves and safety glasses when handling leaking batteries.

Important information on product safety!

- Do not place your device near extreme temperatures, vibrations or shocks.

• Clean the instrument with a soft damp cloth. Do not use solvents or scouring agents.
• Protect it from moisture.

3. Getting started

• Remove the protective foil from the display.
• Remove the magnetic holder.
• Open the battery compartment and insert a new battery 1,5 V AAA, ensure that the batteries' polarities are correct. Close the battery compartment again.
• All segments will be displayed for a short moment.
  • The device is ready for use.
• The upper display will show the indoor temperature.
• The lower display will show the indoor humidity.
• Remove the battery to shut down the device.

4. Positioning and fixing

• Fix the magnetic holder with the enclosed adhesive at your desired location. Please clean the surface before.
• The device can also be positioned on a flat surface by securing the holder to the bottom.

Digital thermo-hygrometer

5. Troubleshooting

Problems Solutions

No display Ensure that the battery polarity is correct Change the battery

Incorrect indication → Change the battery

Indication LL/HH → Outside measuring range

6. Waste disposal

Never dispose of empty batteries and rechargeable batteries in household waste.

As a consumer, you are legally required to take them to your retail store or to an appropriate collection site depending on national or local regulations in order to protect the environment.

The symbols for the heavy metals contained are: Cd=cadmium, Hg=mercury, Pb=lead

This instrument is labelled in accordance with the EU Waste Electrical and Electronic Equipment Directive (WEEE).

Please do not dispose of this instrument in household waste. The user is obligated to take end-of-life devices to a designated collection point for the disposal of electrical and electronic equipment, in order to ensure environmentally-compatible disposal.

1. Specifications

TemperatureMeasuring range -10°C... +50 °CAccuracy ±1°C

HumidityMeasuring range 10 ... 99 %rHAccuracy ±5 % @ (20...80%)

Update Every second

Power consumption 1,5 V AAA battery(not included)

Dimensions 61 x 24 (31) x 61 (65) mm

Weight 44 g (instrument only)

Digital thermo-hygrometer

No part of this manual may be reproduced without written consent of TFA Dostmann. The technical data are correct at the time of going to print and may change without prior notice.

The latest technical data and information about this product can be found in our homepage by simply entering the product number in the search box.

www.tfa-dostmann.de 07/19

Précision ±5 % @ (20...80%)
