USER MANUAL 45071 KORONA

Modern kitchen grater with various dishes and a digital controller (no visible text or symbols)

KORONA electric GmbH, Sundern/Germany

www.korona-electric.de

Before use, please read these instructions carefully and keep them in a safe place for future reference. When passing on the appliance to a third party, make sure to include these instructions for use.

This appliance is only intended for broiling, au gratin and keeping foods warm. This appliance is only intended for private household use!

Safety:

This symbol identifies hazards which may cause injuries!

This symbol warns of hot surfaces. Risk of burns!

This symbol identifies electric shock hazards!

General Safety Instructions

• Manufacturer takes no responsibility for any damage caused by incorrect use.
• Incorrect or improper use can damage the appliance and cause injuries to the user.
• Before connecting this appliance to the mains, make sure your local voltage matches the technical data of the appliance. Otherwise the appliance may overheat and get damaged.

Caution! Danger of electric shock!

• Never put the appliance, cord or plug into water or any other liquid.
  • Do not use the appliance near a sink or wash basin.
  • Do not use the appliance with wet hands.
• Do not use the appliance outdoors.

An electric appliance is not a toy!

• Never leave the appliance unattended during use.
• This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning the use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children unless they are older than 8 and supervised.
• Keep the appliance and its cord out of reach of children less than 8 years.
• Always unplug your appliance when it is not in use, and before cleaning.
  • Always pull the plug – not the cord.
• Keep the appliance and the cord well away from any hot surfaces to avoid any damage to the appliance.
• Make sure the cord may not inadvertently be pulled or cause anyone to trip when in use. Do not allow the cord to hang over sharp edges.
• Do not bend the cord or wind it round the appliance.

Do not use the appliance,

• if the cord is damaged.
• in case of malfunction.
- if the appliance was dropped or is damaged otherwise. Have it checked and, if necessary, repaired by a qualified person/Customer Service. Never attempt to make any modifications to or repair the appliance yourself.
- Only use accessories evaluated for use with this appliance.
- Never attempt to drive any objects into the appliance.
• Never attempt to open the housing yourself!
- The appliance is not intended to be operated by means of an external timer or separate remote-control system.

Special Safety Instructions

Warning! To avoid the possibility of injury/damage to the appliance, electric shock, fire, and risk of burns!

• Only use the appliance for its intended purpose and as described in this manual.
• Place the appliance on a table or an even and heat-resistant surface. We recommend to use a heat resistant support in order to protect the table from grease splatters.
• Do not place it on top of a metal surface.
• Attention: The temperature of accessible surfaces may be high during operation. Therefore, do not touch the appliance during and/or immediately after operation. Only use the resp. handles. Danger of serious burns!

• When preparing foods, always use the provided wooden spatula or a heat resistant plastic spatula. Never use any sharp or metal objects (e.g. knife, metal spatula, etc.) as they would damage the non-stick coating of the grill plate and the raclette pans.

• Bring meat to room temperature, before cooking.

• Attention: If you use a big amount of cold resp. frozen meat on the grill plate it could occur that the grill plate might momentarily deform. After a few seconds, the grill plate will return to its original form. This is no default, but triggered by the big difference in temperature.

- Do not place any frozen or pickled foods on the hot stone.

• Never soak the stone plate in water.

- Do not touch the accessible heating elements. Danger of serious burns.

- Do not move the appliance during operation.

- Do not use the appliance close to or under inflammable objects, e.g. table cloth, curtains, wall cabinets.

- Do not leave appliance unattended while in use.

- Make sure that the equipment is kept in a well ventilated place.

- Attention: Foods with a high oil and fat content might easily ignite and catch fire.

- Do not place any heat sources and magnetic objects near or on top of the appliance and make sure that the surrounding environment shall be dry and free of damp.

- Do not connect any other household appliances to the same receptacle / multiple receptacle, as in an emergency the plug must be quickly accessible.

- Always unplug the appliance after use and let it completely cool down before cleaning.

Product Description

Labeled diagram of a grater with food preparation and kitchen equipment, showing numbered components from top to bottom.

1. Removable grill plate
2. Removable stone plate
3. ON / Off switch with indicator light
4. Rotating base
5. Raclette pans with heat insulated handles
6. Base for raclette pans
7. Heating element
8. Support for grill plate / stone plate
9. Power cord and plug
10. Wooden spatula

Before First Use

• Remove all packaging material and check whether the appliance is complete and undamaged.
  • Completely unwind the power cord (9).
• Do not use the appliance if it shows any sign of damage.
• Clean the grill plate (1), grill stone (2) and the raclette pans (5) according to “Cleaning and Care”.

Warning: Plastic bags are a danger to toddlers and babies, therefore keep them away to avoid on.

Protective coating

The grill plate (1) and the raclette pans (5) do have a protective coating. Apply some oil on the grill plate (1) and raclette pans (5) using a brush or a piece of paper kitchen towel. Place the raclette pans (5) inside the appliance and heat up the appliance, without food, for approx. 10 minutes.

This could cause a slight build-up of smoke and odour. This doesn't cause any harm nor does it mean that your appliance does not work properly. Make sure that the room is well ventilated!

Afterwards, let the appliance and accessories completely cool down and clean them according to "Cleaning and Care".

Raclette

Raclette is the perfect way to gather family and friends around the table for a delicious, casual dining experience. Prepare your individual typical Swiss raclette cheese meal or make your own creations.

Stone plate

Attention: The stone plate (2) needs approx. 20 - 30 minutes to heat up.

The stone plate (2) is a natural and food safe product.

Small cracks, which can occur due to the natural expansion of the stone during the heating up process, do not have any impact on the usage resp. function of the stone plate (2).

Apply heat-resistant vegetable oil to the stone plate (2) before first use and every other use thereafter. This procedure will not only avoid that the foods will stick to the stone plate (2), but will also increase the life span of it.

Sprinkle some salt onto the stone plate (2), that way the meat won't stick to it.

After continuous usage, the color of the stone will become darker.

Operation

Due to its 180 degree rotation ability, the appliance is perfect to be used as a compact grill in the middle of a small table or if unfolded to double length, but half as wide, on a longer table. Even corner tables are no longer a problem.

Or

Just use the raclette grill halves on their own.

The temperature of accessible surfaces may be high during operation. Therefore, do not e appliance during and/or immediately after operation.

Tip: Before switching on the appliance, prepare all ingredients in advance in bite size portions and arrange them in bowls or on a platter, in order for everyone to serve themselves.

Attention: Bring meat to room temperature, before cooking.

1. Place the raclette grill in the middle of the table.

Attention: Make sure that the appliance is properly placed onto the contact unit of the rotating base (4), otherwise it cannot be switched on.

1. Make sure that the grill plate (1) and stone plate (2) are properly fitted onto the appliance and that the smooth side of the stone plate (2) is facing upwards.
2. Apply some oil on the grill plate (1) and the raclette pans (5).
3. Connect the appliance to a properly installed and easily accessible socket.
4. Press the On/Off switch (3) to switch on the appliance. Heat the appliance up for approx. 10 minutes.

Attention: The stone plate (2) needs approx. 20 - 30 minutes to heat up.

After this heating up process, the appliance is ready to use.

1. Fill the raclette pans (5) according to your taste only with cheese or other foods/trimmings and place them in the appliance. Remove the pans (5) as soon as the cheese has melted or the other food is done according to your liking.

Do not place empty raclette pans onto the base (6) (raclette position) as this might damage the non-stick coating of the pans.

1. The grill plate (1) and grill stone (2) can be used for broiling meat, sausages, skewers, vegetables, etc.

Attention: Only use the provided wooden spatula (10) or a heat resistant plastic spatula. Never use any sharp or metal objects (e.g. knife, metal spatula, etc.) as they would damage the non-stick coating of the grill plate (1) and the raclette pans (5).

1. After use, always switch off the appliance and disconnect it from the mains.
2. Let the appliance and accessories completely cool down before cleaning.

Classic Raclette recipe:

For 4 people:

8 small new potatoes (same size)

1 glass pearl onions

1 glass cornichons

Pepper from the pepper mill

600 - 800 gr. Raclette cheese

Wash the potatoes thoroughly and boil them in their jackets. Make sure to keep them warm. Place the pearl onions and cornichons in two separate bowls. Cut the raclette cheese into pan size slices and place them on a plate.

Place the raclette cheese in the raclette pans and let it melt. Once the cheese has melted put it over the halved potatoe. Add some pepper and enjoy.

According to your taste you can add additional trimmings, e.g. various kinds of ham, "Bündnerfleisch" (special kind of smoked meat), salami, bell pepper, tomatoes, mushrooms, etc.

Serve it with a dry, light white wine.

Enjoy!

Cleaning and Care

Due to hygienic reasons clean your raclette grill on a regular basis, best after each use, and remove any food residues. Not doing so could possibly result in a hazardous situation.

Before cleaning, always switch off the appliance, disconnect it from the mains and let it completely cool down.

Never immerse the appliance in water. Danger! Electric Shock!

When cleaning the appliance or accessories never use any aggressive cleaning agents and/or other hard objects.

Food residues on the grill plate (1) or the raclette pans (5) can be removed with a kitchen paper towel or a soft moist cloth. Make sure that the grill plate (1) and the pans (5) are not too hot.

Afterwards, once the grill plate (1) and the raclette pans (5) have cooled down, clean them in warm water using some dishwashing detergent, rinse and dry them thoroughly.

Once, the stone plate (2) has completely cooled down, clean it only under running tap water using a synthetic sponge.

Do not use any dishwashing detergent and do never soak/immerse the stone plate (2) in water.

The grill plate (1), the stone plate (2) and the raclette pans (5) are not dishwasher safe.

Cleaning and user maintenance shall not be made by children without supervision.

Storage

After use disconnect the appliance from the mains and let it completely cool down.

Keep it away from children and store it in a clean and dry place.

Disposal Instructions

Waste electrical devices marked with this sign must not be disposed of with your household waste, but are to be collected separately. Therefore, please return this device at the end of its life cycle to special collection points for disposal or your local dealer.

Your Raclette Grill 45071 is packed in a retail box. Such boxes are recyclable waste, i.e. they are reusable or recyclable.

Technical Data:

Voltage: 220 - 240 V \~ 50 / 60 Hz

Rated Power: 1200 W

Protection Class: I

CE

Technical data subject to change!

Guarantee:

This product is guaranteed against defects in materials and workmanship for a period of 2 years.

This guarantee is not valid:

• if the appliance has not been used in accordance to the instructions
  • for damages due to wear and tear (batteries, etc.)
  • for damages known by customer at time of purchase
  • for damages caused by owner

This guarantee does not affect your statutory right, nor any legal right you may have as a customer under applicable national legislation governing the purchase of goods.

In order to assert his/her right in a guarantee case during the guaranteed period, the customer must provide evidence of the date of purchase (receipt).

The guarantee is to be asserted against

KORONA electric GmbH, Sundern/Germany.

Telephone Hotline: [phone]

Mail: [e-mail]

web: www.korona-electric.de

within 2 years after the date of purchase. In case of guarantee the customer is given the right to get the appliance repaired at our own or at an authorized shop. Further rights (due to guarantee case) are not given to the customer.
