DSW-HDMI-34 - Splitter Cablexpert - Free user manual and instructions

Product Type	HDMI Splitter
Brand	Cablexpert
Model	DSW-HDMI-34
Number of Inputs	1
Number of Outputs	4
Maximum Resolution	3840x2160 (4K) at 30 Hz
Supported Audio Formats	PCM, Dolby Digital, DTS
Power Supply	5V DC via micro-USB cable (power adapter not included)
Power Consumption	< 2W
Dimensions (L x W x H)	10 x 5 x 2 cm
Weight	100 g
Housing Material	ABS Plastic
HDCP	Compatible with HDCP 1.4 and 2.2
3D Support	Yes
HDMI Standard	HDMI 2.0
Warranty	2 years
Care and Cleaning	Clean with a soft, dry cloth. Do not use liquid or abrasive products.
Safety	Do not expose to moisture, excessive heat, or direct sunlight.
Spare Parts and Repairability	Not available separately. In case of failure, contact customer service.

Frequently Asked Questions - DSW-HDMI-34 Cablexpert

What is the maximum resolution supported by the DSW-HDMI-34 splitter?

The splitter supports resolutions up to 4K (3840x2160) at 30 Hz. It is also compatible with 1080p and lower resolutions.

How many outputs does this device have?

The DSW-HDMI-34 has 4 HDMI outputs, allowing you to connect up to 4 screens simultaneously.

Does the device come with an HDMI cable?

No, the splitter does not include an HDMI cable. You must use your own cables to connect sources and screens.

How to power the splitter?

Power is supplied via a micro-USB cable (not included) with a 5V source. You can use a standard power adapter or a USB port from a TV/computer.

Can I connect a 4K source to this splitter?

Yes, the splitter is compatible with 4K sources. However, the output will be limited to 30 Hz and requires that all cables and screens are HDCP 2.2 compatible.

Does the splitter work with game consoles?

Yes, it is compatible with consoles like PlayStation, Xbox, and Nintendo Switch, provided they output via HDMI and adhere to the supported resolutions.

Is there a risk of video quality loss?

No, the splitter reproduces the signal without degradation as long as the resolution and bitrate are within the limits of the HDMI 2.0 standard.

Are 3D signals transmitted?

Yes, the DSW-HDMI-34 supports passing through 3D signals without requiring additional configuration.

How to clean the splitter?

Use a soft, dry cloth to wipe the surface. Avoid contact with liquids or chemicals.

What to do in case of failure or malfunction?

First check the connections and power supply. If the problem persists, contact Cablexpert customer service via the manufacturer's website for warranty assistance.

USER MANUAL DSW-HDMI-34 Cablexpert

DSW-HDMI-34

HDMI INTERFACE

SWITCH, 3 PORTS

USER MANUAL

HANDBUCH

HANDLEIDING

MANUEL DESCRIPTIF

Features

• Switches up to 3 HDMI sources to a single monitor, TV set or plasma screen
- The digital 2.55 GHz bandwidth amplifier increases the transmission distance with about 25 meters and improves the signal quality
• Infrared remote control

Specifications

• Ports: 3x input, 1x output HDMI port
• Interface standard: HDMI + HDCP v.1.4a backward compatible with versions 1.0/1.1/1.2/1.2a/1.3/1.4, compatible with CTS 1.4a, DVI 1.0 standards
• Video formats: HDMI of 480i, 576i, 480p, 576p, 720p, 1080i, 1080p, 4K x 2K (3840 x 2160 at 24/25/30 Hz, 4096 x 2160 at 24 Hz)
• Input cable distance: up to 15 m AWG26 HDMI standard cable
  • Output cable distance: up to 25 m AWG26 HDMI standard cable
  • Power consumption: 5 V DC up to 0.15 A
  • Dimensions: 77 x 56 x 15 mm
• Net weight: 0.4 kg

All brands and logos are registered trademarks of their respective owners

②

This product is tested and complies with the essential requirements of the laws of member states concerning EMC(2004/108/EC). The CE declaration can be found under www.gembird.eu

Waste disposal:

Do not deposit this equipment with the household waste. Improper disposal can harm both the environment and human health. For Information about waste collection facilities for used electrical and electronic devices, please contact your city council or an authorized company for the disposal of electrical and electronic equipment.
