Product Type	Internal all-in-one memory card reader
Brand	CSL
Model	300270
Form Factor	3.5 inches (8.89 cm)
Connectivity	USB 3.2 Gen1 (USB 3.0 compatible)
Card Interfaces	MS/MS Duo, CF/CF2, SD/SDHC/MMC, XD, microSD/TF
Front USB Ports	2 USB 3.2 Gen1 ports
Compatible Operating System	Microsoft Windows XP or later
Power Supply	Powered via USB (internal cable to motherboard)
Driver Installation	Automatic (Plug & Play)
Package Contents	Reader, internal USB cable, user manual
Mounting	3.5-inch bay, screw mounting
Maintenance and Cleaning	Clean with a dry cloth, avoid moisture
Safety	Disconnect PC before installation, avoid electrostatic discharge
Operating Temperature	Dry environment, avoid high temperatures
Weight	Approximately 150 g (estimated)
Warranty	Standard manufacturer's warranty

Frequently Asked Questions - 300270 CSL

How to install the CSL 300270 card reader in my PC?

Open your computer case, remove the 3.5-inch bay cover, insert the reader and secure it with the provided screws. Connect the internal USB cable to a free USB 3.2 Gen1 port on the motherboard.

What types of memory cards are compatible?

The reader supports MS/MS Duo, CF/CF2, SD/SDHC/MMC, XD, microSD/TF. It also has two front USB ports.

Do I need to install drivers for the CSL 300270?

No, driver installation is automatic under Windows. The reader is operational a few minutes after startup. If not recognized, perform a Windows update.

The reader is not recognized by Windows, what should I do?

Check that the USB cable is properly connected to a USB 3.2 Gen1 port on the motherboard. Make sure Windows is up to date. If the problem persists, restart the computer.

Can I use the card reader externally?

No, this model is designed for internal installation in a 3.5-inch bay of a desktop computer.

What is the data transfer speed?

The reader uses the USB 3.2 Gen1 interface, offering transfer speeds up to 5 Gbit/s (theoretical).

Does the reader work under Linux or macOS?

The manual mentions only Windows XP or later. Under Linux or macOS, it might work without specific drivers, but no guarantee is provided.

How to clean the card reader?

Unplug the computer and clean the exterior with a dry, lint-free cloth. Avoid any liquid or abrasive product.

What to do if a memory card gets stuck?

Do not use sharp tools. Try to eject the card through the operating system. If it remains stuck, contact a professional.

Where to find a manual in English for this product?

The manual is available free of charge in PDF format on notice-facile.com or on the manufacturer's website. You can also request a translation via the form on the page.

USER MANUAL 300270 CSL

Internal USB 3.2 Gen1 All-In-One Card Reader 3.5"

Mod.-Nr.: 300270

Table of contents

1. Deutsch .... 3
2. English 7
3. Italiano .... 11
4. Français.... 15
5. Español....19

ENG: Current drivers, user manuals and other relevant documents for this product can be found on our homepage.

Pure electrical circuit lines without any symbols

Thank you for choosing a CSL product. To ensure that you can enjoy your newly purchased device for a long time, please read the following abbreviated instructions for use attentively. Before using the delivered product, check that it is complete, faultless and undamaged.

1. Delivery scope

• Internal USB 3.2 Gen1 All-In-One Card Reader 3.5"
• User manual

2. Technical specifications

Connection USB 3.2 Gen1
Form factor 3,5" / 8,89 cm
Interfaces	MS/MS DuoCF/CF2SD/SDHC/MMCXDmicroSD/TFUSB
Compatibility Microsoft Windows XP or higher

3. Installation

Please unplug your computer entirely from the power grid before starting the installation process. Avoid touching any of the sensitive components of your computer. When the device is put into operation for the first time, check the intactness of the product or components and their function again.

Pure electrical circuit lines without any symbols

Open the housing of your computer. Remove the cover from the drive bay.

Insert the card reader into the 3.5" drive bay provided and then connect it to the PC housing, using suitable attachment screws.

Now look for a free USB 30 and USB 2.0 socket on the main board or on your controller expansion card. Usually such a socket will be labelled "USB XX". Please make use of your main board manual to help you. The next step is to connect the USB cable of the card reader to the free sockets.

The cable can only be connected in one direction. Please do not use force.

4. Driver installation

Driver installation takes place fully automatically. The card reader is ready for use within a few minutes after the system starts up. Please carry out a Windows update if the card reader is not detected/installed.

Please Note!

5. Safety instructions and disclaimer

VPlease never try to perform repairs or conversions of your device yourself. Avoid contact with the power grid. The product is only voltage-free once it has been unplugged. Always ensure that you are grounded before you touch electronic components. This will prevent damage caused by electrostatic discharge from your body.

Electrostatic discharge (ESD) can cause irreparable damage to your device and to all the connected hardware components!

Installation of the product takes place at your own risk.

Please have the installation of the device performed by a specialised company if you do not have any technical and practical experience in the field of computers/electrotechnology. The manufacturer cannot be held liable for any direct or indirect damage caused by improper installation or use.

It is the customer's responsibility to back up any data.

The device has not been approved for outdoor use. It should therefore be used only in dry areas. Protect it against high humidity levels, water and snow. Always keep the device away from high temperatures.

Do not expose the device to any sudden temperature changes or strong vibrations, as this could damage the electronic components.

Check the device for possible damage before using it. The device should not be used if it has been subjected to an impact or damaged in any other way.

Please also take the national regulations and restrictions into account.

Do not use the device for any purposes other than those described in these instructions.

This product is not a toy. Store it outside the reach of children or intellectually disabled persons.

Any repairs or changes to the device not carried out by the original supplier will result in the expiry of any warranty or guarantee claims.

The device specifications may change without any specific prior notice.

6. Instructions for disposal

Electrical and electronic devices may not be disposed of together with domestic waste, in accordance with the European WEEE directive. Their components must be separately sent for recycling or disposal, as toxic and hazardous components may do long-term damage to the environment in the event of improper disposal.

As a consumer according to the Electrical and Electronic Equipment Act (ElektroG), you are obliged to return electrical and electronic devices to the manufacturer, the point of sales or a specially set up public collection point free of charge at the end of their service life.

The relevant national laws provide detailed regulations. The symbol on the product, the user manual and/or the packaging refers to such regulations. This form of material separation, recycling and disposal of obsolete devices makes an important contribution towards the protection of our environment. For information on authorised collection points in your area, please contact your local city or municipal administration.

WEEE guideline: 2012/19/EU

WEEE Register number: DE 67896761

WD Plus GmbH, herewith declares that this product 300270 conforms to the principlerequirements and other relevant stipulations. The complete Declaration of Conformity can be obtained from: WD Plus GmbH, Wohlenbergstraße 16, 30179 Hannover
