USER MANUAL 306900 CSL

ENG: Current drivers, user manuals and other relevant documents for this product can be found on our homepage.

Thank you for having chosen this CSL product and for placing your trust in our company. Please read this manual carefully before installation to ensure your long-term enjoyment of this product. For future reference, please keep this manual. Before using the delivered product, check that it is complete, faultless and undamaged.

1. Scope of delivery

• SmartCard Reader
• User manual

2. Technical specifications

Port USB
Card connections Smartcard
Compatible cards Smartcard
Compatible Formats • T0, T1	Protocol • ISO7816 Class A, B and C (5V/3V/1.8V) Cards • EMV 4.0 Level 1 Specification Certified • PC Smart Card Industry Standard – PC/SC 2.0 • Microsoft WHQL Smart Card Reader • I2C memory card, SLE4418, SLE4428, SLE4432, SLE4442, SLE4436, SLE5536, SLE6636, AT88SC1608, AT45D041 card & AT45DB041 card via ext. EEPROM
Compatible operating systems	Windows 7/8/10/11, macOS 10.10 and higher

3. Getting started

Take the device out of its packaging and remove any packaging material. Connect the SmartCard Reader to an available USB port on your computer or notebook. The driver installation is fully automatic. The device is then ready for operation.

To check whether the device is displayed in your device manager, go to the "Smartcard reader" tab. This device is displayed as "Microsoft Usbccid Smartcard Reader (WUDF)".

Smartcard-Leser

Microsoft Usbccid-Smartcard-Leser (WUDF)

4. Safety instructions and liability disclaimer

Never try to open the device to carry out repairs or conversions. Avoid contact with mains voltages. Do not short-circuit the product. The device is not certified for use in the open air; only use it in dry conditions. Protect it from high humidity, water and snow. Keep it away from high temperatures.

Do not subject the device to sudden changes in temperature or heavy vibration as this might damage electronic components. Examine the device for damage before using it. The unit should not be used if it has received an impact or has been damaged in any other way. Please observe national regulations and restrictions. Do not use the device for purposes other than those described in the instructions. This product is not a toy. Keep it out of the reach of children or mentally impaired persons. Any repair or alteration to the device not carried out by the original supplier, will invalidate the warranty or guarantee. The product may only be used by persons who have read and understood these instructions. The device specifications may change without any separate prior notice to this effect.

5. Disposal instructions

Electrical and electronic devices may only be disposed of in accordance with the European WEEE Directive and not with household rubbish. Components must be disposed of or recycled separately as dangerous, toxic elements can inflict sustained damage on the environment if they are disposed of incorrectly. As a consumer, you are bound by the Electrical and Electronic Devices Act (ElektroG) to return electrical and electronic goods free of charge at the end of their useful life to the manufacturer, the place of purchase or to specially set up, public collection points. The details in each case are governed by national law. The symbol on the product, the operating instructions and/or the packaging refers to these regulations. By separating materials in this way, recycling and disposing of old devices, you are making an important contribution towards protecting our environment.

C E

WEEE guideline: 2012/19/EU

WEEE register number: DE 67896761

WD Plus GmbH herewith declares that this product 306900 conforms to the principle requirements and other relevant stipulations. The complete Declaration of Conformity can be obtained from: WD Plus GmbH Wohlenbergstraße 16, 30179 Hanover

MO-FR 9:30am - 18pm CET
