Super Wand HB-80G.026A - Hand blender Haeger - Free user manual and instructions

USER MANUAL Super Wand HB-80G.026A Haeger

Super Wand * HB-10S.022A

Exterior view of a modern stainless steel Super Wand stand (no text or symbols visible on body)

CERoHS

Thank you for having chosen a HÆGER product.

The HÆGER products have been produced to think about the welfare of the consumer privileging the most raised standards of quality, functionality and assign. We are sure you will be happy with this appliance.

We assume that the user is familiar with the common procedures of handling household appliances.

Before using the appliance for the first time please read carefully and thoroughly through these operating instructions and the safety advice, completely familiarising yourself with the appliance. Retain these instructions for future reference and pass them on to whoever might acquire the appliance at a future date.

Intended use

This hand blender set is intended exclusively for processing foodstuffs in small quantities. It is intended for domestic use only. This hand blender is not intended for commercial use.

General Safety Instructions

To reduce the risk of fire, electrical shock, or injury when using your appliance, follows these basic precautions:

WARNING:

Do not touch the plug at the mains cable with wet or moist hands when connecting or disconnecting. Risk of death by electric shock!

• The blades are very sharp! Handle with care.
• In case of emergency, unplug the device immediately.
• Hold the plug when disconnecting the mains cable; do not pull the cable.
• Disconnect the plug before cleaning or servicing.
• Regularly check the device and cable for signs of damage. Do not continue to operate the device in case of damage.

• A damaged mains cable must be replaced by the manufacturer or a technician and without any delay. Do not use the device with a damaged cable or plug.

• Do not repair the device by yourself. Please contact authorized personnel. In order to avoid hazards a damaged mains cable must be replaced with an equivalent cable by the manufacturer or qualified specialist.

• Except for cleaning and maintenance work described in this manual, no other alterations of this device must be executed.
• Do not operate the device with an external timer or separate remote-control system.

CAUTION!

In order to ensure your children's safety, please keep all packaging (plastic bags, boxes, polystyrene etc.) out of their reach.

Do not allow small children to play with the foil as there is a danger of suffocation!

- This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.

. Cleaning and user maintenance shall not be made by children unless they are older 8 years and supervised.

- Keep the appliance and its cord out of reach of children less than 8 years.

. Children should be supervised to ensure that they do not play with the appliance.

- The packaging must be undamaged. Check the device for any possible transport damage. Do not install a damaged device. In case of damage, please contact your distributor.

- The appliance is constructed to process normal household quantities.

Overview of the components

A. Switch (I) (variable speed)
C. Motor unit
E. Cross blade

B. Turbo Speed (II) (fixed speed)
D. Detachable shaft
F. Multi-speed control knob

2 Instructions for use

Electrical connection

1. Connect the device to a duly installed 220-240V\~ 50/60Hz protective contact socket.
2. Before inserting the plug into the socket, make sure that the mains voltage to be used matches that of the device. You can find this information on the nameplate.

How to use the hand blender

The hand blender is perfectly suited for preparing dips, sauces, soups, mayonnaise and baby food as well as for mixing and milkshakes.

1. Insert the blender shaft onto the motor unit until you hear the "click" that tells you it has locked.
2. To avoid splashing, first immerse the blade guard completely into the ingredients, plug in the appliance and then press the switch (I) to work at the set speed (control knob F) or turbo switch (II).
3. Move the appliance slowly up and down and in circles to blend the ingredient.
4. Unplug then remove the blender shaft after use.
5. You can use the hand blender in the measuring beaker and just as well in any other vessel.

Warning: Maximum operation time is 1 minute. Allow to cool for 4 minutes before using the blender again.

Cleaning

Risk of electric shock!

Before you clean the hand blender, unplug the appliance from the power socket. Under no circumstances may the motor unit be cleaned by immersing it in water or holding it under running water.

• Clean the motor unit, the hand blender, with a moist cloth.
  • After processing very salty food, you should rinse the blades right away.
• Ensure that water cannot permeate through the openings of the hand mixer. For stubborn soiling use a mild detergent on the cloth.
• Clean the rest of the attachment components under running water and dry them off well with a dish towel.

Technical Data

Model No	HB-10S.022A	Insulation
Voltage	AC 220-240V
Frequency	50/60Hz	Continuous working time	≤slant 1 min
Power	1000W	Intermission time	≥slant 4 min

Conformity

This product has been tested and produced according to all relevant current CE guidelines, such as:

• Electromagnetic compatibility Directive 2014/30/EU,
• Low voltage Directive (LVD) Directive 2014/35/EU,
• RoHS with its amendments Directive (EU) 2015/863,

and has been constructed in accordance with the latest safety regulations.

The CE mark attests this product with all relevant directives.

Environment

Please consider our environment

Do not dispose of the appliance in your normal domestic waste. This product is subject to the European guideline 2012/19/EU.

Dispose of the appliance through an approved disposal centre or at your community waste facility. Observe the currently applicable regulations. In case of doubt, please contact your waste disposal centre.

Dispose of all packaging materials in an environmentally responsible manner.

When you wish to dispose of the appliance, remove the cable and dispose it in an environmentally friendly way (e.g. recycling plant).

4 Instructions for use

Guarantee

This unit is covered by a 24 months (*) warranty, from the purchase date, and covers the repair free of charges of the damaged due to the manufacturer fault or defected components. The distributor reserves the right to change the unit for an equivalent model.

The warranty does not cover any damaged caused by incorrect use, lightning, incorrect installation, external factors or any intentional damaged. The warranty does not cover damage thus attributable to falls, blows, spill, exposure to extreme environmental conditions or deterioration caused by normal use of plastic parts or keyboards, as well as by the use of batteries other than those specified in this manual.

For the repairing, during the warranty period, the unit shall be sent to the distributor or reseller, or to the address indicated by them, and must be jointed the warranty certificated and the respective original invoice or selling ticket, where the buying date is expressed indicated.

The consumer is protected by the guarantee provided by Directive 1999/44/CE of European Parliament and Council of 25 May.

(*) Only for European Union countries
