USER MANUAL SC ZWE 1000 Efbe-Schott

Front cover page (first page)

Assembly page 1/18

Labeled diagram of a white griddle with five numbered parts showing internal structure and interior layout.

D

1. Housing
2. Red pilot light
3. Green pilot light
4. Handle release button
5. Baking plates

F

☐ Please read these instructions carefully before using the appliance.

☐ Only use the appliance in the way indicated in this instruction manual.

☐ Should you hand over the appliance to another user, make sure to hand over the instruction manual together with the appliance.

☐ Check that your mains voltage corresponds to that stated on the rating plate of the appliance before using the appliance.

☐ Never leave the appliance unsupervised when in use.

☐ People (including children) who are not able to use the appliance in a safe way, due to their physical, sensorial or mental capacity or their lack of experience or knowledge, must never use the appliance without supervision or instructions of a responsible person.

☐ Close supervision is necessary if children are near the appliance in order to avoid that they use it as a toy.

From time to time check the appliance and its cord for damages. Never use the appliance if cord or appliance shows any signs of damage. In that case, all repairs should be made by a competent qualified electrician(*). Never use the appliance if it shows visible damage.

☐ Only use the appliance for domestic purposes and in the way indicated in these instructions.

☐ Never immerse the appliance in water or any other liquid for any reason whatsoever. Never place it into the dishwasher.

☐ Never use the appliance near hot surfaces. Do not stand the appliance on hot surfaces (eg cooker) or near a flame.

□ Unplug the appliance before cleaning it.

☐ Never use the appliance outside and always place it in a dry environment.

☐ Never use accessories that are not recommended by the producer. They could constitute a danger to the user and risk to damage the appliance.

☐ Never move the appliance by pulling the cord. Make sure the cord cannot get caught in any way. Do not wind the cord around the appliance and do not bend it.

☐ Put the appliance on a table or other flat surface in horizontal position.

☐ Let the appliance cool down before cleaning or storing it.

☐ Make sure the cord does not come into contact with the hot parts of the appliance.

☐ The temperature of the accessible surfaces, such as the door of the oven, may be very high when the appliance is in use. Never touch those surfaces during use nor before the

appliance has totally cooled down, and only use the handle. Should the symbol be indicated on a certain surface, you need to be careful when handling the product. This symbol means CAUTION, this surface may get very hot during use.

☐ Make sure the appliance never comes into contact with inflammable materials, such as curtains, cloth, etc...when it is in use, as a fire might occur.

☐ Be careful not to scratch the special coating of the cooking plate, as it would lose its non-stick feature. Use a classical wooden spatula or a heat resistant plastic one.

□ Always unplug the appliance when it is not in use, especially since it is not equipped with an on/off switch.
☐ Only use the appliance for food that is supposed to be cooked.

(1) Competent qualified electrician: after sales department of the producer or importer or any person who is qualified, approved and competent to perform this kind of repairs in order to avoid all danger. In any case you should return the appliance to this electrician.

BEFORE FIRST USE

• Unpack the appliance and its accessories, wipe it them with a damp cloth and dry them.
- Plug in the appliance.
- During the first use some smoke or smell might escape. This is perfectly normal during the first use. Therefore we advise you to operate the appliance empty for about 10 minutes.
• Before use, grease the plates.
- Do not eat the first waffles.
• After a certain period of time, the housing of some appliance might get a light brown colour. This is due to the steam coming out during cooking, and this is inevitable.

USE

• Caution! During operation, the baking plates become very hot. Do not touch them!
• To open the appliance, press the handle and release button simultaneously.
- Close the appliance, plug it in and put the thermostat on its maximum position. The red pilot light goes on to indicate that the appliance is plugged in and heating.
- As soon as the desired temperature is reached, the green pilot light will go on as well. Now you can pour the dough into the waffle maker.
- The pilot light will come on and out according to the heating cycle. This means that the thermostat regulates the temperature automatically during use.
- Cover your hands with flour, then take the batter and form 8 balls. Put them in the moulds of the baking plates and close the lid until it is locked. This way, the batter will be spread over the plates. HINT: If you cannot close the appliance, this means that the batter is too hard.
• The result of the first operation will show whether us used the correct batter quantity or not.
- During operation, hot steam will come out of the appliance. Make sure not to burn your fingers.
- After about 7 minutes, the waffles will be ready. Hint: open the lid now and then to check the browning degree during operation.
- Open the lid and remove the waffles with a wooden or plastic spatula. Never use metallic objects as these could damage the non-stick coating of the baking plates.
• UNPLUG THE APPLIANCE WHEN YOU ARE FINISHED.

CLEANING AND CARE

• Unplug the appliance.
• Let the appliance and the baking plates cool down before cleaning.
• Clean the housing with a damp cloth and make sure no damp, grease or oil seeps into the appliance.
• Clean the plates of the appliance with a damp cloth or paper towel.
• For tenacious residues, you can use a soft brush.
• Never use metallic objects or abrasive products.
• Never immerse it in water or any other liquid.

- Only use the appliance for domestic purposes. This appliance is not suitable for professional or continuous use.

PROTECTION OF THE ENVIRONMENT- DIRECTIVE 2002/96/EC

In order to preserve our environment and protect human health, the waste electrical and electronic equipment should be disposed of in accordance with specific rules with the implication of both suppliers and users.

For this reason, as indicated by the symbol ☐ the rating label or on the packaging, your appliance should not be disposed of as unsorted municipal waste. The user has the right to bring it to a municipal collection point performing waste recovery by means of reuse, recycling or use for other applications in accordance with the directive.

TERMS OF GUARANTEE

For our products, the legal terms concerning claims under guarantee are valid. During the legal period, all material and manufacturing defects are covered. No claims will be accepted for broken accessories, defects resulting from inappropriate use or care, excessive wear due to intensive use, wrong use due to the non-observance of the instruction manual, or normal wear and tear. No guarantee claims will be accepted if the appliance has been modified or if attempts have been made to repair the appliance. In such case, the vendor cannot be held responsible in case of accidents.

If you detect a defect, please contact your vendor or shop and return your complete appliance in its original packaging together with the receipt. Claims under guarantee will only be valid if the receipt or a copy of a repair bill is handed over with the appliance that needs repair.

Or send the appliance cleaned, well packed and with a short, easily readable description of the default as well as the receipt freight prepaid to our customer service in our firm in Bad Blankenburg.

In case of a defective accessory, the complete appliance will not be exchanged, but only the accessory will be sent free of charge. In such case, do not return the complete appliance but only order the accessory! In case of glass damages, glass spare parts will be charged. Pieces undergoing wear and tear as well as cleaning and maintenance or the exchange of worn out pieces are not covered by the guarantee and will thus be charged!

AFTER THE LEGAL PERIOD OF GUARANTEE

Repairs after the guarantee period can be performed at a charge by a competent qualified technician or a repair service.

CUSTOMER SERVICE
