USER MANUAL Wave 8x42 BRESSER
This instruction manual was created for various models in our series of binoculars. Pages 2-7 present the relevant features in pictures. Depending on the model you have purchased, this chapter of the manual covers the binoculars in full or in part. As a result, please pay attention to the letters (P, R or C) to make sure that a chapter applies to your model.
Please read this manual carefully and completely before using the binoculars.
Your
BRESSER Team
P = Porro prism model · R = Roof prism model · C = Compact model
12
BINOCULARS
List of Parts
1 Centre axle
a Twist-up eyecups or
Rubber eyecups
3 Dioptré adjustment
Body of the binoculars
Lens tube
Central focussing wheel
Eyepiece
Objective lens
Threaded tripod connection
10 Image circle with correctly set eye distance
Eyepieces for spectacle wearers P R C
Depending on the model, your binoculars are equipped with either twist-up eyecups (2a) or rubber eyecups (2b). Since there is a larger distance between the binocular eyepiece and the pupil for those wearing glasses, both eyecup varieties can be adjusted individually.
Twist-up Eyecups (2a)
Screw in the twist-up eyecups (2a) to use the binoculars while wearing glasses. If you are not wearing glasses, unscrew the eyecups to achieve the required distance from the pupils.
OR
Rubber Eyecups (2b)
To use the binoculars while wearing glasses, turn the rubber eyecups (2b) towards the sides and down. If you are not wearing glasses, leave the eyecups in the upright position to achieve the required distance from the pupils.
Adjusting the eyepiece distance
The distance between the eyes differs between individuals. To achieve perfect interaction between your eyes and the eyepieces of your binoculars set the angle at the centre of the binoculars (1) so that you see a circular image (10). Note this setting for later use.
JUMELLES
Chere cliente, cher client,
GB Warranty & Service
The guarantee period is 5 years and begins on the day of purchase. You can consult the full guarantee terms as well as information on details of our services at www.bresser.de/warranty_terms.
