Viaggio Pro PV1652 - Iron SOLAC - Free user manual and instructions

Product type	Iron
Brand	Solac
Model	Viaggio Pro PV1652
Power supply	Dual voltage (voltage selector 110-240 V)
Functions	Dry ironing, steam ironing, steam burst, vertical ironing
Foldable handle	Yes, with button (H)
Temperature regulator	Yes, MIN to MAX positions (linen, cotton, wool, silk, synthetics)
Steam regulator	Yes
Indicator light	Yes, indicates temperature
Water filling	Via opening (B), respect MAX level
Soleplate	Non-stick
Maintenance	Clean with damp cloth and mild detergent; do not immerse
Descaling	Recommended every 6 to 12 weeks depending on water hardness, with specific product
Safety	Unfold cable completely; do not leave unattended; unplug after use
Warranty	In accordance with current legislation, authorized technical service
Country of origin	Not specified in the manual

Frequently Asked Questions - Viaggio Pro PV1652 SOLAC

How to fill the water tank?

Open the filling spout cover (B), pour water up to MAX level (Fig.1), then close the cover. Preferably use distilled water if water is hard.

How to use the steam burst function?

Press the steam burst button (A) for an extra steam jet. Wait a few seconds between bursts to allow steam to penetrate fibers. Do not apply more than three consecutive bursts.

How to iron vertically?

Select maximum temperature, then pass the iron from top to bottom while pressing the steam button (A). For delicate fabrics, keep the iron a few centimeters away.

How to clean the iron?

Unplug and wait for complete cooling. Clean with a damp cloth soaked with a few drops of mild detergent. Do not use solvents, abrasives, or immerse the iron.

How to descale the appliance?

Use a specific anti-scale product for irons, sold in specialized stores. The frequency depends on water hardness: every 6 weeks if water is very hard, every 12 weeks if hard. Avoid vinegar.

What to do if the soleplate is stained?

Clean the cooled soleplate with a damp cloth and mild detergent. Do not use metal or sharp objects to avoid damaging the non-stick coating.

How to adjust the temperature?

Turn the temperature regulator (G) to the position corresponding to the fabric: synthetics (●), silk/wool (●●), cotton (●●●), linen (MAX). Wait for the indicator light to turn off before ironing.

How to use the voltage selector?

The iron has a dual voltage selector (E). Before plugging in, ensure the position matches the mains voltage (110-240 V). See Fig.2 in the manual.

How to fold the handle?

Press the foldable handle button (H) to fold the handle, making it easier to store.

What to do if the iron does not heat?

Check that the iron is plugged in and the voltage selector is in the correct position. Turn the temperature regulator to a higher setting. If the indicator does not light up, contact an authorized technical service.

USER MANUAL Viaggio Pro PV1652 SOLAC

Exterior view of a Sollac air iron with visible branding and warning symbol (no text-heavy elements)

PLANCHA DE VIAJE

TRAVEL IRON

FER À REPASSER DE VOYAGE

REISEBÜGELEISEN

FERRO DA VIAGGIO

FERRO DE VIAGEM

PLANXA DE VIATGE

REIZEN IJZER

PODRÓŻE ŻELAZA

ΣΙΔΕΡΟ ΤΑΞΙΔΙΟΥ

ДОРОЖНЫЙ УТЮГ

FIER DE CĂLCAT PENTRU VOIAJ

ТУРИСТИЧЕСКА ЮТИЯ

مكواة السفر

Fig.1 MAX

Fig.2 100-120V 220-240V 100V 120V 220V 240V

ESPAÑOL ES

PLANCHA DE VIAGE PV1652

DESCRIPCIÓN

A Steam blast button
B Filling spout
C Soleplate
D Pilot light
E Dual voltage selector
F Steam regulator
G Temperature regulator
H Foldable handle button

USE AND CARE:

• Fully unroll the appliance's power cable before each use.
• Use the appliance handle, to catch it or move it.
• To keep the non-stick treatment in good condition, do not use metal or pointed utensils on it.
• Respect the MAX level indicator. (Fig.1).
• Disconnect the appliance from the mains when not in use and before undertaking any cleaning task.
• This appliance is for household use only, not professional, industrial use.
• Store this appliance out of reach of children and/or persons with physical, sensory or reduced mental or lack of experience and knowledge.
• Do not store or transport the appliance if it is still hot.
• Keeping the iron in its housing support at maximum temperature for too long time, may cause its colour change, which will not affect the correct working order of the appliance.
• For a correct operation, keep the soleplate in proper conditions does not operate over metal objects (ironing board metal parts, buttons, zips etc.).
• It is advisable to use distilled water, especially if the water in your area contains

clay or if it is "hard" (containing lime or magnesium).

• Check that the lid is closed properly before starting the appliance.
• Never leave the appliance connected and unattended if is not in use. This saves energy and prolongs the life of the appliance.
• Never rest the appliance into a surface while in use.
• Do not use the appliance on any part of the body of a person or animal.
• Do not use the appliance with pets or animals.
• Turn the thermostat control to the minimum (MIN) setting. This does not mean that the iron is switched off permanently.

INSTRUCTIONS FOR USE

BEFORE USE:

• Remove the appliance's protective film.
• Ensure that the selected tension on the voltage selector coincides with the tension of the mains.
• To eliminate the smell given off by the appliance when used for the first time, it is recommended to have it on at full power for 2 hours in a well-ventilated room.
• Prepare the appliance according to the function you wish to use.

VOLTAGE SELECTOR:

- The appliance has a voltage selector control, situate the selector according to the type of voltage available in the mains where the appliance is to be connected. (Fig.2).

FILLING WITH WATER:

• It is essential to have filled the deposit with water to be able to work with steam.
• Open water inlet lid.
• Fill the deposit taking care to observe the

EN

MAX level (Fig.1).

- Close water inlet lid.

USE:

• Unroll the cable completely before plugging it in.
• Connect the appliance to the mains.
• Slide the thermostat control to the desired temperature position.
  • The pilot light (D) comes on.
• Do not use temperatures higher than those indicated on the garments to be treated.
• • Temperature for synthetic fibres (Polyester, Nylon...).
• ●● Temperature for silk and wool.
• ●●● Temperature for cotton. (Minimum temperature for steam ironing)
• Max Temperature for linen.
• If garment has various kinds of fibres, select the temperature for the fibre that requires the lowest temperature. (For example, select the temperature for polyester for an article made out of 60% polyester and 40% cotton).
• Wait until the pilot light has gone out which will indicate that the appliance has reached an adequate temperature.
• During the appliance's use the pilot light will come on and off automatically, indicating the heating elements are working, and therefore maintaining the desired temperature.

DRY IRONING:

- The appliance has an option to dry ironing (without steam). To use this option turns on only the iron switch.

STEAM IRONING:

- It is possible to iron with steam whenever the deposit is filled with water and the adequate temperature is selected.

FORDABLE HANDLE:

- By pressing the button (H) the handle is folded for an easy storage.

STEAM BLAST:

• This function proportions extra steam for eliminating wrinkles.
• Press the steam blast button (A). Wait a few seconds until vapour penetrates the fibres of the garment before pushing the button again. For optimum steam quality, do not apply more than three successive blasts.
• The steam blast button has to be pressed repeatedly to release the first shot.

VERTICAL STEAMING:

• It is possible to iron hanging curtains, items of clothing on his hanger, etc. To do so, follow the instructions:
• Select the maximum temperature of the iron, while turning the temperature regulator of the iron in a clockwise direction.
• Move the iron in a top to bottom direction while pressing the steam control (A). Important: for cotton and linen, it's recommended to put the iron base in contact with the material. For other more delicate fibres, it's recommended to keep the iron base at some centimetres of distance.

ONCE YOU HAVE FINISHED USING THE APPLIANCE:

• Select the minimum position (MIN) using the thermostat control.
• Unplug the appliance from the mains.
• Remove the water from the inside of the appliance.
• Clean the appliance.

PRACTICAL RECOMMENDATIONS:

- Classify the garments into groups by ironing temperature. The appliance heats up more quickly than it cools down, therefore,

EN

to avoid accidents, minimise energy consumption and optimise time, it is advisable to start off ironing items that require lower temperatures and progress to those that need higher temperatures.

- Pure wool fabrics (100%) can be ironed with the iron set to steam. Select a high steam temperature and place a cotton cloth between the iron's metal surface and the garment.

CLEANING

• Disconnect the appliance from the mains and allow it to cool before undertaking any cleaning task.
• Clean the equipment with a damp cloth with a few drops of washing-up liquid and then dry.
• Do not use solvents, or products with an acid or base pH such as bleach, or abrasive products, for cleaning the appliance.
• Never submerge the appliance in water or any other liquid or place it under running water.

HOW TO DEAL WITH LIME SCALE IN-CrustATIONS:

• For the appliance to work correctly it should be kept free of limescale or magnesium incrustations caused by the use of hard water.
• To avoid this kind of problem it is advisable to use distilled water.
• To prevent this kind of problem, we recommend the use of water with low lime or magnesium mineralisation.
• However, if it is not possible to use the kind of water recommended above, you should periodically remove the limescale from the appliance:
• Every 6 weeks if the water is "very hard".
• Every 12 weeks if the water is "hard".
  • To do so, we recommend the use of the

specific product for this kind of appliance, which can be found in specialised shops and authorised technical services.

• A specific anti-lime scale product should be used on this kind of product.
• Homemade solutions are not recommended in the decaling of this appliance, such as the use of vinegar.

FRANÇAIS FR

FER À REPASSER DE VOYAGE PV1652

DESCRIPTION

This product enjoys the recognition and protection of the legal guarantee in accordance with current legislation. To enforce your rights or interests you must go to any of our official technical assistance services.

You can find the closest one by accessing the following web link: http://solac.com

You can also request related information by contacting us by phone.

You can download this instruction manual and its updates at http://solac.com
