Product type	Sewing machine
Brand	Bomann
Model	NM 6063 CB
Net weight	Approx. 2.1 kg
Power supply	DC 6 V, 1200 mA (via power adapter or 4 AA/LR6 batteries)
Power adapter	Input 100-240 V ~ 50/60 Hz, output 6 V DC 1.2 A
Work light	LED 0.1 W, 3 V (non-replaceable)
Number of stitch patterns	12 stitch patterns (including straight stitch, zigzag stitch, elastic stitch, blind stitch, buttonhole)
Sewing speed	Adjustable via switch (L/H) or pedal
Needle threader	Yes, built-in
Thread cutter	Yes
Included accessories	Pedal, power adapter, 2 needles, 2 upper thread spools, 2 lower thread bobbins, needle threader, presser foot
Presser foot types	Standard presser foot included; other feet commercially available
Reverse function	Yes, dedicated button
Care and cleaning	Clean the housing with a damp cloth and a little detergent; brush the area under the bobbin cover
Safety instructions	Turn off before cleaning; disconnect pedal when changing needle; use only the supplied power adapter
Storage	In a dry, well-ventilated place, out of reach of children; preferably in original packaging
Protection class	III (device); II (power adapter)
Repairability	Wear parts (needles, bobbins) commercially available; for other repairs, contact customer service

Frequently Asked Questions - NM 6063 CB BOMANN

How to thread the upper thread on the Bomann NM 6063 CB?

Make sure the presser foot is raised and the thread lever is in the up position. Place the spool on the spool pin, pass the thread through the thread guide, then down around the tension adjustment wheel. Bring it back up to the thread lever and pass the thread through its hole from right to left. Continue down into the needle clamp and finally through the needle eye. Pull about 10 cm of thread to the back under the presser foot.

How to adjust the upper thread tension?

Tension is adjusted by turning the tension dial (2). The basic setting is between 4 and 5. Adjust so that the knot of the upper and lower threads is visible in the middle of the stitch. If loops form, the tension is too low; increase the number.

How to wind the lower thread bobbin?

Place a spool of thread on the spool pin and an empty bobbin on the bobbin winder. Pass the thread through the thread guide, wind it a few times clockwise around the bobbin, then push the bobbin against the stopper. Use the pedal or switch to wind. Winding stops automatically when the bobbin is full.

What to do if the needle breaks?

First disconnect the power. Remove needle pieces. Ensure the replacement needle is suitable for the fabric and thread (size 80-110). Insert the new needle with the flat side to the back, up to the stop, and tighten the screw. Make sure the presser foot is correctly attached and the fabric is not pulled during sewing.

How to make a buttonhole with the NM 6063 CB?

Place the fabric under the presser foot and lower it. Select pattern 8, sew 5-6 stitches at slow speed (L). Switch to pattern 7, sew a straight line to the desired length. Return to pattern 8 for 5-6 stitches. Turn the fabric 180°, select pattern 7 again and sew to the end.

How to clean the Bomann NM 6063 CB sewing machine?

Turn off the device and disconnect the power adapter. Clean the housing with a moderately damp cloth and a little mild detergent. Never immerse in water. Brush the area under the bobbin cover with a dry brush to remove threads and dust.

Why are stitches skipping?

Possible causes: needle incorrectly inserted (flat side to back), damaged needle, wrong needle size for fabric, or presser foot not properly attached. Check each point and correct. If the needle is bent or blunt, replace it.

How to change the needle?

Disconnect the machine from power. Turn the handwheel to raise the needle guide. Loosen the needle set screw (21), remove the old needle. Insert the new needle fully, flat side to the back, then tighten the screw.

How to use the sewing machine pedal?

Plug the pedal into the designated socket (23). Ensure the switch (8) is set to OFF. Press gently on the pedal to sew; release to stop. Speed depends on pressure. You can also use the switch for constant speed (L or H).

How to change the presser foot?

Raise the presser foot lever (17). Loosen the presser foot set screw (a). Remove the old foot. Place the new foot on the needle plate, lower the lever until the notch engages on the stem, then press the lever (g) to lock.

USER MANUAL NM 6063 CB BOMANN

White BOMANN sewing machine with visible control knobs and a scale ruler (no text or symbols on main body)

Bedienungsanleitung

CE

Labeled diagram of a sewing machine with numbered parts for identification

13 14 15 16 17 18 24 23 22 21 20 19

27

28

30

WICHTIG:

Close-up of a microscope with an arrow pointing to the base (no visible text or symbols)

Simple line drawing of a hook and a ruler on a wall (no text or symbols)

Close-up of a vehicle's front wheel and side door (no visible text or symbols)

Close-up of a mechanical device with lever and base mount (no visible text or symbols)

Close-up of a sewing machine needle stitching fabric (no visible text or symbols)

Close-up of a sewing machine needle stitching fabric (no visible text or symbols)

Mechanical device with attached gauges and a magnified inset showing internal components (no visible text or symbols)

Close-up of a sewing machine needle and fabric with measurement scales (no visible text or symbols)

Close-up of mechanical components with no visible text or symbols

Exterior view of a mechanical device on a textured surface (no visible text or symbols)

Close-up of a pressure gauge and mechanical component (no visible text or symbols)

Betrieb beenden

Be sure to read the separately enclosed safety instructions first.

Instruction Manual

Thank you for choosing our product. We hope you will enjoy using the appliance.

Read the instruction manual and the separately enclosed safety instructions very carefully before using this appliance. Keep these documents, including the warranty certificate, receipt and, if possible, the box with the inner packaging in a safe place. If you pass the appliance on to a third party, always include all the relevant documents.

Symbols in this Instruction Manual

Important information for your safety is specially marked. It is essential to comply with these instructions in order to avoid accidents and prevent damage to the appliance:

WARNING:

This warns you of dangers to your health and indicates possible injury risks.

CAUTION:

This refers to possible hazards to the appliance or other objects.

Content

Overview of the Components....3

Unpacking the Appliance.... 11

Scope of Delivery....11

Overview of the Components.... 11

Warnings for the Use of the Appliance ....12

Handling Batteries....12

Notes for Use....12

Inserting the Batteries 12

Connecting the Power Supply Unit....12

Switching the Appliance On and Off 12

LED Sewing Field Light....12

Selection of Needle Size and Threads ....13

Operation 13

Inserting the Needle....13

Attaching and Removing the Presser Foot....13

Threading the Upper-thread 13

Adjusting the Upper-thread Tension 14

Winding the Under-thread Bobbin ....14

Inserting the Under-thread Bobbin....14

Bringing up the Under-thread 14

Select Stitch Pattern....14

Sewing....14

Buttonholes 15

End Operation 15

Cleaning....15

Storage....15

Troubleshooting....15

Technical Data....16

Product Specifications in Accordance

with Regulation (EU) 2019/1782 Power Supplies......16

Disposal 17

Battery Disposal 17

Meaning of the "Dustbin" Symbol 17

Unpacking the Appliance

1. Remove the appliance from its packaging.
2. Remove all packaging material, such as foils, filling material, cable ties and cardboard packaging.
3. Check the scope of delivery for completeness.
4. If the contents of the packaging are incomplete or if damage can be detected, do not operate the appliance. Return it to the dealer immediately.

Scope of Delivery

1× Sewing machine
1 × Foot pedal
1 × Power supply unit
2× Sewing needle
2×Upper-threadbobbin
2×Under-thread bobbin
1× Threader
1×Presserfoot

Overview of the Components

1 Thread lever
3 Stitch pattern adjusting wheel
4 Carrying handle
5 Symbolism stitch selection
6 Handwheel
7 Back button
8 On / off switch / speed switch
9 Battery compartment
10 Bobbin cover
11 Light switch
12 Thread cutter
13 Bobbin winder stop
14 Winder
15 Thread spool holder
16 Thread guide
17 Lever for the presser foot
18 Presser foot fixing screw

2 Upper-thread tension adjusting wheel

19 Lever for releasing the presser foot
20 Presser foot
21 Needle clamp screw
22 Mains connection socket
23 Foot pedal connection socket
24 Accessories compartment
25 Foot pedal
26 Power supply unit
27 Bobbin under-thread
28 Thread spool
29 Sewing needle
30 Threader

Warnings for the Use of the Appliance

Read the instructions!

Only use with "SW0601200-W02" power supply unit! For the purpose of recharging the battery, only use the detachable supply unit provided with this appliance.

Do not use power supply with damaged plug! If the pins of the plug part are damaged, the plug-in power supply shall be scrapped.

WARNING:

• Make sure that the switch (8) is in the OFF position. Otherwise the sewing machine will start sewing immediately.
• Always unplug the foot pedal (25) from the appliance when threading, changing needles or inserting the bobbin.
• Use only the accessories supplied or recommended in these instructions. Use of non-recommended accessories may cause injury.

Handling Batteries

Do not charge batteries!

Do not disassemble batteries!

Do not short-circuit batteries!

Observe polarity (+ / -)!

Danger of explosion!

Do not expose batteries to intense heat, such as sunshine, fire or similar.

• Batteries can leak battery acid. If the appliance will not be used for a longer period of time, remove the batteries.

• If a battery leaks, do not rub the liquid into the eyes or mucous membranes. In case of contact, wash hands, rinse eyes with clean water. Seek medical attention if any discomfort persists.

• Different battery types and new and used batteries must not be used together.

• Batteries are not to be disposed of together with domestic wastes. Return used batteries to the responsible collection points or to the dealer.

Notes for Use

You can operate the appliance either with batteries or with the power supply unit supplied.

Inserting the Batteries

(Batteries not included in scope of delivery)

WARNING:

Make sure that the switch (8) is in the OFF position. Otherwise the sewing machine will start sewing immediately.

1. Remove the battery compartment cover on the underside of the appliance.
2. Insert 4 AA / LR6 batteries into the battery compartment. Pay attention to the correct polarity. You will find a note on this in the battery compartment. Do not use rechargeable batteries.
3. Close the battery compartment again with the cover.

Connecting the Power Supply Unit

WARNING:

Make sure that the switch (8) is in the OFF position. Otherwise the sewing machine will start sewing immediately.

1. Check that the mains voltage you want to use matches that of the power supply unit.
2. Insert the mains plug into the mains connection socket (22) on the back of the appliance.
3. Connect the appliance to a properly installed protective contact socket.

Switching the Appliance On and Off

• The appliance is switched off when the switch (8) is in the OFF position.
  • There are two ways to switch on the appliance:
  1) Set the switch to OFF and use the foot pedal (25).
  2) Select a speed level L (Low) or H (High) with the switch and the machine starts sewing directly.

LED Sewing Field Light

The LED sewing lamp is maintenance-free and does not require replacement.

Selection of Needle Size and Threads

Needle system: System 130 flat-shank needle

Needle Size	Fabrics Thread
80(12)	Medium weight fabrics: Cotton, satin, workwear, canvas, double-faced fabrics, lightweight wool	Most threads are of medium size and suitable for these fabrics and needle sizes. For best results: use polyester threads for synthetics and cotton or naturally woven fabrics. Always use the same thread at the top and bottom.
90(14)	Medium weight fabrics: Wool, heavier knitwear, terry cloth, denim fabrics
100(16)	Heavy fabrics: Wool, tent fabrics and quilted fabrics, denim, upholstery fabrics (light to medium)
110(18)	Heavy fabrics: Wool, coat fabrics, upholstery fabrics, some leather and vinyl (with leather needles)	Durable thread

Operation

Inserting the Needle

WARNING: Risk of Injury!

Before inserting or replacing the needle, unplug the power supply unit from the sewing machine.

Change the needle regularly, especially if it is bent or the tip is damaged. A bent needle causes skipped stitches.

Defective needle tips damage the fabric.

Insert the needle as follows:

1. The needle guide must be completely raised. Turn the handwheel (6) in the direction of the arrow.

2. Loosen the needle clamp screw (21) and remove the old needle.

3. Insert the new needle as far as it will go. The flat side of the needle must face backwards.

4. Tighten the needle clamp screw again.

Close-up of a precision optical instrument with a circular component and an arrow pointing to it (no visible text or symbols)

Attaching and Removing the Presser Foot

There are different types of presser feet. You can buy them in shops. Make sure you get the right size. Not all presser feet fit every sewing machine.

To change or remove the presser foot, refer to the following description with the illustrations 1–3.

1. Illustration 1:

Pull the presser foot lever (17) up. Loosen the presser foot

fixing screw (a). Place the presser foot holder (b) on the presser foot bar (c) and tighten the screw (a).

2. Illustration 2:

Place the presser foot (d) on the needle plate. Lower the presser foot lever (17) until the notch (e) is exactly over the presser foot pin (f). Press the lever (g) until the pin (f) engages in the notch (e).

3. Illustration 3:

To remove the presser foot (20), press lever (g). The presser foot falls off.

Threading the Upper-thread

For threading the upper-thread, refer to the illustrations below. Also refer to the illustrated instructions on the appliance.

When threading, make sure that the presser foot (20) is raised and the thread lever (1) is in the uppermost position!

1. Place the thread spool on the thread spool holder (15).

2. Pull the thread through the thread guide (16).

3. Guide the thread down past the adjusting wheel (2).

4. When you reach the bottom, guide it up the left side to the thread lever (1).

5. Guide the thread through the hole on the thread lever (1). Make sure that the thread is inserted from right to left.

Close-up of a sewing machine needle and handle (no visible text or symbols)

Simple line drawing of a hook on a vertical pole next to a rectangular object (no text or symbols)

Close-up of a car's front and side panels showing engine, dashboard, and window (no visible text or symbols)

1. Continue to guide the thread down and pass it through the hole on the needle clamp.

1. Finally, pull the thread through the needle hole. Let the thread run to the back under the presser foot (20). Make sure you pull the thread about 10 cm behind the presser foot.

Close-up of a sewing machine needle and fabric workpiece on a sewing machine (no visible text or symbols)

Adjusting the Upper-thread Tension

The setting is made by turning the adjusting wheel (2).

The basic setting is between 4 and 5.

Depending on the fabric and yarn thickness, turn the adjusting wheel so that the knotting of the upper and lower threads is visible as a dot on the top of the fabric. If loops form, the thread tension is too loose.

Winding the Under-thread Bobbin

CAUTION:

Remove the upper thread completely from the sewing machine. Otherwise it will wrap around internal components and the sewing machine will block.

1. Place a thread spool on the thread spool holder (15).
2. Put an empty under-thread bobbin (27) on the bobbin winder (14).
3. Guide the thread through the thread guide (16) to the empty bobbin.
4. Wind the thread clockwise a few times around the empty bobbin.
5. Push the bobbin against the bobbin winder stop (13) (see illustration).
6. Start winding with the foot pedal (25) or use the switch (8).
7. When the winder is full, the winding stops automatically. If you want to stop winding prematurely, release the foot pedal.
8. Cut the thread and remove the bobbin.

Close-up of a white industrial pipe fitting with a black arrow pointing to a component (no visible text or symbols)

Inserting the Under-thread Bobbin

1. The needle must be fully raised when inserting or removing the under-thread bobbin (27). Turn the handwheel (6) in the direction of the arrow.
2. Pull the bobbin cover (10) off to the front.
3. Place the bobbin in the hook so that it turns anticlockwise (see illustration). Let the thread hang out of the bobbin by about 10 cm.
4. Push the bobbin cover back in.

Close-up of a sewing machine needle stitching a small mechanical component (no visible text or symbols)

Bringing up the Under-thread

1. Raise the presser foot (20).
2. Hold the upper-thread with your left hand.
3. At the same time, with your right hand, turn the handwheel (6) in the direction of the arrow until the needle is raised (one complete turn of the handwheel).
4. Pull the lower and upper-threads 10 cm back under the presser foot. You can use a scissor or the thread cutter (12) for this.

Select Stitch Pattern

There are 12 stitch pattern types to choose from.

Select a stitch pattern using the table below. When turning the stitch pattern adjusting wheel (3), the needle must always be in the uppermost position.

Stitch Pattern	Explanation
1 Straight stitch, small stitch length
2 Straight stitch, medium stitch length
3 Straight stitch, long stitch length
4 Straight stitch, needle left, medium stitch length
5 Elastic stitch
6 Blind stitch
7 Buttonhole
8 Buttonhole
9 Wide zigzag stitch, small stitch length
10 Narrow zigzag stitch, medium stitch length
11 Wide zigzag stitch, medium stitch length
12 Wide zigzag stitch, long stitch length

1. The needle must be completely raised. Turn the handwheel (6) in the direction of the arrow.
2. Set the stitch pattern adjusting wheel to the desired setting. Make sure that the stitch pattern adjusting wheel locks in the desired position.

Sewing

1. Make sure that the winder (14) is in the left position.
2. Raise the presser foot (20). Make sure that the upper-thread and under-thread is pulled back about 10 cm.
3. Place the fabric under the presser foot and lower the presser foot.
4. Start sewing. Slowly press the foot pedal (25) or select one of the two speed levels with the switch (8). Guide the fabric with your hand.

- IMPORTANT! Do not pull or push the fabric while sewing. This can cause damage to the needle!

1. To sew a bartack at the end of the seam or in the seam, press down the button to sew backwards (7). When the button is released, the sewing machine sews forward again.

2. At the end of the seam, the needle must be in the upper position to allow the thread to be pulled out easily.

3. Lift the presser foot to remove the fabric.
4. To cut the threads, you can pass them over the thread cutter (12). Or use a pair of scissors.

Buttonholes

1. Place the fabric under the presser foot (20).
2. Lower the presser foot where you want to sew the buttonhole.
3. Then select stitch pattern 8 with the adjusting wheel (3).
4. Sew 5 - 6 stitches with low speed (L).
5. Select stitch pattern 7 with the adjusting wheel (3).
6. Sew on the fabric at a suitable length. Make sure the stitch is sewn in a straight line.
7. Select stitch pattern 8 with the adjusting wheel (3).
8. Sew 5 - 6 stitches with low speed (L).
9. Lift the presser foot (20) and turn the fabric 180°.
10. Select stitch pattern 7 with the adjusting wheel (3).
11. Sew until the buttonhole is completely sewn.

Close-up of a mechanical device with two circular inset views showing magnified views (no visible text or symbols)

Close-up of a sewing machine needle with attached gauges (no visible text or symbols)

Medical or laboratory equipment setup with gauges and tubing (no visible text or symbols)

Close-up of a mechanical device on a textured surface with no visible text or symbols

Close-up of a pressure regulator with gauges and tubing (no visible text or symbols)

End Operation

1. Switch off the appliance by sliding the switch (8) to the OFF position.
2. Switch off the light with the switch (11).
3. Unplug the power supply unit (26) from the socket.
4. Disconnect the foot pedal (25) and power supply unit (26) from the sewing machine.

Cleaning

WARNING:

• Switch off the appliance before cleaning. Unplug the power supply unit from the socket.
• Never immerse the sewing machine, the foot pedal or the power supply unit in water for cleaning! It could cause an electric shock or fire.

CAUTION:

• Do not use a wire brush or other abrasive objects.

• Do not use any sharp or abrasive cleaning agents.

• Use only a moderately damp cloth to clean the outside of the housing. If necessary, use a little hand dishwashing detergent. Then dry the housing with a soft cloth.

• Clean the area underneath the bobbin cover with a dry brush.

Storage

• We recommend storing the appliance in its original packaging if you do not intend to use it for a long period of time.
• Always store the appliance out of the reach of children in a well-ventilated and dry place.

Troubleshooting

Problem Possible Cause	Remedy
The upper-thread breaks.	The upper-thread is not threaded correctly in the sewing machine.	Re-thread the upper-thread.
	The thread tension is too tight. Loosen the thread tension (lower number).
	The thread is too thick for the needle. Select a larger needle.
	The needle is not inserted correctly. Remove the needle and reinsert it. (Flat side of the needle points to the back.)
	The needle is damaged. Replace the needle.
Problem Possible Cause Remedy
The under-thread breaks.	The under-thread bobbin is not inserted correctly.	Check the position of the under-thread bobbin.
	The upper-thread tension is too loose. Adjust the upper-thread tension (higher number).
Stitches are skipped. The needle is not inserted correctly. Remove the needle and reinsert it. (Flat side of the needle points to the back).
The needle is damaged. Insert a new needle.
The needle was damaged. Insert a new needle.
The needle size for the fabric. Choose a needle that is suitable for the thread and fabric.
The presser foot is not attached correctly. Check the position of the presser foot and insert it correctly.
The needle was damaged. Insert a new needle.
The needle is not inserted correctly. Remove the needle and reinsert it. (Flat side of the needle points to the back).
Wrong needle size for the fabric. Choose a needle that is suitable for the thread and fabric.
The presser foot is not attached correctly. Check the position of the presser foot and insert it correctly.
Loose stitches	The upper-thread is not threaded correctly in the sewing machine.	Check the threading of the upper-thread.
	The under-thread bobbin is not inserted correctly.	Insert the under-thread bobbin correctly.
	Needle / fabric / thread combination is wrong.	The needle size must be suitable for fabric and thread (see table on page 13).
	Wrong thread tension.	Correct the thread tension.
Seam curls	The needle is too big for the fabric.	Select a finer needle.
	The stitch length is set incorrectly.	Select a suitable stitch pattern with the stitch pattern adjustment wheel.
	The thread tension is too tight.	Loosen the thread tension (lower number).

Technical Data

Model: NM 6063 CB

Protection class:....III

Power supply:......DC 6 V, 1200 mA

Sewing field light:......LED 0.1 W, 3 V

Net weight: .... approx. 2.1 kg

Power Supply Unit

Protection class:....II

Input: AC 100–240V, 50/60Hz, max. 0.4A

Output:.....DC 6V, 1200 mA

Polarity:

Battery operation: 4× 1.5V type AA/LR6

The right to make technical and design modifications in the course of continuous product development remains reserved.

This appliance has been tested according to all applicable, current CE directives and built according to the latest safety regulations.

* not applicable due to an output power of less than 10 W.
Product Specifications in Accordance with Regulation (EU) 2019/1782 Power Supplies

Information about the Power Supply Used	Value	Unit
DistributorC. Bomann GmbHCommercial register number HRB 9845Heinrich-Horten-Straße 17, 47906 KempenGermany
Model identifier	SW0601200-W02
Input voltage	100–240	V~
Input alternating current frequency	50/60	Hz
Output voltage AC /DC	6.0	V DC
Output current	1.2	A
Information about the Power Supply Used	Value Unit
Output power 7.2 W
Average efficiency in operation 81.38 %
Low load efficiency (10 %)	*	%
No-load power consumption 0.071 W

The relevant load conditions are as follows:

Percentage of nameplate output current

Load condition 1 100% ± 2%
Load condition 2 75% ± 2%
Load condition 3 50% ± 2%
Load condition 4 25% ± 2%
Load condition 5 10% ± 1%
Load condition 6 0% (no-load condition)

Disposal

Battery Disposal

As a consumer you are obliged by law to return old batteries / accumulators.

Your appliance contains batteries. If these batteries are spent, follow the instructions below:

CAUTION:

Batteries / rechargeable batteries must not be disposed of with household waste!

• The batteries must be removed from the appliance.
  • Take spent batteries to the appropriate collection point or to a dealer.
• Your town or local authority can provide information about public collection points.

Meaning of the "Dustbin" Symbol

Protect our environment: do not dispose of electrical equipment in the domestic waste.

Please return any electrical equipment that you will no longer use to the collection points provided for their disposal.

This helps avoid the potential effects of incorrect disposal on the environment and human health.

This will contribute to the recycling and other forms of re-utilisation of electrical and electronic equipment.

Information concerning where the equipment can be disposed of can be obtained from your local authority. Your dealer and contractual partner is also obliged to take back the old appliance free of charge.

BELANGRIJK:

Close-up of a microscope instrument with a metallic handle and optical components (no visible text or symbols)

Close-up of a metallic object with vertical lines and a small mark, possibly part of a device or component (no visible text or symbols)

Close-up of a car's front wheel and side door, showing no visible text or symbols

Close-up of a mechanical device with lever and base mount (no visible text or symbols)

Close-up of a white industrial piping bag with a valve and outlet (no visible text or symbols)

Close-up of a sewing machine needle stitching a small mechanical component (no visible text or symbols)

Onderdraad opnemen

Close-up of a mechanical device with dual gauges and a close-up inset showing a magnified view (no readable text or symbols)

Industrial machinery setup with conveyor system and control panel (no visible text or symbols)

Close-up of a precision optical instrument with a circular component and an arrow pointing to it (no visible text or symbols)

Close-up of a vehicle's side panel with a door and window, no visible text or symbols

Close-up of a mechanical device with a lever and adjustment knobs (no visible text or symbols)

Exterior view of a mechanical device on a textured surface (no visible text or symbols)

Close-up of a pressure gauge and mechanical component (no visible text or symbols)

Condition de charge 1 100% ± 2%
Condition de charge 2 75% ± 2%
Condition de charge 3 50% ± 2%
Condition de charge 4 25% ± 2%
Condition de charge 5 10% ± 1%
Condition de charge 6	0% (condition sans charge)

Élimination

Close-up of a microscope with an arrow pointing to the lens (no visible text or symbols)

Close-up of a bathroom sink appliance with a glass tube and metal holder (no visible text or symbols)

Close-up of a small mechanical component with a curved handle and circular end (no visible text or symbols)

Close-up of a white object with vertical lines and a small mark, possibly part of a device or tool (no readable text or symbols)

Close-up of a mechanical device with lever and base mount (no visible text or symbols)

Close-up of a sewing machine needle stitching a small electronic component (no visible text or symbols)

Close-up of a sewing machine with measurement scales and a close-up inset showing a measurement (no visible text or symbols)

Black-and-white photo of a mechanical device on a dark surface, no visible text or symbols

Close-up of a mechanical device with pressure gauges and a ruler, no visible text or symbols

Fin del manejo

Close-up of a precision optical instrument with a circular dial and mechanical components (no visible text or symbols)

Close-up of a bathroom sink with a glass tube and handle (no visible text or symbols)

Simple line drawing of a hanging hook on a wall next to a rectangular object (no text or symbols)

Close-up of a pressure regulator with gauges and a magnified inset showing internal components (no visible text or symbols)

Fine dell'utilizzo

Close-up of a microscope with an arrow pointing to the lens (no visible text or symbols)

Close-up of a small cylindrical object with a metallic handle, possibly a container or fixture (no visible text or symbols)

Close-up of a vehicle's side panel with a door and window, no visible text or symbols

Close-up of a mechanical sewing machine needle and base mount (no visible text or symbols)

Close-up of a sewing machine needle stitching a small electronic component (no visible text or symbols)

Podnoszenie pod nici

Close-up of a mechanical device with two circular gauges (no visible text or symbols)

Close-up of a sewing machine needle with measurement scales (no visible text or symbols)

Close-up of a mechanical pressure regulator with dual gauges and a magnified inset showing internal components (no visible text or symbols)

Zakończenie obsługi

CTC Clatronic Sp. z o.o

Ul. Brzeska 1

45-960 Opole

Usuwanie

Usuwanie baterii

Close-up of a precision optical instrument with a metallic handle and mounted base, showing no visible text or symbols.

Close-up of a vehicle's front panel showing the door and side window (no visible text or symbols)

Close-up of a mechanical device with no visible text or symbols

Close-up of a sewing machine needle stitching fabric (no visible text or symbols)

Close-up of a mechanical pressure regulator with dual gauges and a magnified inset showing internal components (no visible text or symbols)

Művelet befejezése

Close-up of a precision optical instrument with a mounted scale and adjustment knob (no visible text or symbols)

Close-up of a bathroom sink appliance with a glass tube and handle (no visible text or symbols)

Close-up of a metallic object with vertical lines and a small mark, no visible text or symbols

Close-up of a mechanical device with no visible text or symbols

Close-up of a sewing machine needle stitching fabric (no visible text or symbols)

Close-up of a sewing machine needle stitching a small electronic component (no visible text or symbols)

Вывод нижней нити

Mechanical device with circular gauges and a magnified inset showing internal components (no visible text or symbols)

Окончание работы

Close-up of a mechanical device with two circular gauges and a magnified inset showing internal components (no visible text or symbols)

Medical or laboratory setup with a patient in bed and measurement scales (no visible text or symbols)

Close-up of a mechanical device with measurement scales and a close-up inset showing a scale (no visible text or symbols)

Industrial machine in operation on a dirt site, no visible text or symbols

Close-up of a mechanical device with dual pressure gauges and a ruler for scale (no visible text or symbols)

العراوي

Close-up of a sewing machine needle stitching a small electronic component (no visible text or symbols)

Close-up of a metallic object with vertical lines and a small mark, no visible text or symbols

13 improves from the MacKay

14 ملفاف الخيط

15 حامل بكرة الخيط

16 دليل Highway
