KHF 695 610 S - Basket AMICA - Free user manual and instructions
Find the device manual for free KHF 695 610 S AMICA in PDF.
📄
Document temporarily unavailable
The manual is currently being transferred to our new server. It will be accessible again in a few hours. Thank you for your patience.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product type | Range hood |
| Brand | AMICA |
| Model | KHF 695 610 S |
| Width (estimated) | 90 cm |
| Main material | Stainless steel |
| Mounting type | Wall-mounted (chimney) |
| Number of speeds | 4 (including a booster speed) |
| Control type | Touch controls |
| Lighting | LED, with intensity adjustment (dimmer) and color |
| Grease filter | Aluminum, dishwasher safe |
| Charcoal filter | Active, replaceable (not washable) |
| Evacuation mode | Recirculation or external evacuation |
| Duct diameter | 120 mm or 150 mm |
| Timer | Delayed shut-off of 15 minutes |
| Booster function | Yes, automatic reduction after a few minutes |
| Grease filter cleaning | Every month |
| Charcoal filter cleaning | Every 3 to 4 months |
| Warranty | 2 years (according to warranty card) |
Frequently Asked Questions - KHF 695 610 S AMICA
How to clean the grease filter of my AMICA KHF 695 610 S hood?
The aluminum grease filter can be cleaned in the dishwasher or manually with a mild detergent. It is recommended to clean it every month. After several washes, the color may change, which is normal.
How often should the charcoal filter be replaced?
The activated charcoal filter must be replaced every 3 to 4 months, or more frequently in case of heavy use. It is neither washable nor regenerable.
How to use the timer (delayed shut-off)?
To activate the delayed shut-off, press and hold the active speed button for 3 seconds. The button flashes, indicating that the hood will automatically turn off after 15 minutes. To deactivate, press the button again.
How to adjust the lighting intensity (dimmer)?
With the light on, press and hold the lighting button for 3 seconds. The intensity decreases gradually. Each additional press reduces the intensity further until the minimum, then returns to maximum.
How to change the lighting color?
Press and hold the ⚙️ and 4 buttons simultaneously for 2 seconds. Buttons 1 and 4 flash. Use them to choose the color, then confirm with the ⚙️ button.
What is the recommended installation height above the cooking hob?
The minimum installation height is indicated on the technical data sheet of the appliance. In general, for an electric hob, it is about 65 cm and for a gas hob, 75 cm. Always follow the hob manufacturer's instructions.
Can I use the hood without the grease filter?
No, it is forbidden to use the hood without the grease filter. The filter retains grease and prevents fire hazards.
What to do if the hood does not work or the light does not turn on?
First check that the appliance is plugged in and the fuse has not blown. If the light does not work, it may be necessary to replace the LED bulb (have this done by a professional). For any other malfunction, contact the after-sales service.
How to switch between recirculation mode and evacuation mode?
For recirculation mode, install a charcoal filter and an air deflector. For evacuation mode, remove the charcoal filter and connect the hood to an external evacuation duct. Some models require a manual change (refer to drawing 8 of the manual).
The hood is making noise, is this normal?
A slight noise is normal, but if it is excessive, check that the grease filter is correctly installed and that nothing is obstructing the duct. If the noise persists, contact the after-sales service.
