USER MANUAL BigToast Double CECOTEC

1. Parts and components 26

3. Cleaning and maintenance 28

4. Technical specifications 29

5. Disposal of old electrical appliances 29

6. Technical support service and warranty 29

1. 35-mm (maximum width) and 130-mm bread slots (maximum height).

The slots allow you to bake many different products.

2. Elevation-system control lever

For a 80-mm high slice of bread, the top edge should not be less than 20 mm above the toaster's surface after the elevation system comes out.

Add extra time to the cycle for toasting frozen bread.

Unwind the power cord. Check that the crumb tray is in correctly placed and that there is nothing inside the toaster slots. Plug the power cord into the wall outlet.

1. Insert slice(s) of bread inside the device.

2. Set the level of toasting

Turn the toasting-control selector to select the toasting of your toasts: Browning control setting Toasting type 1-2 Light 2-4 Medium 5-6 Dark

3. Toasting the bread:

• For slightly dry bread, use a lower setting than you normally would.

• For fresh bread or whole-wheat bread, use a higher setting than normal.

• Breads with uneven surfaces (such as muffins) will require a higher toast setting.

• Thick slices of bread (including bagels or baguettes and muffins) will take longer to toast, sometimes significantly longer, since more moisture must be evaporated for the bread to 03084_BigToast Double_Manual_YV_01200430.indd 2603084_BigToast Double_Manual_YV_01200430.indd 26 4/5/20 12:014/5/20 12:01BIGTOAST DOUBLE

ENGLISH be toasted. Very thick slices may require two cycles.

• When toasting bread with raisins or with other fruits, remove any loose raisins, etc. from the surface of the bread before putting it into the toaster. This will prevent fruit pieces from falling into the toaster or sticking inside the slot.

For toasting a single slice of bread, set the toasting selector to a lower setting than you normally would. The device is designed to heat both bread slots. By lowering the heat lever for a single slice, you will not over-toast it.

3.2 Frozen waffles, pancakes, French toasts and frozen bagels should be cooked using the

Be careful when toasting pastries; the filling can become quite hot, long before the surface of the pastry is toasted. Do not leave pastries unattended while toasting.

4. Starting and stopping the toasting:

For starting the toasting, push down the lever until it reaches its lock-down position. When the toasting cycle is over, the toast will come out automatically. For stopping the toasting before it finishes, just press the Stop button. Note: Do not force the bread into the slots. Do not introduce glazed or stuffed pastries or buttered breads as this may cause a fire. Uneven toasting usually happens because of toasting bread of uneven thickness. After using it, unplug the device from the electrical outlet.

5. Defrosting button

The defrosting function is intended to defrost the bread and then toast it slightly.

5.1 Introduce a slice of bread

Make sure the slices of bread do not overlap and that the lever is lifted.

5.2 Set the toasting selector

• Settings 1-2: For frozen breads and thinner frozen pieces such as frozen pancakes.

• Settings 3-4: For pastries, frozen waffles, thin baguettes and frozen bagels.

• Settings 5-6: For thicker frozen items such as bagels, hand-cut bread and thick baguettes

5.3 Begin toasting: Push down the lever until it reaches its lock-down position (it must remain

5.4 Press the Defrost button. A LED light will indicate that this feature has been activated.

5.5. When the defrosting is completed, the lever will go to its upper position taking with it the bread. If you wish to stop the cycle before it finishes, just press the Stop button. After using the device, unplug it. 03084_BigToast Double_Manual_YV_01200430.indd 2703084_BigToast Double_Manual_YV_01200430.indd 27 4/5/20 12:014/5/20 12:01BIGTOAST DOUBLE

The reheating function is intended to reheat the bread without toasting it.

6.1 Introduce a slice of bread. Make sure they do not overlap and the lever is lifted (it must

6.2 To begin reheating, push down the lever until it reaches its lock-down position.

6.3 Press the Reheating button. A LED light will indicate that this feature has been activated.

6.4 When the reheating is completed, the lever will go to its upper position taking with it the

bread. If you wish to stop the cycle before it finishes, just press the Stop button. After using the device, unplug it.

This functions is designed to last the same as the toasting cycle. When you use it to toast thicker breads, baguettes, muffins or other thick breads, a higher toasting setting may be required.

7.1 Insert slice(s) of halved bagels/baguettes. Make sure they do not overlap.

7.2 Push down the lever until it reaches its lock-down position (it must remain fix).

7.3 Press the Bagel button. A LED light will indicate that this feature has been activated.

7.4 When this function is completed, the lever will go to its upper position taking with it the

bread. If you wish to stop the cycle before it finishes, just press the Stop button. After using the device, unplug it.

To reheat the pastry, place the holder on the device, using the side clampings. Make sure the clampings ends are slightly inside the slots. Place the food on the holder. To start the reheating, push the lever all the way down (it should remain fix). Press the reheat button. A LED light will indicate that this function has been activated When the reheating is completed, the lever will go to its upper position. If you wish to stop the cycle before it finishes, just press the Stop button. After using the device, unplug it.

3. CLEANING AND MAINTENANCE

Disconnect the appliance from the power supply and allow it to cool down before cleaning. Use a soft, damp cloth to clean the product’s surface. Do not immerse the appliance in water or other liquid. Do not use abrasive scouring pads, powders or cleaners. To remove any crumbs inside the device, take out the crumb tray. Do not operate the device without the crumb tray in place. To remove any crumbs of bread remaining in the device, turn the device upside down and shake it carefully. Do not insert any hard or sharp objects inside the slot, as this could damage the device. Do not wrap the power cord around the outside of the device. Use the cord storage cleats 03084_BigToast Double_Manual_YV_01200430.indd 2803084_BigToast Double_Manual_YV_01200430.indd 28 4/5/20 12:014/5/20 12:01BIGTOAST DOUBLE

ENGLISH under the device.

The European directive 2012/19/EU on Waste Electrical and Electronic Equipment (WEEE), specifies that old household electrical appliances must not be disposed of with the normal unsorted municipal waste. Old appliances must be collected separately, in order to optimize the recovery and recycling of the materials they contain and reduce the impact on human health and the environment. The crossed out “wheeled bin” symbol on the product reminds you of your obligation to dispose of the appliance correctly. If the product has a built-in battery or uses batteries, they should be removed from the appliance and disposed of appropriately. Consumers must contact their local authorities or retailer for information concerning the correct disposal of old appliances and/or their batteries.

6. TECHNICAL SUPPORT SERVICE AND WARRANTY

This product is under warranty for 2 years from the date of purchase, as long as the proof of purchase is submitted, the product is in perfect physical condition, and it has been given proper use, as explained in this instruction manual. The warranty will not cover the following situations: The product has been used for purposes other than those intended for it, misused, beaten, exposed to moisture, immersed in liquid or corrosive substances, as well as any other fault attributable to the customer. The product has been disassembled, modified, or repaired by persons, not authorised by the official Technical Support Service of Cecotec. Faults deriving from the normal wear and tear of its parts, due to use. The warranty service covers every manufacturing defects of your appliance for 2 years, based on current legislation, except consumable parts. In the event of misuse, the warranty will not apply. If at any moment you detect any problem with your product or have any doubt, do not hesitate to contact Cecotec Technical Support Service at [phone]. 03084_BigToast Double_Manual_YV_01200430.indd 2903084_BigToast Double_Manual_YV_01200430.indd 29 4/5/20 12:014/5/20 12:01BIGTOAST DOUBLE
