Product Type	4-Slice Toaster
Model	78824
Brand	WestBend
Capacity	4 slices
Browning Levels	7 (1 light to 7 dark)
Functions	Cancel, Bagel, Defrost, Waffle
Special Features	Ultimate Lift lever for easy removal
Power Source	120V AC, 60 Hz
Plug Type	Polarized plug
Crumb Tray	Removable, slide-out
Cleaning	Wipe exterior with damp cloth; do not immerse in water
Safety Features	Auto shut-off, cool-touch exterior? No, but has polarized plug
Warranty	1 Year Limited Warranty
Country of Origin	Printed in China
Product Registration	Optional, not required for warranty

Frequently Asked Questions - 78824 WestBend

How do I use the bagel setting?

Press the toast lever down, then press the Bagel button. The indicator light will glow, and both sides of the bagel will be toasted.

How should I clean the toaster?

Unplug and let cool. Slide out the crumb tray and empty it. Wipe the exterior with a damp cloth. Do not immerse in water or use abrasive cleaners.

Why is my toast uneven in color?

Variations in toast color are normal, especially when toasting one slice. Factors like moisture content, thickness, and grain type affect browning.

Can I toast pastries or items with frosting?

Use the lowest setting and watch constantly. Frostings can catch fire. Avoid toasting items with open fillings or that may drip.

What should I do if bread gets stuck inside the toaster?

Unplug the toaster and let it cool completely. Turn it upside down and shake to dislodge. Never use metal objects to remove stuck food.

What does the defrost setting do?

The Defrost setting toasts frozen bread or pastries in one step. Press the toast lever down, then press the Defrost button.

Can I use an extension cord with this toaster?

It is not recommended. If necessary, use a grounding-type 3-wire cord with a rating equal to or greater than the toaster's.

Why does the toaster produce smoke or odor on first use?

This is normal due to manufacturing oils burning off. Run the toaster empty on the darkest setting once before first use.

How do I store the power cord?

Wrap the cord around the clips on the underside of the toaster for easy storage.

What is covered by the warranty?

The 1 Year Limited Warranty covers material and workmanship failures. It does not cover non-stick surface damage or misuse. Proof of purchase is required.

USER MANUAL 78824 WestBend

Register this and other West Bend products through our website: http://registerproductsonline

Product registration is not required to activate warranty.

Important Safeguards 2

Before Using for the First Time 3

Using Your 4-Slice Toaster 4

Helpful Hints 5

Cleaning Your 4-Slice Toaster 5

Warranty 6

SAVE THIS INSTRUCTION MANUAL FOR FUTURE REFERENCE

IMPORTANT SAFEGUARDS

CAUTION

To prevent personal injury or property damage, read and follow all instructions and warnings.

When using electrical appliances, basic safety precautions should always be followed including:

• Read all instructions.
• Do not touch hot surfaces. Use handles or knobs.
• To protect against fire, electric shock, and injury to persons do not immerse cord, plugs, or other electric parts in water or other liquids.
• Close supervision is necessary when this appliance is used by or near children.
• Always unplug from outlet when not in use and before cleaning. Allow to cool before putting on or taking off parts and before cleaning.
• Do not operate any appliance with a damaged cord or plug, after the appliance malfunctions, or has been damaged in any manner. For service information see warranty page.
• The use of accessory attachments not recommended by West Bend may cause fire, electric shock, or injury.
• Do not use this appliance outdoors.
• Do not let cord hang over the edge of the table or counter, or touch hot surfaces.
• Do not place on or near a hot gas or electric burner, or in a heated oven.
• Always plug cord into wall outlet. To disconnect, turn any control to "OFF," then remove plug from wall outlet.
• Do not use appliance for other than intended use.
• Extreme caution must be used when moving an appliance containing hot oil or other hot liquids.
• Do not attempt to repair this appliance yourself.
• A short power-supply cord is provided to reduce risks resulting from becoming entangled in or tripping over a longer cord.
• Longer extension cords are available, but care must be exercised in their use. While use of an extension cord is not recommended, if you must use one, ensure that the marked electrical rating of the extension cord is equal to or greater than that of the appliance. If the plug is of the grounded type, the extension cord must be a grounding-type 3-wire cord. To avoid pulling, tripping or entanglement, position the extension cord so that it does not hang over the edge of the counter, table or other area where it can be pulled on by children or tripped over.
• This appliance has a polarized plug (one blade is wider than the other). To reduce the risk of electric shock, this plug is intended to fit into a polarized outlet only one way. If the plug does not fit fully into the outlet, reverse the plug. If it still does not fit, contact a qualified electrician. Do not attempt to modify the plug in any way.
• Do not use an outlet or extension cord if the plug fits loosely or if the outlet or extension cord feels hot.

• Oversized foods, metal foil packages, or metal utensils must not be inserted in a toaster as they may involve a risk of fire or electric shock.

• A fire may occur if the appliance is covered or touching flammable material, including curtains, draperies, walls, and the like, when in operation.

• Do not attempt to dislodge food when toaster is plugged in.
• Avoid toasting foods with frostings or fillings that may run or that are made with open fillings. Frostings and fillings can catch fire.
• Do not toast pastries, tarts and the like at any setting other than the lowest or lightest setting and never toast twice as these items can ignite if over-heated and cause fire.
• Failure to clean and replace crumb tray after each use may result in fire hazard.
• For household use only.

SAVE THESE INSTRUCTIONS

BEFORE USING FOR THE FIRST TIME

Please check all packaging material carefully before discarding. Accessory parts may be contained within the packaging material.

Before using, wipe the outside of the toaster with a damp cloth then dry thoroughly. Operate the toaster the first time without any food in the toaster slots and with the browning control knobs set to darkest settings. This will eliminate any residual manufacturing oils. Please note that a small amount of smoke and/or odor may occur upon heating due to the release of manufacturing oils - this is normal. Some minor expansion/contraction sounds may occur during heating and cooling - this is also normal.

CAUTION: Do not immerse any part of the appliance in water or any other liquid.

USING YOUR 4-SLICE TOASTER

1. Place toaster on a dry, level, heat-resistant surface, away from any edge or flammable materials. Plug cord into 120-volt, AC outlet only.

2. Place one piece per toaster slot of bread, bagels, English muffins, pastry slices, etc., into bread slots. Select toast color setting from 1 (light) to 7 (dark). Place one slice only of the food to be toasted in each slot.

3. Press the toast lever(s) down until locked into place. The toasting cycle will automatically begin. Toaster must be plugged in for toast levers to lock in place. Toast will pop up and toaster will turn off when the selected color is reached. After the toast has popped up, the Ultimate Lift™ lever can be raised to safely assist in removing foods. The toast cycle can be stopped at any time by pressing the cancel button(s). Note: Do not attempt to dislodge food when toaster is plugged in.

4. Unplug the cord from wall outlet when not in use and allow to cool before cleaning.

Bagel Setting: The bagel setting will add additional time for toasting bagels. To use, press toast lever down and press the bagel button. The bagel indicator light will glow when activated. Both sides of the bagel will be toasted.

Defrost Setting: The defrost setting will take the bread/frozen pastry from frozen to toasted in one step. To use, press toast lever down and press the defrost button. The defrost indicator light will glow when activated.

Waffle Setting: Use the waffle setting to toast frozen waffles. To use, press toast lever down and press the waffle button. The waffle indicator light will glow when activated.

Note: The above settings can only be activated after the toast lever is pushed down and locked.

HELPFUL HINTS

• Toasting can be stopped any time by pressing the "Cancel" buttons.
• Use the "Defrost" setting for frozen foods. They may also require a darker setting.
• While it is not recommended, if you do toast foods with frosting or icing, toast at the lowest setting with constant attention.
• Do not cook, warm, or toast fried foods, rice cakes, or non-bread items in the toaster. Do not heat any foods that have been spread with butter, jelly, frosting, syrup, or other spread.
• Unplug the toaster immediately if fire or smoke is observed.
• If food becomes lodged inside the toaster, unplug the cord from the wall outlet and allow the toaster to cool completely. Turn the toaster upside down and shake to dislodge.
• Never insert a metal fork or any other metal objects into the toasting slot.
• Please note that many variables factor into making toast; moisture content and temperature of the bread, thickness, sugars and starches, and grains can all affect the browning of the bread when making toast.
• Wheat and whole grain breads tend to require longer toasting times. We recommend toasting somewhere between settings 3 and 5; adjust to your preference.
• When toasting, you may notice variations in toast color from side to side. This is normal, especially when toasting one slice of bread.

CLEANING YOUR 4-SLICE TOASTER

1. Unplug toaster from outlet and allow to cool before cleaning. Slide crumb trays out from under toaster, empty and wipe clean with damp cloth if necessary. Replace the crumb trays. Note: Failure to clean crumb tray regularly may result in a fire hazard.
2. Wipe the outside surfaces of toaster with a damp cloth and dry thoroughly. Do not use any metal or abrasive scouring pads or cleansers on any toaster surfaces. To clean the inside of toaster, turn toaster upside down and shake crumbs free.
3. Wrap the cord around the clips on the underside of the toaster for storage, if desired.

CAUTION: Do not immerse any part of the appliance in water or any other liquid.

This appliance has no user serviceable parts.

PRODUCT WARRANTY

Appliance 1 Year Limited Warranty

West Bend® ("the Company") warrants this appliance from failures in the material and workmanship for one (1) year from the date of original purchase with proof of purchase, provided that the appliance is operated and maintained in conformity with the Instruction Manual. Any failed part of the appliance will be repaired or replaced without charge at the Company's discretion. This warranty applies to indoor household use only.

This warranty does not cover any damage, including discoloration, to any non-stick surface of the appliance. This warranty is null and void, as determined solely by the Company, if the appliance is damaged through accident, misuse, abuse, negligence, scratching, or if the appliance is altered in any way.

THIS WARRANTY IS IN LIEU OF ALL IMPLIED WARRANTYES, INCLUDING WARRANTYES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, PERFORMANCE, OR OTHERWISE, WHICH ARE HEREBY EXCUSED. IN NO EVENT SHALL THE COMPANY BE LIABLE FOR ANY DAMAGES, WHETHER DIRECT, INDIRECT, INCIDENTAL, FORSEEABLE, CONSEQUENTIAL, OR SPECIAL ARISING OUT OF OR IN CONNECTION WITH THIS APPLIANCE.

If you think the appliance has failed or requires service within its warranty period, please contact the Customer Care Department through our website at www.westbend.com "Support" - > "Contact Us". A receipt proving the original purchase date will be required for all warranty claims, hand written receipts are not accepted. You may also be required to return the appliance for inspection and evaluation. Return shipping costs are not refundable. The Company is not responsible for returns lost in transit.

Valid only in USA and Canada

REPLACEMENT PARTS

Replacement parts, if available, may be ordered online at www.westbend.com.

This manual contains important and helpful information regarding the safe use and care of your product. For future reference, attach dated sales receipt for warranty proof of purchase and record the following information:

Date purchased or received as gift:

Where purchased and price, if known:

Item number and Date Code (shown bottom/back of product):

English 6

L5960B

0821

West Bend®

Printed in China
