Vacuum cleaner type	Bagless canister vacuum (dust container)
Brand	Hoover
Model	Breeze BR40PET 011
Power supply	Mains, power cord with rewind
Suction power	Electronic power control on handle
Filtration system	Washable pre-motor filter and exhaust filter
Container capacity	Dust container with maximum level indicator
Included accessories	Combination hard floor/carpet brush, 2-in-1 crevice tool, mini turbo brush for pet hair, super turbo brush, parquet brush
Features	Floor type selector pedal (carpet/hard floor), Vortex detector, cord rewind
Weight (estimated)	Approximately 4.5 kg
Warranty	According to retailer's conditions
Maintenance	Emptying container, washing filters every 5 emptying or when clogged
Safety	Thermal cut-out, automatic shutdown in case of overheating
Repairability	Hoover spare parts available, repair by approved service
Usage	Household use only
Certifications	CE compliant (Directives 2014/35/EU, 2014/30/EU, 2011/65/EU)

Frequently Asked Questions - Breeze BR40PET 011 HOOVER

How to empty the dust container?

Stop the vacuum and unplug it. Press the container unlock button, remove the container, then remove the cover by turning it counterclockwise. Remove the pre-motor filter and the cyclone diaphragm, empty the container, then reassemble everything.

How to clean the washable filters?

Remove the pre-motor filter and the exhaust filter. Gently tap to remove dust, then wash with warm water without detergent. Let dry completely before reinstalling. Clean filters every 5 empties or if suction decreases.

What to do if the vacuum stops working?

Check if the container is full, if the filters are clogged, or if there is a blockage in the tube/hose. If the vacuum has overheated, the thermal cut-out will automatically reset after about 45 minutes. Let it cool down, unplug it, and resolve the cause.

How to use the mini turbo brush for pet hair?

Attach the mini turbo brush to the hose handle or the tube. It is designed to effectively remove pet hair from carpets and rugs. Do not use on long-fringed rugs, animal skins, or carpets with pile over 15 mm.

Can I use the vacuum on hard floors?

Yes, the vacuum comes with a combination brush that has a selector pedal. For hard floors, press the pedal to lower the protective brushes. Also use the supplied parquet brush for delicate floors.

How to adjust the telescopic tube?

Push the telescopic tube adjustment button upward, then slide the handle to the desired height. Release the button to lock.

What accessories are included with the Breeze BR40PET 011 model?

The accessories include: a combination hard floor/carpet brush, a 2-in-1 crevice tool (flat crevice tool and upholstery brush), a mini turbo brush for pet hair, a super turbo brush, and a parquet brush.

How to rewind the power cord?

Hold the plug of the cord with one hand and press the cord rewind pedal located on the vacuum. The cord winds automatically. Do not pull on the cord.

Is this vacuum suitable for allergy sufferers?

Yes, the vacuum is equipped with a washable pre-motor filter and exhaust filter that trap dust and allergens. Some models include a mini turbo brush limiting bacteria proliferation.

Where can I find spare parts for this vacuum?

Hoover spare parts and consumables are available from your Hoover retailer. When ordering, specify the model number (Breeze BR40PET 011).
For repairs, contact an approved Hoover repair service.

USER MANUAL Breeze BR40PET 011 HOOVER

INSTRUCTIONS FOR SAFE USE

This appliance should only be used for domestic cleaning, as described in this user guide. Please ensure that this guide is fully understood before operating the appliance.

Do not leave the appliance plugged in. Always switch off and remove the plug from the socket after use, or before cleaning the appliance or any maintenance task.

This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.

If the power cord is damaged stop using the appliance immediately. To avoid a safety hazard, an authorised HOOVER service engineer must replace the power cord.

Keep hands, feet, loose clothing and hair away from rotating brushes.

Use only attachments, consumables or spares recommended or supplied by HOOVER.

Static electricity: Some carpets can cause a small build up of static electricity. Any static discharge is not hazardous to health.

Do not use your appliance out of doors or on any wet surface or for wet pick up.

Do not pick up hard or sharp objects, matches, hot ashes, cigarette ends or other similar items.

GB

Do not spray with or pick up flammable liquids, cleaning fluids, aerosols or their vapours.

Do not run over the power cord when using your appliance or remove the plug by pulling on the power cord.

Do not continue to use your appliance if it appears faulty.

HOOVER service: To ensure the continued safe and efficient operation of this appliance we recommend that any servicing or repairs are only carried out by an authorised HOOVER service engineer.

Do not stand on or wrap the cord around arms or legs when using your appliance.

Do not use the appliance to clean animals or people.

Do not position the appliance above you when cleaning the stairs.

The Environment

The symbol on this appliance indicates that this appliance may not be treated as household waste. Instead it must be handed over to the applicable collection point for the recycling of electrical and electronic equipment. Disposal must be carried out in accordance with local environmental regulations for waste disposal. For more detailed information about treatment, recovery and recycling of this appliance, please contact your local city office, your household and waste disposal service or the shop where you purchased the appliance.

This appliance complies with the European Directives 2014/35/EU, 2014/30/EU and 2011/65/EU.

CANDY HOOVER GROUP S.r.l. Via Privata Eden Fumagalli, 20861 Brugherio (MB) Italy

GETTING TO KNOW YOUR CLEANER

A. Suction Regulator B. Hose Handle C. Telescopic Tube D. On/Off E. Exhaust filter cover F. Carpet & Floor nozzle (GP) F1. Carpet Nozzle (CA)* F2. Hard Floor Nozzle (HF) G. Floor type selector pedal H. Park Slot I. Cord reel Pedal J. Cleaner Main Body

K. Hose L. Dust Container lid M. Dust Container N. Vortex Finder O. Pre-motor Filter P. Dust Container Release Button Q. Exhaust Filter R. 2 in 1 accessory S. Pet Hair Remover Mini Turbo Nozzle# T. Allergen Remover Mini Turbo Nozzle U. Grand Turbo nozzle V. Parquet Nozzle*

ASSEMBLING YOUR CLEANER

Remove all components from the packaging.

1. Connect the hose to the cleaner main body, ensuring it clips and locks into position. [1]
2. To release: simply press the button on the hose end and pull.
3. Connect the hose handle to the upper extension tube end [2], or accessories if required.
4. Connect the extension tube lower end to the carpet and floor nozzle [3] or accessories if required.

USING YOUR CLEANER

1. Extract power cord and plug it into the power supply. Do not pull the cord beyond the red marker, [4]
2. Adjust the telescopic tube to the desired height by moving the telescopic tube adjuster up and raise or lower the handle to the most comfortable cleaning position. [5]
3. Carpet & Floor Nozzle** Press the floor type selector on the nozzle [6] to select the ideal cleaning mode for the floor type.

Hard Floor -Brushes are lowered to protect the floor.

Carpet - Brushes are raised for the deepest clean.

1. Switch the cleaner on by pressing the on/off Pedal on the cleaner main body. [7]
2. Adjust the suction regulator on the handle to the desired level.
3. Switch off at the end of use by pressing the on/off Pedal. Unplug and press the cord reel pedal to wind the power cord back into the cleaner.

PARKING AND STORAGE SECTION

The tube and nozzle can be parked on back of the cleaner for storage or temporary storage while in use.

ACCESSIONS

To obtain the best performance and efficiency it is recommended that the correct nozzles are used for the main cleaning operations. These nozzles are indicated in the diagrams by the letters GP, HF or CA.

A nozzle type GP can be used to clean both carpet and hard floor.

A nozzle type HF is suitable for use only on hard floor.

A nozzle of type CA is suitable for use only on carpet.

The other nozzles are accessories for specialist cleaning tasks and are recommended for occasional use only.

All accessories can be fitted to the hose handle or the end of the tubes.

2 in 1 Tool combines several functions into one tool: Crevice Tool - For corners and hard to reach areas. Dusting Brush - For bookshelves, frames, keyboards and other delicate areas.

Pet Hair Remover Mini Turbo Nozzle* - Use the mini turbo nozzle on stairs or for deep cleaning on textile surfaces and other hard to clean areas. Particularly suitable for pet hairs removal.

Allergen Remover Mini Turbo Nozzle* - Use the mini turbo nozzle on stairs or for deep cleaning on textile surfaces and other hard to clean areas. Particularly suitable for allergen removal.

Parquet Nozzle* - For parquet floors and other delicate floors.

IMPORTANT: Do not use the Mini Turbo Nozzles on rugs with long fringes, animal hides and carpet pile deeper than 15mm. Do not keep the nozzle stationary while the brush is rotating.

CLEANER MAINTENANCE

Emptying the Dust Container

When the dust reaches the max level indicator on the container, empty the dust container.

IMPORTANT: To maintain optimum performance, do not allow the dust to exceed the max level. 1. Turn off the cleaner with the main switch and unplug the power cable. 2. Press the bin release button and remove the bin assembly from the cleaner. [8] 3. Hold the dust container with one hand, and remove the dust container lid by rotating anti-clockwise. [9] 4. Remove the pre-motor filter assembly from bin assembly. [10] 5. Remove the Vortex Finder from bin assembly. [11] 6. Empty the dust from the bin. [12] 7. Refit the vortex finder and pre-motor filter assembly to bin assembly. 8. Refit the dust container lid to bin assembly. 9. Close and refit to the cleaner main body.

Cleaning the Washable Filters

The cleaner is fitted with pre motor filter and exhaust filter. To maintain optimum cleaning performance, regularly remove the filters and tap against the side of the bin to release dust. The filters should be washed every 5 cassette empties or when the filter has excessive dust level.

IMPORTANT: All bagless cleaners require regular filter cleaning. Failure to clean your filters may result in air blockage, overheating and product failure. This may invalidate your guarantee.

IMPORTANT: Regularly check and maintain the filters. IMPORTANT: Always ensure the filter pack is fully dry before use.

To access the filter:

1. Remove the dust container from the cleaner. [8]
2. Hold the dust container with one hand, and remove the dust container lid by rotating anti-clockwise. [9]
3. Remove the pre-motor filter assembly from bin assembly. [10]
4. Gently tap and wash the pre-motor filter. Do not use hot water or detergents. Remove excess water from the filter and leave to dry fully before re-using. [13] [17]
5. Reassemble the pre-motor filter assembly once fully dry and refit to the cleaner.

To access the exhaust filter:

1. Unclip the exhaust filter cover from the rear of the cleaner main body. [14]
2. Remove the exhaust filter from the rear of the cleaner. [15]
3. Gently tap and wash the filter using warm water. Do not use hot water or detergents. Remove excess water from the filter and leave to dry fully before re-using. [16] [17]
4. Refit the exhaust filter to the rear of the cleaner once fully dry and refit the exhaust filter cover.

IMPORTANT: Do not use the product without the filter pack fitted.

Cleaning the dust container / separation unit

This cleaner uses a separation system unique to Hoover. If necessary, the separation unit can be disassembled from the dust container and cleaned.

1. Press the dust container release button and remove the bin assembly from the cleaner. [8]
2. Hold the bin with one hand and with the other hand remove the dust container lid by rotating anti-clockwise. [9]
3. Remove the dust container lid by rotating anti-clockwise. And remove the pre-motor filter from dust container assembly. [10] And then remove the vortex finder from the dust container by pulling. [11]
4. If necessary, use a cloth to remove excessive dust from the vortex finder surface. Reassemble the internal components to the bin.
5. Reassemble the dust container lid to the dust container. Refit the dustbin to the cleaner.

Removing a blockage

1. Check if the Dust Container is full. If so, refer to 'Emptying The Dust Container'.
2. If the Dust Container is empty, but suction is still low:

A. Do the filters need cleaning? If so, refer to 'Cleaning the Washable Filters'. B. Check if there is any other blockage in the system - Use a rod or a pole to remove any blockage from the tubes or hose.

C. Check for and clear any blockage in the Nozzle

D. Check if the separation unit needs to be cleaned. Refer to 'Cleaning the separation unit.'

WARNING - If the cleaner is used for a significant period of time with a blockage, a thermal cut out will switch the cleaner off to prevent overheating. If this should happen, switch the cleaner off, unplug and correct the fault. It will take about 45 minutes for the cut out to automatically reset.

USER CHECKLIST

Should you have a problem with the product, complete this simple user checklist before calling your local Hoover service.

• Is there a working electricity supply to the cleaner? Please check with another electrical appliance.
• Is the dust container over-filled? Please refer to 'Cleaner Maintenance'.
• Is the filter blocked? Please refer to 'Cleaner Maintenance'.
• Is the hose or nozzle blocked? Please refer to 'Removing a blockage from the system'.
• Has the cleaner overheated? If so, it will take approximately 30 minutes to automatically reset.

IMPORTANT INFORMATION

Hoover Spares and Consumables

Always replace parts with genuine Hoover spares. These are available from your local Hoover dealer or direct from Hoover. When ordering parts always quote your model number.

Quality

Hoover's factories have been independently assessed for quality. Our products are made using a quality system which meets the requirements of ISO 9001.

Your Guarantee

The guarantee conditions for this appliance are as defined by our representative in the country in which it is sold. Details regarding these conditions can be obtained from the dealer from whom the appliance was purchased. The bill of sale or receipt must be produced when making any claim under the terms of this guarantee.

Subject to change without notice.

SAFETY INSTRUCTIONS FOR USE

Do not vacuum up hair, sharp objects, matches, hot ash, cigarette butts, or other similar objects.

MAINTENANCE OF THE VACUUM CLEANER

Emptying the dust container

When the dust reaches the maximum level indicator on the container, the dust container must be emptied. IMPORTANT: To maintain optimal performance, do not let the dust amount exceed the maximum level. 1. Turn off the vacuum cleaner with the main switch and unplug the power cord. 2. Press the release button for the dust container and remove it from the cleaning appliance.[8] 3. Hold the dust container with one hand and remove the dust container lid by turning it counterclockwise.[9] 4. Take the pre-motor filter out of the dust container.[10] 5. Take the Vortex fins out of the dust container. [11] 6. Empty the dust from the container. [12] 7. Put the Vortex fins and pre-motor filter back into the dust container. 8. Put the dust container lid back on the dust container. 9. Close and put the main part of the cleaning appliance back in place.

Cleaning the washable filters

The vacuum cleaner is equipped with a pre-motor and an exhaust filter. To maintain optimal cleaning performance regularly, remove the filters and tap them gently against the side of a trash bin to release the dust. The filters should be washed every 5 times the container is emptied, or when the dust level is too high.

USING THE CLEANER

This appliance is intended for household use only, as described in this user manual. Before using this household appliance, make sure you understand this manual.

Do not leave the appliance plugged into the outlet. After use, before cleaning or servicing, always unplug the appliance from the outlet.

Children older than eight years, as well as persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge, may use the appliance if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Cleaning and user maintenance shall not be made by children without supervision.

If the power cord is damaged, immediately unplug the appliance. To avoid hazards, the replacement of the power cord must be carried out by authorized Hoover service engineers.

Do not touch the rotating brush with hands, feet, loose clothing or hair.

Use only the nozzles, consumable materials or spare parts recommended or supplied by Hoover.

Static electricity: Some types of carpet coverings can accumulate a small static charge. The discharge of static electricity is not a danger to health.

RU

Do not use the appliance outdoors, on wet surfaces, or to collect liquids.

Do not use the appliance to collect sharp objects, matches, hot ashes, cigarette butts or similar objects.

Do not use or collect flammable liquids, cleaning agents, aerosols or their vapors.

Do not carry the appliance by the power cord and do not pull the cord when unplugging from the outlet.

In case of malfunction, do not attempt to use the appliance.

Hoover service: For safety and reliable operation of this appliance, we recommend that maintenance and repairs be carried out by authorized Hoover service engineers.

Do not stand on the cord and do not wrap it around your arm or leg while using the appliance.

Do not use the device for cleaning living animals.

Do not place the device above your head during cleaning of stairs.

Environment:

The symbol on the product indicates that it must not be disposed of with household waste. It must be taken to a suitable collection point for further recycling of electrical and electronic equipment. Disposal must be carried out in accordance with local environmental regulations for waste disposal. For more information about the treatment, recovery, and recycling of this product, please contact your local city office, your household waste disposal service, or the shop where you purchased the product.

Additional accessories

To improve cleaning efficiency, it is recommended to use the nozzles correctly for the main cleaning operations. These nozzles are marked with letters on the diagram, see figure.

Nozzle type A can be used for both carpets and hard floors.

Nozzle type B is suitable for hard floors.

Nozzle type C is only for carpets.

Other nozzles are marked with letters and numbers and are recommended for use only in specific situations.

All accessories can be attached to the tube.

Nozzle 2 in 1 performs several functions simultaneously:

Upholstery nozzle - designed for cleaning hard-to-reach places.

Brush nozzle - designed for cleaning delicate surfaces, picture frames, computer keyboards, and other sensitive surfaces.

Mini turbo brush for pet hair - the mini turbo brush is designed for cleaning pet hair and other hard-to-reach surfaces. It is especially suitable for cleaning pet hair.

The pipe nozzle is designed for cleaning hard-to-reach surfaces and pipes. It is especially suitable for use on radiators.

The nozzle is for cleaning radiators and other hard-to-reach surfaces that require careful handling.

WARNING! Do not use the pipe nozzle on carpets with long pile, more than 15 mm, or on animal fur. It is forbidden to keep the nozzle in a stationary position while the vacuum cleaner is on.

MAINTENANCE OF THE VACUUM CLEANER

Emptying the dust container

When the dust in the container reaches the maximum level indicated by the indicator, the container should be emptied.

WARNING! Do not allow the dust to accumulate above the maximum level.

1. Switch off the vacuum cleaner using the main switch and unplug it from the socket.
2. Press the container release button and remove the container from the vacuum cleaner. [8] Empty the container over a waste bin, remove the lid by turning it.
3. Remove the washable filter from the container. [10]
4. Remove the foam filter from the container. [11]
5. Remove the dust from the dust container. [12]
6. Replace the foam filter and the washable filter.
7. Replace the lid on the dust container.
8. Close the lid. Return the container to the main body of the vacuum cleaner.

Filter cleaning error

The vacuum cleaner may switch off if the filter is clogged or the dust container is full. To maintain optimal performance, regularly clean the filters and empty the dust container. Filters must be cleaned at least every 5 times the container is emptied, or when the filter shows visible dirt.

WARNING! Filters for all bagless vacuum cleaner versions require regular cleaning. If the filters are not cleaned, this may lead to blockage of the air flow, overload and overheating of the vacuum cleaner. This may lead to invalidation of the warranty.

WARNING! Regularly check the filters and clean them.

WARNING! Make sure that the filters are completely dry before reuse.

To remove the filters:

1. Remove the dust container from the vacuum cleaner. [8]
2. Press the container release button, remove the lid by turning it counterclockwise. [9]
3. Remove the pre-motor filter from the container. [10] 4. Carefully tap and brush the filter. Do not wash with hot water or cleaning agents. Dry the filter thoroughly and place it back before next use. [13][17] 5. After drying, insert the filter back into the container and install the container into the vacuum cleaner.

To remove the exhaust filter, perform the following steps:

1. Open the filter clamp at the rear part of the main body of the vacuum cleaner. [14]
2. Remove the filter from the vacuum cleaner. [15]
3. Carefully shake out and brush the filter with warm water. Do not wash with hot water or cleaning agents. Dry the filter thoroughly and leave it to dry before next use. [16][17]
4. Good vacuuming, return the filter to its place in the vacuum cleaner and install the cover.

WARNING! Using the vacuum cleaner without the filter installed is prohibited!

Vacuum cleaner fault / Separator fault

The vacuum cleaner may be used with a fine dust filter system. If necessary, clean the filter. 1. Press the dust container release button and remove it from the vacuum cleaner. [8] 2. Hold the handle with one hand, and with the other remove the cover by turning it counterclockwise. [9] 3. Remove the cover from the dust container by turning it counterclockwise. Pull the filter out of the container. [10] Then pull the separator out of the container by pulling it. [11] If necessary, use a cloth to remove dirt from the surface of the separator. Install the internal components of the dust container back in place. 5. Install the cover on the dust container. Install the vacuum cleaner housing.

Clearing blockages

1. Make sure the dust container is full. If so, see section "Cleaning the dust container".
2. If the dust container is empty but suction remains low,

A. Does the filter need cleaning? If so, see section "Cleaning the motor protection filter".

Only on specific models *Only for some models, the shape of the nozzle may vary depending on the model.

B. Check for other blockages in the vacuum cleaner. - Check the telescopic tube or hose for blockages. C. Turn the nozzle and remove any blockage.

D. Turn the nozzle and remove the separator. See section "Separator cleaning". WARNING: If the vacuum cleaner is used with a full dust container, the motor may overheat and shut off. In this case, disconnect the vacuum cleaner from the power supply and replace the dust container. The motor will cool down and return to normal operation after about 30 minutes.

USER QUESTIONNAIRE

If you encounter difficulties during operation, try to identify the minor faults before contacting the service center.

Does the vacuum cleaner not turn on? Check the power supply with another electrical appliance. Is the dust container full? See section "Technical maintenance of the vacuum cleaner". - Is the filter clogged? See section "Technical maintenance of the vacuum cleaner". - Is the hose or nozzle clogged? See section "Clearing blockages in the system". - Has the vacuum cleaner overheated? If so, after about 30 minutes it will become operational again.

IMPORTANT INFORMATION

Spare parts and consumables of Hoover company

When replacing parts, use only genuine spare parts and consumables of Hoover company. They can be purchased from your local Hoover dealer or directly from Hoover company. When ordering spare parts, be sure to specify the model number of the appliance.

Quality requirements for products

The factory is independent and meets the quality requirements for the products it manufactures. The products are manufactured using a quality system that meets the requirements of the ISO 9001 standard.

Your guarantee

The guarantee conditions for this household electrical appliance are determined by our representative office in the country where you purchased this electrical appliance. You can get more detailed information about these conditions from our dealer. When making a claim under the terms of these guarantee obligations, it is necessary to present the receipt of purchase of the goods.

Changes may be made without prior notice.

Static electricity: It is not always possible to prevent known static electricity discharges. Not every static discharge is dangerous to health.

Do not use the device outdoors or on wet surfaces, or for collecting damp debris.

Do not collect hard or sharp objects, matches, hot ashes, gas, or similar items.

Do not spray or use with flammable liquids, cleaning agents, aerosols, or technical vapors.

Do not use the device with a damaged cable or plug, and do not pull the cable to unplug it.

Do not continue to use the device if it appears damaged.

IMPORTANT: To ensure the safe and efficient use of this appliance, servicing and repairs should only be carried out by an authorized HOOVER service engineer.

Do not place the appliance on or near hot surfaces or open flames while in use.

Do not use the appliance to vacuum up liquids or sharp objects.

Do not place the appliance on a soft surface, such as a carpet, while it is in use.

Environmental protection

This appliance is marked with the symbol for separate collection of waste electrical and electronic equipment. This means that this product must be disposed of separately from normal household waste. It must be handed over to a collection point designated for waste electrical and electronic equipment or a recycling facility. For more information about the treatment, recovery, and recycling of this product, please contact your local city office, your household waste disposal service, or the shop where you purchased the product.

This appliance complies with European Directives 2014/35/EU, 2014/30/EU, and 2011/65/EU.

HOOVER Limited, Pentrebach, Merthyr Tydfil, Mid Glamorgan, CF48 4TU, United Kingdom

DESCRIPTION OF YOUR VACUUM CLEANER

A. Suction regulator B. Handle C. Telescopic tube D. On/Off switch E. Dust container F. HEPA filter

F1. HEPA filter cover

F2. HEPA filter for hard floors

G. Floor nozzle H. Parking slot I. Cord hook J. Main body of vacuum cleaner

K. Handle L. Dust container release button M. Dust container N. Telescopic tube O. Motor protection filter P. Button for releasing the container Q. Exhaust filter R. Accessory 2-in-1 S. Mini turbo nozzle for pet hair T. Mini turbo nozzle for upholstery U. Turbo nozzle for parquet V. Parquet nozzle

USING THE VACUUM CLEANER

The vacuum cleaner components are shown in the figure.

C. Insert the hose into the main body of the vacuum cleaner, making sure it is securely attached. 2. To release: simply press the button on the hose and pull it out. 3. Attach the hose to the handle with the upper end of the extension tube [2] or directly, if necessary. 4. Attach the nozzle to the end of the extension tube for carpets and hard floors [3a] or accessories, if necessary.

USING THE VACUUM CLEANER

1. Pull out the power cord and plug it into the socket. Do not pull the cord out completely. [4] 2. Adjust the telescopic tube to the desired height by moving the adjuster up or down, or by sliding the handle to the most comfortable position. [5] 3. Nozzle for carpets and hard floors*. Press the selector for the desired floor type [6] to select the appropriate setting for the floor type. For hard floors - lower the nozzle for hard floors. For carpets - raise the nozzle for deep cleaning. 4. Turn on the vacuum cleaner by pressing the On/Off button on the body [7]. 5. Adjust the suction power regulator to the desired level. 6. Turn off the vacuum cleaner when you are done by pressing the On/Off button. Unplug the power cord from the socket and press the cord rewind button to retract the cord back into the vacuum cleaner.

*Only for models with a nozzle for carpets and hard floors. **Only for models with a nozzle for carpets and hard floors. The nozzle may be

PARKING AND STORAGE

The nozzle can be parked on the back of the vacuum cleaner for storage, and the vacuum cleaner can be stored upright during use.

ACCESSORIES

For optimal performance and energy efficiency, it is recommended to use the correct nozzle for the basic cleaning tasks. These nozzles are indicated in the diagrams with the letters GP, HF, etc.

The GP nozzle can be used for cleaning both carpets and hard floors.

The HF nozzle is suitable for use only on hard floors. The CA nozzle is suitable for use on carpets and rugs.

Other nozzles are accessories for special cleaning tasks and are recommended only for use when necessary.

All accessories can be attached to the handle or the hose.

The tool 2-in-1 combines several functions in one tool:

Tool for tight spaces - for corners and hard-to-reach areas.

For the dust container, frame, and control panel, use a damp cloth to clean the area.

For the exhaust filter, clean it with a brush or wash it under running water. The filter can be washed with a mild detergent and a soft brush. Pay special attention to cleaning the exhaust filter.

For the exhaust filter, for cleaning the pre-filter, wash the exhaust filter with a mild detergent on the textile surface and other parts for cleaning the area. Especially suitable for cleaning the pre-filter.

For the parquet nozzle: for parquet and other hard floors.

IMPORTANT: Do not use the exhaust filter on wet surfaces, and do not use it with liquids. Do not leave the filter wet while the vacuum cleaner is running.

CLEANING THE DUST CONTAINER

Emptying the dust container

When the dust reaches the maximum level mark on the container, empty the container.

IMPORTANT: For proper operation, do not allow the dust to exceed the maximum level.

1. Turn off the vacuum cleaner, unplug it from the mains, and remove the power cord.
2. Press the button to release the dust container and

remove the container from the vacuum cleaner. [8]

1. Hold the dust container over a trash bin and empty it. Then, replace the container, making sure it clicks into place. [9]
2. Remove the filter before the motor from the container. [10]
3. The vacuum cleaner is intended for household use only. [11]
4. Read the instructions carefully before use. [12]
5. Insert the filter into the filter holder until it clicks into place.
6. Place the dust container onto the separation unit.
7. Close and place the main body of the vacuum cleaner.

Placement of the appliance

The vacuum cleaner is equipped with a motor protection filter. Regular replacement ensures efficient operation.

Regularly clean the filter and the separation unit to release the dust. The filter should be cleaned at least every 5 uses or when the dust reaches the indicated level.

IMPORTANT: All vacuum cleaners without a bag require regular cleaning of the filter. Failure to clean the filter may lead to blockage of the air inlet, interruption of operation, and malfunction of the appliance. This may void the warranty.

IMPORTANT: Regularly check and service the filters.

IMPORTANT: Always make sure the filter is completely dry before use.

To achieve optimal filtration:

1. Remove the separation unit from the vacuum cleaner. [8]
2. Remove the separation unit with a twist and pull the filter out of the separation unit, turning it counterclockwise. [9]
3. The filter is inserted before the motor from the insertion into the compartment. [10]
4. CAREFULLY READ AND FOLLOW THE FILTER BEFORE THE MOTOR. DO NOT USE BOILING WATER OR DETERGENTS. RINSE THE FILTER UNDER RUNNING WATER AND LEAVE IT TO DRY COMPLETELY BEFORE USING IT AGAIN. [13][17] 5. REPLACE THE FILTER BEFORE THE MOTOR AFTER IT HAS DRIED COMPLETELY, THEN PUT IT BACK INTO THE VACUUM CLEANER.

To reach the exhaust filter:

1. Remove the exhaust filter from the left side and from the main body of the vacuum cleaner. [14]
2. Remove the exhaust filter from the left side of the vacuum cleaner. [15] 3. CAREFULLY READ AND FOLLOW THE FILTER WITH WARM WATER. DO NOT USE BOILING WATER OR DETERGENTS. RINSE THE FILTER UNDER RUNNING WATER AND LEAVE IT TO DRY COMPLETELY BEFORE USING IT AGAIN. [16] [17]
3. Put the exhaust filter back on the left side of the vacuum cleaner, after it has dried completely, put the exhaust filter back.

IMPORTANT: Do not use the appliance without the filter bag installed.

Placement of the compartment for dust / separating block

The vacuum cleaner uses a separating system, which is a Hoover innovation. The separating block can be removed from the dust compartment and cleaned.

1. Press the button on the dust compartment and remove the insertion from the vacuum cleaner. [8]
2. Remove the compartment with one hand and with the other hand remove the block from the dust compartment, turning it counterclockwise. [9]
3. Remove the block from the dust compartment, turning it counterclockwise.

*Only for some **Only for some models, the accessories may be

Arrow. Remove the filter before the motor, which is connected to the dust compartment. [10] After that, remove the release tab from the dust compartment, pulling it. [11]

1. If necessary, use the accessories for cleaning the filter from the surface of the release tab. Remove the internal components of the compartment.
2. Remove the filter for the account. Place the account filter in the vacuum cleaner.

Troubleshooting

1. Check that the filter is clean. If it is dirty, see "Cleaning the filter." 2. If the filter is still weak after cleaning:

A. Replace the filter? If so, see "Replacing the filter." B. Check another blockage in the system - unblock the hose to remove blockages. C. Check the brush roll for blockages. D. Check the brush roll for blockages. See "Cleaning the brush roll." NOTE: If the vacuum cleaner is used for a long time, the thermal cut-out may activate to prevent damage. If this happens, turn off the vacuum cleaner, unplug it, and let it cool down. It may take about 45 minutes for the thermal cut-out to reset.

TROUBLESHOOTING CHECKLIST

Before calling for service, check the following items. If any are not working, see the relevant section. - Is the vacuum cleaner plugged in? If not, plug it in. - Is the filter clean? If not, see "Cleaning the vacuum cleaner" and clean the filter. - Is the filter blocked? If so, see "Cleaning the vacuum cleaner". - Is the brush roll jammed? If so, see "Clearing blockages from the system". - Is the vacuum cleaner overheating? If so, it may need about 30 minutes to cool down.

IMPORTANT INFORMATION

Genuine Hoover parts

Use only genuine Hoover parts. They are available from your local Hoover dealer or directly from Hoover. When ordering parts, always quote your model number.

Quality

Hoover products are manufactured to a high quality standard. Our products are produced in accordance with a quality system certified to ISO 9001.

Your guarantee

The guarantee conditions for this appliance are as defined by our representative in the country in which it is sold. Details of these conditions can be obtained from the retailer from whom you purchased the appliance. The guarantee is in addition to your statutory rights as a consumer.

Product warranty is void if not used in accordance with instructions.

SAFETY INSTRUCTIONS

Read the instructions carefully before using the appliance, as described in the instruction manual, to ensure you understand them before starting operation of this household electrical appliance.

Do not leave the appliance plugged in when not in use. Before cleaning or maintenance, always unplug the appliance from the outlet.

Children aged 8 and above, as well as persons with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, may use the appliance if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not play with the appliance. Do not allow children to clean or maintain the appliance without supervision.

If the power cord is damaged, it must be replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. To avoid danger, the power cord replacement must be carried out by an authorized Hoover service engineer.

Do not use the appliance to pick up flammable or combustible liquids, such as petrol, or use it in areas where such liquids may be present.

Use only the accessories, consumables or spare parts recommended or supplied by Hoover.

Electric shock: Some types of floor coverings can generate static electricity.

The battery must be removed from the appliance before disposal. The disposal of the battery should be done in accordance with local regulations.

Do not use the appliance outdoors, on wet surfaces, or to collect water.

Do not use the appliance to collect sharp objects, nails, hot ashes, or similar items.

Do not immerse or spill flammable liquids, cleaning agents, aerosols or their vapors on the appliance.

Do not carry the appliance by the power cord, do not pull the cord to unplug it, and always unplug by grasping the plug. In case of malfunction, do not continue using the appliance.

Hoover service center: For safety and reliable operation of this appliance, we recommend that you request authorized Hoover service engineers to carry out technical maintenance and repairs.

Do not step on the cord and do not wrap it around your hand or foot while using the appliance.

Do not use the appliance to clean animals or people.

The product is intended for household use.

Environment protection:

The symbol on the product or its packaging indicates that this product cannot be disposed of with household waste. It must be handed over to the appropriate collection point for recycling of electrical and electronic equipment. Disposal of waste must be carried out in accordance with local environmental regulations for waste disposal. For more detailed information on the treatment, recovery, and recycling of this product, please contact your local city office, your household waste disposal service, or the shop where you purchased the product.

This appliance complies with the requirements of European Directives 2014/35/EU, 2014/30/EU, and 2011/65/EU.

CANDY HOOVER GROUP S.r.l. Via Privata Eden Fumagalli, 20861 Brugherio (MB) Italy

GET TO KNOW YOUR APPLIANCE

A. On/off speed regulator B. Handle C. Telescopic tube D. On/off button E. Exhaust filter cover F. Accessory for carpets and hard floors (GP)*

ADDITIONAL ACCESSORIES

To increase productivity and efficiency, it is recommended to use the correct accessories for the cleaning operations. These accessories are not suitable for use with the main unit.

The GP accessory can be used for cleaning carpets and hard floors. The HF accessory is only for hard floors. The CA accessory is only for carpets.

OTHER ACCESSORIES ARE AVAILABLE FOR SPECIFIC CLEANING TASKS AND ARE RECOMMENDED FOR USE IN CERTAIN CASES.

All accessories can be fitted to the tube. The 2-in-1 accessory performs two functions: one is for cleaning corners and hard-to-reach places. The brush for removing pet hair is for cleaning upholstery, picture frames, computer keyboards, and other delicate surfaces. The mini turbo brush is for cleaning stairs or deep cleaning fabric surfaces and other hard-to-reach places for cleaning. It is not suitable for removing pet hair. The mini turbo brush is for cleaning stairs or deep cleaning fabric surfaces and other hard-to-reach places for cleaning. It is not suitable for removing pet hair. The parquet brush is for parquet floors and other coverings that require gentle cleaning. WARNING! Do not use the mini turbo brush on carpets with pile longer than 15 mm, or on animal skins. It is forbidden to leave the accessory in a stationary position while the brush is rotating.

TECHNICAL MAINTENANCE OF THE APPLIANCE

Cleaning the dust container

Remove the container from the machine at maximum pressure, as indicated by the indicator. The container must be cleaned. WARNING! Do not exceed the maximum productivity. Do not fill above the maximum level. 1. Turn the pump off using the main switch. 2. Press the container release button and remove the container from the pump. [8] 3. Turn the container upside down over a sink, remove the lid, and rinse it with clean water. [9] 4. Remove the filter that is to be washed from the container. [10] 5. Remove the suction hose from the container. [11] 6. Pour out the contents of the bag. [12] 7. Install the suction hose and the filter that is to be washed. 8. Put the lid back on the container and turn it upright.

9. Close the lid and return the container to the pump housing.

Cleaning the filter

To ensure the pump operates at maximum productivity, regularly remove and clean the filter. The filter is located in the container. If the filter is clogged, the pump may overheat.

WARNING! The filter must be cleaned regularly to prevent clogging, which can reduce the pump's performance and cause damage.

WARNING! Regularly check the filter.

WARNING! Do not use the pump without the filter.

Cleaning the filter

1. Remove the container from the pump. [8]
2. Turn the container upside down over a sink, remove the lid, and rinse it with clean water. [9]
3. Remove the filter that is to be washed from the container. [10]

4. Carefully follow the instructions. To ensure proper operation, use only clean water or mild detergent. Do not use abrasive cleaners or solvents. [13][17]

1. Place the plug, filter, and gasket into the container and install the container.

To remove the outlet filter, perform the following steps:

1. Unscrew the filter cap from the spare part of the main body of the juicer. [14]
2. Remove the filter from the juicer. [15]
3. Carefully rinse and wash the filter with warm water. Do not wash with hot water or use abrasive cleaners. Dry the filter and store it for future use. [16] [17]
4. Dry the filter thoroughly before reinstalling it into the juicer.

WARNING! Using the juicer without the installed filter is prohibited!

Cleaning the juicer / Cleaning the filter

The juicer uses a filter system. If necessary, clean the filter as follows: 1. Press the latch on the container for collecting pulp and remove it from the juicer. [8] 2. Hold the container with one hand, turning it counterclockwise. [9] 3. Remove the lid from the pulp collection container by turning it counterclockwise. Remove the filter by pulling it out of the container. [10] Then remove the strainer from the container by pulling it. [11] 4. If the strainer is damaged, replace it with a new one. Install the new strainer into the container for collecting pulp. 5. Install the lid on the container for collecting pulp. Install the bag into the juicer body.

Replacing the filter

1. Check that the bag is empty. If not, see Cleaning the juicer.
2. AKIOHNIO 3BIPHNKIIOPOKHI, a BC MOKTYBAHNN 3dINIIIAETbCHHNN3bKHM;

A. Nt porfio npouhcttnn fiipn? Iaio taK, dN. «OuHneIa fiiptn, 100 MoTcBra.

Tinbkn y konkpeTHnx moedenei *TinbKn dnn decknx MocneN. FopMa Hacadkn MoKe 3MHHoBATnCn B3anckHOCTi Bid Moceni.

B.IIpeKoIHIEcLbYBiCyTHIOCTiHINHX3AcMIeHILyHINOCci.-OChrTtTeJeckoniny Tpy6a0rHuKmHIIAH3aJIOOMTOOcTreKHHa0nHJI. C.Ipepeipre hacdky iBnnditb Bce 3aMieHH. D.IIpeBipre Hne hortpebyc cencapatop OunHnHn. /IIN.Po3in "OnnnnHn BiiDaJIeHNHa"

YBAI JIKUO HINOCO BHKOPHCTOVETCB3 3aBHTHM IHHROM IPOTHOM TPNBAHO Yacy, pepe TEJIIOBORXAAHCTY NIKKHOHTIHO, OIOY BHKHYTNeperyi. YIOMY BHNATKY BHKMHTBHIOOC, BID'EDHAIREHO BID MEPEKI XHHENHRA TaAMHITMIHOK. PeIE TEJIIOBORXAAHCTY ANOTMATWNI NOBEPHETB C INOHATKOBI NIOOOEHN HUEp345 XBNHH

AHKETA KOPNCTYBAUA

JiHIO y Bac BHHKHNpyHOOBI X ODI EKCHUYATAU HINOCCA, CPO6yIe BCTAHOBHTN pinnnH np16Hnx HenoAok, nepu HIK 3eptarHcdo MICENORO cepaICHO eHTPy npoydkuHover.

-Qu noaactbca enektpka nnnococa? Ipepenipte harnhictb eEektpnK 3a nnomoolio 6yIy-kofo eEektpnHoro npHaay. -He HepeHOBHeHH KOHeHep 360py Hny? IIB. pO3JI "Texhue 06CJyROBYBaHHHINIO - Hn He 3acmitHBc fiIbTp? Hb. po3in "Texhiue he6cyrobybaHHaHIOcoca". -He 3acmitnncnnnaa nnae haca?n. poan "Cynne Hnacmiy y cntemi" -He nepeperpncnnooc?KIOe TaK, npu6HnHnepe3 30 xbnnn Bn HIOB CTaHe npaue3daTHHM.

BAKJIINBAIHΦOPMALIJI

3anachi yactHH Ta BntpaTHI MaTeplJI KOMnaHI Hoover

Ipn 3aHmI qACTHn BHKOPCHOTyBE tTlKN pOHRININII 3aNACNI qACTHHI bHTPARI MATEPAH NOMAHII Hoover. IX MOKHAp nPHJbSbTH y BuHIO RMCIEBORO duHEpa KOMANII Hoover ao6e3nocepeDIO B KOMANII Hoover.Ipn oOpMNEHI 3aMOBENHI

Ha 3aIaTIACH TACTNIHOB 083KBOB BRA3yHTe HOMep McJeiTINIOOCa. BmOnrdo JaoKtO npOduki

3a0Dn KOMHJIUHoovro npIeHJN He3AekHcy OUYHKy IOIOOyTOPMAHNA BHMOTdo AKoCTri npOyKII, IIIO BNYCKACTcB. Huaia npOyKII BNTPOTACTcB 13actocynAHM CTCHEMINHOCTI, KIA 3aOBOIBOHHE BMOITAM CTADAPTY ISO 9001.

Bawa rapahtir

YMOBH rapaHITI DIAHOIO HObyTOBO EJEKTPNHOIO pHJADy B3HNAKbCh HAaHMM PnpETABHHTBOM y TIK KpAIN, B kAI ENeKTPponPAH BY KPNLEHH. BILNI JETALHBY IHOPMAUIO npI yMOBH BN MOKERE OTHMATH BID HAOIOTO dHIEPA. PnIPpe'NBHeHH PIPETAHII IIOO yMOB DAIH RAPAIIRHX 306OB'3AANTN NOE6XIIIO Pnp'BAHTN Kek ABO KBIATAUHO HA IpODAHN TOBAP.
