RTAC87R - Wireless Router ASUS - Free user manual and instructions
Find the device manual for free RTAC87R ASUS in PDF.
📄
Document temporarily unavailable
The manual is currently being transferred to our new server. It will be accessible again in a few hours. Thank you for your patience.
Pick your language and provide your email: we'll send you a specifically translated version.
| Product Type | Wireless Router |
| Brand | ASUS |
| Model | RT-AC87R |
| Wireless Standards | IEEE 802.11a/b/g/n/ac |
| Frequency Bands | 2.4 GHz and 5 GHz (dual-band simultaneous) |
| Maximum Wireless Data Rate | AC2400 (up to 600 Mbps on 2.4 GHz + 1734 Mbps on 5 GHz) |
| Network Ports | 1 Gigabit WAN RJ-45 port, 4 Gigabit LAN RJ-45 ports (including 2 link aggregation ports) |
| USB Ports | 1 USB 3.0, 1 USB 2.0 |
| Antennas | 4 removable external antennas |
| Power Supply | AC adapter, DC output +19V max 2.37A |
| Main Features | Firewall, parental control, QoS, VPN server, guest network, WPS, DDNS, AiCloud, AiDisk, DLNA/Samba/FTP media server, print server |
| Wireless Security | WEP, WPA/WPA2 (Personal and Enterprise), MAC filtering, URL filtering, keyword filtering |
| Network Protection | SPI firewall, DoS attack protection |
| Operating Temperature | 0 to 40 °C |
| Operating Humidity | 50 to 90% |
| Storage Temperature | 0 to 70 °C |
| Storage Humidity | 20 to 90% |
| Maintenance and Cleaning | Unplug the power before cleaning; use a dry, soft cloth. Avoid moisture and chemicals. |
| Spare Parts and Repairability | Removable antennas (replaceable). Specific AC adapter included. Professional repair recommended. |
| General Information | AC2400 dual-band router with USB ports and advanced network management. Compatible with most ISPs. ASUS technical support available. |
Frequently Asked Questions - RTAC87R ASUS
How to set up the ASUS RT-AC87R router for the first time?
Plug in the power adapter, connect your modem to the WAN port and your computer to a LAN port. Open a browser and go to http://router.asus.com or 192.168.1.1. Use the default credentials admin/admin. The Internet setup wizard will guide you to configure the connection (PPPoE, dynamic IP, etc.) and the wireless network (SSID, password).
How to reset the router to factory settings?
Press and hold the Reset button on the back of the router for about 5 to 10 seconds until the LEDs flash. You can also from the administration interface go to Administration > Restore/Save/Upload Settings and click Restore. The default settings are: IP 192.168.1.1, user admin, password admin.
How to update the router's firmware?
Download the latest firmware version from the ASUS support site. Log in to the administration interface, go to Administration > Firmware Update. Click Browse to select the file, then click Upload. Do not disconnect power during the update. The router will reboot automatically.
How to configure the wireless network (SSID and password)?
From the administration interface, go to Wireless > General. Select the band (2.4 GHz or 5 GHz). Enter an SSID (network name). Choose an authentication method (recommended: WPA2-Personal) and enter a security key (password). Click Apply. Repeat for the other band if necessary.
How to enable parental control?
Go to Parental Control in the administration interface. Enable the feature by clicking ON. Add a client by entering its MAC address or selecting it from the list. Configure access time schedules by clicking the edit icon in the Time Schedule column. Click Apply to save.
How to share a printer via the router's USB port?
Connect your printer to a USB port on the router. From a Windows computer, install the ASUS EZ Printer Sharing utility (provided on CD or downloadable). Launch the utility, it will detect the printer and allow you to install it as a network printer. You can also use the LPR protocol for manual sharing.
How to set up a VPN server on the router?
Go to VPN Server in the interface. Check Yes for Enable PPTP Server. Enter a username and password for VPN clients. You can also configure advanced options such as the IP address range. Click Apply. VPN clients can connect using the router's public IP address.
What to do if I forget the login password for the router interface?
Reset the router to factory settings by holding the Reset button (see the reset question). The default credentials are admin (username) and admin (password). Remember to change the password after reset to secure access.
How to use AiCloud to access my files remotely?
Connect a USB storage device to the router. Enable Cloud Disk in the AiCloud interface. Go to https://www.asusnetwork.net and log in with your router credentials. You can also use the ASUS AiCloud mobile app (Google Play or App Store). To access from outside, use ASUS DDNS (e.g., yourname.asuscomm.com).
How to optimize the router's wireless signal?
Place the router in a central location, away from metal obstacles, microwaves, and cordless phones. Orient the 4 antennas vertically or at 45° for better coverage. In the interface, go to Wireless > General and set the channel to Auto to avoid interference. For the 5 GHz band, use a wide channel (40 MHz) if possible.
