Product Type Flash cobra (Speedlight) for Sony DSLR
Model MODUS 600RT MK II (Sony)
Brand Hähnel
Dimensions (approx.) 208 x 79 x 60 mm
Weight (without battery) 430 g
Power Source Rechargeable Li-ion battery HLX-MD1 (included)
Guide Number (ISO 100, 200 mm) 60
Motorized Zoom 20 to 200 mm (with 14 mm wide-angle panel)
Flash Modes Intelligent TTL, Manual (1/1 to 1/128 in 1/3 stops), Multi-stroboscopic
Wireless Communication 2.4 GHz radio (range 100 m) and optical (range 15 m)
Radio Channels Digital Channel Matching (DCM)
Wireless Groups Master + 3 groups (A, B, C)
Synchronization High-speed (HSS), 1st and 2nd curtain
Number of flashes at full power Approximately 500
Recycling Time 0.5 to 2.5 seconds
Head Rotation Horizontal rotation 360°, vertical tilt -7° to 90°
LCD Screen Dot matrix with backlight
Special Features AF assist beam, bounce flash, light capture panel, customizable functions (C.Fn)
Maintenance and Cleaning Clean with a soft, dry cloth. Do not use solvents.
Safety Do not aim at eyes. Observe rest times to avoid overheating. Use only recommended accessories.
Spare Parts and Repairability Battery, charger, tripod, Viper TTL transmitter available. Repairs by authorized service.
General Information 1-year warranty. Compliant with directive 2014/53/EU. Firmware update via micro USB port.

Frequently Asked Questions - MODUS 600RT MK II (Sony) Hähnel

How to charge the battery of the MODUS 600RT MK II?
Use the supplied MD1 MKII charger. Plug it into a USB adapter (min 5V 2A) via the micro USB cable. Insert the HLX-MD1 battery; the 4 green LEDs indicate full charge. Then remove it.
How to switch to wireless flash mode?
Press the Z button to display the wireless icon. Select MASTER or SLAVE as needed. For 2.4 GHz radio, use the MASTER or SLAVE setting.
What does error E1 on the screen mean?
Error E1 indicates a defect in the recycling system. Restart the flash. If the problem persists, contact an authorized service center.
How to adjust flash exposure compensation (FEC)?
Press function button 2 (±). Turn the selection dial to adjust the value from -3 to +3 EV in 1/3 steps. Press SET to confirm.
What is the range of the radio wireless control?
The maximum range is approximately 100 meters outdoors, without obstacles. Distance may vary depending on the environment.
How to activate high-speed synchronization (HSS)?
Press function button 4 (SYNC) until the H icon appears on the screen. To deactivate, press twice.
Can I use the flash with a tripod?
Yes, the kit includes a mini tripod stand. Screw the flash onto the tripod via the screw hole under the foot.
How to update the firmware?
Download the update from hahnel.ie. Connect the flash to a computer via a micro USB cable and follow the instructions.
What to do if the flash overheats?
The screen shows E2 or the overheating icon. Let it rest for at least 10 minutes. Avoid prolonged bursts at full power.
How to set the flash as an optical slave?
In manual mode (M), press the 01/02 button to select O1 or O2. The flash will fire on the main flash (O1: with pre-flash, O2: without pre-flash).
