USER MANUAL Wonderwall Air 36 Klarstein

Dear Customer, Congratulations on purchasing this device. Please read the following instructions carefully and follow them to prevent possible damages. We assume no liability for damage caused by disregard of the instructions and improper use. Scan the QR code to get access to the latest user manual and more product information. CONTENTS TECHNICAL DATA Item number 10034231 Power supply 220-240 V ~ 50 Hz Power consumption (Watt) 360 W (±10%) Dimensions 29.5 cm x 119.5 cm Technical Data 1 Product Data Sheet 2 Safety Instructions 3 Wall Installation 4 Remote Control Display Indicators 5 Operation and Functions 5 Quick Start 7 Disposal Considerations 13 Manufacturer & Importer (UK) 1320

0.36 kW manual heat charge control, with inte-

Minimum heat output (indicative)

0.0 kW manual heat charge control with room

and/or outdoor temperature feedback

Maximum continuous heat output

0.36 kW electronic heat charge control with

room and/or outdoor temperature feedback

Auxiliary electricity consumption fan assisted heat output no At nominal heat output (fan motor)

0.360 kW Type of heat output/room temperature control

0.000 kW single stage heat output and no room

with mechanic thermostat room tem- perature control

with electronic room temperature control

electronic room temperature control plus day timer

electronic room temperature control plus week timer yes Other control options (multiple selections possible) room temperature control, with pres- ence detection

room temperature control, with open window detection yes with distance control option no with adaptive start control no with working time limitation no with black bulb sensor no Contact details Chal-Tec GmbH, Mühlenstrasse 25, 10243 Berlin, Germany.21

• Do not use the appliance until it is securely xed as described in this manual.

• Check that the voltage indicates on the data plate corresponds with that of the local network before connecting the appliance to the mains power supply.

• If the supply cord is damaged, it must be replaced by a qualied engineer in order to avoid a hazard.

• The replace heater must not be positioned directly under the power socket.

• Keep furniture, curtains and other ammable material at least 1 meter away from the appliance.

• Do not leave the appliance unattended during use.

• Do not leave the appliance unattended whilst connected to the mains supply.

• Keep out of reach of children and do not allow them to operate this appliance.

• This appliance is intended for household use only and should not be used for industrial purposes.

• Do not operate this appliance after a malfunction or after being damaged in any way.

• Repairs to electrical appliances should only be performed by a qualied electrician.

• Improper repairs may place user at serious risk.

• Do not run the mains cable under carpets, rugs, etc.

• Do not allow the mains cable to hang over sharp edges or come in contact with hot surfaces.

• In order to avoid overheating, do not cover the heater.

• Do not use this heater with a programmer, timer, separate remote control system or any other device that switches the heater on automatically, since a re risk exists if the heater is covered or positioned incorrectly.

• Never immerse the product in water or any other liquid for any reasons.

• Do not use this heater in the immediate surroundings of a bath, a shower or a swimming pool.

• Do not use the appliance outdoors.

• Do not use if you have wet hands.

• Never use the appliance on or near hot surfaces.

• Do not operate with a damaged cord.

• Before cleaning the appliance, make sure it is unplugged from the power and that it is completely cooled.

• Do not clean the appliance with abrasive chemicals.

• Never use accessories that are not recommended or supplied by the manufacturer. It could cause danger to the user or damage to the appliance.

• This appliance is not intended for use by persons (including children) with reduced Physical, sensory or mental capabilities, or lack of experience and knowledge unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

• Children should be supervised to ensure that they do not play with the appliance. CAUTION Risk of burns! Some parts of this product can become very hot and cause burns. Particular attention has to be given where children and vulnerable people are present.22

• Continuous operation shortens the service life of the heaters. If possible, the appliance should be paused every 12 hours.

• Do not use the unit when the ambient temperature is above 20 °C, as high temperatures will affect performance.

• The outlet should be at least 20 cm above the ground.

• Keep the unit away from ammable and explosive materials.

• Leave a safety distance of 30 cm around the unit to the front, top and rear. Leave a safety distance of 10 cm to the right and left around the unit.

• During the rst one or two days, new heaters may emit odours that are harmless to humans.23

• Press the [M] button switch between System time/Thermostat

• Press and hold the [M] button under certain program slot to initiate a programming into the slot. System Thermostat Day Program type AM/PM RF Connection status Current temperature Socket status Target temperature Degree Celius Degree Fahrenheit Battery low warning Program start time Program end time24

• Choose the 1,2,3,4 slot. Press [OK] to turn on/off the slot.

• Under programming or setting status, press the OK button to conrm and proceed to next step. Button [+] and [-]

• Choose the program slots.

• Press button increase or decrease, the digit in programming and setting mode, press and hold [-] or [+] to fast increase/decrease. Pair to control box

1. Turn on the heating panel using

the switch on the back.

2. Point to the heating panel

and press and hold "+" and "-" simultaneously. Two beeps indicate successful pairing. Note: The remote control only works within a radius of 10 meters from the unit. Establishing the connection usually takes 5 seconds.25

QUICK START Manual Override Press the [OK] button repeatedly to select one of the following functions:

• ON Note: Manual operation override all slot programs, and set all running slots into OFF status. Vice verse, turning on slots program will erase all manual setting. Manual operation will features in the switch ON/OFF icons stay on while slot program will feature in the ON/OFF icons ashing. Manual switch-off of the system (the symbol lights up continuously) Switching on the system manually (the symbol lights up continuously) Manual setting of the temperature (the symbol lights up continuously) Program on-the-run Activate either of the slots program will erase the manual setting, and execute the slot program instead.26

Display on System page when program is on-the-run The ashing MODE symbol indicates that the preset program for slot 3 is currently active. The ashing ON/OFF symbol indicates that the heater is currently controlled by a program. Weekly program Slot program In thermostat mode, press [+] or [-]. Set the day of the week for the start time (ST) with +/-. Set the exact start time (hour and min- utes) with +/-. Set the day of the week for the end time (ET) to +/-. Select the programme po- sition to be programmed and conrm with [OK]. Press [+] or [-] and conrm the target temperature with [OK]. Set the exact end time (hour and minutes) with +/- and conrm with [OK]. Programming is now complete.27

Current day of week and time settings Press and hold „M“to enter the interface of setting the current time and day of the week. Press „+“ and „-“ to select. Press „OK“ to conrm.

1. Press “+” or “-” to select

24h or 12h, press “OK” button to conrm.

3. Press “+” or “-” to set the

hourly time, press “OK” button to conrm.

4. Press “+” or “-” to set

the minutely time, press “OK” button to conrm.

5. Press “+” or “-” to select

In Automatic Mode, press the „+“ or „−“ buttons to adjust the target temperature to your desired setting. Weekly programming setting Short press the „M“ button to enter the interface of setting weekly programming. "00" on the left ashes and "ST" is displayed. Press + or - to set the start heating time. Press the OK button to conrm. „00“ on the right ashes and „ET“ is displayed. Press + or - to set the end heating time. Press the OK button to conrm. Press the + or - buttons to set your target temperature. Press the M button to the next day setting.29

Notes about programs

• Place the remote control and the heating panel in the same room.

• If a battery icon stays on the remote's screen, it means the battery is running low. A low battery may cause the remote to malfunction or stop working. Please replace the battery promptly to avoid interruptions.

• Make sure the straight-line distance between them is no more than 5 meters for proper communication.

• Red light ON: The system is powered and the main board is working normally. Green light ON: The heating panel is currently heating. Weekly programming settings

• Before setting a schedule, please ensure to set the correct day and time rst. Without this, weekly programming will not function correctly.

• Choose the hour to turn ON and the hour to turn OFF each day. Example: Turn ON at 10:00 AM, turn OFF at 5:00 PM.

• Weekly programming will not activate if the turn ON time is the same as or later than the turn OFF time. For example, if you set the heater to turn ON at 10:00 and OFF at 8:00, the system will ignore the schedule for that day. To skip heating on a specic day, simply set the turn ON time to be the same as or later than the turn OFF time.

• The system uses a 24-hour format by default. If you enter a 12-hour time format, the system will automatically convert it—no need to adjust manually.

• The heater runs only when both time and temperature settings are met. Example

• Heating will start if the temperature drops to 22 °C or lower (current ambient temperature 3 degree lower than the set temperature).

• Heating will stop if the temperature rises to above 25 °C (current ambient temperature 1 degree higher than the set temperature).

• Outside the scheduled time, the heater will not turn on, even if the temperature is low.30

Display slot info Users can view their programmed time or temperature by selecting the slot in program mode, user are allow to close or open the slot easily.

1. Go the program mode.

2. Select the target slot you want to view, the programmed start time and end

time will scroll in 1 second and repeat, all other information is displayed as well.

3. Press the OK button to turn off this slot, press again to recover the slot.

Open-window mode Note: Open-window mode when running overrides all modes.

• If the temperature in the room drops by more than 6 °C within 20 minutes, the device interprets this as an open window and the heating switches off automatically.

• As long as the mode is active, OPEN ashes in the display.

• Press any button on the remote control to return to the manual setting mode. Battery change

• Remove the cover of the battery compartment.

• Replace the old batteries with 2 new AA batteries and close the battery compartment again.31

DISPOSAL CONSIDERATIONS If there is a legal regulation for the disposal of electrical and electronic devices in your country, this symbol on the product or on the packaging indicates that this product must not be disposed of with household waste. Instead, it must be taken to a collection point for the recycling of electrical and electronic equipment. By disposing of it in accordance with the rules, you are protecting the environment and the health of your fellow human beings from negative consequences. For information about the recycling and disposal of this product, please contact your local authority or your household waste disposal service. This product contains batteries. If there is a legal regulation for the disposal of batteries in your country, the batteries must not be disposed of with household waste. Find out about local regulations for disposing of batteries. By disposing of them in accordance with the rules, you are protecting the environment and the health of your fellow human beings from negative consequences. MANUFACTURER & IMPORTER (UK) Chal-Tec GmbH, Mühlenstrasse 25, 10243 Berlin, Germany. Contact: [e-mail]33
