| Product Type | Headlamp |
| Brand | Silva Schneider |
| Model | Trail Speed X |
| Weight (with battery) | 135 g |
| Battery Type | Li-Po 7,4 V, 900 mAh |
| Battery Life - Max Mode | 1 h 30 |
| Battery Life - Min Mode (two LEDs) | 6 h |
| Battery Life - Wide Mode (one LED) | 6 h |
| Battery Life - Flash Mode | 12 h |
| Charging Time | Approximately 4 h |
| Water Resistance | IPX6 |
| Operating Temperature Range | -20 °C to +60 °C |
| Lighting Technology | Intelligent Light® (wide beam + long range) |
| Lighting Modes | Full power, two LEDs minimum, one LED minimum, flash |
| Included Mounts | Ergonomic headband, helmet mount (adhesive), handlebar mount (25-32 mm) |
| Package Contents | Lamp, headband, helmet mount, handlebar mount, Li-Po battery with case, USB-microUSB cable, quick guide |
| Warranty | 2 years |
| Maintenance | Clean the lamp with a damp cloth; headband washable in hot water |
| Protection | Temperature control, low battery indicator (20%) |
| Environmental Certification | End-of-life recycling |
Frequently Asked Questions - Trail Speed X Silva Schneider
User questions about Trail Speed X Silva Schneider
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
Download the instructions for your Flashlight in PDF format for free! Find your manual Trail Speed X - Silva Schneider and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. Trail Speed X by Silva Schneider.
USER MANUAL Trail Speed X Silva Schneider
FULL VERSION MANUAL TRAIL SPEED X Art.no 37414
Art.no 37414
SILVATRAIL SPEED X AND INTELLIGENT LIGHT ^®
Thank you for choosing a Silva Trail Speed X headlamp. This ultra-compact high power headlamp is designed for athletes who put performance and weight first.
The Trail Speed X headlamp is equipped with Intelligent Light ^® which is a light distribution technology that combines a wide angle flood light with a long reach spot light. This unique light image gives the user peripheral and long distance vision at the same time. For a runner, cross country skier, mountain biker or night orienteer this translates into less head movement, increased control, better balance and more speed.
PRODUCT OVERVIEW
The Trail Speed X headlamp consists of the following parts:
- Headlamp unit
- Ergonomic headset
- Helmet bracket
- Bike handlebar bracket
• Rechargeable Li-Po battery in rubber case and battery soft case
• USB cable for charging - Quick guide
BEFORE USE
BATTERY CHARGING
The battery needs to be charged before first use.
- Disconnect headlamp from Battery
- Open the rubber lid on the battery pack side and insert the micro USB connector on charge cable.
- Insert the USB connector in a USB-port
- On the battery there is an LED showing the battery status during charging:
• red light = battery is charging - green light = battery is fully charged
Battery charging time is approximately 4hrs hours.
Note! When the battery is fully charged the battery automatically switches off charging. However, never leave the battery connected to a USB-port unattended for longer periods.
HEADSET
The elastic headset is designed to give a comfortable fit at speed activities such as running, XC skiing etc. Adjust the headset by moving the sliding buckle to fit it onto your head.
To remove, press the push button on the bracket and move the bike light up and out.
BIKE HANDLEBAR ATTACHMENT
The bike handlebar attachment is designed for use on bike handlebars with a dimension between 25 and 32 mm. Simply mount the attachment by wrapping the rubber strap around the handlebar and fasten it on the plastic hook.
Attach the bike light in the bike handlebar attachment by sliding the bike light bracket into the snap-in socket.
To remove, press the push button on the bracket and move the bike light up and out.
HELMET ATTACHMENT
The helmet attachment comes with a pre-mounted adhesive for easy mounting on any helmet. It is designed to not affect the protective characteristics of the helmet.
To mount the helmet attachment, make sure the surface of the helmet is clean and dry. Remove the protective film covering the adhesive and press the bracket onto its correct position.
If you do not want to use the adhesive on your helmet the attachment is prepared for mounting with 2 cable ties on the sides. [Not included]
Attach the bike light in the helmet attachment by simply sliding the bike light bracket into the snap-in socket.
To remove, press the push button on the socket and move the bike light up and out.
DURING USE
SWITCH ON YOUR HEADLAMP
On the side of the headlamp body there is a push button which controls all light modes.
Each press on the button gives you the following light:
-
Turns the headlamp ON with all LEDs in maximum power.
-
Both LEDs in min mode
-
Flood light LED in min mode
-
Starts over from 1
To turn OFF the headlamp; press and hold the button for 1 second.
The flash function, which is used to attract attention, is started from OFF mode by pressing and holding the button for 1 second. To turn OFF: press and hold the button for 1 second.
TEMP CONTROL
Note that the headlamp body temperature will increase during use. The headlamp temperature is depending on light mode, ambient air temperature and the airflow (speed). The Trail Speed X headlamp is equipped with a temperature control that prevents the headlamp body from overheating by reducing the power to the LEDs.
BATTERY INDICATION
During operation of the headlamp there will be a low battery warning when 20% of the battery time remains. This is done by flashing both LEDs for 1 second and repeated again after 5 seconds.
AFTER USE
MAINTENANCE
To make sure you get maximum performance from your Trail Speed X headlamp, clean it regularly with a damp cloth. Headset cleaning – rince in warm water.
ABOUT LI-ION (LI-PO) BATTERIES
The battery should be stored in a dry environment within the temperature range of -20°C and +35°C.
If you would like to store your battery for a longer period (more than 30 days) the battery should not be fully charged. This may cause loss of its characteristics.
Li-Ion batteries have a discharge rate of approx. 20% over a 30 day period. You can always charge a half full battery without damaging its characteristics.
Do not expose the battery for extreme temperatures which may cause fire or explosion.
Do not disassemble or mistreat the battery, risk for chemical burn. Keep away from children.
Do not dispose of batteries in fire. This may cause an explosion.
Do not submerge the batteries in water.
Do not short circuit the contacts.
Replace only with Silva Trail Speed X batteries.
Note! Always make sure to disconnect the battery when the head-lamp is not used.
TECHNICAL SPECIFICATIONS
Weight: headlamp (including battery): 135 grams
Battery type: Li-Po 7.4V, 900mAh
Light distance (Max/Min/Wide): 80m/40m/20m
Lumen (Max/Min/Wide): 500/150/150
Burn time: Max/Min/Wide/Flash: 1h30min/6 hours/6 hours/12 hours Water resistance: IPX6
Operative temperature range: -20 - +60°C
Storage temperature range: -20 - +60°C
PROTECT THE ENVIRONMENT.
Headlamp and batteries should be recycled and must not be thrown in the regular trash. Dispose these items in accordance with applicable local regulations.
WARRANTY
Silva warrants that, for a period of two (2) years, your Silva Product will be substantially free of defects in materials and workmanship under normal use. Silva's liability under this warranty is limited to repairing or replacing the product. This limited warranty extends only to the original purchaser.
If the Product proves defective during the Warranty Period please contact the original place of purchase. Make sure to have your proof of purchase on hand when returning the product. Returns cannot be processed without the original proof of purchase. This warranty does not apply if the Product has been altered, not been installed, operated, repaired, or maintained in accordance with instructions supplied by Silva, or has been subjected to abnormal physical or electrical stress, misuse, negligence or accident. Neither does the warranty cover normal wear and tear. Silva is not responsible for any consequences, direct or indirect, or damage resultant from use of this product. In no event will Silva's liability exceed the amount paid by you for the product. Some jurisdictions do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. This Warranty is valid and may be processed only in the country of purchase.
For more information please visit www.silva.se
