Product Type	HDMI Switch (video adapter)
Model	B119-002-UHD (2 inputs)
Number of HDMI Inputs	2 (female connectors)
Number of HDMI Outputs	1 (female connector)
Maximum Resolution	3840 x 2160 @ 60 Hz (Ultra HD 4K)
Color Depth	48 bits (16 bits per channel)
Supported Audio Formats	DTS-HD, Dolby True HD, 7.1 channel surround sound
Functions	Intelligent auto-switching, manual selection via button or remote control, 3D compatible, HDCP 2.2 and EDID
Power Supply	External: input 100-240 V, 50/60 Hz, 0.3 A; output 5 V, 1 A
Maximum Power Consumption	2 W
Dimensions (H x W x D)	20 x 80 x 51 mm (0.8 x 3.1 x 2.0 in)
Weight	0.106 kg (0.23 lb)
Operating Temperature	0 to 40 °C (32 to 104 °F)
Operating Humidity	10 to 85% RH, non-condensing
Warranty	3-year limited
Package Contents	Switch, remote control, power adapter with interchangeable plugs (NEMA 1-15P, CEE 7/16, BS 1363, AS/NZS 3112), user manual
Care and Cleaning	No special maintenance required. Clean with a dry, soft cloth.
Safety	Use only the supplied power adapter. Do not expose to extreme temperatures or humidity.
Spare Parts and Repairability	No user-serviceable parts. In case of failure, contact Tripp Lite for warranty service.

Frequently Asked Questions - B119002UHD Tripp Lite

How to connect the HDMI switch?

Make sure all devices are turned off. Connect the HDMI sources to the Input ports of the switch, then connect the Output port to your monitor. Plug in the external power adapter and turn on the devices. Use the Select button or remote control to change sources.

What if auto-switching does not work?

Auto-switching only works if the source device is completely turned off (not in standby). Verify that the power is off on the source you want to deactivate. If multiple sources are on, the port with the lowest number takes priority.

What is the maximum supported resolution?

The switch supports Ultra HD 4K resolution up to 3840 x 2160 @ 60 Hz, with 48-bit color depth. Make sure to use compatible high-speed HDMI cables.

What HDMI cable length can I use?

For optimal reliability, the cable length between the source and the switch should not exceed 5 meters. Similarly, the connection between the switch and the monitor should be less than 5 meters. Use Tripp Lite P569 cables.

Is the switch compatible with my 7.1 audio system?

Yes, it supports DTS-HD and Dolby True HD audio formats, as well as 7.1 channel surround sound. Connect the HDMI output directly to your compatible audio receiver.

Can I use the switch with a universal remote?

The switch comes with a dedicated infrared remote control. It is not guaranteed to work with universal remotes. Use the supplied remote for maximum reliability.

What to do if no image appears?

First check that the external power is connected and on (red/green LED). Make sure the HDMI cables are firmly inserted and in good condition. Reduce the source resolution or color depth. Test the cable directly between source and monitor.

Is HDCP supported?

Yes, the switch is HDCP 2.2 compliant, allowing it to work with protected content such as 4K Blu-ray and streaming services.

What is the warranty for this product?

Tripp Lite offers a 3-year limited warranty against defects in materials and workmanship. Keep your proof of purchase and contact Tripp Lite support to obtain a Return Merchandise Authorization (RMA) number.

Can I use a different power adapter?

No, use exclusively the supplied power adapter (5V/1A). Using a different adapter may damage the switch. The included plug adapters allow worldwide use (100-240V).

USER MANUAL B119002UHD Tripp Lite

Register your product today and be automatically entered to win an ISOBAR surge protector in our monthly drawing!

triplite.com/warranty

Manufacturing Excellence.

1111 W. 35th Street, Chicago, IL 60609 USA tripplite.com/support

Copyright © 2019 Tripp Lite. All rights reserved.

Product Features

• Switch between multiple HDMI source devices connected to a single HDMI port on a monitor
• Switch devices via pushbutton or the included remote control
• Intelligent Auto Switching functionality will automatically switch to the next powered-on device when the power to the current device is turned off*
  Supports 4K x 2K Ultra High Definition (UHD) video resolutions up to 3840 x 2160 @ 60 Hz
  Supports up to 48-bit Deep Color (16 bits per channel)
  Supports DTS-HD, Dolby® TrueHD and 7.1 channel surround sound audio
  3D, HDCP v2.2 and EDID compatible
• The B119-005-UHD model includes an international power supply with compatible North American, U.K., European and Australian plug adapters.
• Plug and play; no software or drivers required

Product Features

*Auto switching will not work properly if you have a device that is in sleep mode. Devices must be powered off completely for auto switch to work properly.

Package Contents

• B119-002-UHD, B119-004-UHD or B119-005-UHD

Remote Control

• External Power Supply Input: 100-240V, 50/60 Hz, 0.3A; Output: 5V 1A)*

• Owner's Manual

*Includes NEMA 1-15P (North America), CEE 7/16 Schuko (Europe), BS 1363 (U.K.) and AS/NZS 3112 (Australia) plugs.

Optional Accessories

• P569-XXX-CERT Premium High-Speed HDMI with Ethernet Cables

Installation

1. Make sure the power to all devices that you will be connecting is turned off.
2. Connect an HDMI source device to an Input port on the switch.

Note: The length of the HDMI cable connecting the source to the switch must not exceed 16 ft. (5 m).

1. Repeat step 2 to connect source devices to the remaining Input ports on the switch.
2. Connect the Output port on the switch to the HDMI input port of your display.

Note: The length of the HDMI cable connecting the switch to the display must not exceed 16 ft. (5 m).

Installation

1. Connect the external power supply to the switch, and then plug it into a Tripp Lite Surge Protector, Uninterruptible Power Supply (UPS), or Power Distribution Unit (PDU). The red Power LED and green Input 1 LED will illuminate to indicate that power is being received.
2. Turn on the power to the HDMI source devices and display.
3. Switch between source devices via the Select pushbutton on the unit or the included remote control. You can also let the Auto Switch functionality automatically switch to ports that are powered on. When multiple ports have powered on devices connected to them, the lowest numbered port will be switched to. Once the device connected to the lowest numbered port is powered off, the next powered on port in line will be switched to.

Troubleshooting

If you are unable to get an acceptable image after following the installation instructions, try the troubleshooting tips below.

1. Is the external power supply that came with the product connected and plugged into a working power source? For the product to function properly, the switch must be connected to and receiving power from an external power supply.
2. Was the power to the connected devices turned off prior to installation? If not, restart them.
3. What resolution are you trying to reach? Tripp Lite’s B119- 002-UHD, B119- 004-UHD and B119- 005-UHD are tested to support 4K x 2K Ultra High Definition (UHD) video resolutions up to 3840 x 2160 @ 60 Hz, and 48-bit Deep Color (16 bits per channel).
4. What length HDMI cable are you using? (See the Installation section in this manual for details on the maximum cable distance). The shorter the cable being used, the higher the resolution you will be able to obtain. (continued)

If you are not able to get an acceptable image, try using a shorter cable, or lowering your source's video resolution or color depth settings.

5. What type of cabling are you using?

Inferior cabling can result in poor performance, so it is important that you use cables that can support the video resolution you are trying to obtain. It is recommended that you use Tripp Lite's P569-Series High Speed HDMI cables, as they have been tested to work with the B119-002-UHD, B119-004-UHD and B119-005-UHD.

6. Test your cables to ensure they are working properly. For example, connect your HDMI cable between a source and monitor that you know works to see if the cable is functioning.

7. Is the unit located in an area that exposes it to higher temperatures? If the product is overheated, it will not function properly.

Specifications

Model B119-002-UHD B119-004-UHD B119-005-UHD

Connectors

Input (x2) HDMI Female (x4) HDMI Female (x5) HDMI Female
Output HDMI Female HDMI Female HDMI Female

Video

Maximum Resolution	3840 x 2160 (60 Hz)	3840 x 2160 (60 Hz)	3840 x 2160 (60 Hz)
Color Depth 48-bit	Deep Color (16 bits per channel)	48-bit Deep Color (16 bits per channel)	48-bit Deep Color (16 bits per channel)
Video Amplifier Bandwidth	6Gbps / 600Mhz 6Gbps / 600Mhz 6Gbps / 600Mhz

Environmental

Operating Temperature	32 to 104°F (0 to 40°C)	32 to 104°F (0 to 40°C)	32 to 104°F (0 to 40°C)
Operating Humidity	10% to 85% RH, Non-Condensing	10% to 85% RH, Non-Condensing	10% to 85% RH, Non-Condensing
Storage Temperature	14 to 176°F (-10 to 80°C)	14 to 176°F (-10 to 80°C)	14 to 176°F (-10 to 80°C)
Storage Humidity	5% to 90% RH, Non-Condensing	5% to 90% RH, Non-Condensing	5% to 90% RH, Non-Condensing

Physical

Unit Dimensions (HxWxD, in.)	0.8 x 3.1 x 2.0 0.8 x 4.8 x 2.0 x 2.0
Unit Dimensions (HxWxD, mm)	20 x 80 x 51 20 x 123 x 51 20 x 123 x 51
Unit Weight (lb.)	0.23 0.33 0.33
Unit Weight (kg)	0.1062 0.15 0.15

Power Requirements

External Power Supply	5V/1A	5V/1A	5V/1A
Power Consumption (Max)	2W	2W	2.5W

Warranty and Product Registration

3-YEAR LIMITED WARRANTY

TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of three (3) years from the date of initial purchase. TRIPP LITE's obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. To obtain service under this warranty, you must obtain a Returned Material Authorization (RMA) number from TRIPP LITE or an authorized TRIPP LITE service center. Products must be returned to TRIPP LITE or an authorized TRIPP LITE service center with transportation charges prepaid and must be accompanied by a brief description of the problem encountered and proof of date and place of purchase. This warranty does not apply to equipment, which has been damaged by accident, negligence or misapplication or has been altered or modified in any way.

EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the purchaser.

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specifically, TRIPP LITE is not liable for any costs, such as lost profits or revenue, loss of equipment, loss of use of equipment, loss of software, loss of data, costs of substitutes, claims by third parties, or otherwise.

Warranty and Product Registration

PRODUCT REGISTRATION

Visit tripplite.com/warranty today to register your new Tripp Lite product. You'll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*

• No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

WEEE Compliance Information for Tripp Lite Customers and Recyclers (European Union)

Under the Waste Electrical and Electronic Equipment (WEEE) Directive and implementing regulations, when customers buy new electrical and electronic equipment from Tripp Lite they are entitled to:

• Send old equipment for recycling on a one-for-one, like-for-like basis (this varies depending on the country)
• Send the new equipment back for recycling when this ultimately becomes waste

Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the life support equipment or to significantly affect its safety or effectiveness is not recommended.

Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.

1111 W. 35th Street, Chicago, IL 60609 USA tripplite.com/support

1111 W. 35th Street, Chicago, IL 60609 EE UU triplite.com/support

1111 W. 35th Street, Chicago, IL 60609 EE UU triplite.com/support

19-08-201 93-37C3_RevD

B119-002-UHD (2 ports),

B119-004-UHD (4 ports),

B119-005-UHD (5 ports)

English 1 • Espanol 11 • Pyszczny 31

1111 W. 35th Street, Chicago, IL 60609 USA tripplite.com/support

1111 W. 35th Street, Chicago, IL 60609 USA tripplite.com/support

19-08-201 93-37C3_RevD

1111 W. 35th Street, Chicago, IL 60609 USA tripplite.com/support
