| Product Type | HDMI to VGA Adapter with Audio |
| Brand | Tripp Lite |
| Model | P131-000-A |
| Input Connector | HDMI (Male) |
| Video Output Connector | HD15 / VGA (Female) |
| Audio Output Connector | 3.5 mm (Female) |
| Power | Powered by HDMI bus; additional Micro-B USB port if needed |
| Maximum Resolution | 1920 x 1200 @ 60 Hz |
| HDCP Compatibility | HDCP 1.4 |
| HDMI Compatibility | HDMI 1.4 |
| Installation | Plug-and-play, no software or driver required |
| Operating Temperature | 0 to 40 °C |
| Storage Temperature | -15 to 50 °C |
| Storage Humidity | 0 to 85% RH, non-condensing |
| Warranty | 1 year |
| Care and Cleaning | Clean with a dry cloth; avoid liquids |
| Safety | Do not use for life support devices |
| Spare Parts and Repairability | Not user-serviceable; contact Tripp Lite |
| General Information | Manufactured by Tripp Lite, Chicago, IL 60609, USA |
Frequently Asked Questions - P131000A Tripp Lite
User questions about P131000A Tripp Lite
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
Download the instructions for your Network adapter in PDF format for free! Find your manual P131000A - Tripp Lite and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. P131000A by Tripp Lite.
USER MANUAL P131000A Tripp Lite
HDMI to VGA Adapter with Audio
Model: P131-000-A
Español 8 • Français 14 • Русский 20
PROTECT YOUR INVESTMENT!
Register your product for quicker service and ultimate peace of mind. You could also win an ISOBAR6ULTRA surge protector—a \$100 value!
www.tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 USA www.tripplite.com/support
Copyright © 2017 Tripp Lite. All rights reserved.
Product Features
- Connect your HDMI-enabled device to a VGA display with audio
• Supports resolutions up to 1920 x 1200 @ 60Hz - Bus-powered via HDMI, plus a USB Micro-B port for when additional power is needed
• HDCP 1.4 and HDMI 1.4 compliant - Plug-and-play; no software or drivers to install
Installation
Note: Make sure that all devices you are connecting are powered off prior to installation.
1 Connect the HDMI connector to an HDMI source.
2 Connect the VGA cable to the adapter's VGA port and a VGA display.
3 Connect a 3.5 mm audio cable from the unit's audio jack to the audio-in jack on the monitor or speakers.
4 Power on the connected devices. If the unit does not receive a signal after powering on the devices, connect a USB cable from the adapter's USB Micro-B port to the USB-A port on a USB charger or HDMI source.
Specifications
| Connectors | |
| Audio/Video Input HDMI (Male) | |
| Video Output HD15 (Female) | |
| Audio Output 3.5 mm (Female) | |
| USB (Power) USB Micro-B (Female) |
| Environmental | |
| Operating Temperature | 32 to 104°F(0 to 40°C) |
| Storage Temperature | 5 to 122°F(-15 to 50°C) |
| Storage Humidity 0% | to 85% RH,Non-Condensing |
Warranty and Product Registration
1-Year Limited Warranty
TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of one (1) year from the date of initial purchase. TRIPP LITE's obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. To obtain service under this warranty, you must obtain a Returned Material Authorization (RMA) number from TRIPP LITE or an authorized TRIPP LITE service center. Products must be returned to TRIPP LITE or an authorized TRIPP LITE service center with transportation charges prepaid and must be accompanied by a brief description of the problem encountered and proof of date and place of purchase. This warranty does not apply to equipment, which has been damaged by accident, negligence or misapplication or has been altered or modified in any way.
EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specifically, TRIPP LITE is not liable for any costs, such as lost profits or revenue, loss of equipment, loss of use of equipment, loss of software, loss of data, costs of substitutes, claims by third parties, or otherwise.
Warranty and Product Registration
Product Registration
Visit www.triplite.com/warranty today to register your new Tripp Lite product. You'll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.
FCC Notice, Class B
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Warranty and Product Registration
Any changes or modifications to this equipment not expressly approved by Tripp Lite could void the user's authority to operate this equipment.
WEEE Compliance Information for Tripp Lite Customers and Recyclers (European Union)
Under the Waste Electrical and Electronic Equipment (WEEE) Directive and implementing regulations, when customers buy new electrical and electronic equipment from Tripp Lite they are entitled to:
- Send old equipment for recycling on a one-for-one, like-for-like basis (this varies depending on the country)
- Send the new equipment back for recycling when this ultimately becomes waste
Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the life support equipment or to significantly affect its safety or effectiveness is not recommended.
Tripp Lite has a policy of continuous improvement. Product specifications are subject to change without notice.
