Product Type	3-Port USB Hub with Gigabit Ethernet and PD Charging
Brand	Tripp Lite
Model	U4600033AGC (U460-003-3AG / U460-003-3AG-C / U460-003-3AGB-C)
Input Connectors	1 x USB-C Male (integrated cable), 1 x USB-C PD Female
Output Connectors	3 x USB-A Female, 1 x RJ45 Female
USB-A Transfer Rate	Up to 5 Gbit/s (USB 3.2 Gen 1)
Ethernet Speed	10/100/1000 Mbps
USB-A Fast Charging	5 V, 1.5 A (7.5 W) - -C models only
USB-C PD Charging	20 V, 3 A (60 W) - -C models only
Power	Via USB-C PD (input up to 20 V 3 A)
Operating Temperature	0 °C to 45 °C (32 °F to 113 °F)
Storage Temperature	-10 °C to 70 °C (14 °F to 158 °F)
Operating Humidity	10 % to 85 % RH (non-condensing)
Storage Humidity	5 % to 90 % RH (non-condensing)
Dimensions (estimated)	10 x 4 x 1.5 cm
Weight (estimated)	60 g
Main Function 1	Expansion of 3 high-speed USB-A ports
Main Function 2	Gigabit Ethernet port for wired network connection
Main Function 3	Fast charging of devices via USB-A (7.5 W)
Main Function 4	Host Pass-Through charging via USB-C PD (60 W)
Plug and Play	Yes, installation without software
Maintenance and Cleaning	Clean with a dry, soft cloth. Do not use liquids.
Safety	Use in a dry environment. Do not expose to water or moisture.
Spare Parts and Repairability	Not user-serviceable. Contact Tripp Lite support for any repairs.
General Information	3-year limited warranty. Compliant with WEEE directive.

Frequently Asked Questions - U4600033AGC Tripp Lite

How to connect the hub to my computer?

Simply connect the hub's integrated USB-C cable to a USB-C port on your computer. No driver is needed, the hub is Plug and Play.

The hub does not detect my USB devices, what should I do?

Check that the hub is properly connected to the computer. Try another USB-C port. Make sure the USB device is compatible. If the problem persists, restart the computer or test the hub on another device.

Can I use the hub to charge my smartphone?

Yes, -C models have a dedicated USB-A port for fast charging, providing up to 5 V / 1.5 A (7.5 W). Quick Charge is not supported.

What is the maximum transfer speed of the USB ports?

The hub's USB-A ports support transfer rates up to 5 Gbit/s, corresponding to the USB 3.2 Gen 1 standard.

How to use the Ethernet port?

Connect an Ethernet cable (Cat5e/6) between the hub's RJ45 port and your network. A network connection will be established automatically. If not, manually configure your computer's network settings.

Does the hub work with a Mac computer?

Yes, the hub is compatible with Mac computers with a USB-C port. It works as Plug and Play on macOS. For network configuration, go to System Preferences > Network.

What to do if the hub is not recognized?

Try disconnecting and reconnecting the hub. Restart the computer. Test the hub on another device. If no result, the hub may be defective; contact Tripp Lite support.

Can I use the hub to charge my laptop?

Yes, -C models support Pass-Through charging via the USB-C PD port, with output up to 20 V / 3 A (60 W). Connect the laptop charger to the hub's USB-C PD port.

Is the USB-C PD port compatible with all chargers?

The USB-C PD port accepts input up to 20 V / 3 A (60 W). It is compatible with most USB-C PD chargers, but the power delivered depends on the charger. Does not support Quick Charge.

What is the product warranty?

The product has a 3-year limited warranty against defects in materials and workmanship. For any claims, visit Tripplite.Eaton.com/support before returning the product.

USER MANUAL U4600033AGC Tripp Lite

Optional Accessories

• N201-Series Cat6 Gigabit Snagless Patch Cables
  U322-Series USB 3.2 A/B Device Cables
  U326-Series USB 3.2 Micro-B Device Cables
• U420-003 USB 3.2 Gen 1 USB-C Cable (M/M), 3 ft.

Product Features

• Portable design with built-in cable is perfect for travel and stowing in a laptop bag
• USB-A hub ports support data transfer rates up to 5 Gbps
• Dedicated fast-charging USB-A port provides up to 5V 1.5A (7.5W) for charging smartphones and other mobile devices (U460-003-3AG-C and U460-003-3AGB-C only)
• Ethernet port supports true 10/100/1000 Mbps networks speeds
• USB-C PD port supports 20V 3A (60W) power output for charging host device (U460-003-3AG-C and U460-003-3AGB-C only)

Product Features

• Plug-and-play operation with no software required for easy, immediate installation

Installation

Note: When the unit is connected to the USB-C port on your computer and to a network via Cat5e/6 cabling, a network connection will be automatically established. If no connection is made, you can manually establish one by going to your computer's network settings page. For example, on a Mac, you would navigate to the Network section found in System Preferences, click the 'Assist Me' button to get to the Network Setup Assistant, then follow the prompts to establish a connection

1. Connect the unit's USB Type-C connector to the USB-C port on your laptop, tablet or other device.
2. Connect up to three USB devices to the USB-A hub ports on the unit.
3. Connect the unit's RJ45 port to a network using a UTP cable (such as N201-Series Cat6 cables).
4. Charge and power your host device by connecting its AC wall charger to the adapter's USB-C PD port (U460-003-3AG-C and U460-003-3AGB-C only).

Note: USB-C PD port does not support Quick Charge (QC).

Specifications

Input Connectors
USB USB-C (Male)
Charging USB-C (Female)
Output Connectors
USB-A USB-A (Female) x 3
Ethernet RJ45 (Female)
Environmental
Operating Temperature	32°F to 113°F (0°C to 45°C)
Operating Humidity 10% to 85% RH, Non-Condensing
Storage Temperature	14°F to 158°F (-10°C to 70°C)
Storage Humidity 5% to 90% RH, Non-Condensing
Power Requirements
USB-C PD Charging Port*	Supports up to 20V 3A (60W) Input
USB-A Charging Port*	Provides up to 5V 1.5A (7.5W) Output

• U460-003-3AG-C and U460-003-3AGB-C only

Warranty

3-YEAR LIMITED WARRANTY

We warrant our products to be free from defects in materials and workmanship for a period of three (3) years from the date of initial purchase. Our obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. Visit Tripplite. Eaton.com/support/product-returns before sending any equipment back for repair. This warranty does not apply to equipment which has been damaged by accident, negligence or misapplication or has been altered or modified in any way.

EXCEPT AS PROVIDED HEREIN, WE MAKE NO WARRANTYES, EXPRESS OR IMPLIED, INCLUDING WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the purchaser.

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL WE BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specifically, we are not liable for any costs, such as lost profits or revenue, loss of equipment, loss of use of equipment, loss of software, loss of data, costs of substitutes, claims by third parties, or otherwise.

Warranty

FCC Notice, Class B

This device complies with part 15 of the FCC Rules.

Operation is subject to the following two conditions: (1)

This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

Any changes or modifications to this equipment not expressly approved by Eaton could void the user's authority to operate this equipment.

Warranty

WEEE Compliance Information for Customers and Recyclers (European Union)

Under the Waste Electrical and Electronic Equipment (WEEE) Directive and implementing regulations, when customers buy new electrical and electronic equipment from Eaton, they are entitled to:

• Send old equipment for recycling on a one-for-one, like-for-like basis (this varies depending on the country)
• Send the new equipment back for recycling when this ultimately becomes waste

Eaton has a policy of continuous improvement.

Specifications are subject to change without notice.

Powering Business Worldwide

Eaton

1000 Eaton Boulevard

Cleveland, OH 44122

United States

Eaton.com

© 2023 Eaton

All Rights Reserved

Publication No.

23-08-178/

93-3745_RevE

August 2023

Eaton is a registered trademark.

All trademarks are property of their respective owners.

Hubs de 3 Puertoos USB
