U4600033AGBC - USB Hub Tripp Lite - Free user manual and instructions

Product Type	USB Hub with USB-A, Ethernet, and USB-C PD ports
Model Numbers	U460-003-3AG, U460-003-3AG-C, U460-003-3AGB-C
Input Connector	USB-C male (built-in)
Output Ports	3 USB-A female ports, 1 RJ45 Ethernet female port, 1 USB-C PD female port
USB-A Speed	Up to 5 Gbps (USB 3.2 Gen 1)
USB-A Fast Charging	5V, 1.5A (7.5W) on -C models
USB-C PD Charging	20V, 3A (60W) on -C models
Ethernet	10/100/1000 Mbps
Power Source	Via host USB-C; optionally via USB-C PD charger (20V 3A) on -C models
Operating Temperature	0°C to 45°C
Operating Humidity	10% to 85% RH non-condensing
Storage Temperature	-10°C to 70°C
Storage Humidity	5% to 90% RH non-condensing
Warranty	3-year limited
Plug and Play	Yes, no driver installation required
Design	Portable with built-in cable
Maintenance and Cleaning	Clean with a soft, dry cloth
Safety	Compliant with applicable standards
Repairability	Not user-serviceable

Frequently Asked Questions - U4600033AGBC Tripp Lite

How to install the Tripp Lite U4600033AGBC USB Hub?

Connect the hub's USB-C connector to a USB-C port on your computer. Connect up to three USB devices to the USB-A ports. For Ethernet, connect the RJ45 port to a network using a Cat5e/6 cable. On -C models, you can plug in a USB-C PD charger to power the host.

Which devices are compatible with this hub?

The hub is compatible with any computer, tablet, or smartphone with a USB-C port supporting USB 3.0 mode or higher. It works with Windows, macOS, Chrome OS, Linux, and Android.

What is the transfer speed of the USB-A ports?

The USB-A ports support transfer speeds up to 5 Gbps (USB 3.2 Gen 1). They are backward compatible with USB 2.0 and 1.1 devices.

Can I charge my smartphone through the hub?

Yes, on the U460-003-3AG-C and U460-003-3AGB-C models, one of the USB-A ports offers fast charging at 5V, 1.5A (7.5W). On the standard model, the USB-A ports only provide standard charging.

Does the hub support laptop charging?

Yes, on the -C models, the USB-C PD port accepts incoming power of 20V, 3A (60W) to charge the connected laptop. However, Quick Charge is not supported.

How do I connect the hub to an Ethernet network?

Use an Ethernet cable (Cat5e/6) to connect the hub's RJ45 port to your router or wall jack. Once connected to the computer via USB-C, the network connection is established automatically with Plug-and-Play.

What should I do if no network connection is established after connecting?

Manually configure the network connection in your computer's settings. For example, on macOS: go to System Preferences > Network, click Assist me and follow the setup assistant. On Windows, check the DHCP settings.

What is the product warranty?

Tripp Lite offers a 3-year limited warranty from the date of purchase, covering hardware and manufacturing defects. To return a product, contact support before shipping.

Is the hub compatible with Mac and Windows computers?

Yes, the hub works without additional drivers on Windows, macOS, Chrome OS, Linux and other systems with standard USB and Ethernet drivers.

Can I use the hub to power my laptop via USB-C PD?

Yes, on the -C models, plug a USB-C PD charger (up to 60W) into the hub's USB-C PD port. The connected laptop will then be charged while using the hub's other ports.

USER MANUAL U4600033AGBC Tripp Lite

Optional Accessories

• N201-Series Cat6 Gigabit Snagless Patch Cables
  U322-Series USB 3.2 A/B Device Cables
  U326-Series USB 3.2 Micro-B Device Cables
• U420-003 USB 3.2 Gen 1 USB-C Cable (M/M), 3 ft.

Product Features

• Portable design with built-in cable is perfect for travel and stowing in a laptop bag
• USB-A hub ports support data transfer rates up to 5 Gbps
• Dedicated fast-charging USB-A port provides up to 5V 1.5A (7.5W) for charging smartphones and other mobile devices (U460-003-3AG-C and U460-003-3AGB-C only)
• Ethernet port supports true 10/100/1000 Mbps networks speeds
• USB-C PD port supports 20V 3A (60W) power output for charging host device (U460-003-3AG-C and U460-003-3AGB-C only)

Product Features

• Plug-and-play operation with no software required for easy, immediate installation

Installation

Note: When the unit is connected to the USB-C port on your computer and to a network via Cat5e/6 cabling, a network connection will be automatically established. If no connection is made, you can manually establish one by going to your computer's network settings page. For example, on a Mac, you would navigate to the Network section found in System Preferences, click the 'Assist Me' button to get to the Network Setup Assistant, then follow the prompts to establish a connection

1. Connect the unit's USB Type-C connector to the USB-C port on your laptop, tablet or other device.
2. Connect up to three USB devices to the USB-A hub ports on the unit.
3. Connect the unit's RJ45 port to a network using a UTP cable (such as N201-Series Cat6 cables).
4. Charge and power your host device by connecting its AC wall charger to the adapter's USB-C PD port (U460-003-3AG-C and U460-003-3AGB-C only).

Note: USB-C PD port does not support Quick Charge (QC).

Specifications

Input Connectors
USB USB-C (Male)
Charging USB-C (Female)
Output Connectors
USB-A USB-A (Female) x 3
Ethernet RJ45 (Female)
Environmental
Operating Temperature	32°F to 113°F (0°C to 45°C)
Operating Humidity 10% to 85% RH, Non-Condensing
Storage Temperature	14°F to 158°F (-10°C to 70°C)
Storage Humidity 5% to 90% RH, Non-Condensing
Power Requirements
USB-C PD Charging Port*	Supports up to 20V 3A (60W) Input
USB-A Charging Port*	Provides up to 5V 1.5A (7.5W) Output

• U460-003-3AG-C and U460-003-3AGB-C only

Warranty

3-YEAR LIMITED WARRANTY

We warrant our products to be free from defects in materials and workmanship for a period of three (3) years from the date of initial purchase. Our obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. Visit Tripplite. Eaton.com/support/product-returns before sending any equipment back for repair. This warranty does not apply to equipment which has been damaged by accident, negligence or misapplication or has been altered or modified in any way.

EXCEPT AS PROVIDED HEREIN, WE MAKE NO WARRANTYES, EXPRESS OR IMPLIED, INCLUDING WARRANTY OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the purchaser.

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL WE BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specifically, we are not liable for any costs, such as lost profits or revenue, loss of equipment, loss of use of equipment, loss of software, loss of data, costs of substitutes, claims by third parties, or otherwise.

Warranty

FCC Notice, Class B

This device complies with part 15 of the FCC Rules.

Operation is subject to the following two conditions: (1)

This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.

Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

Any changes or modifications to this equipment not expressly approved by Eaton could void the user's authority to operate this equipment.

Warranty

WEEE Compliance Information for Customers and Recyclers (European Union)

Under the Waste Electrical and Electronic Equipment (WEEE) Directive and implementing regulations, when customers buy new electrical and electronic equipment from Eaton, they are entitled to:

• Send old equipment for recycling on a one-for-one, like-for-like basis (this varies depending on the country)
• Send the new equipment back for recycling when this ultimately becomes waste

Eaton has a policy of continuous improvement.

Specifications are subject to change without notice.

Powering Business Worldwide

Eaton

1000 Eaton Boulevard

Cleveland, OH 44122

United States

Eaton.com

© 2023 Eaton

All Rights Reserved

Publication No.

23-08-178/

93-3745_RevE

August 2023

Eaton is a registered trademark.

All trademarks are property of their respective owners.

Hubs de 3 Puertoos USB
