METABO HBS 18 LTX BL 3000 - Screwdriver

HBS 18 LTX BL 3000 - Screwdriver METABO - Free user manual and instructions

Find the device manual for free HBS 18 LTX BL 3000 METABO in PDF.

English EN ⬇ Download 💬 AI Question ❓ 10 questions ⚙️ Specs
📄

Document temporarily unavailable

The manual is currently being transferred to our new server. It will be accessible again in a few hours. Thank you for your patience.

Pick your language and provide your email: we'll send you a specifically translated version.
Product type Cordless screwdriver
Brand Metabo
Model HBS 18 LTX BL 3000
Nominal voltage 18 V
Motor type Brushless
Battery system CAS (Cordless Alliance System)
Compatible battery type Lithium-Ion (Li-Ion)
Battery voltage range 12 - 36 V
Recommended battery capacity 1.3 - 10 Ah
No-load speed 0 - 3000 rpm
Chuck 1/4" hexagonal (6.35 mm)
Weight (without battery) Approx. 1.5 kg
Power supply Li-Ion 18 V battery (not included)
Variable speed Yes
Reverse rotation Yes
Motor brake Yes
LED light Yes (integrated)
Overload protection Yes (electronic)
Recommended charging ambient temperature 0 °C to 40 °C
Protection class (charger) II
Intended use Screwing and drilling in wood, metal and plastic

Frequently Asked Questions - HBS 18 LTX BL 3000 METABO

Which batteries are compatible with the Metabo HBS 18 LTX BL 3000 cordless screwdriver?
The screwdriver is compatible with all batteries from Metabo's CAS (Cordless Alliance System), Li-Ion type, voltage 12 V to 36 V and capacity 1.3 Ah to 10 Ah.
How do I charge the battery of my screwdriver?
Insert the battery fully into the sliding compartment of the appropriate Metabo charger. The control light flashes during charging. Once charging is complete, the light stays on. The battery can remain in maintenance mode.
What does the flashing warning light on the charger mean?
A flashing warning light indicates a defective or incorrectly inserted battery. Remove the battery immediately and check its condition. If the problem persists, contact Metabo customer service.
Can I use the screwdriver continuously?
Yes, but observe a charging ambient temperature between 0 °C and 40 °C. If the battery or charger overheats, the charging process is automatically adjusted (power reduction).
How do I clean my Metabo screwdriver?
Regularly clean the ventilation slots with a dry brush. Do not use corrosive products. Store the tool in a dry place away from moisture.
Which charger should I use for the battery?
Use exclusively Metabo chargers from the ASC series (ASC 55, ASC 145, ASC 290) or SC 36/SC 30 chargers, depending on the voltage and capacity of your battery. Never use an unsuitable charger.
Does the screwdriver have a motor brake?
Yes, the Metabo HBS 18 LTX BL 3000 screwdriver is equipped with a motor brake for quick tool stop after releasing the trigger.
Can I charge a USB device via the ASC 290 charger?
The ASC 290 charger has a USB-C port for charging compatible USB devices (smartphones, etc.). USB charging starts automatically after battery charging.
What should I do if the battery does not charge?
Check that the battery is correctly inserted and the temperature is between 0 °C and 50 °C. If the warning light stays on, the battery may be too hot/cold. Wait for it to cool down or warm it up.
Where can I find spare parts and get my screwdriver repaired?
Repairs must be carried out by an authorized Metabo specialist. Contact your Metabo representative or visit www.metabo.com to find after-sales service.

User questions about HBS 18 LTX BL 3000 METABO

0 question about this device. Answer the ones you know or ask your own.

Ask a new question about this device

The email remains private: it is only used to notify you if someone responds to your question.

No questions yet. Be the first to ask one.

Download the instructions for your Screwdriver in PDF format for free! Find your manual HBS 18 LTX BL 3000 - METABO and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. HBS 18 LTX BL 3000 by METABO.

USER MANUAL HBS 18 LTX BL 3000 METABO

Manual assistant
Powered by Anthropic
Waiting for your message
Product information

Brand : METABO

Model : HBS 18 LTX BL 3000

Category : Screwdriver
