USER MANUAL Graphite Airforce

INSTRUCTIONS ON MOUNTING AND USE

TSE A: Light ON/OFF key: press this touch sensor to switch on or o the lights of the hood. B: Motor ON/OFF key (4 speed): press this touch sensor to switch on the hood extractor fan at the same speed as it was when last switched o. Use the „D“ and „C“ keys to vary the speed (power) of extraction. C: Decrease extraction speed (power) key: press this touch sensor to reduce the extraction speed of the hood. D: Increase extraction speed (power) key: press this touch sensor to increase the extraction speed of the hood. E: Timer key: irrespective of the extraction speed selected, touching the key will activate the timer function for 5 minutes (during this phase a dot will ash on and o on the display). To reset the timer operate the E motor key. F: Filters reset key: touching this key will reset the metal anti-grease lter (1) saturation and carbon lter replacement (2) warning. (1) After the hood has been operating for 40 hours, the “FG“or”G” symbol on the display will begin to ash, indicating the need to clean the metal antigrease lters. (2) After the hood has been operating for 120 hours, the “FC”or”C” symbol on the display will begin to ash, indicating the need to clean the active carbon lters. Automatic Sensor: tapping both “C” and “D” keys at the same time will activate the “Automatic Sensor” function. This function, indicated with an “A” on the display, automatically sets the hood at the best extraction speed, depending on the cooking going on. To return to manual operation, press “C” or “D” button. Note: 4 hours after the last key touch, the fan will automatically turn o. All hoods with capacities exceeding 650 m3/h have the last timed speed; It lasts for 7 minutes, after which it automatically returns to the last non-timed speed.AVVERTENZE

OPERATION GB Maintenance Prior to any maintenance operation ensure that the cooker hood is disconnected from the electrical outlet. Cleaning The hood must be cleaned frequently both inside (apart from the area behind the grease lter) and outside. Use a cloth moistened with neutral liquid detergents. Never use products containing abrasives. Warning Failure to carry out the basic standards of the cleaning of the cooker hood and replacement of the lters may cause re risks. Therefore we recommend observing these instructions. Anti-grease Filter must be cleaned once a month, with non abrasive detergents, by hand or in dishwasher on low temperature and short cycle. When washed in a dishwasher, the grease lter may discolour slightly, but this does not aect its ltering capacity. Charcoal Filter - (only for lter version) The active charcoal lters F are not washable nor regenerative. It should be changed every 6 months in normal use. The active charcoal lters capture unpleasant cooking odours. Reducing environmental impact: To reduce energy consumption, we recommend you always use the lowest suction speed among those suitable for the cooking mode currently active, avoid leaving the appliance running for more than 15 minutes after burner shutdown and switch o the lights if you leave the cooking area. Replacing lightbulbs Warning! Prior to touching the light bulbs ensure they are cooled down. Led Light If the lighting group LED does not work, please contact the technical service center in order to replace the whole group.18
