USER MANUAL CEMO23GSM CONTINENTAL EDISON

Istruzioni per l’uso FOUR À MICRO-ONDES Guide d’utilisationEN [original version] Please read through this user manual thoroughly, its detailed instructions, warnings and safety precautions to ensure you get the most out of your product. Keep this manual for future reference.21

PRECAUTIONS TO AVOID

possible exposure to excessive microwave energy

IMPORTANT SAFETY INSTRUCTIONS

When using electrical appliance basic safety precautions should be followed, including the following:

WARNING: To reduce the risk of burns, electric shock, re, injury to persons or exposure to

excessive microwave energy:

1. Read all instructions before using the appliance and keep for future reference.

2. Use this appliance only for its intended use as described in this manual. Do not use corrosive

chemicals or vapors in this appliance. This type of oven is specically designed to heat, cook or dry food. It is not designed for industrial or laboratory use.

3. Do not operate the oven when empty.

4. Do not operate this appliance if it has a damaged cord or plug, if it is not working properly or if it has

been damaged or dropped. If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a similarly qualied person in order to avoid a hazard.

WARNING: Only allow children to use the oven without supervision when adequate instructions

have been given so that the child is able to use the oven in a safe way and understands the hazards of improper use.

6. To reduce the risk of re in the oven cavity:

a) When heating food in plastic or paper container, check the oven frequently to the possibility of ignition. b) Remove wire twist-ties from paper or plastic bags before placing bag in oven. c) If smoke is observed, switch off or unplug the appliance and keep the door closed in order to stie any ames. d) Do not use the cavity for storage purposes. Do not leave paper products, cooking utensils or food in the cavity when not in use. e) The microwave oven is intended for heating food and beverages. Drying of clothing and heating of warming pads, slippers, sponges, damp cloth and similar may lead to risk of injury, ignition or re.

WARNING: Liquid or other food must not be heated in sealed containers since they are liable

1. Do not attempt to operate this oven with the door open since open door operation can result in

harmful exposure to microwave energy. It is important not to defeat or tamper with the safety interlocks.

2. Do not place any object between the oven front face and the door or allow soil or cleaner residue

to accumulate on sealing surfaces.

3. Do not operate the oven if it is damaged. It is particularly important that the oven door close properly

and that there is no damage to the a) Door (bent), b) Hinges and latches (broken or loosened), c) Door seals and sealing surfaces.

4. The oven should not be adjusted or repaired by anyone except properly qualied service personnel.22

8. Microwave heating of beverage can result in delayed eruptive boiling, therefore care has to be

taken when handle the container.

9. Do not fry food in the oven. Hot oil can damage oven parts and utensils and even result in skin

10. Eggs in their shell and whole hard-boiled eggs should not be heated in microwave ovens since they

may explode even after microwave heating has ended.

11. Pierce foods with heavy skins such as potatoes, whole squashes, apples and chestnuts before

12. The contents of feeding bottles and baby jars should be stirred or shaken and the temperature

should be checked before serving in order to avoid burns.

13. Cooking utensils may become hot because of heat transferred from the heated food. Potholders

may be needed to handle the utensil.

14. Utensils should be checked to ensure that they are suitable for use in microwave oven.

15. Utensil Test: Place the empty utensil in the oven, microwave at high power for 60 seconds. A utensil

which becomes very hot should not be used.

WARNING: It is hazardous for anyone other than a trained person to carry out any service or

repair operation which involves the removal of any cover which gives protection against exposure to microwave energy.

17. This product is a Group 2 Class B ISM equipment. The denition of Group 2 which contains all

ISM (Industrial, Scientic and Medical) equipment in which radio-frequency energy is intentionally generated and/or used in the form of electromagnetic radiation for the treatment of material, and spark erosion equipment. For Class B equipment is equipment suitable for use in domestic establishments and in establishments directly connected to a low voltage power supply network which supplies buildings used for domestic purpose.

18. This appliance is not intended for use by persons (including children) with reduced physical,

sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.

19. Children should be supervised to ensure that they do not play with the appliance.

20. The microwave oven is only used in freestanding.

WARNING: Do not install oven over a range cook top or other heat-producing appliance. if

installed could be damaged and the warranty would be avoid .

22. The microwave oven shall not be placed in a cabinet.

23. The door or the outer surface may get hot when the appliance is operating.

WARNING: Accessible parts may become hot during use. Young children should be kept

25. When in use, the unit becomes hot. Do not touch the heating elements inside the oven.

26. The temperature of accessible surfaces may be high when the appliance is operating.

27. Appliance is not to be used by children or persons with reduced physical, sensory or mental

capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction.

WARNING: If the door or door seals are damaged, the oven must not be operated until it has

been repaired by a competent person.

29. The instructions shall state that appliances are not intended to be operated by means of an external

timer or separate remote-control system.

30. The microwave oven is for household use only and not for commercial use.

31. Never remove the distance holder in the back or on the sides, as it ensures a minimum distance

from the wall for air circulation.23

32. Please secure the turntable before you move the appliance to avoid damages.

CAUTION: It is dangerous to repair or maintain the appliance by no other than a specialist because under these circumstances the cover have to be removed which assures protection against microwave radiation. This applies to changing the power cord or the lighting as well. Send the appliance in these cases to our service centre.

34. The microwave oven is intended for defrosting, cooking and steaming of food only.

35. Use gloves if you remove any heated food.

37. This appliance can be used by children aged from 8 years and above and persons with reduced

physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved. Children shall not be made by children unless they are aged from 8 years and above and supervised. Keep the appliance and its cord out of reach of children under 8 years old.

38. If smoke is emitted, switch off or unplug the appliance and keep the door closed in order to stie

39. This device is intended for use in domestic and similar applications such as:

- Kitchen corners reserved for store staff, ofces and other professional environments; - The farms; - The use by customers of hotels, hotels and other residential environments; - Bed and Breakfast environments. Information on the meaning of the conformity mark The mark indicates that the product meets the main requirements of the European directives: 2014/35 / EU (low voltage), 2014/30 / EU (electromagnetic compatibility), 2011/65 / EU (restriction of the use of certain substances in electronic equipment ).24 CONTENT THIS USER GUIDE IS AVAILABLE IN THE FOLLOWING LANGUAGES: - FR (version originale) - EN (translated from the original) - IT (tradotto dall’originale) Any other translation would be a translation of the original version. This user guide, any modications or any new version, is available on our website. PRECAUTIONS TO AVOID (possible exposure to excessive microwave energy) Page 21 IMPORTANT SAFETY INSTRUCTIONS Page 21 I - SPECIFICATIONS Page 25 II - PRODUCT DIAGRAM Page 26 III - CONTROL PANEL Page 27 IV - INSTALLATION Page 28 V - GROUNDING INSTRUCTIONS Page 28 VI - RADIO INTERFERENCE Page 29 VII - OPERATION INSTRUCTIONS Page 29 A - Setting Clock Page 29 B - Microwave Cooking Page 29 C - Grill Cooking Page 30 D - Combination 1 Page 30 E - Combination 2 Page 31 F - Auto defrost Page 31 G - Multistage Cooking Page 31 H - Preset Page 31 I - Quick Start Page 32 J - Child Lock Page 32 K - Auto Cook Page 32 VIII - COOKING TECHNIQUES Page 33 IX - COOKING UTENSILS GUIDE Page 33 X - CLEANING AND CARE Page 34 XI - BEFORE YOU CALL FOR SERVICE Page 35 XII - GUARANTEE Page 35 XIII - ENVIRONMENT AND RECYCLING Page 3625

II - PRODUCT DIAGRAM

● COOKING MENU Cooking time, power, action indicators, and clock time are displayed. ● POWER LEVEL Touch this button a number of times to set microwave cooking power level. ● CLOCK Touch this button to start setting the oven clock and ending by touching it again. ● WEIGHT ADJUST After choosing an auto-cooking menu, use it to specify food weights or number of servings. ● GRILL Press this button to set a grill-cooking program. ● COMBINATION Cooking with combined microwave and grill power. ● PRESET Touch to set the preset feature.

Touch to start a cooking program. Simply touch it a number of times to set cooking time and cook immediately at full power level. ● STOP/CANCEL Press to cancel setting or reset the oven before setting a cooking program. Press once to temporarily stop cooking, or twice to cancel cooking altogether. It is also used for setting child lock. ● MENU/TIME Turn the dial to set the oven clock time and input cooking time. Turn the dial to select an auto cook menu28

1. Make sure that all the packing materials are removed from the inside of the door.

WARNING: Check the oven for any damage, such as misaligned or bent door, damaged

door seals and sealing surface, broken or loose door hinges and latches and dents inside the cavity or on the door. If there is any damage, do not operate the oven and contact qualied service personnel.

3. This microwave oven must be placed on a at, stable surface to hold its weight and the heaviest

food likely to be cooked in the oven.

4. Do not place the oven where heat, moisture, or high humidity are generated, or near combustible

5. For correct operation, the oven must have sufcient airow. Allow minimum 20cm of free space

necessary above the top surface of the oven and 5cm at both sides. The microwave oven rear plate must be placed close to the wall. Do not cover or block any openings on the appliance. Do not remove feet.

6. Do not operate the oven without glass tray, roller support, and shaft in their proper positions.

7. Make sure that the power supply cord is undamaged and does not run under the oven or over any

hot or sharp surface.

8. The socket must be readily accessible so that it can be easily unplugged in an emergency.

9. Do not use the oven outdoors.

This appliance must be grounded. This oven is equipped with a cord having a grounding wire with a grounding plug. It must be plugged into a wall receptacle that is properly installed and grounded. In the event of an electrical short circuit, grounding reduces risk of electric shock by providing an escape wire for the electric current. It is recommended that a separate circuit serving only the oven be provided. Using a high voltage is dangerous and may result in a re or other accident causing oven damage.

WARNING: Improper use of the grounding plug can result in a risk of electric shock.

1. If you have any questions about the grounding or electrical instructions, consult a qualied electrician

2. Neither the manufacturer nor the dealer can accept any liability for damage to the oven or personal

injury resulting from failure to observe the electrical connection procedures. The wires in this cable main are colored in accordance with the following code: Green and Yellow = EARTH Blue = NEUTRAL Brown = LIVE

Operation of the microwave oven can cause interference to your radio, TV, or similar equipment. When there is interference, it may be reduced or eliminated by taking the following measures:

1. Clean door and sealing surface of the oven.

2. Reorient the receiving antenna of radio or television.

3. Relocate the microwave oven with respect to the receiver.

4. Move the microwave oven away from the receiver.

5. Plug the microwave oven into a different outlet so that microwave oven and receiver are on different

● Please place the glass tray in your microwave oven to heat your food. ● When the oven first plugged in, the display will show and “1:00” ● During cooking, if press STOP/CANCEL pad once or open the door, the program will be paused, then press START/QUCIK START pad to resume, but if press STOP/CANCEL pad twice, the program will be canceled. ● After ending cooking, the screen will display End with sound every two minutes until user press any pad or open the door. A - Setting Clock The clock works in 12- or 24-hour cycle, just press the CLOCK button to select. Suppose you want to set the oven clock time to 8:30.

1. In standby mode, press CLOCK button once or twice to set the clock in 24- or 12-hour cycle.

5. Press CLOCK to conrm the setting.

NOTE: You can check the clock time during cooking by pressing CLOCK button. B - Microwave Cooking For microwave cooking, the longest cooking time is 95 minutes. You can select power level by pressing the POWER LEVEL button.30 Press POWER LEVEL Cooking Power Once 100% Twice 90% 3 times 80% 4 times 70% 5 times 60% 6 times 50% 7 times 40% 8 times 30% 9 times 20% 10 times 10% 11 times 0% For example, suppose you want to cook for 1 minute at 60% of microwave power.

1. In standby mode, press POWER LEVEL repeatedly to select cooking power.

NOTE: You can check the cooking power during cooking by pressing POWER LEVEL. C - Grill Cooking The longest cooking time is 95 minutes. The grill cooking is particularly useful for thin slices of meat, steaks, chops, kebabs, sausages of piece of chicken. It is also suitable for hot sandwiches and au gratin dishes. For example, suppose you want to grill for 12 minutes.

D - Combination 1 The longest cooking time is 95 minutes. Use for sh or au gratin. Suppose you want to set combination 1 cooking for 25 minutes.

NOTE: During cooking you can check the combination mode by pressing COMBINATION pad.31 E - Combination 2 The longest cooking time is 95 minutes. Use for puddings omelettes, baked potatoes and poultry. Suppose you want to set combination 2 cooking for 12 minutes.

NOTE: During cooking you can check the combination mode by pressing COMBINATION pad. F - Auto Defrost The oven can be used to defrost food based on the weight you entered. The defrosting time and power level are automatically set once the food category and the weight are programmed. The frozen food weight ranges from 100g to1800g. Suppose you want to defrost 600g of shrimp.

1. In standby mode, turn MENU/TIME anti-clockwise to select “10”.

2. Press WEIGHT ADJUST repeatedly to indicate weight 600g.

3. Press START/QUICK START button.

NOTE: The oven will pause and signal during defrosting process to remind user to turn over food, after that, press START/QUICK START to resume. G - Multistage Cooking Your oven can be programmed for up to 2 automatic cooking sequences. Suppose you want to set the following cooking program. ● Microwave-cooking

3. Input Grill-cooking program.

4. Touch START/QUICK START pad.

NOTE: Quick Start, Auto Defrost and Auto Cook cannot be set in the multistage cooking mode. The respective lights will turn on to indicate which stage the oven is operating in. After total time has elapsed, beeps will sound. H - Preset Preset function allows the oven to start up in a later time. Suppose now the clock running at 11:10 and you want the oven to start cooking at 11:30.

1. In standby mode, set a cooking program.

4. Touch PRESET button again.

NOTE: Quick start cooking program cannot preset. After the function has been set, you can check the preset time by pressing the PRESET button. To cancel the feature, touch PRESET and then press STOP/CANCEL in 5 seconds.32 I - Quick Start The oven will operate at 100% power output for Quick Start program. The longest cooking time is 10 minutes. In standby mode, press the START/QUICK START button a number of times to set cooking time, the oven starts working automatically at full power. J - Sécurite enfant Use to prevent unsupervised operation of the oven by little children. The child lock indicator will show up on display screen, and the oven cannot be operated while the Child Lock is set. ● To set: In standby mode, press and hold the STOP/CANCEL button for 3 seconds, a beep sounds and lock indicator lights. ● To cancel: Press and hold the STOP/CANCEL button for 3 seconds until lock indicator on display goes off. K - Auto Cook For the following foods or cooking operation, you do not need to input cooking power and time. Try to focus on telling the oven what you want to cook and how much the food weighs.

1. In standby mode, turn MENU/TIME dial anti-clockwise to select food code.

2. Press WEIGHT ADJUST button a number of times to indicate food weight or number of servings.

3. Press START/QUICK START button.

Cooking Menu : Code Food 1 Milk/Coffee (200 ml/cup) 2 Rice (g) 3 Spaghetti (g) 4 Potato (each 230g) 5 Auto Reheat (g) 6 Fish (g) 7 Chicken (g) 8 Beef/Mutton (g) 9 Skewered Meat (g) NOTE : ● The result of auto cook depends on factors such as the shape and size of food, your personal preference as to the doneness of certain foods and even how well you happen to place food in the oven. If you nd the result at any rate not quite satisfactory, please adjust the cooking time a little bit accordingly. ● For milk/coffee and potato, parameters on display are not weight but number of servings. ● For chicken, beef/mutton and skewered meat, the oven pauses and beeps during cooking to remind you to turn food over for uniform cooking.VIII - COOKING TECHNIQUES

1. Arrange food carefully. Place thickest areas towards outside of dish.

2. Cover foods while cooking. Covers prevent spattering and help foods to cook evenly.

3. Turn foods over once during microwaving to speed cooking of such foods as chicken and hamburgers.

Large items like roasts must be turned over at least once.

4. Rearrange foods such as meatballs halfway through cooking both from top to bottom and from the

center of the dish to the outside.

COOKWARE Microwave Grill Combination Heat–Resistant Glass Yes Yes Yes Non Heat–Resistant Glass No No No Heat–Resistant Ceramics Yes Yes Yes Microwave–Safe Plastic Dish Yes No No Kitchen Paper Yes No No Metal Tray No Yes No Metal Rack No Yes No Aluminum Foil & Foil Containers No Yes No

1. Only use utensils that are suitable for use in microwave ovens. Metallic containers for food and

beverages are not allowed during microwave cooking. This requirement is not applicable if the manufacturer species size and shape of metallic containers suitable for microwave cooking.

2. Microwave can not penetrate metal, so metal utensils or dishes with metallic trim should not be

3. Do not use recycled paper products when microwave cooking, as they may contain small metal

fragments which may cause sparks and/or res.

4. Round /oval dishes rather than square/oblong ones are recommend, as food in corners tends to

5. Narrow strips of aluminum foil may be used to prevent overcooking of exposed areas. But be

careful don’t use too much and keep a distance of 1 inch (2.54cm) between foil and cavity. The list below is a general guide to help you select the correct utensils.34

X - CLEANING AND CARE

1. Turn off the oven and remove the power plug from the wall socket before cleaning.

2. Keep the inside of the oven clean. When food splatters or spilled liquids adhere to oven walls, wipe

with a damp cloth. Mild detergent may be used if the oven gets very dirty. Avoid the use of spray and other harsh cleaners as they may stain, streak or dull the door surface.

3. The outside surfaces should be cleaned with a damp cloth. To prevent damage to the operating

parts inside the oven, water should not be allowed to seep into the ventilation openings.

4. Wipe the door and window on both sides, the door seals and adjacent parts frequently with a damp

cloth to remove any spills or spatters. Do not use abrasive cleaner.

5. A steam cleaner is not be used.

6. Do not allow the control panel to become wet. Clean with a soft, damp cloth. When cleaning the

control panel, leave oven door open to prevent oven from accidentally turning on.

7. If steam accumulates inside or around the outside of the oven door, wipe with a soft cloth. This may

occur when the microwave oven is operated under high humidity condition. And it is normal.

8. It is occasionally necessary to remove the glass tray for cleaning. Wash the tray in warm sudsy

water or in a dishwasher.

9. The roller ring and oven oor should be cleaned regularly to avoid excessive noise. Simply wipe the

bottom surface of the oven with mild detergent. The roller ring may be washed in mild sudsy water or dishwasher. When removing the roller ring from cavity oor for cleaning, be sure to replace in the proper position.

10. Remove odors from your oven by combining a cup of water with the juice and skin of one lemon in

a deep microwaveable bowl, microwave for 5 minutes. Wipe thoroughly and dry with a soft cloth.

11. When it becomes necessary to replace the oven light, please consult a dealer to have it replaced.

12. The oven should be cleaned regularly and any food deposits removed. Failure to maintain the oven

in a clean condition could lead to deterioration of the surface that could adversely affect the life of the appliance and possibly result in a hazardous situation.

13. Please do not dispose this appliance into the domestic rubbish bin, it should be disposed to the

particular disposal center provided by the municipalities.

14. When the microwave oven with grill function is rst used, it may produce slight smoke and smell.

This is a normal phenomenon, because the oven is made of a steel plate coated with lubricating oil, and the new oven will produce fumes and odor generated by burning the lubricating oil. This phenomenon will disappear after a period of using35

XI - BEFORE CALLING FOR SERVICE

If the oven fails to operate:

1. Check to ensure that the oven is plugged in securely. If it is not, remove the plug from the outlet,

wait 10 seconds, and plug it in again securely.

2. Check for a blown circuit fuse or a tripped main circuit breaker. If these seem to be operating

properly, test the outlet with another appliance.

3. Check to ensure that the control panel is programmed correctly and the timer is set.

4. Check to ensure that the door is securely closed engaging the door safety lock system. Otherwise,

The warranty does not cover the wear parts of the product, nor the problems or damages resulting from:

1. Supercial deterioration due to normal wear of the product;

2. Defects or deteriorations due to the contact of the product with liquids and due to corrosion caused

3. Any incident, misuse, misuse, alteration, disassembly or unauthorized repair;

4. Any improper maintenance operation, use not in accordance with product instructions or incorrect

5. Any use of accessories not supplied or not approved by the manufacturer.

The warranty will be void if the nameplate and / or serial number of the product is removed.36

XIII - ENVIRONMENT AND RECYCLING

Disposal of old electrical appliances 2012/19/UE The European Directive on Waste Electrical and Electronic Equipment (WEEE) requires that old household electrical appliances must not be disposed of in the normal unsorted municipal waste stream. Old appliances must be collected separately in order to optimize the recovery and recycling of the materials they contain, and reduce the impact on human health and the environment. The crossed out “wheeled bin” symbol on the product reminds you of your obligation, that when you dispose of the appliance, it must be separately collected. Consumers should contact their local authority or retailer for information concerning the correct disposal of their old appliance. To know more : www.quefairedemesdechets.fr Continental Edison 120-126, Quai de Bacalan CS 11584 – 33067 Bordeaux CEDEX Importé par VESTEL France, 17 rue de la couture – 94563 Rungis CEDEXwww.continentaledison.fr CEMO23GSM
