USER MANUAL IAN 305867 MELINERA

Assembly, operating and safety instructions GUIRLANDES LUMINEUSES

Socket of solar panel

LED solar light chain Scope of delivery 1 100 LED Solar Fairy Lights 2 x 5 m 1 Ground spike 1 Pole 1 Assembly, operating and safety instructions Technical data Operating voltage: 3.7 V (direct current) Rechargeable battery: 1 x 3.7 V (direct current) not replace- able /rechargeable Lithium ion battery with 1300 mAh LED: HG05422A: 100 LEDs x 0.06 W (warm white) HG05422B: 100 LEDs x 0.06 W (cold white) HG05422C: 100 LEDs x 0.06 W (colourful (red, green, yellow and blue)) Protection type: IP44 (splash proof) Solar panel: approx. 11.5 x 11.5 cm22 GB/IE Lighting time (with full charge): approx. 8 hours Safety instructions PLEASE READ THE INSTRUCTIONS FOR USE PRIOR TO USE! PLEASE KEEP THE INSTRUCTIONS IN A SAFE PLACE! IF PASS- ING THIS PRODUCT ON TO A THIRD PARTY ALSO INCLUDE ALL DOCUMENTS. This product can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the product in a safe way and understand the hazards involved. Children shall not play with the product. Cleaning and user maintenance shall not be made by children without supervision. Do not use the product if you detect any kind of damage. Always switch off the product, when storing it in a dark envi- ronment, in order not to discharge the rechargeable battery. The LEDs are not replaceable. If the LEDs fail at the end of their lives, the entire product must be replaced. The product does not contain any parts that can be serviced by the user. Never plug in the product directly into a 230 V

(alternating current). The product is not a toy and should not be played with by children. Children are not able to understand the dangers that can occur when handling the product.23 GB/IE WARNING! This lighting chain must not be used without all gaskets being in place. Product-specific safety instructions Make sure that the solar panel

is free of dirt and free of snow and ice in winter. Otherwise the performance of the solar panel

will diminish. CAUTION: When removing the product, make sure to also remove the pole

so it cannot pose any risk (e. g. tripping). Safety instructions for batteries / rechargeable batteries DANGER TO LIFE! Keep batteries / rechargeable batteries out of reach of children. If accidentally swallowed seek immediate medical attention. DANGER OF EXPLOSION! Never recharge non-rechargeable batteries. Do not short-circuit batteries / rechargeable batteries and / or open them. Overheating, fire or bursting can be the result. Never throw batteries / rechargeable batteries into fire or water. Do not exert mechanical loads to batteries / rechargeable batteries. Risk of leakage of batteries / rechargeable batteries Avoid contact with the skin, eyes and mucous membranes. In the event of contact with battery acid, thoroughly flush the affected area with plenty of clean water and seek immediate medical attention.24 GB/IE WEAR PROTECTIVE GLOVES! Leaked or dam- aged batteries / rechargeable batteries can cause burns on contact with the skin. Wear suitable pro- tective gloves at all times if such an event occurs. This product has a built-in rechargeable battery which cannot be replaced by the user. The removal or replacement of the re- chargeable battery may only be carried out by the manufacturer or his customer service or by a similarly qualified person in order to avoid hazards. When disposing of the product, it should be noted that this product contains a rechargeable battery. Functioning The solar panel

installed in the product converts sunlight into electrical energy and stores it in the rechargeable battery. Insert the supply line plug

into the socket of the solar panel

for 1 time, the product will automatically light on as it begins to get dark. The LEDs are a very long-life and energy-saving light source. The light duration depends on the amount of sunlight, the angle of light on the solar panel

and the temperature (the rechargeable battery capacity is temperature-dependent). A vertical angle of light at temperatures above the freezing point is ideal. The rechargeable battery does not achieve maximum capacity until after several charge and discharge cycles. In summer a completely drained rechargeable battery takes about 2 to 4 days to fully recharge in constant sunlight. To switch the product off, press the mode button

for 1 time again.25 GB/IE Installation (see Fig)

into the ground spike holder

and insert the ground spike

2. Push the stake into the ground (lawn, flower bed, etc.).

3. You can fix the product on the desired surface, twist on the

tree or railing by using the mounting material such as cable tie (mounting material is not included). Note: Ensure the product is stable. Do not use force when assembling or setting up the prod uct e.g. hammer blows. This will damage the product. Note: For the best results, put the product in a place where the solar panel

is exposed to di rect sunlight for as long as possible. Do not put the product under bushes, trees, canopies etc. as this reduces the incidence of incoming sun light. Position the product in such a way that the solar panel

is not cov- ered or in the shade. Note: Make sure the solar panel

is not impacted by other light sources, e.g. yard- or street light ing, or the product will not switch on at twilight. Operation Setting up the product

for one time, the product will automatically switch on at dusk.

to switch to the next lighting mode. When you reach lighting mode 8, the next press of the mode button

switches the product back into lighting mode 1. The lighting modes are listed as below:26 GB/IE Mode 1: combination (combination of all lighting mode) Mode 2: in wave (red-orange LEDs and blue-green LEDs shine alternately) Mode 3: sequential (HG05422A: warm white only; HG05422B: cold white only; HG05422C: red-or- ange LEDs and blue-green LEDs flash alternately in different frequencies

Mode 4: Slo-Glo (HG05422A: warm white only; HG05422B: cold white only; HG05422C: red-orange LEDs and blue-green LEDs slowly light up alternating) Mode 5: chasing / flash (HG05422A: warm white only; HG05422B: cold white only; HG05422C: red-or- ange LEDs and blue-green LEDs flash at the same time) Mode 6: slow fade (LEDs light up and fade out slowly) Mode 7: twinkle / flash (HG05422A: warm white only; HG05422B: cold white only; HG05422C: red-orange LEDs and blue-green LEDs light up alternating like twinkle) Mode 8: steady on (all LED on)

to disable the product and charging process. Note: If you no longer use the product, please unplug the supply line plug

from the socket of solar panel

Note: The charging time of the rechargeable battery when the solar panel

is used depends on the intensity of the sun- light and the angle of incidence of the light on the solar panel

as perpendicular as possible to the angle of incidence of the light. In this way you will receive the highest light levels.27 GB/IE Timer function

1. To switch on the timer function, connect the product to the

socket of solar panel

for 3 second. The mode button

lights up green when the timer is pressed. Function is activated.

2. The product will automatically light on as it begins to get dark.

Once get bright light or light up for 6 hours, the product will turn off. Afterwards, the product will light up 6 hours again when get dark and then turn off again.

again and the light of the mode button

will be turned off. Note: The timer function can only be switched on or off in dark. (The green light goes out in daylight, but switches on again in dark.) Note: If no longer use, please unplug the supply line plug

from the socket of solar panel

Maintenance and care The LEDs cannot be replaced. The product requires no maintenance. Clean the product regularly with a dry, lint-free cloth. Use a slightly dampened cloth to remove more stubborn dirt. Troubleshooting Note: This product has delicate electronic components. This means that if it is placed near an object that transmits radio sig- nals, it could cause interference. If you notice that the product is28 GB/IE malfunctioning, remove any sources of interference from the area of the product. Error Cause Solution The product will not switch on even though the sun shone on the product all day.

es of light, e.g. street lighting, are interfering with the prod- uct.

could be discharged.

1. Mount the product in a

place where it cannot be disturbed by other sources of light.

battery cannot be re- placed. Dispose of the product properly (see “Disposal”). The product doesn’t light up Rechargeable battery defective The rechargeable battery cannot be replaced. Dis- pose of the product prop- erly (see “Disposal”) Disposal The packaging is made entirely of recyclable materials, which you may dispose of at local recycling facilities.
