| Product Type | IDE to SATA Adapter |
| Brand | Tripp Lite |
| Model | P937-000 |
| Connectivity | 40-pin male IDE (motherboard) to SATA (drive) |
| Supported Drive Form Factors | 2.5" / 3.5" / 5.25" |
| Max Transfer Rate | 6 Gbps (SATA I/II/III) |
| Compatibility | Ultra ATA 133 |
| Power Supply | Via included 4-pin Molex cable |
| Power Requirement | Free Molex connector on PC power supply |
| Dimensions (approx.) | 10 x 5 x 2 cm |
| Weight (approx.) | 30 g |
| Main Functions | Connect a SATA drive to an older IDE/ATA motherboard |
| Drive Compatibility | Hard drives, SSDs, optical drives (Blu-ray, DVD, CD-ROM) |
| Required Software | None (Plug and Play) |
| Master/Slave Mode Selection | Via jumper J3 on the board |
| Installation | Connect to motherboard IDE, Molex power, SATA cable to drive |
| Maintenance and Cleaning | Disconnect before cleaning; use a dry, non-abrasive cloth |
| Safety | Power off the computer before any intervention; observe connector polarity |
| Included Parts | Adapter, Molex power cable |
| Repairability | Not user-repairable; limited 1-year warranty |
| Manufacturer Warranty | 1-year limited (materials and workmanship) |
| General Information | Manufactured by Tripp Lite, Chicago, IL USA |
Frequently Asked Questions - P937000 Tripp Lite
User questions about P937000 Tripp Lite
0 question about this device. Answer the ones you know or ask your own.
Ask a new question about this device
Download the instructions for your Computer Adapter in PDF format for free! Find your manual P937000 - Tripp Lite and take your electronic device back in hand. On this page are published all the documents necessary for the use of your device. P937000 by Tripp Lite.
USER MANUAL P937000 Tripp Lite
40-Pin Male IDE to 2.5"/3.5"/5.25" SATA Adapter
Model: P937-000
Español 5 • Français 9 • Русский 13
PROTECT YOUR INVESTMENT!
Register your product for quicker service and ultimate peace of mind. You could also win an ISOBAR6ULTRA surge protector—a \$100 value!
www.tripplite.com/warranty
1111 W. 35th Street, Chicago, IL 60609 www.tripplite.com/support
Copyright © 2017 Tripp Lite. All rights reserved.
Product Features
- Connect a SATA drive to an IDE/ATA motherboard
- Ideal for older motherboards that do not support SATA
- Optical Disk Drive (ODD) support, including Blu-ray™, DVD and CD-ROM drives
• Supports data transfer rates up to 6 Gbps (SATA I/II/III) - Compatible with Ultra ATA 133 specification
- Plug-and-Play; no software or drivers required
System Requirements
• Computer with an available IDE connection
- SATA drive
• 40-pin IDE drive cable
Package Includes
• P937-000
• 4-Pin Molex Power Cable
- Owner's Manual
Installation
Note: To use the installed SATA drive as a bootable device, it must be able to operate in Master Mode
- Turn off the computer, unplug its power cord, and disconnect all peripheral devices (e.g. monitor, keyboard, etc.).
- Open the computer chassis. Make sure the hard drive is fastened to the chassis appropriately.
Installation
- Using the jumper (J3) provided on the circuit board, select the mode you want the installed SATA drive to operate under (S for Slave, M for Master).
- Connect the SATA drive to the circuit board using the designated SATA power and data ports. Insert the connector on the board into the drive ports.
- Connect the LP4 end of the provided 4-Pin Molex Cable to the computer's power supply and the SP4 end to the adapter unit's power port.
- Using a 40-Pin IDE cable, connect the IDE connector on the adapter unit's circuit board to an available IDE port on the motherboard. The pin positioning will ensure a proper connection. An arrow on the circuit board indicates Pin 1 of the IDE connector.
- Replace the computer chassis and power cord on the computer.
Warranty & Product Registration
1-Year Limited Warranty
TRIPP LITE warrants its products to be free from defects in materials and workmanship for a period of one (1) year from the date of initial purchase. TRIPP LITE's obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. To obtain service under this warranty, you must obtain a Returned Material Authorization (RMA) number from TRIPP LITE or an authorized TRIPP LITE service center. Products must be returned to TRIPP LITE or an authorized TRIPP LITE service center with transportation charges prepaid and must be accompanied by a brief description of the problem encountered and proof of date and place of purchase. This warranty does not apply to equipment which has been damaged by accident, negligence or misapplication or has been altered or modified in any way.
EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specifically, TRIPP LITE is not liable for any costs, such as lost profits or revenue, loss of equipment, loss of use of equipment, loss of software, loss of data, costs of substitutes, claims by third parties, or otherwise.
Warranty & Product Registration
PRODUCT REGISTRATION
Visit www.triplite.com/warranty today to register your new Tripp Lite product. You'll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.
FCC Notice, Class B
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
Any changes or modifications to this equipment not expressly approved by Tripp Lite could void the user's authority to operate this equipment.
WEEE Compliance Information for Tripp Lite Customers and Recyclers (European Union)
Under the Waste Electrical and Electronic Equipment (WEEE) Directive and implementing regulations, when customers buy new electrical and electronic equipment from Tripp Lite they are entitled to:
- Send old equipment for recycling on a one-for-one, like-for-like basis (this varies depending on the country)
- Send the new equipment back for recycling when this ultimately becomes waste
Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.
