Product Type	M.2 NGFF SSD to 2.5-inch SATA Adapter
Brand	Tripp Lite
Model	P960-001-M2-NE
Form Factor	2.5-inch, 7mm height
Input Connector	M.2 NGFF (B and B+M keys)
Output Connector	SATA 7-pin
Supported SATA Revisions	SATA I/II/III (1.5/3/6 Gbps)
Supported M.2 Card Lengths	2242, 2260, 2280
Case Type	Open frame (improved heat dissipation)
Power Supply	SATA bus (host powered)
Drive Compatibility	M.2 SATA SSD only (not PCIe NVMe)
Required Operating System	None (plug-and-play)
Package Contents	Adapter, mounting hardware, screwdriver, user manual
Warranty	1 year limited
Certification	WEEE (EU compliance)
Safety Instructions	Antistatic precautions required; handle with care
Maintenance and Cleaning	Clean with a dry, lint-free cloth
Repairability	Repair or replacement under warranty (1 year)

Frequently Asked Questions - P960001M2NE Tripp Lite

How to install the M.2 SSD into the adapter?

Insert the SSD at a slight angle into the M.2 connector, then screw it in with the provided screw after placing the nut in the slot corresponding to the SSD length (42, 60, or 80 mm).

What types of M.2 keys are supported?

The adapter supports SSDs with B and B+M keys. SSDs with M key (PCIe) are not supported.

Does this product work with an NVMe PCIe SSD?

No, this adapter is designed only for M.2 SATA SSDs. NVMe PCIe SSDs are not compatible.

Do I need to format the SSD before using it?

If the SSD is new or unformatted, you must use your operating system's disk management utility to format it before accessing it.

How do I safely eject the adapter from the computer?

Before disconnecting the adapter, eject the device via the operating system (safely remove hardware icon) to avoid data loss.

What if the SSD is not recognized?

Check that the SSD is properly inserted and screwed in, and that the adapter is connected to a functional SATA port. If necessary, format the disk in the disk management utility.

Do I need a specific driver or software?

No, the adapter is plug-and-play. No driver or software is required.

Can the adapter be used on a desktop PC with an internal SATA port?

Yes, it plugs directly into a standard SATA port on a desktop or laptop computer, provided SATA power is supplied.

What size are the provided screws?

The screws and nuts provided are suitable for M.2 SSD mounting holes (cross-head screws). Use the included screwdriver.

What is the duration of the warranty?

Tripp Lite offers a limited one-year warranty from the date of purchase, covering defects in materials and workmanship.

USER MANUAL P960001M2NE Tripp Lite

Register your product today and be automatically entered to win an ISOBAR surge protector in our monthly drawing!

www.triplite.com/warranty

Manufacturing Excellence.

1111 W. 35th Street, Chicago, IL 60609 USA • www.triplite.com/support

Copyright © 2019 Tripp Lite. All rights reserved.

Product Features

• Convert an M.2 NGFF SSD into a 7 mm high, 2.5 in. SATA SSD
• Open-frame housing helps maximize heat dissipation
  Supports full-length M.2 NGFF SSD B/B+M-key (2242, 2260, 2280)
  Supports SATA revisions I/II/III (1.5/3/6 Gbps)
• Plug-and-play—no software or drivers required

System Requirements

• M.2 NGFF SATA Drive (supports B & B+M Key SATA drives—PCIe drives are not supported)
• SATA Host Device

Package Contents

P960-001-M2-NE
- Mounting Hardware
Screwdriver
Owner's Manual

Installation

Notes:

• SSD drives are sensitive to static electricity. To avoid the risk of data loss, the SSD must be handled properly. Always handle your SSD with caution by wearing an anti-static strap (such as Tripp Lite's P999-000) when transporting it, or by touching a grounded metal surface to discharge yourself of static electricity prior to picking up the drive.
• If your drive has not been formatted, you will first need to format it using your computer's Disk Management utility in order to copy and access files.

• Prior to unplugging the open frame adapter, make sure to properly eject the drive from your computer to avoid any potential data loss.

• Depending on the size of your drive, insert the included nut into the circular slot at the 42mm , 60mm or 80mm lines.

• Connect your drive by inserting it into the M.2 NGFF connector. Keep the drive at a low angle to minimize stress on the connector.
• Using the included screw and screwdriver, secure the drive by screwing it into the nut.
• Connect the unit to the SATA port on your computer. Your drive is now ready for use.

Warranty and Product Registration

1-Year Limited Warranty

Tripp Lite warrants its products to be free from defects in materials and workmanship for a period of one (1) year from the date of initial purchase. Tripp Lite's obligation under this warranty is limited to repairing or replacing (at its sole option) any such defective products. To obtain service under this warranty, you must obtain a Returned Material Authorization (RMA) number from Tripp Lite or an authorized Tripp Lite service center. Products must be returned to Tripp Lite or an authorized Tripp Lite service center with transportation charges prepaid and must be accompanied by a brief description of the problem encountered and proof of date and place of purchase. This warranty does not apply to equipment, which has been damaged by accident, negligence or misapplication or has been altered or modified in any way.

Warranty and Product Registration

EXCEPT AS PROVIDED HEREIN, Tripp Lite MAKES NO WARRANTYES, EXPRESS OR IMPLIED, INCLUDING WARRANTYES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.

Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid limitation(s) or exclusion(s) may not apply to the purchaser.

EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL Tripp Lite BE LIABLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE. Specifically, Tripp Lite is not liable for any costs, such as lost profits or revenue, loss of equipment, loss of use of equipment, loss of software, loss of data, costs of substitutes, claims by third parties, or otherwise.

Product Registration

Visit www.triplite.com/warranty today to register your new Tripp Lite product. You'll be automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*

• No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.

WEEE Compliance Information for Tripp Lite Customers and Recyclers (European Union)

Under the Waste Electrical and Electronic Equipment (WEEE) Directive and implementing regulations, when customers buy new electrical and electronic equipment from Tripp Lite they are entitled to:

• Send old equipment for recycling on a one-for-one, like-for-like basis (this varies depending on the country)
• Send the new equipment back for recycling when this ultimately becomes waste

Use of this equipment in life support applications where failure of this equipment can reasonably be expected to cause the failure of the life support equipment or to significantly affect its safety or effectiveness is not recommended.

Tripp Lite has a policy of continuous improvement. Specifications are subject to change without notice.

Manufacturing Excellence.

1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support

1111 W. 35th Street, Chicago, IL 60609 USA • www.triplite.com/support

1111 W. 35th Street, Chicago, IL 60609 USA • www.triplite.com/support

PykoBODCTBO N0Ib30BaTeЯ

TapaHTnHbIe 06aTeJIbCTBa

3A NCKIQUEHHEM IPEYCMOTPEHbIX 3DECb CJUYAEB KOMIANHTRipp Lte HE IPEIOCTABJRET KAKNX-JN50 ABHbIXNJIN IOPA3YMEBAEMbIX TAPAHNTBI, BKJIQUAH TAPAHNTKOMMEPUECKO INPIROHOCTNI INPIROHOCTN DJIAR KAKONJINBO KOHKPETHOI CEIN. B HeKOToBPbIX Wtatax/TOcydapcTBax ORpAHUeHne ININ NCKLIQUHHe NOppa3yMeBaembIX rapaHTNI HeOnyckaETCA; CIEOBATEbHO, Bblweyka3aHHoe(-bie) ORpAHUeHne(-) ININ NCKLIQUHHe(-) MOrTy HE paCnPoCTpAHrTbCa H NaKynateH. 3A NCKIQUEHHEM IPEYCMOTPEHbIX Bblwe CJUYAEB KOMIANHTRipp Lte HN IN PKN KAKNX OBCTOREJBCTBAX HE HECET OTBETCTBEHHOCTN 3A INPMBIE, KOCBEHHbIE, CJUYAHNBIE ININ IOBOUHBe YbBITKN IN50 UbITKN, ONPEJENAEMbIE OC0bIMN OBCTOReTbCTBAMN, BO3NHKAIOUIBE BCRAICNCPOJb3OBAHmE DAHHORIO3DEINNA, DAXE B CUYAE EE INHOPMPOBAHn O BO3MOXHOCTN HACTUYIIIEHNA TAKNX YbBITKOB. B VactHOCTN, KOMPANHTRipp Lte He Hecet OTBETCEHHoCTN 3a KaKme-Ni60 M3depKKn, TAKNE KAYuyeHhbe pnp6bn ININ DoXoDbI, NOTEPRAOBOPAHN, NOTEPRA BO3MOXHOCTN NCIOJIb3OBAHn OBOPyOBaHN, NOTEPRA pOgPamMHorO o6ceueHn, NOTEPra DaHHbIX, paCXoDbI Ha ZAMeHNTeIN, yperynipOBaHnpeTeHN TpreTbIX NInI np.

Hhopmaqna no Bbnohnene Tpe6oBaan DneKTHBb WEE nnooknatee nepepa6otukOB npoduknn KOMNAHN Tripp Lite (Abnnouxce pe3ndentamn Ebponeckoro co03a)

Cornacno nonoKeHnAm DnpeKTHBbO6 yTuIN3aun OTOxOoB 3neKtpueckoro n 3neKtpoHHoro 06OpdyobHaHn (WEEE) IN cNOHNHTbHbIX paCnopJaeHn no ee npImeHnIO, pNn NOKyNke NOTpe6ntHmN HOBOr 3neKtpueckoro nn 3neKtpoHHoro 06OpdyoBaHn npOn3BODCTBA KOMNaHn Tripp Lte OHn NOnyauKT npabo Ha:

• Piopaxy cnaporo 06opuyobAHnno npinunny "oDHH 3a oDHH" n/nnn Ha 3KBnBaHENTHOOCHOBE (B 3aBNCUMOCTH OTOKOHKeTHOH CTpaHbI)
• 0Tnpabky HOBoro 06opydoBaHnHa Napepa6oTy Noce OOKHataeBhoB Bbpa6oTk erocypca

He peKomeHnyeTcNcNoJIb3ObaHnE daHnHO 6OpuyOBaHnB CnCTeMaX KIn3HeoBeCneueHnra, Ige erO BbIXoI n3 cTPO npEnIOJNOJtENbHO MoKET npuBecrN K nepe6oAM B pa6ote 6OpuyOBaHn Jn3HeoBeCneueHnra NmB 3HaunTeNbHO Mepe CHM3ntb er0 6e3ONaCHOCTb Nm 3ΦΦKeTINBHOCTb.

Komnna Tripp Lite noCToHNO coBepHeCTByET CBOIO npOdyKmIO. B cBa3N C 3TMM BO3MOxHO m3MeHeHneTexHHeCKHX xapaKTePNCIK 6e3 npedBapntbHoro yBeDOMHeHn.
